The marine controlled-source electromagnetic (CSEM) method serves as an effective tool for detecting hydrocarbon reservoirs. However, it faces a key challenge in shallow water: the airwave, an EM signal lacking subsurface information, often obscures reservoir responses. Conventional CSEM analysis, conducted in the diffusive frequency domain (DFD), only captures the steady-state behavior of the airwave, limiting physical insight into its propagation. In this study, we introduce the fictitious wave domain (FWD) method to reinterpret and visualize the airwaves’ trajectory and attenuation, individually. By transforming diffusive EM fields into fictitious lossless propagating waves, the FWD enables the use of kinematic wave concepts such as reflection, refraction, and travel time. The airwave is clearly identified as a refracted wave generated when a transverse electromagnetic (TEM) mode wave impinges perpendicularly on the air–seawater interface. Its path and arrival time become directly observable, allowing clear separation from other wave types. This approach visualizes and extracts the airwave even in complex inhomogeneous seawater, enabling its accurate transformation back to the DFD. The FWD thus provides a powerful tool for enhancing interpretation in marine EM exploration and offers a theoretical foundation for the development of tailored marine electromagnetic sensors. Full article

Efficient and accurate forward modeling of electromagnetic fields is essential for advancing geophysical exploration in complex marine environments. However, realistic survey conditions characterized by low-frequency spectra, fine sedimentary strata, irregular bathymetry, and anisotropic materials pose significant challenges for conventional numerical methods. To address these issues, this work presents a parallel modeling framework that combines coordinate transformations with an adaptive high-order finite-element approach for 3D marine controlled-source electromagnetic (MCSEM) simulations. The algorithm exploits the form invariance of Maxwell’s equations to map the original boundary value problem over the physical domain to one defined over a computationally favorable domain filled with anisotropic media. The transformed model is then discretized and solved using a parallel high-order finite-element scheme enhanced with a goal-oriented adaptive mesh refinement strategy. We examine the performance of the proposed framework using both synthetic models and the realistic Marlim R3D benchmark dataset. The results demonstrate that the proposed approach can effectively reduce computational costs while maintaining high accuracy across a wide frequency range and varying water depths. These findings highlight the framework’s potential for large-scale, high-resolution CSEM exploration of offshore resources. Full article

The proposed 3D stitching of spatially constrained Common Midpoint (CMP) 1D inversions is a method that integrates 1D laterally constrained inversion of marine Controlled-Source Electromagnetic (CSEM) data in the CMP domain to generate a cube of resistivities from 3D surveys. An interpretive model is built in the form of a set of columns of homogeneous cells that form a 3D resistivity grid. The proposed methodology is an iterative process that updates the entire model until it minimizes the data misfit between the real and synthetic data. We connect the model cells by smoothing regularization applied in all three directions, which generates stable solutions. Additionally, we evaluate the inversion result constrained by hard information, for example, well log resistivity data. Two applications to synthetic data and the inversion of a real data set illustrate the method. The synthetic data were generated from 3D models, one with two resistive targets at different depths and a second with a target inside a conductive layer over a resistive basement. The real data were gathered off the southeast coast of Brazil, in an area of gas hydrate accumulation. The results indicate that the method can generate useful approximations to the resistivity structures under the survey area in a much shorter time than that of a full 3D inversion. Full article

Traditionally, 3D modeling of marine controlled-source electromagnetic (CSEM) data (in the frequency domain) involves high-memory demand, requiring solving a large linear system for each frequency. To address this problem, we propose to solve Maxwell’s equations in a fictitious dielectric medium with time-domain finite-difference methods, with the support of the correspondence principle. As an advantage of this approach, we highlight the possibility of its implementation for execution with GPU accelerators, in addition to multi-frequency data modeling with a single simulation. Furthermore, we explore using the correspondence principle to the inversion of CSEM data by calculating the gradient of the least-squares objective function employing the adjoint-state method to establish the relationship between adjoint fields in a conductive medium and their counterparts in the fictitious dielectric medium, similar to the approach used in forward modeling. We validate this method through 2D inversions of three synthetic CSEM datasets, computed for a simple model consisting of two resistors in a conductive medium, a model adapted from a CSEM modeling and inversion package, and the last one based on a reference model of turbidite reservoirs on the Brazilian continental margin. We also evaluate the differences between the results of inversions using the steepest descent method and our proposed momentum method, comparing them with the limited-memory BFGS (Broyden–Fletcher–Goldfarb–Shanno) algorithm (L-BFGS-B). In all experiments, we use smoothing by model reparameterization as a strategy for regularizing and stabilizing the iterations throughout the inversions. The results indicate that, although it requires more iterations, our modified momentum method produces the best models, which are consistent with results from the L-BFGS-B algorithm and require less storage per iteration. Full article

