Search Results (12)

CubeSats provide a wealth of high-frequency observations at a meter-scale spatial resolution. However, most current methods of inferring water depth from satellite data consider only a single image. This approach is sensitive to the radiometric quality of the data acquired at that particular instant in time, which could be degraded by various confounding factors, such as sun glint or atmospheric effects. Moreover, using single images in isolation fails to exploit recent improvements in the frequency of satellite image acquisition. This study aims to leverage the dense image time series from the SuperDove constellation via an ensembling framework that helps to improve empirical (regression-based) bathymetry retrieval. Unlike previous studies that only ensembled the original spectral data, we introduce a neural network-based method that instead ensembles the water depths derived from multi-temporal imagery, provided the data are acquired under steady flow conditions. We refer to this new approach as NN-depth ensembling. First, every image is treated individually to derive multitemporal depth estimates. Then, we use another NN regressor to ensemble the temporal water depths. This step serves to automatically weight the contribution of the bathymetric estimates from each time instance to the final bathymetry product. Unlike methods that ensemble spectral data, NN-depth ensembling mitigates against propagation of uncertainties in spectral data (e.g., noise due to sun glint) to the final bathymetric product. The proposed NN-depth ensembling is applied to temporal SuperDove imagery of reaches from the American, Potomac, and Colorado rivers with depths of up to 10 m and evaluated against in situ measurements. The proposed method provided more accurate and robust bathymetry retrieval than single-image analyses and other ensembling approaches. Full article

The oceans remain one of Earth’s last great unknowns, with about 74% still unmapped to modern standards. Consequently, interpolation is employed to create seamless digital bathymetric models (DBMs) from incomplete hydrographic datasets, but this introduces unquantified depth uncertainties. This study aims to estimate and characterize uncertainties arising from set-line spacing hydrographic surveys, which are important for nautical charting, navigational safety, and many other applications. By sampling four distinct complete-coverage testbeds in United States waters that vary in slope and roughness at different line spacings, this study interpolates across entire testbed areas using Spline, Inverse Distance Weighting, and Linear interpolation. Uncertainty is calculated by comparing interpolated depths against the source depths for independent points. The resulting interpolation uncertainties are evaluated from both scientific and operational perspectives. Linear regression and machine learning techniques, specifically artificial neural networks and random forest, are used to model the relationship between these uncertainties and three ancillary predictors (distance to the nearest known measurement, slope, and roughness) for interpolation uncertainty quantification. The results show operational equivalence among the three interpolators, how line spacing and morphology impact uncertainty, and the statistical significance of the examined uncertainty predictors. However, the relationships between the combined ancillary predictors and interpolation uncertainty are weak. These findings suggest the potential presence of unaccounted-for factors influencing uncertainty yet provide a foundational understanding for improving uncertainty estimates in DBMs within operational settings. Full article

Coastal environments, which are crucial for economic and strategic reasons, heavily rely on accurate bathymetry for safe navigation and resource monitoring. Recent advancements in through-water photogrammetry have shown promise in mapping shallow waters efficiently. However, robust uncertainty modeling methods for these techniques, especially in challenging coastal environments, are lacking. This study introduces a novel likelihood-based approach for through-water photogrammetry, focusing on uncertainties associated with camera pose—a key factor affecting depth mapping accuracy. Our methodology incorporates probabilistic modeling and stereo-photogrammetric triangulation to provide realistic estimates of uncertainty in Water Column Depth (WCD) and Water–Air Interface (WAI) height. Using simulated scenarios for both drone and airborne surveys, we demonstrate that viewing geometry and camera pose quality significantly influence resulting uncertainties, often overshadowing the impact of depth itself. Our results reveal the superior performance of the likelihood ratio statistic in scenarios involving high attitude noise, high flight altitude, and complex viewing geometries. Notably, drone-based applications show particular promise, achieving decimeter-level WCD precision and WAI height estimations comparable to high-quality GNSS measurements when using large samples. These findings highlight the potential of drone-based surveys in producing more accurate bathymetric charts for shallow coastal waters. This research contributes to the refinement of uncertainty quantification in bathymetric charting and sets a foundation for future advancements in through-water surveying methodologies. Full article

