When rivers impinge on the steep bluffs of valley walls, dynamic changes stem from a combination of fluvial and mass wasting processes. This study identifies the geomorphic changes, drivers, and timing of a landslide adjacent to the Apalachicola River at Alum Bluff, the tallest natural geological exposure in Florida at ~40 m, comprising horizontal sediments of mixed lithology. We used hydrographic surveys from 1960 and 2010, two sets of LiDAR from 2007 and 2018, historical aerial, drone, and ground photography, and satellite imagery to interpret changes at this bluff and river bottom. Evidence of slope failure includes a recessed upper section with concave scarps and debris fans in the lower section with subaqueous features including two occlusions and a small island exposed from the channel bottom at lower water levels. Aerial photos and satellite images indicate that the failure occurred in at least two phases in early 2013 and 2015. The loss in volume in the 11-year interval, dominantly from the upper portion of the bluff, was ~72,750 m³ and was offset by gains of ~14,760 m³ at the lower portion of the bluff, suggesting that nearly 80% of the material traveled into the river, causing changes in riverbed morphology from the runout. Despite being along a cutbank and next to the scour pool of a large meandering river, this failure was not driven by floods and the associated lateral erosion, but instead by rainfall in noncohesive sediments at the upper portion of the bluff. This medium-magnitude landslide is now the second documented landslide in Florida. Full article

This paper introduces a novel miniaturized, four-mode, semi-flexible leaky wave Multiple-Input Multiple-Output (MIMO) antenna specifically designed to advance vehicular communication systems. The proposed antenna addresses key challenges in 5G low- and high-frequency bands, including millimeter-wave communication, by integrating innovative features such as a periodic Spoof Surface Plasmon Polariton Transmission Line (SSPP-TL) and logarithmic-spiral-like semi-circular strip patches parasitically fed via orthogonal ports. These design elements facilitate stable impedance matching and wide impedance bandwidths across operating bands, which is essential for vehicular networks. The hybrid combination of leaky wave and SSPP structures, along with a defected wide-slot ground structure and backside meander lines, enhances radiation characteristics by reducing back and bidirectional radiation. Additionally, a naturalization network incorporating chamfered-edge meander lines minimizes mutual coupling and introduces a fourth radiation mode at 80 GHz. Compact in size (14 × 12 × 0.25 mm³), the antenna achieves high-performance metrics, including S11 < −18.34 dB, dual-polarization, peak directive gains of 11.6 dBi (free space) and 14.6 dBi (on vehicles), isolation > 27 dB, Channel Capacity Loss (CCL) < 3, Envelope Correlation Coefficient (ECC) < 0.001, axial ratio < 2.25, and diversity gain (DG) > 9.85 dB. Extensive testing across various vehicular scenarios confirms the antenna’s robustness for Vehicle-to-Vehicle (V2V), Vehicle-to-Pedestrian (V2P), and Vehicle-to-Infrastructure (V2I) communication. Its exceptional performance ensures seamless connectivity with mobile networks and enhances safety through Specific Absorption Rate (SAR) compliance. This compact, high-performance antenna is a transformative solution for connected and autonomous vehicles, addressing critical challenges in modern automotive communication networks and paving the way for reliable and efficient vehicular communication systems. Full article

