Search Results (50)

In this study, we propose a novel wideband aperture-coupled magneto-electric (ME) dipole antenna that achieves enhanced bandwidth by simultaneously leveraging ME resonance and aperture-coupled excitation. Building upon the conventional ME dipole architecture, the antenna integrates a pair of horizontal metal patches forming the electric dipole and a pair of vertical metal patches forming the magnetic dipole. A key innovation is the aperture-coupled feeding mechanism, where electromagnetic energy is transferred from a tapered microstrip line to the dipole structure through a slot etched in the ground plane. This design not only excites the characteristic ME resonances effectively but also significantly improves impedance matching, delivering a markedly broader impedance bandwidth. To validate the proposed concept, a prototype antenna was fabricated and experimentally characterized. Measurements show an impedance bandwidth of 84.48% (3.61–8.89 GHz) for $S_{11}$ ≤ −10 dB and a maximum in-band gain of 7.88 dBi. The antenna also maintains a stable, unidirectional radiation pattern across the operating band, confirming its potential for wideband applications such as 5G wireless communications. Full article

The impact of a lightning electromagnetic pulse (LEMP) on a power line or power station produces an effect similar to that of switching between a significant power source and a power line circuit. This switch closure causes a sudden change in routing conditions, creating a transient state. This situation has been studied in terms of electrostatic and electromagnetic induction, as well as overvoltage changes. Appropriate mathematical models were used to analyze these changes. While vertical electric field analysis has been carried out in a few studies, magnetic field and horizontal electric field vectors have not been studied. In this study, the Rusck formulation and the Heidler current formulation are combined at the current level, developed and analyzed. This is because the Rusck expression can sometimes give incorrect results at the current level. Also, in the analysis, electromagnetic field formulations based on accelerating charges are used instead of the dipole approximation to eliminate the need for interpolation in the graphical results. In contrast to other studies in the literature, this study proposes the use of moving and accelerating load techniques to better understand the effects of LEMPs on power transmission lines. Also, in this study, the double exponential problem of the current form in Rusck’s formulation is addressed in order to obtain a close approximation of the physical form of the LEMP. Additionally, the field–line (coupling) relationship is studied according to a unique closed formulation, leading to important determinations about the overvoltages generated on a line depending on the propagation speed of the LEMP sprout and the electrical changes in the area where the LEMP first occurs. Full article

This work presents a design for a complementary antenna with circular polarization that has a wide operating bandwidth, stable broadside radiation, and stable gain for X-band applications. The proposed antenna consists of an irregular loop and a parasitic electric dipole, which work together to produce equivalent radiation from the magnetic and electric dipoles. By arranging the dipole and the loop in a specific geometry, this antenna effectively generates circularly polarized wave propagation. A substrate integrated coaxial line (SICL) is applied to feed the antenna through an aperture cutting on the ground. The proposed antenna achieves a wide axial ratio (AR) and impedance bandwidths of 27.4% (from 8.5 to 11.22 GHz, for the AR ≤ 3 dB) and 39.6% (from 7.5 to 11.2 GHz, for the reflection coefficient ≤ −10 dB), respectively. Moreover, the antenna maintains a stable broadside radiation pattern across the operating bandwidth, with an average gain of 10 dBic. This proposed antenna design is competitive for X-band wireless communications. Full article

We present a detailed analysis of a partial eruption of a sigmoid filament lying along the polarity inversion line (PIL) of the small active region (AR) NOAA 12734 (with an area of 1.44 $\times {10}^3$ square megameters). The active filament was rooted in a dipole sunspot of the AR. The eruption was associated with a C1.3 flare and subsequent large-scale coronal disturbances. During its solar disk passage before the flare, the AR had the following characteristics: (1) Most of the time, the magnetic field lines in the AR showed a sigmoidal structure (‘L1’) in the low corona and arc-shaped loops (i.e., ‘L2’) in the upper atmosphere. (2) An ‘X’-shaped structure was formed between the original ‘S’-shaped magnetic loop (‘L1’) and the newly rising one (‘L3’) between the main positive and negative magnetic polarities of the sunspots, and the intersection point of flux ropes ‘L1’ and ‘L3’ corresponds well with the area where the initial extreme-ultraviolet (EUV) 1600 Å brightening of the flare occurred. (3) The AR disobeyed the hemispherical helicity rule and had magnetic twist and writhe of the same signs, i.e., its magnetic helicity/current helicity were positive in the northern hemisphere. (4) Sustained magnetic emergence and cancellation occurred before the flare. Therefore, the magnetic reconnection of highly twisted helical flux ropes under the confinement of the overlying magnetic fields is probably responsible for the partial eruption of the filament. Full article