Information pertaining to a reservoir’s bathymetry is of utmost significance for water resource sustainability and management. The current study evaluated and compensated the reservoir’s bathymetric patterns established using radial basis function (RBF) approaches. Water depth data were acquired by conventionally rolling out a measuring tape into the water. The water depth data were split into three (3) categories, i.e., training data, validation data, and test dataset. Spatial variations in the field-measured bathymetry were determined through descriptive statistics. The thin-plate spline (TPS), multiquadric function (MQF), inverse multiquadric (IMQF), and Gaussian function (GF) were integrated into RBF to establish bathymetric patterns based on the training data. Spatial variations in bathymetry were assessed using Levene’s k-comparison of equal variance. The coefficient of determination ($R^2$), root mean square error (RMSE) and absolute error of mean (AEM) techniques were used to evaluate the uncertainties in the interpolated bathymetric patterns. The regression of the observed estimated (ROE) was used to compensate for uncertainties in the established bathymetric patterns. The Levene’s k-comparison of equal variance technique revealed variations in the predicted bathymetry, with the standard deviation of 8.94, 6.86, 4.36, and 9.65 for RBF with thin-plate spline, multi quadric function, inverse multiquadric function, and Gaussian function, respectively. The bathymetric patterns predicted with thin-plate spline, multiquadric function, inverse multiquadric function, and Gaussian function revealed varying accuracy, with AEM values of −1.59, −2.7, 2.87, and −0.99, respectively, $R^2$ values of 0.68, 0.62, 0.50, and 0.70, respectively, and RMSE values of 4.15, 5.41, 5.80 and 3.38, respectively. The compensated mean bathymetric values for thin-plate spline, multiquadric function, inverse multiquadric function, and Gaussian-based RBF were noted to be 18.21, 17.82, 17.35, and 18.95, respectively. The study emphasized the ongoing contribution of geospatial technology towards inland water resource monitoring. Full article

The proposed novel “BathySent” approach for coastal bathymetric mapping, using the Copernicus Sentinel-2 mission, as well as the assessment and specification of the uncertainties of the derived depth results, are the objectives of this research effort. For this reason, Sentinel-2 bathymetry retrieval results for three different pilot sites in Greece (islands of Kos, Kasos, and Crete) were compared with ground-truth data. These data comprised high-resolution swath bathymetry measurements, single-beam echosounder measurements at very shallow waters (1–10 m), and the EMODnet DTM 2018 release. The synthetic tests showed that the “BathySent” approach could restitute bathymetry in the range of 5–14 m depth, showing a standard deviation of 2 m with respect to the sonar-based bathymetry. In addition, a comparison with the “ratio model” multispectral technique was performed. The absolute differences between conventional Earth Observation-based bathymetry retrieval approaches (i.e., linear ratio model) and the suggested innovative solution, using the Sentinel-2 data, were mainly lower than 2 m. According to the outcome evaluation, both models were considered to provide results that are more reliable within the depth zone of 5–25 m. The “ratio model” technique exhibits a saturation at ~25 m depth and demands ground calibration. Though, the “BathySent” method provides bathymetric data at a lower spatial resolution compared to the “ratio model” technique; however, it does not require in situ calibration and can also perform reliably deeper than 25 m. Full article