The marine controlled-source electromagnetic (CSEM) method has been used in different applications, such as oil and gas reservoir exploration, groundwater investigation, seawater intrusion studies and deep-sea mineral exploration. Recently, the utilization of the marine CSEM method has shifted from petroleum exploration to active monitoring due to increased environmental concerns related to hydrocarbon production. In this study, we utilize the various dynamic reservoir properties available through reservoir simulation of the Wisting field in the Norwegian part of the Barents Sea. In detail, we first developed geologically consistent rock physics models corresponding to reservoirs at different production phases, and then transformed them into resistivity models. The constructed resistivity models pertaining to different production phases can be used as input models for a finite difference time domain (FDTD) forward modeling workflow to simulate EM responses. This synthetic CSEM data can be studied and analyzed in the light of production-induced changes in the reservoir at different production phases. Our results demonstrate the ability of CSEM data to detect and capture production-induced changes in the fluid content of a producing hydrocarbon reservoir. The anomalous CSEM responses correlating to the reservoir resistivity change increase with the advance of the production phase, and a similar result is shown in anomalous transverse resistance (ATR) maps derived from the constructed resistivity models. Moreover, the responses at 30 Hz with a 3000 m offset resulted in the most pronounced anomalies at the Wisting reservoir. Hence, the method can effectively be used for production-monitoring purposes. Full article

The marine controlled-source electromagnetic (CSEM) method is an efficient tool for hydrocarbon exploration. The amplitudes of signals decay rapidly with the increasing offset, so signals are easily contaminated by various kinds of noise. A denoising method is critical to improve the data quality, but the diversity of noise makes denoising difficult. Specific frequency signals are transmitted for exploration requirements, and thus traditional filtering methods are not suitable. Symplectic geometry mode decomposition (SGMD), a new method to decompose signals, has an outstanding decomposition performance and noise robustness. Furthermore, it can reduce multiple types of noise by reconstructing the single components. In this study, we introduced SGMD to reduce the noise of marine CSEM data and improved the data quality significantly. The experiments show that SGMD is better than variational mode decomposition and the sym4 wavelet method. Full article

The recycling or burial of carbon dioxide in depleted petroleum reservoirs and re-imagining exploration strategies that focus on hydrogen reservoirs (with any associated hydrocarbon gas as the upside potential) are a necessity in today’s environmental and geopolitical climate. Given that geologic hydrogen and hydrocarbon gases may occur in the same or different reservoirs, there will be gains in efficiency when searching for both resources together since they share some commonalities, but there is no geophysical workflow available yet for this purpose. Three-dimensional (3D) marine controlled-source electromagnetic (CSEM) and magnetotelluric (MT) methods provide valuable information on rock-and-fluid variations in the subsurface and can be used to investigate hydrogen and hydrocarbon reservoirs, source rocks, and the migration pathways of contrasting resistivity relative to the host rock. In this paper, a process-oriented CSEM-MT workflow is proposed for the efficient combined investigation of reservoir hydrocarbon and hydrogen within a play-based exploration and production framework that emphasizes carbon footprint reduction. It has the following challenging elements: finding the right basin (and block), selecting the right prospect, drilling the right well, and exploiting the opportunities for sustainability and CO₂ recycling or burial in the appropriate reservoirs. Recent methodological developments that integrate 3D CSEM-MT imaging into the appropriate structural constraints to derive the geologically robust models necessary for resolving these challenges and their extension to reservoir monitoring are described. Instructive case studies are revisited, showing how 3D CSEM-MT models facilitate the interpretation of resistivity information in terms of the key elements of geological prospect evaluation (presence of source rocks, migration and charge, reservoir rock, and trap and seal) and understanding how deep geological processes control the distribution and charging of potential hydrocarbon, geothermal, and hydrogen reservoirs. In particular, evidence is provided that deep crustal resistivity imaging can map serpentinized ultramafic rocks (possible source rocks for hydrogen) in offshore northwest Borneo and can be combined with seismic reflection data to map vertical fluid migration pathways and their barrier (or seal), as exemplified by the subhorizontal detachment zones in Eocene shale in the Mexican Ridges fold belt of the southwest of the Gulf of Mexico, raising the possibility of using integrated geophysical methods to map hydrogen kitchens in different terrains. The methodological advancements and new combined investigative workflow provide a way for improved resource mapping and monitoring and, hence, a technology that could play a critical role in helping the world reach net-zero emissions by 2050. Full article

