Gastrointestinal (GI) tract diseases are among the most common diseases in the world, resulting in more than 8 million deaths. The majority of these deaths occur due to cancer or tumors. Early detection of these tumors can greatly lower the mortality rate. In this work, an implantable multiple-input-multiple-output (MIMO) antenna sensor is constructed for GI tract devices to detect the tumor. The implantable MIMO antenna sensor has two embedded antennas, each operating at 915 MHz. Both elements of the system are placed 0.6 mm apart from each other (edge-to-edge). The volume consumed by this design is measured to be 7 × 7 × 0.25 = 12.25 mm³. It occupies a very small volume due to miniaturization achieved using meandered resonating structures and a high-permittivity substrate. It maintains stable radiation performance (gain = −26.2 dBi at resonance). The antenna units are decoupled by maintaining a proper gap between them and adding a slot on the bottom side. An isolation level greater than 28.7 dB is achieved using these approaches. Since the MIMO system utilizes two antenna elements, its effectiveness is verified using MIMO parameters. At SNR = 20 dB, the channel capacity reaches 8.75 bps/Hz. The proposed antenna ensures high channel capacity and enables seamless communication while simultaneously acting as a sensor to monitor internal changes in the observed region. The frequency response change with variations in the permittivity of human tissue, enabling its sensing capability. Moreover, the antenna sensor maintains stable radiation and S-parameter performance throughout the sensing mechanism. Thus, the proposed solution is suitable for biomedical implants requiring both high-data-rate communication and sensing. Full article

The research on MEMS wireless sensing technology adapted to strong power frequency electromagnetic field environments is of great significance to our energy security, economic society, and even national security. Here, we propose a subwavelength cross-meandering resonator (0.49λ₀ × 0.49λ₀) to simultaneously achieve power frequency electromagnetic field shielding and wireless communication signal transmission. The element size of the resonator is only λ₀/11, which is much smaller than that of previous works. In the resonator, a resonance mode with the significant near-field enhancement effect (about 180 times that at f = 1 GHz) is supported. Based on the self-made shielding box experimental setup, the measured shielding effectiveness of the resonator sample can reach more than 33 dB. Moreover, by integrating the cross-meandering resonator with the MEMS sensor, a wireless communication signal can be successfully transmitted. A dual-function cross-meandering resonator integrated with sensors may find potential applications in many military and civilian industries associated with strong power frequency electromagnetic fields. Full article

There has been a lot of interest in microstrip diplexers lately due to their potential use in numerous wireless and computer communication technologies, including radio broadcasts, mobile phones, broadband wireless, and satellite-based communication systems. It can do this because it has a communication channel that can combine two distinct filters into one. This article presents a narrow-band microstrip diplexer that uses a stepped impedance resonator, a uniform impedance resonator, tiny square patches, and a meander line resonator. The projected diplexer might be made smaller than its initial dimensions by utilizing the winding construction. To model the microstrip diplexer topology for WiMAX and WIFI/WLAN at 1.66 GHz and 2.52 GHz, the Advanced Wave Research (AWR) solver was employed. It exhibited an insertion loss of 3.2 dB and a return loss of 16 dB for the first channel, while the insertion loss and return loss were 2.88 dB and 21 dB, respectively, for the second channel. When both filters were simulated, the band isolation was 31 dB. The projected microstrip diplexer has been fabricated using an FR4 epoxy laminate with dimensions of 32 × 26 mm². The simulated S-parameters phase and group delay closely matched the measurements. Full article

A review on planar printed structures that are based on Matryoshka-like geometries is presented. These structures use the well-known principle of Matryoshka dolls that are successively nested inside each other. The well-known advantages of the planar printed technology and of the meandered nested Matryoshka geometries are combined to generate miniaturized, multi-resonance, and/or wideband configurations. Both metal and complementary slot structures are considered. Closed and open configurations were analyzed. The working principles were explored in order to obtain physical insight into their behavior. Low-cost and single-layer applications as frequency-selective surfaces, filters, antennas, and sensors, in the microwave frequency region, were reviewed. Potential future research perspectives and new applications are then discussed. Full article