The ENUBET project aims to reduce the flux-related systematics to 1% on a narrow band neutrino beam through monitoring the associated charged leptons in an instrumented decay tunnel. A key element of the project is the design of a meson transfer line with conventional magnets that maximize the yield of K${}^{+}$ and ${\pi }^{+}$ while minimizing the total length to reduce meson decay outside the instrumented region. In order to limit particle rates in the tunnel instrumentation, a high level of beam collimation is needed, thus allowing non-decayed mesons to reach the end of the tunnel. At the same time, fine-tuning of the shielding and the collimators is required to minimize any beam-induced background in the decay region. The magnetic lattice is optimized with TRANSPORT. The focusing of mesons from the target is performed with a static (quadrupole-based) system that, coupled with a slow proton extraction scheme, allows for a significant pile-up reduction at the tunnel instrumentation while retaining a particle yield large enough for high-precision neutrino cross-section measurements on a 3 year time scale. Charge and momentum selection in an 8.5GeV ± 10% momentum bite is performed by a double dipole system. Shielding elements are optimized with full simulation of the facility in Geant4. In particular, a powerful genetic algorithm is used to scan the parameter space of the collimators automatically in order to find a configuration that minimizes the halo background in the decay tunnel while preserving a large meson yield. This contribution will report the results of the optimization studies and the final design of the ENUBET beamline, together with dose estimation through a FLUKA simulation. The design of an alternative secondary beamline with a broad momentum range (4, 6, and 8.5 GeV/c) that could enhance the physics reach of the facility is additionally discussed. Full article

The present review is dedicated to the problem of an array of transitions between highly-excited atomic levels. Hydrogen atoms and hydrogen-like ions in plasmas are considered here. The presented methods focus on calculation of spectral line shapes. Fast and simple methods of universal ionic profile calculation for the $H_{n\alpha }$ ($\mathsf{\Delta }n=1$) and $H_{n\beta }$ ($\mathsf{\Delta }n=2$) spectral lines are demonstrated. The universal dipole matrix elements formulas for the $H_{n\alpha }$ and $H_{n\beta }$ transitions are presented. A fast method for spectral line shape calculations in the presence of an external magnetic field using the formulas for universal dipole matrix elements is proposed. This approach accounts for the Doppler and Stark–Zeeman broadening mechanisms. Ion dynamics effects are treated via the frequency fluctuation model. The accuracy of the presented model is discussed. A comparison of this approach with experimental data and the results of molecular dynamics simulation is demonstrated. The kinetics equation for the populations of highly-excited ionic states is solved in the parabolic representation. The population source associated with dielectronic recombination is considered. Full article

The treatment of N-Phenylmorpholine-4-carbothioamide (HPMCT) with bivalent metal ions in a 2:1 mol ratio without a base present affords [MCl₂(κ¹S-HPMCT)₂] {M = Cu(1), Pd(2), Pt(3), and Hg(4)} in a good yield. Furthermore, the reaction of two equivalents of HPMCT and one equivalent of bivalent metal ions in the presence of Et₃N has afforded [M(κ²S,N-PMCT)₂] {M = Ni(5), Cu(6), Pd(7), Pt(8), Zn(9), Cd(10), and Hg(11)}. Infrared, ¹H, ¹³C Nuclear Magnetic Resonance molar conductivity, and elemental analysis were used to characterize the synthesized complexes. The results suggest that HPMCT is bonded as monodentate via an S atom in Complexes (1–4), whereas linkage as a bidentate chelating ligand via S and N atoms gives two chelate rings. Moreover, the synthesized ligand and the complexes were screened for antibacterial activity, which displayed that the very best antibacterial activities for Complexes (1), (6), and (3). In addition, the cytotoxic activity of the HPMCT ligand, [PdCl₂(HPMCT)₂] (2), and [PtCl₂(HPMCT)₂] (3) were screened on breast cancer cell lines (MCF-7), and Complex (3) reveals the most promising activity with an IC₅₀ value 12.72 ± 0.4 μM. Using the B3LYP method and 6-311++G(d,p) basis sets for the ligand and the SDD basis set for the central metal, the synthesized complexes utilizing the prepared ligand were optimized. Various quantum parameters such as hardness, electron affinity, dipole moment, vibrational frequencies, and ionization energy for the ligand and its complexes have been calculated. In general, a favorable agreement was found between the experimental results and the obtained theoretical results. Full article