Natural gas hydrates have been an unconventional source of energy since the beginning of this century. Gas-hydrate-filled reservoirs show higher resistivity values compared with water-filled sediments. Their presence can be detected using marine controlled-source electromagnetic methods. We classify acquisition configurations into stationary and moving receiver configurations, which are described in terms of the design group, the operational details, and where they have been used successfully in the field for natural gas hydrate exploration. All configurations showed good numerical results for the detection of a 700 m long gas hydrate reservoir buried 200 m below the seafloor, but only the stationary configurations provided data that can be used to estimate the horizontal boundaries of the resistive part of the reservoir when the burial depth is known from seismic data. We discuss the operational steps of the configurations and provide the steps on how to choose a suitable configuration. Different CSEM configurations were used together with seismic data to estimate the edge of the gas hydrate reservoir and the total volume of the gas hydrates, to optimize the drilling location, to increase production safety, and to improve geological interpretations. It seems that CSEM has become a reliable method to aid in the decision-making process for gas hydrate reservoir appraisal and development. Full article

Offshore geological sequestration of CO₂ offers a viable approach for reducing greenhouse gas emissions into the atmosphere. Strategies include injection of CO₂ into the deep-ocean or ocean-floor sediments, whereby depending on pressure–temperature conditions, CO₂ can be trapped physically, gravitationally, or converted to CO₂ hydrate. Energy-driven research continues to also advance CO₂-for-CH₄ replacement strategies in the gas hydrate stability zone (GHSZ), producing methane for natural gas needs while sequestering CO₂. In all cases, safe storage of CO₂ requires reliable monitoring of the targeted CO₂ injection sites and the integrity of the repository over time, including possible leakage. Electromagnetic technologies used for oil and gas exploration, sensitive to electrical conductivity, have long been considered an optimal monitoring method, as CO₂, similar to hydrocarbons, typically exhibits lower conductivity than the surrounding medium. We apply 3D controlled-source electromagnetic (CSEM) forward modeling code to simulate an evolving CO₂ reservoir in deep-ocean sediments, demonstrating sufficient sensitivity and resolution of CSEM data to detect reservoir changes even before sophisticated inversion of data. Laboratory measurements place further constraints on evaluating certain systems within the GHSZ; notably, CO₂ hydrate is measurably weaker than methane hydrate, and >1 order of magnitude more conductive, properties that may affect site selection, stability, and modeling considerations. Full article

Marine controlled source electromagnetic (CSEM) is an efficient method to explore ocean resources. The amplitudes of marine CSEM signals decay rapidly with the measuring offsets. The signal is easily contaminated by various kinds of noise when the offset is large. These noise include instrument internal noise, dipole vibration noise, seawater motion noise and environmental noise Suppressing noise is the key to improve data quality and interpretation accuracy. Sparse representation based denoising method has been used for denoising for a long time. provides a new way to remove noise. Under the framework of sparse representation, the denoising effect is closely related to the chosen transform matrix. This matrix is called dictionary and its column named atom. In general, the stronger the correlation between signal and dictionary is, the sparser representation will be, and further the better the denoising effect will be. In this article, a new method based on dictionary learning is proposed for marine CSEM denoising. Firstly, the signal segments suffering little from noise are captured to compose the training set. Then the learned dictionary is trained from the training set via K-singular value decomposition (K-SVD) algorithm. Finally, the learned dictionary is used to sparsely represent the contaminated signal and reconstruct the filtered one. The effectiveness of the proposed approach is verified by a synthetic data denoising experiment, in which windowed-Fourier-transform (WFT) and wavelet-transform (WT) denoising methods and three dictionaries (discrete-sine-transform (DST) dictionary, DST-wavelet merged dictionary and the learned dictionary) under a sparse representation framework are tested. The results demonstrate the superiority of the proposed dictionary-learning-based denoising method. Finally, the proposed approach is applied to field data denoising process, coupled with DST and DST-wavelet dictionaries based denoising methods. The outcomes further proves that the propsoed approach is effective and superior for marine CSEM data denoising. Full article

We introduce a new synthetic marine model for 3D controlled-source electromagnetic method (CSEM) surveys. The proposed model includes relevant features for the electromagnetic geophysical community such as large conductivity contrast with vertical transverse isotropy and a complex bathymetry profile. In this paper, we present the experimental setup and several 3D CSEM simulations in the presence of a resistivity unit denoting a hydrocarbon reservoir. We employ a parallel and high-order vector finite element routine to perform the CSEM simulations. By using tailored meshes, several scenarios are simulated to assess the influence of the reservoir unit presence on the electromagnetic responses. Our numerical assessment confirms that resistivity unit strongly influences the amplitude and phase of the electromagnetic measurements. We investigate the code performance for the solution of fundamental frequencies on high-performance computing architectures. Here, excellent performance ratios are obtained. Our benchmark model and its modeling results are developed under an open-source scheme that promotes easy access to data and reproducible solutions. Full article