A novel quasi-twisted miniaturized wideband branch line coupler (BLC) is proposed. The design is based on bisecting the conventional microstrip line BLC transversely and folding bisected sections on double-layered substrates with a common ground plane in between. The input and output terminals, each with a length of λ_g/4, and the pair of quarter-wavelength horizontal parallel arms are converted into a Z-shaped meandered microstrip line in the designed structure. Conversely, the pair of quarter-wavelength vertical arms are halved into two lines and transformed into a periodically loaded slow-wave structure. The bisected parts of the BLC are placed on the opposite side of the doubled-layer substrate and connected through four vias passing through the common ground plane. This technique enabled a compact BLC size of 6.4 × 18 mm², which corresponds to a surface area miniaturization by ~50% as compared to the classical BLC size of 10 × 23 mm² at 6 GHz. Moreover, the attained relative bandwidth is 73.9% (4.6–10 GHz) for S11, S33, S21, and the phase difference between outputs (∠S21 − ∠S41). However, if a coupling parameter (S41) of up to −7.5 dB is considered, then the relative bandwidth reduces to 53.9% (4.6–10 GHz) for port 1 as the input. Similarly, for port 3 as the input, the obtained bandwidth is 75.8% (4.5–10 GHz) for S33, S11, S43, and the phase difference between outputs (∠S43 − ∠S23). Likewise, this bandwidth reduces to 56% (4.5–8 GHz) when a coupling parameter (S23) of up to −7.5 dB is considered. In contrast, the relative bandwidth for the ordinary BLC is 41% at the same resonant frequency. The circuit is constructed on a double-layered low-cost FR4 substrate with a relative permittivity of 4.3 and a loss tangent of 0.025. An isolation of −13 dB was realized in both S₁₃ and S₃₁ demonstrating an excellent performance. The transmission coefficients between input/output ports S₂₁, S₄₁, S₂₃, and S₄₃ are between −3.1 dB to −3.5 dB at a frequency of 6 GHz. Finally, the proposed BLC provides phase differences between output ports of 90.5° and 94.8° at a frequency of 6 GHz when the input ports 1 and 3 are excited, respectively. The presented design offers the potential of being utilized as a unit cell for building a Butler matrix (BM) for sub-6 GHz 5G beamforming networks. Full article

This paper introduces a novel algorithm for designing a low-pass filter (LPF) and a microstrip Wilkinson power divider (WPD) using a neural network surrogate model. The proposed algorithm is applicable to various microwave devices, enhancing their performance and frequency response. Desirable output parameters can be achieved for the designed LPF and WPD by using the proposed algorithm. The proposed artificial neural network (ANN) surrogate model is employed to calculate the dimensions of the LPF and WPD, resulting in their efficient design. The LPF and WPD designs incorporate open stubs, stepped impedances, triangular-shaped resonators, and meandered lines to achieve optimal performance. The compact LPF occupies a size of only 0.15 λg × 0.081 λg, and exhibits a sharp response within the transmission band, with a sharpness parameter of approximately 185 dB/GHz. The designed WPD, operating at 1.5 GHz, exhibits outstanding harmonics suppression from 2 GHz to 20 GHz, with attenuation levels exceeding 20 dB. The WPD successfully suppresses 12 unwanted harmonics (2nd to 13th). The obtained results demonstrate that the proposed design algorithm effectively accomplishes the LPF and WPD designs, exhibiting desirable parameters such as operating frequency and high-frequency harmonics suppression. The WPD demonstrates a low insertion loss of 0.1 dB (S₂₁ = 0.1 dB), input and output return losses exceeding 30 dB (S₁₁ = −35 dB, S₂₂ = −30 dB), and an output ports isolation of more than 32 dB (S₂₃ = −32 dB), making it suitable for integration into modern communication systems. Full article

This paper proposes a hexagonal meander-shaped wideband electronically reconfigurable transmitarray (HMRTA) at Ku band for satellite communications and radar applications. The proposed transmitarray offers high gain, low profile, and wideband characteristics with beam-scanning and beam-forming features. The cascaded structure is a low-profile and compact transmitarray. The transmitter (T_x) layer has an angular hexagonal patch with a meandered shape and resonating parasitic patches to enhance the bandwidth. The receiver (R_x) layer comprises a two-part hexagonal receiver patch and a dual ring impedance-matching receiver layer. The current reversal phenomena have executed the 180° phase shift by integrating two diodes in opposite directions. The measured results of a unit cell achieve a minimum insertion loss of 0.86 dB and 0.92 dB for state I and state II. The maximum insertion loss is 2.58 dB from 14.12 GHz to 18.02 GHz and is about 24.83% at 16.5 GHz. The full-wave simulations of a 20 × 20 space-fed reconfigurable transmitarray were performed. Good radiation patterns at all scanning angles of two principal planes are achieved, and the cross-polarization level remains less than −20 dB. The simulated 3 dB gain fluctuation bandwidth of the array is 15.85~18.35 GHz, and the wideband characteristics are verified. The simulation results show that the array can perform beam scanning ±60° in the elevation (y-z) plane and obtain the beam-scanning characteristics for ±60° in the Azimuth (x-z) plane. Full article