Real-Time/Post-Processing Kinematic (RTK/PPK) technology has been widely applied in Unmanned Aerial Vehicle (UAV) photogrammetry in glaciological research. Considering that ground control points (GCPs) cannot be set on glaciers, evaluating the impacts of one-sided distribution is essential. In this study, 8571 images were captured at Sermeq Avannarleq glacier in western Greenland from 4 August 2021 to the 6th, covering approximately 85 km², with the furthest distance being 13.22 km away from the coastline. Benefited by the meandering coastline, 11 roving stations roughly uniformly distributed on bare rock were surveyed with the RTK technique. PPK-geotagged images were processed in Agisoft Metashape Professional to derive the DSMs, utilizing eight different configurations of GCP distributions that gradually extended longitudinally (along the glacier flow direction) to the upper part of the glacier. The accuracy of DSMs was evaluated by referring to the validation points (VPs) that were not employed in the Bundle Block Adjustment (BBA). The results indicated that the RMSE values of the easting, northing, and height of the reconstruction model georeferenced by only PPK geotagging (no GCPs applied) were 0.038 m, 0.031 m, and 0.146 m, respectively. Applying four GCPs located at one side of the region but with both longitudinal and lateral distribution improved the RMSE values in easting, northing, and vertical to 0.037 m, 0.031 m, and 0.081 m, respectively, and these values were stable even when distributing four GCPs evenly or when increasing the number of GCPs to eleven. Moreover, the cross-validation with ICESat-2 and ArcticDEM performed only at an off-glacier region also suggested that vertical accuracy shows significant improvements for every configuration of GCPs compared to the reconstruction model optimized only by PPK, but such improvements were not obvious if the number of GCPs exceeded four. Moreover, no elevation ramps appeared in the UAV DSM, even for the GCP configuration with only two GCPs distributed at the terminus. Therefore, combining PPK with only a few GCPs but distributing in both directions of the surveying region can offer a viable solution for obtaining glacier DSMs at the coastline with decimeter-level accuracy. Full article

The Central Australian red honey-pot ant Melophorus bagoti maintains non-cryptic ground-nesting colonies in the semi-desert habitat, performing all the activities outside the nest during the hottest periods of summer days. These ants rely on path integration and view-based cues for navigation. They manage waste by taking out unwanted food, dead nestmates, and some other wastes, typically depositing such items at distances > 5 m from the nest entrance, a process called dumping. We found that over multiple runs, dumpers headed in the same general direction, showing sector fidelity. Experienced ants dumped waste more efficiently than naive ants. Naive individuals, lacking prior exposure to the outdoor environment around the nest, exhibited much scanning and meandering during waste disposal. In contrast, experienced ants dumped waste with straighter paths and a notable absence of scanning behaviour. Furthermore, experienced dumpers deposited waste at a greater distance from the nest compared to their naive counterparts. We also investigated the navigational knowledge of naive and experienced dumpers by displacing them 2 m away from the nest. Naive dumpers were not oriented towards the nest in their initial trajectory at any of the 2 m test locations, whereas experienced dumpers were oriented towards the nest at all test locations. Naive dumpers were nest-oriented as a group, however, at the test location nearest to where they dumped their waste. These differences suggest that in red honey ants, learning supports waste disposal, with dumping being refined through experience. Dumpers gain greater spatial knowledge through repeated runs outside the nest, contributing to successful homing behaviour. Full article

In this article, the authors present the design of a compact multiband monopole antenna measuring 30 × 10 × 1.6 mm³, which is aimed at optimizing performance across various communication bands, with a particular focus on Wi-Fi and sub-6G bands. These bands include the 2.4 GHz band, the 3.5 GHz band, and the 5–6 GHz band, ensuring versatility in practical applications. Another important point is that this paper demonstrates effective methods for reducing mutual coupling through two meander slits on the common ground, resembling a defected ground structure (DGS) between two antenna elements. This approach achieves mutual coupling suppression from −6.5 dB and −9 dB to −26 dB and −13 dB at 2.46 GHz and 3.47 GHz, respectively. Simulated and measured results are in good agreement, demonstrating significant improvements in isolation and overall multiple-input multiple-output (MIMO) antenna system performance. This research proposes a compact multiband monopole antenna and demonstrates a method to suppress coupling in multiband antennas, making them suitable for internet of things (IoT) sensor devices and Wi-Fi infrastructure systems. Full article

Mid-field wireless power transfer (WPT) offers a compelling solution for delivering power to miniature implantable medical devices deep within the human body. Despite its potential, the current power delivery levels remain constrained, and the design of a compact source structure to focus the transmitter field on such implants presents significant challenges. In this paper, a novel miniaturized transmitter antenna operating at 1.71 GHz is proposed. Leveraging the antenna proximity-coupled feeding technique, we achieve optimal current distribution for efficient power transfer. Additionally, a receiver integrated within the human body is proposed, comprising a slotted ground and a meandering slotted radiating element. This receiver is excited via a coaxial feedline with a truncated ground. Our findings demonstrate wireless power transfer of −23 dB (0.501%) at a distance of 30 mm between the transmitter and receiver, alongside a peak gain of −20 dB with an impedance bandwidth of 39.61%. These results highlight promising advancements in enhancing energy transfer efficiency for deep-implant applications. Full article