This paper examines how tactical-grade Inertial Navigation Systems (INS), aided by Global Navigation Satellite System (GNSS) modules, vary from a survey-grade system in the bathymetric mapping in depths less than 20 m. The motivation stems from the advancements in sensor developments, measurement processing algorithms, and the proliferation of autonomous and uncrewed surface vehicles often seeking to use tactical-grade systems for high-quality bathymetric products. While the performance of survey-grade GNSS + INS is well-known to the hydrographic and marine science community, the performance and limitations of the tactical-grade micro-electro-mechanical system (MEMS) and tactical-grade fiber-optic-gyro (FOG) INS aided with GNSS require some study to answer the following questions: (1) How close or far is the tactical-grade GNSS + INS performance from the survey-grade systems? (2) For what survey order (IHO S-44 6th ed.) can a user deploy them? (3) Can we use them for navigation chart production? We attempt to answer these questions by deploying two tactical-grade GNSS + INS units (MEMS and FOG) and a survey-grade GNSS + INS on a survey boat. All systems collected data while operating a multibeam system with the lever-arm offsets accurately determined using a total station. The tactical-grade GNSS + INSs shared one pair of antennas for heading, while the survey-grade system used an independent antenna pair. We analyze the GNSS + INS results in sequence, examine the patch-test results, and the sensor-specific SBET-integrated bathymetric surfaces as metrics for determining the tactical-grade GNSS + INSs’ reliability. In addition, we evaluate the multibeam’s sounding uncertainties at different beam angles. The bathymetric surfaces using the tactical-grade navigation solutions are within 15 cm of the surface generated with the survey-grade solutions. Full article

Realistic predictions of the contribution of the uncertainty sources affecting the quality of the bathymetric measurements prior to a survey is of importance. To this end, models predicting these contributions have been developed. The objective of the present paper is to assess the performance of the bathymetric uncertainty prediction model for Phase Difference Bathymetric Sonars (PDBS) which is an interferometric sonar. Two data sets were acquired with the Bathyswath-2 system with a frequency of 234 $\mathrm{k}$$\mathrm{Hz}$ at average water depths of around 26 $\mathrm{m}$ and 8 $\mathrm{m}$ with pulse lengths equal to $0.0555$ $\mathrm{m}$$\mathrm{s}$ and $0.1581$ $\mathrm{m}$$\mathrm{s}$, respectively. The comparison between the bathymetric uncertainties derived from the measurements and those predicted using the current model indicates a relatively good agreement except for the across-track distances close to the nadir. The performance of the prediction model can be improved by modifying the term addressing the effect of footprint shift, i.e., spatial decorrelation, on the bottom due to fact that at a given time the footprints seen by different receiving arrays are slightly different. Full article

Coastal regions are undergoing rapid change, due to natural and anthropogenic forcings. A current constraint in understanding and modeling these changes is the lack of multi-temporal bathymetric data, or recursive observations. Often, it is difficult to obtain the repeat observations needed to quantify bathymetric change over time or events. However, the recent availability of ICESat-2 bathymetric lidar creates the option to map coastal bathymetry from solely space-based measurements via satellite-derived bathymetry with multispectral imagery (IS-2/SDB). This compositional space-based bathymetric mapping technique can assess temporal change along the coasts without other remote sensing or in situ data. However, questions exist as to the accuracy of the technique relative to both quantitative uncertainties and the ability to resolve the spatial patterns of erosion and deposition in the nearshore environment, indicative of geomorphologic change. This paper addresses the concept using data from the Florida panhandle (Northern Gulf of Mexico) collected by Sentinel-2 and ICESat-2 at two epochs to assess the feasibility of using IS-2/SDB for bathymetric change detection at scientifically relevant scales, spatial resolutions and accuracies. The comparison of the satellite-only result is compared to airborne data collected at similar epochs to reveal both quantitatively and qualitatively the utility of this technique. Full article

Resolving surf-zone bathymetry from high-resolution imagery typically involves measuring wave speeds and performing a physics-based inversion process using linear wave theory, or data assimilation techniques which combine multiple remotely sensed parameters with numerical models. In this work, we explored what types of coastal imagery can be best utilized in a 2-dimensional fully convolutional neural network to directly estimate nearshore bathymetry from optical expressions of wave kinematics. Specifically, we explored utilizing time-averaged images (timex) of the surf-zone, which can be used as a proxy for wave dissipation, as well as including a single-frame image input, which has visible patterns of wave refraction and instantaneous expressions of wave breaking. Our results show both types of imagery can be used to estimate nearshore bathymetry. However, the single-frame imagery provides more complete information across the domain, decreasing the error over the test set by approximately 10% relative to using timex imagery alone. A network incorporating both inputs had the best performance, with an overall root-mean-squared-error of 0.39 m. Activation maps demonstrate the additional information provided by the single-frame imagery in non-breaking wave areas which aid in prediction. Uncertainty in model predictions is explored through three techniques (Monte Carlo (MC) dropout, infer-transformation, and infer-noise) to provide additional actionable information about the spatial reliability of each bathymetric prediction. Full article