Gas hydrate is seen as a kind of new energy resources, yet it may also be one of the main greenhouse gases as its dissociation may release methane into the atmosphere. Furthermore, a severe hazard to offshore infrastructures may also be introduced by extensive gas hydrate dissociation associated with the stability of the geological structures after gas production. Therefore, it is essential to investigate the gas hydrate as well as its environmental impacts before drilling and extracting it. The geophysical seismic reflection data is usually used for exploring the gas hydrate. The gas hydrate can be effectively identified by the bottom simulating reflectors (BSRs) on seismic reflection data. However, the BSR is only for identifying the bottom boundary and it is difficult to estimate its space distribution and saturation within the hydrate stability zone. The marine controlled-source electromagnetic (CSEM) data is suitable for detecting the gas hydrate as the resistivity of the seafloor increases significantly in the presence of gas hydrate or free gas. In this study, a weighted differential-field method is applied to improve the detectivity for identifying the gas hydrate. Numerical tests show that the difference of the EM fields can effectively suppress the airwaves in shallow waters. Therefore, the detectivity given by the field ratio between the models with and without the gas hydrate target is enhanced. Full article

The marine controlled-source electromagnetic method (MCSEM) has attracted considerable attention as an approach to explore marine oil and gas resources and geological structures. This study presents a new wavelet Galerkin method (WGM) to solve the forward modeling problem of 2D MCSEM data incorporating conductivity anisotropy. The method uses Daubechies wavelets that may be differentiated based on the need to solve the governing field equations of MCSEM. A quasi-minimal residual method was adopted by combining an incomplete LU preconditioner to solve the WGM equations. The numerical results were compared with the analytical solution and those obtained by the finite difference and element methods. The results show that the proposed WGM is superior to the finite element and difference methods in terms of computing time and memory requirements. This algorithm can be applied to solve the forward modeling problem of MCSEM. The conductivity anisotropy of the background medium affects the MCSEM response more than the reservoir anisotropy. The match between the modeled results and measured data for the simplified real model demonstrates the necessity for using the anisotropic model to interpret data. Although this study used the proposed algorithm for 2D models, it may also be used for 3D models. Full article

Natural gas hydrate is one of the most important clean energies and part of carbon cycle, due to the least carbon content. Natural gas hydrates depend on high pressure and low temperatures, located under seabed or permafrost. Small changes in temperature and pressure may lead gas hydrates to separate into water and gas, commonly as methane. As a powerful greenhouse gas, methane is much stronger than carbon dioxide. Therefore, it is necessary to detect the gas hydrates stable zone (GHSZ) before the methane gas escapes from GHSZ. Marine controlled source electromagnetic method (CSEM) is a useful tool to detect gas hydrate in offshore. The results from 3D CSEM method are a resistivity cube to describe the distribution of gas hydrates. In order to study the detectability of CSEM method, we simulate the sensitivity and resolution of marine CSEM synthetic data. By using the sensitivity and resolution, a simple statement may be quickly judged on the existence and occurrence range of the natural gas hydrate. In this paper, we compare the resolution of marine CSEM method with various transverse resistance. This information may help researchers find out whether the GHSZ exists or not. Full article

Seafloor massive sulfide (SMS) deposits have attracted growing interest and become the focus of current seafloor mineral exploration. One key challenge is to delineate potential SMS accumulations and estimate their quantity and quality for prospective resource mining. Recently, geophysical electromagnetic methods which are routinely used for land-based mineral exploration are being adapted to detect and assess SMS occurrences by imaging their conductivity distributions. However, the rough seafloor topography and electrical anisotropy of the seafloor formations encountered in practical surveys pose challenges for reliable data interpretation, and recent studies have revealed that the rough bathymetry could cause measurable distortions. Here, we consider a fixed-offset marine controlled-source electromagnetic method (CSEM) for SMS exploration, and investigate the effects of electrical anisotropy of sedimentary formations through numerical simulations for marine CSEM surveys aiming at conductive targets in the shallow regions of the seafloor. Numerical results demonstrate that the presence of electrical anisotropy could impose significant influence on fixed-offset marine CSEM data and suggest that the distortions should be sufficiently accounted for reliable data interpretation, thus lending confidence to subsequent quantification of available SMS minerals. Full article