Designing antennas for vehicular communication systems presents several unique challenges due to the dynamic nature of vehicular environments, mobility, and the need for reliable connectivity. A wider bandwidth is a critical requirement of vehicular antennas. In this paper, a super-wideband FR4 epoxy-based low-cost meander line patch antenna is designed for fifth-generation (5G) vehicular mobile frequency applications. The proposed antenna is excited through a microstrip feedline on top of the substrate with a continuous ground plane. The meander line is implemented through a theoretical formula to cover upper-5G frequency range 1 (FR1) and frequency range 2 (FR2). The proposed antenna has 7.5 dBi peak gain when operated at 28 GHz. The simulated bandwidth ratio (BWR) is 9.09:1 for a −10 dB reflection coefficient covering a 53.4 GHz (6.6 GHz to 60 GHz) frequency range. The proposed antenna has a linear meander line planar structure, occupies a small area of 34 mm × 20 mm × 1.6 mm, and satisfies the bandwidth requirements of 5G millimeter-wave and sub-bands of the sixth generation for vehicular applications. Full article

A novel quasi-twisted miniaturized wideband branch line coupler (BLC) is proposed. The design is based on bisecting the conventional microstrip line BLC transversely and folding bisected sections on double-layered substrates with a common ground plane in between. The input and output terminals, each with a length of λ_g/4, and the pair of quarter-wavelength horizontal parallel arms are converted into a Z-shaped meandered microstrip line in the designed structure. Conversely, the pair of quarter-wavelength vertical arms are halved into two lines and transformed into a periodically loaded slow-wave structure. The bisected parts of the BLC are placed on the opposite side of the doubled-layer substrate and connected through four vias passing through the common ground plane. This technique enabled a compact BLC size of 6.4 × 18 mm², which corresponds to a surface area miniaturization by ~50% as compared to the classical BLC size of 10 × 23 mm² at 6 GHz. Moreover, the attained relative bandwidth is 73.9% (4.6–10 GHz) for S11, S33, S21, and the phase difference between outputs (∠S21 − ∠S41). However, if a coupling parameter (S41) of up to −7.5 dB is considered, then the relative bandwidth reduces to 53.9% (4.6–10 GHz) for port 1 as the input. Similarly, for port 3 as the input, the obtained bandwidth is 75.8% (4.5–10 GHz) for S33, S11, S43, and the phase difference between outputs (∠S43 − ∠S23). Likewise, this bandwidth reduces to 56% (4.5–8 GHz) when a coupling parameter (S23) of up to −7.5 dB is considered. In contrast, the relative bandwidth for the ordinary BLC is 41% at the same resonant frequency. The circuit is constructed on a double-layered low-cost FR4 substrate with a relative permittivity of 4.3 and a loss tangent of 0.025. An isolation of −13 dB was realized in both S₁₃ and S₃₁ demonstrating an excellent performance. The transmission coefficients between input/output ports S₂₁, S₄₁, S₂₃, and S₄₃ are between −3.1 dB to −3.5 dB at a frequency of 6 GHz. Finally, the proposed BLC provides phase differences between output ports of 90.5° and 94.8° at a frequency of 6 GHz when the input ports 1 and 3 are excited, respectively. The presented design offers the potential of being utilized as a unit cell for building a Butler matrix (BM) for sub-6 GHz 5G beamforming networks. Full article