Realistic predictions of the contribution of the various sources affecting the quality of the bathymetric measurements prior to a survey are of importance to ensure sufficient accuracy of the soundings. To this end, models predicting these contributions have been developed. The objective of the present paper is to assess the performance of the bathymetric uncertainty prediction model for modern Multi-Beam Echo-Sounder (MBES) systems. Two datasets were acquired at water depths of 10 $\mathrm{m}$ and 30 $\mathrm{m}$ with three pulse lengths equaling 27 $\mathrm{s}$ , 54 $\mathrm{s}$ , and 134 $\mathrm{s}$ in the Oosterschelde estuary (The Netherlands). The comparison between the bathymetric uncertainties derived from the measurements and those predicted using the current model indicated a relatively good agreement except for the most outer beams. The performance of the uncertainty prediction model improved by accounting for the most recent insights into the contributors to the MBES depth uncertainties, i.e., the Doppler effect, baseline decorrelation (accounting for the pulse shape), and the signal-to-noise ratio. Full article

Seafloor backscatter data from multibeam echosounders are now widely used in seafloor characterization studies. Accurate and repeatable measurements are essential for advancing the success of these techniques. This paper explores the impact of uncertainty in our knowledge of the local seafloor slope on the overall accuracy of the backscatter measurement. Amongst the various sources of slope uncertainty studied, the impact of bathymetric uncertainty and scale were identified as the major sources of slope uncertainty. The bottom slope affects two important corrections needed for estimating seafloor backscatter: (1) The insonified area and; (2) the seafloor incidence angle. The impacts of these slope-related uncertainty sources were quantified for a shallow water multibeam survey. The results show that the most significant uncertainty in backscatter data arises when seafloor slope is not accounted for or when low-resolution bathymetry is used to estimate seafloor slope. This effect is enhanced in rough seafloors. A standard method of seafloor slope correction is proposed to achieve repeatable and accurate backscatter results. Additionally, a standard data package, including metadata describing the slope corrections applied, needs to accompany backscatter results and should include details of the slope estimation method and resolution of the bathymetry used. Full article

Warm water masses circulating at depth off the coast of Greenland play an important role in controlling rates of mass loss from the Greenland Ice Sheet through feedbacks associated with the melting of marine glacier termini. The ability of these warm waters to reach glacier termini is strongly controlled by fjord bathymetry, which was unmapped for the majority of Greenland’s fjords until recently. In response to the need for bathymetric measurements in previously uncharted areas, we developed two companion methods to infer fjord bathymetry using icebergs as depth sounders. The main premise of our methods centers around the idea that deep-drafted icebergs will become stranded in shallow water such that estimates of iceberg surface elevation can be used to infer draft, and thus water depth, under the assumption of hydrostatic equilibrium. When and where available, surface elevations of icebergs stranded on bathymetric highs were extracted from digital elevation models (DEMs) and converted to estimates of iceberg draft. To expand the spatial coverage of our inferred water depths beyond the DEM footprints, we used the DEMs to construct characteristic depth–width ratios and then inferred depths from satellite imagery-derived iceberg widths. We tested and applied the methods in two fjord systems in western Greenland with partially constrained bathymetry, Ilulissat Isfjord and Naajarsuit Fjord, to demonstrate their utility for inferring bathymetry using remote sensing datasets. Our results show that while the uncertainties associated with the methods are high (up to ±93 m), they provide critical first-order constraints on fjord bathymetry. Full article