The present work describes a new approach for the design of a Frequency-Selective Surface (FSS) in the context of frequency filters to increase isolation between two vehicle-borne antennas. A compact FSS design based on nested square meandered resonators is optimized for multifrequency operation. Furthermore, a design workflow is proposed. In general, the measurement of low-profile FSS does not correspond to simulation through Floquet modes based on periodic boundary conditions due to the lack of uniformity of mutual coupling among the FSS unit cells. The proposed method demonstrates the agreement between the infinite simulation and the measurement of the finite prototype once a convenient scale factor is applied, which facilitates the design workflow. In this case, an FSS is used as an efficient filter to increase the isolation between antennas by 6 dB in three representative bands (3GPP, WiFI I and II). In this way, multifrequency antennas can be placed at approximately half their actual distance with the same performance in spatial-constrained vehicular environments. Full article

In this work, we propose a novel multiband meander line antenna that can operate at three different frequency bands and offer suitable performance for wireless body area network (WBAN) applications. The net geometry of the antenna is 36 × 30 × 1.524 mm${}^3$. The proposed low-profile antenna is analytically modeled and designed in full wave ANSYS HFSS using Rogers TMM4 as the substrate, followed by in-lab prototyping. The designed antenna resonates at 4.5 GHz, 5 GHz, and 5.8 GHz and maintains positive gain, efficiency, and acceptable specific absorption rates at each resonant band. The effectiveness of the antenna for WBAN applications is demonstrated using an in-lab manufactured phantom. The fabrication process of the phantom is described, and dielectric characterization of the phantom mimicking different human tissue layers is presented. Considering results with and without human body phantoms available in the full wave ANSYS HFSS tool, a comparative analysis between simulated and measured antenna parameters concludes this work. Both the simulated and measured results show good agreement. Full article

In the world of digitization, different objects cooperate with the Internet of Things (IoT); these objects also amplify using sensing and data processing structures. Radio frequency identification (RFID) has been identified as a key enabler technology for IoT. RFID technology has been used in different conventional applications for security, goods storage, transportation and asset management. In this paper, a fully inkjet-printed chipless radio frequency identification (RFID) sensor tag is presented for the wireless identification of tagged objects. The dual polarized tag consists of two resonating structures functioning wirelessly. One resonator works for encoding purpose and other resonator is used as a CO₂/temperature sensor. The sensing behavior of the tag relies on the integration of a meandered structure comprising of multi-wall carbon nanotubes (MWCNT). The MWCNT is highly sensitive to CO₂ gas. The backscattered response of the square-shaped cascaded split ring resonators (SRR) is analyzed through a radar cross-section (RCS) curve. The overall tag dimension is 42.1 mm × 19.5 mm. The sensing performance of the tag is examined and optimized for two different flexible substrates, i.e., PET and Kapton^®HN. The flexible tag structure has the capability to transmit 5-bit data in the frequency bands of 2.36–3.9 GHz and 2.37–3.89 GHz, for PET and Kapton^®HN, respectively. The proposed chipless RFID sensor tag does not require any microchip or a power source, so it has a great potential for low-cost and automated temperature/CO₂ sensing applications. Full article

In this paper, a novel microstrip line-fed meander-line-based four-elements quad band Multiple Input and Multiple Output (MIMO) antenna is proposed with a gain enhancement technique. The proposed structure resonates at four bands simultaneously, that is, 1.23, 2.45, 3.5 and 4.9 GHz, which resemble GPS L2, Wi-Fi, Wi-MAX and WLAN wireless application bands, respectively. The unit element is extended to four elements MIMO antenna structure exhibiting isolation of more than 22 dB between the adjacent elements without disturbing the resonant frequencies. In order to enhance the gain, two orthogonal microstrip lines are incorporated between the antenna elements which result in significant gain improvement over all the four resonances. Furthermore, the diversity performance of the MIMO structure is analyzed. The Envelope Co-Relation Coefficient (ECC), Diversity Gain (DG), Channel Capacity Loss (CCL), Mean Effective Gain (MEG) and Multiplexing Efficiency are obtained as 0.003, 10 dB, 0.0025 bps/Hz, −3 dB (almost) and 0.64 (min.), respectively, which are competent and compatible with practical wireless applications. The Total Active Reflection Coefficient (TARC) resembles the characteristic of the individual antenna elements. The layout area of the overall MIMO antenna is 0.33 λ × 0.29 λ, where λ is the free-space wavelength corresponding to the lowest resonance. The advantage of the proposed structure has been assessed by comparing it with previously reported MIMO structures based on number of antenna elements, isolation, gain, CCL and compactness. A prototype of the proposed MIMO structure is fabricated, and the measured results are found to be aligned with the simulated results. Full article