A sinuous antenna is a frequency-independent antenna known for its wide bandwidth and consistent gain, which makes it valuable in broadband applications such as ultrawideband (UWB) radar and ground-penetrating radar (GPR). However, sinuous antennas tend to be rather large. Consequently, numerous studies have explored miniaturization methods, with the gap-loading method emerging as a prominent approach. Unfortunately, it is still difficult to achieve broad bandwidths for conventional miniaturized sinuous antennas. In this paper, we use a novel approach incorporating a meander shape into the sinuous curve and employing gap loading with meandering. This innovative technique results in the development of a fractal-structured two-arm sinuous antenna characterized by an ultra-compact size and significantly expanded bandwidth. Adding a meander line in the outermost part maximizes the capacitance, thereby enhancing the gap-loading effect and minimizing the overall size of the sinuous antenna. In addition, the introduction of an inner meander line increases the inductance, contributing to a further expansion of the antenna’s bandwidth. For example, the electrical length of the antenna without the meander line is 0.552 × 0.552 × 0.052 ${\mathsf{\lambda }}_{\mathrm{g}}{}^3$, while the electrical length of the antenna with the meander line is only 0.445 × 0.445 × 0.036${ \mathsf{\lambda }}_{\mathrm{g}}{}^3$, i.e., 19.4% smaller. The antenna lacking the outermost meander line exhibits a 10 dB impedance bandwidth, spanning from 0.74 to 10.53 GHz. In contrast, the antenna featuring the outermost meander line has a 10 dB impedance bandwidth, extending from 0.51 to 10.72 GHz, which results in a remarkable enhancement in the fractional bandwidth (by 8.1%). Hence, the proposed antenna design is a good candidate for broadband applications that require miniaturization. Full article

This paper proposed a right-handed circularly polarized (RHCP) micro-strip antenna for multi-navigation system applications. The size of the antenna is 70 mm × 70 mm × 2 mm, which is fabricated on an FR4 substrate. A meandering technique on a patch layer and asymmetrical defected ground structures (DGS) are employed to achieve the purpose of miniaturization and increase the bandwidth of the axial ratio. The prototype of this antenna is fabricated according to simulations where the bandwidth of return loss, bandwidth of axial ratio, and radio pattern are further testified. The bandwidth of return loss (S₁₁) and axial ratio (AR) of the antennas are from 1.540 GHz to 1.612 GHz and 1.554 GHz to 1.601 GHz, which would be available for L1 of GPS, L1 of SBAS, E1 of Galileo as well as B1I and B1C of BDS-3, the last two of which can be used for aircraft tracking. The relative bandwidth is 2.98%, which satisfies the standard of wide-band patch antennas. Full article

The installation of ground collectors often has several disadvantages for the user, despite future benefits in more ecological heating, namely the need for a large space for installation, which increases costs, and can also cause inconvenience later, for example, by keeping snow on the surface for a longer time. The goal of this paper was to find out with the help of simulations in ANSYS whether a collector with a different geometry and arrangement (vertical spiral with diameters of 6, 8 and 10 m), which would be more comfortable, cheaper, and also friendlier to the environment, would achieve performance similar to the classic geometry—meander. The initial results are relatively favorable and prove that there is room for optimization and improvement in this field. Verification of network sensitivity in all cases is 8% or less. In the current situation of the energy crisis, it is necessary to look for the possibilities of using heat pumps in cities and metropolises. The new geometry could increase the attractiveness and availability of ground source heat pumps in general, which would support efforts to reduce emissions and possibly also reduce the negative impacts of heating on the environment. Full article

This study aims to design a compact antenna structure suitable for implantable devices, with a broad frequency range covering various bands such as the Industrial Scientific and Medical band (868–868.6 MHz, 902–928 MHz, 5.725–5.875 GHz), the Wireless Medical Telemetry Service (WMTS) band, a subset of the unlicensed 3.5–4.5 GHz ultra-wideband (UWB) that is free of interference, and various Wi-Fi spectra (3.6 GHz, 4.9 GHz, 5 GHz, 5.9 GHz, 6 GHz). The antenna supports both low and high frequencies for efficient data transfer and is compatible with various communication technologies. The antenna features an asynchronous-meandered radiator, a parasitic patch, and an open-ended square ring-shaped ground plane. The antenna is deployed deep inside the muscle layer of a rectangular phantom below the skin and fat layer at a depth of 7 mm for numerical simulation. Furthermore, the antenna is deployed in a cylindrical phantom and bent to check the suitability for different organs. A prototype of the antenna is created, and its reflection coefficient and radiation patterns are measured in fresh pork tissue. The proposed antenna is considered a suitable candidate for implantable technology compared to other designs reported in the literature. It can be observed that the proposed antenna in this study has the smallest volume (75 mm³) and widest bandwidth (181.8% for 0.86 GHz, 9.58% for 1.43 GHz, and 285.7% for the UWB subset and Wi-Fi). It also has the highest gain (−26 dBi for ISM, −14 dBi for WMTS, and −14.2 dBi for UWB subset and Wi-Fi) compared to other antennas in the literature. In addition, the SAR values for the proposed antenna are well below the safety limits prescribed by IEEE Std C95.1-1999, with SAR values of 0.409 W/Kg for 0.8 GHz, 0.534 W/Kg for 1.43 GHz, 0.529 W/Kg for 3.5 GHz, and 0.665 W/Kg for 5.5 GHz when the applied input power is 10 mW. Overall, the proposed antenna in this study demonstrates superior performance compared to existing tri-band implantable antennas in terms of size, bandwidth, gain, and SAR values. Full article