Medical three-dimensional (3D) positioning technology amalgamates traditional medical instrumentation with computational technology and medical imaging to facilitate the real-time visualization of anatomical lesions, surgical implements, and other relevant objects, thereby augmenting the physician’s diagnostic and therapeutic capabilities. Predominantly, optical positioning technologies are employed; however, they inherently suffer from limitations such as optical occlusion, precluding precise positioning. To surmount these challenges, the present manuscript introduces a phase-based 3D electromagnetic positioning technique predicated on spectral interpolation. Initially, four spectral lines exhibiting maximal signal amplitude are designated for the computation of a correction factor. Subsequently, the functional relationship between this correction factor and frequency offset is modeled via polynomial fitting, from which signal frequency and phase correction equations are derived. Experimental analyses executed within the ANSYS software (2021R2) environment substantiate the utility of the phase correction formula in calculating the phase disparity between the signals of the transmitting and receiving electromagnetic coils. This, in turn, enables the acquisition of the linear distance between these coils, which is instrumental in determining their spatial coordinates. The introduced 3D electromagnetic positioning methodology based on spectral interpolation effectively circumvents the issue of multiple solutions engendered by solving nonlinear equations inherent in traditional electromagnetic positioning systems. Simulation analyses corroborate that the proposed technique enhances phase detection accuracy by 1–2 orders of magnitude over conventional methods, achieving a positional accuracy within the effective measurement space of 3 mm—an improvement of at least 70% in comparison with established positioning paradigms. Full article

Recent developments in electromagnetic launchers have created potential applications in transportation, space, and defense systems. However, the total efficiency of these launchers has yet to be fully realized and optimized. Therefore, this paper introduces a new design idea based on increasing the magnetic flux lines that facilitate high output velocity without adding any excess energy. This design facilitates obtaining a mathematical equation for the launcher inductance which is difficult to analytically represent. This modification raises the launcher efficiency to 36% higher than that of the ordinary launcher at low operating voltage. The proposed design has proven its superiority to traditional launchers, which are limited in their ability to accelerate microsatellites from the ground to low Earth orbit due to altitude and velocity constraints. Therefore, an aircraft is used as a flying launchpad to carry the launcher and bring it to the required height to launch. Meanwhile, it is demonstrated experimentally that magnetic dipoles in the projectile material allow the launcher coil’s magnetic field to accelerate the projectile. This system consists of the launcher coil that must be triggered with a high amplitude current from the high DC voltage capacitor bank. In addition, a microcontroller unit controls all processes, including the capacitor bank charging, triggering, and velocity measurement. Full article

This experiment to search for the one of the charged lepton flavor-violating processes, muon-electron conversion, DeeMe, is being conducted at the J-PARC MLF H-Line in Japan. This experiment utilizes a pulsed proton beam from the Rapid Cycling Synchrotron (RCS). A graphite target is bombarded with a pulsed proton beam, negative pion production and pion-in-flight-decay to negative muon; then, the creation of muonic atoms is caused in the same pion production target. A converted electron is expected to be emitted after 1 ∼ 2 micro second-delayed timing. And two-body reaction of the new process, ${\mu }^{-}+(\mathrm{A},\mathrm{Z})\to e^{-}+(\mathrm{A},\mathrm{Z})$, results in 105 MeV monoenergetic electron. Thus, 1 ∼ 2 micro second-delayed 105 MeV monoenergetic electron is a searched signal. Electrons around 105 MeV are transported by the H-Line and analyzed using the dipole magnet (0.4 T) and four multi-wire proportional chambers (MWPCs). However, the burst pulse reaching ${10}^8$ charged particles/pulse attributable to the RCS pulse leads to significant dead time for the MWPC. Thus, the HV switching scheme is introduced to handle the prompt burst. The target single event sensitivity is ${10}^{-13}$. The H-Line construction was completed, and commissioning went well. The overview of the experiment and the current status are described in this article. Full article