The strong localization of the electric and magnetic fields in metamaterial-based structures has attracted a new era of radiation fields in the microwave range. In this research work, we represent a double split ring enclosed nested meander-line-shaped metamaterial resonator with a high effective medium ratio layered on a dielectric substrate to enhance the sensitivity for the material characterization. Tailoring a metallic design and periodical arrangement of the split ring resonator in a subwavelength range introduced field enhancement and strong localization of the electromagnetic field. The design methodology is carried out through the optimization technique with different geometric configurations to increase the compactness of the design. The CST microwave studio is utilized for the extraction of the scattering computational value within the defined boundary condition. The effective parameters from the reflection and transmission coefficient are taken into account to observe the radiation characteristics for the interaction with the applied electromagnetic spectrum. The proposed metamaterial-based sensor exhibits high sensitivity for different dielectric materials with low permittivity values. The numerical data of the frequency deviation for the different dielectric constants have shown good agreement using the linear regression analysis where the sensitivity is R² = 0.9894 and the figure of merit is R² = 0.9978. Full article

An antenna assumes a significant role in expanding the levels of communication to meet the demands of contemporary technologically based industry and private data services. In this paper, a printed compact meander line patch antenna array for wireless local-area network (WLAN) applications in the frequency span of 2.3685–2.4643 GHz is presented. The impedance matching of the antenna is generated by applying a partial rectangular-shaped ground plane backside of the meander line antenna. The proposed antenna evolved on the Rogers RT5880 substrate with a dielectric permittivity of 2.2, and the height of the substrate was 1.575 mm to accomplish the lowest possible return loss. The proposed antenna was developed to achieve particular outcomes, for example, voltage standing wave ratio (VSWR) 1.32, reflection coefficient 20 dB with a bandwidth of 94.2 MHz, a gain of 2.8 dBi, and an efficacy measurement of 97%. This antenna is appropriate for WLAN applications that utilize a 2.4 GHz resonance frequency. The overall dimensions of the antenna are 15 mm × 90.86 mm. Full article

This paper proposes a novel gear-like disk resonator (GDR). The design, fabrication, and characterization of GDR are presented. In comparison with a ring-like disk resonator (RDR), a GDR replaces the circular rings with meander-shaped rings consisting of linear beams. The finite element method (FEM) is implemented, and the simulation results show that the GDR has a much lower frequency and effective stiffness, higher quality factor (Q), and better immunity to crystal orientation error. Affected by high Q and small frequency splits, the mechanical sensitivity (S_mech) is shown to increase greatly. GDR and RDR with the same structure parameters are built side-by-side on the same wafer, and prototypes are fabricated through the SOI fabrication technique. The frequency response test and ring-down test are implemented using a readout circuit under a vacuum condition (5 Pa) at room temperature. The frequency split (9.1 Hz) of the GDR is about 2.8 times smaller than that (25.8 Hz) of the RDR without electrostatic tuning. Compared with the RDR, the Q (19.2 k) and decay time constant (0.59 s) of the GDR are improved by 145% and 236%, respectively. The experimental results show great promise for the GDR being used as a gear-like disk resonator gyroscope (GDRG). Full article

Fifth generation (5G) communication systems deploy a massive MIMO technique to enhance gain and spatial multiplexing in arrays of 16 to 128 antennas. In these arrays, it is critical to isolate the adjacent antennas to prevent unwanted interaction between them. Fifth generation absorbers, in this regard, are the recent interest of many researchers nowadays. The authors present a dual-band novel metamaterial-based 5G absorber. The absorber operates at 24 GHz and 28 GHz and is composed of symmetric meander lines connected through a transmission line. An analytical model used to calculate the total number of required meander lines to design the absorber is delineated. The analytical model is based on the total inductance offered by the meander line structure in an impedance-matched electronic circuit. The proposed absorber works on the principal of resonance and absorbs two 5G bands (24 GHz and 28 GHz). A complete angular stability analysis was carried out prior to experiments for both transverse electric (TE) and transverse magnetic (TM) polarizations. Further, the resonance conditions are altered by changing the substrate thickness and incidence angle of the incident fields to demonstrate the functionality of the absorber. The comparison between simulated and measured results shows that such an absorber would be a strong candidate for the absorption in millimetre-wave array antennas, where elements are placed in proximity within compact 5G devices. Full article