This paper presents an effective way to design an RFID tag antenna to operate at three different frequencies by incorporating a switching technique. PIN diode has been used to switch the RF frequency because of its good efficiency and simplicity. The conventional dipole-based RFID tag has been improvised with added co-planar ground and PIN diode. The layout of the antenna is designed with a size of 0.083 ${\lambda }_0$ × 0.094 ${\lambda }_0$ at UHF (80–960) MHz, where ${\lambda }_0$ is the free-space wavelength corresponding to the mid-point of the targeted UHF range. The RFID microchip is connected to the modified ground and dipole structures. Bending and meandering techniques on the dipole length help to match the complex chip impedance with the dipole impedance. Additionally, it scales down the total structure of the antenna. Two PIN diodes are placed along the dipole length at appropriate distances with proper biasing. The ON-OFF switching states of the PIN diodes enable the RFID tag antenna to switch over the frequency ranges (840–845) MHz (India), 902–928 MHz (North America), and 950–955 MHz (Japan). Full article

Partial discharge (PD) diagnosis tests, including detecting, locating, and identifying, are used to trace defects or faults and assess the degree of aging in order to monitor the insulation condition of medium- and high-voltage power cables. In this context, an experimental evaluation of three different printed circuit board (PCB)-based inductive sensor topologies, with spiral, non-spiral, and meander shapes, is performed. The aim is to assess their capabilities for PD detection along a transmission power cable. First, simulation and experimental characterization are carried out to determine the equivalent electrical circuit and the quality factor of the three sensors. PD activity was studied in the lab on a 10-m-long defective MVAC cable. The three PCB-based sensors were tested in three different positions: directly on the defective cable (P1), at a separation distance of 10 cm to 3 m (P2), and on the ground line (P3). For the three positions, all sensors’ outputs present a damped sine wave signal with similar frequencies and durations. Experimental results showed that the best sensitivity was given by the non-spiral inductor, with a peak voltage of around 500 mV in P1, 428 mV in P2, and 45 mV in P3, while the meander sensor had the lowest values, which were approximately 80 mV in P1. The frequency spectrum bandwidth of all sensors was between 10 MHz and 45 MHz. The high sensitivity of the non-spiral inductor could be associated with its interesting properties in terms of quality factor and SFR, which are due to its very low resistivity. To benchmark the performance of the designed three-loop sensors, a comparison with a commercial high-frequency current transformer (HFCT) is also made. Full article

Recently, new form factors, such as foldable, have increased demand for mobile products.
Moreover, mobile phones should support the RF signal frequency up to the mm-wave frequency
due to the expansion of 5G mobile products. Therefore, 5G foldable products require components
that facilitate both mm-wave RF transmission and ultra-high flexibility for interconnecting through
the hinge structure of foldable products. To improve flexibility, a flexible PCB must be thin with no
ground vias in its bending section; in contrast, the low-loss flexible PCB for mm-wave transmission
must be thick and have many ground vias, so there is a trade-off relationship between flexibility
and RF characteristics. This paper proposes a new flexible PCB structure that does not experience
problems regarding signal transmission to the mm-wave band, even when folded 200,000 times.
To overcome the physical limits of the trade-off relationship, an interlayer air-gap was formed; a
structure with a via-less and meander ground shape is proposed. The simulated loss of the proposed
structure was 0.0254 dB/mm @ 10 GHz, and the isolation between signals ranged from 21.98 dB
to 10 GHz. The simulated results of insertion loss and isolation were experimentally verified. The
proposed structure is currently being applied to the RF flexible PCB that interconnects through the
hinge of a foldable phone, and is currently being mass-produced. Full article