A low-profile broadband dual-polarized antenna is investigated for base station applications. It consists of two orthogonal dipoles, fork-shaped feeding lines, an artificial magnetic conductor (AMC), and parasitic strips. By utilizing the Brillouin dispersion diagram, the AMC is designed as the antenna reflector. It has a wide in-phase reflection bandwidth of 54.7% (1.54–2.70 GHz) and a surface-wave bound range of 0–2.65 GHz. This design effectively reduces the antenna profile by over 50% compared to traditional antennas without an AMC. For demonstration, a prototype is fabricated for 2G/3G/LTE base station applications. Good agreement between the simulations and measurements is observed. The measured −10-dB impedance bandwidth of our antenna is 55.4% (1.58–2.79 GHz), with a stable gain of 9.5 dBi and a high isolation of more than 30 dB across the impedance passband. As a result, this antenna is an excellent candidate for miniaturized base station antenna applications. Full article

In the controlled source radiomagnetotelluric (CSRMT) sounding method, a horizontal magnetic dipole, HMD (vertical loop) or a horizontal electric dipole, and HED (grounded line) are used as sources. When working with HMD, the source is usually tuned to resonance to increase the current in the loop. However, the disadvantage of this approach is the narrow frequency range realized in the CSRMT method (1–12 kHz) and the short operating distance from the source (600–800 m). The need to tune the source to resonance at each selected frequency reduces the efficiency of the survey. In the case of using HED for sounding, measurements are performed in a wider frequency range of 1 to 1000 kHz, and along with the signal of the base frequency, its subharmonics are measured. In this case, emitted signal measurements are possible at a distance of up to 3–4 km from the source. At the same time, the disadvantage of using HED is that it requires grounding, the arrangement of which requires additional time when working on frozen ground or dry stony soil. We consider the possibilities of generation and registration of signals of subharmonics of base frequencies when applying the CSRMT method with loop sources—HMD and VMD (horizontal loop). A matching unit (MU) based on a step-up transformer was developed, which increases the output voltage of the CSRMT transmitter. In a field test with base frequencies of 20, 40, and 80 kHz, the signal amplitudes increased by a factor of two to four for subharmonics at frequencies of 60–200 kHz and by up to 10–13 times for subharmonics at frequencies of 200–500 kHz due to transformation of signal spectrum provided by MU. The possibility of using odd subharmonics of base frequencies for inversion has been demonstrated in the results of field experiments with different sources (HED, HMD, and VMD). This expands the frequency range of the method when working with loop sources and increases the survey’s effectiveness. The use of loop sources in the CSRMT method is especially advantageous for winter work in Arctic regions. Full article

The change in the absorption spectra due to reversal of the direction of light propagation (nonreciprocity of absorption) is a consequence of a simultaneous violation of both time-reversal and spatial-inversion symmetries. Here, we report on a high-resolution spectroscopic study of absorption nonreciprocity in the noncentrosymmetric multiferroic CuB₂O₄ below the antiferromagnetic transition temperature T_N = 21 K in the commensurate phase in magnetic fields up to 0.5 T. The study was performed in a broad spectral region covering several exciton transitions, which all are followed by an anomalously rich structure due to the multiple exciton-magnon-phonon satellites. Two components were resolved for the spectral line near 1.4 eV corresponding to the exciton transition between the ground and the first excited state. A quantitative theory of the optical absorption and nonreciprocity at this line was developed. The theory takes into account the interference between the electric and magnetic dipole contributions to the absorption and gives an adequate explanation of the relevant effects. Full article

The rapid development of the railway industry has brought convenience to people’s lives. However, with the high speed, high frequency and heavy load characteristics of rail use, the safety of rail is seriously threatened. In this paper, a magnetic flux leakage testing (MFL) detection technology of rail based on a double-track flaw detection vehicle is introduced in detail, which can effectively detect the damage of rail top surface, which is the blind area of ultrasonic detection. The magnetic dipole model is used to analyze that the leakage magnetic field in the direction of Bx and Bz above the damage is related to the depth and width of the damage. The relationship between the depth of the damage and the leakage magnetic field is quantitatively studied for the damage with fixed width but varying depth. The finite element simulation tool is used to model and simulate the damage at different depths. After analyzing the different characteristic values, it is found that the peak value of magnetic leakage signal has a certain correlation with the depth of damage, and the natural logarithm function is fitted out—VBx = 0.1451ln(b) + 0.2705, VBz = 2.7787ln(b) + 0.0087. In order to verify the prediction function of the injury depth fitted by the simulation data, the human injury with different depths was processed and the dual-track flaw detector was used to carry out the experiment of high-speed detection environment. The peak-to-peak fitting of the magnetic leakage signals in the direction of Bx and Bz of the experimental results shows that the peak-to-peak variation rule is roughly in line with the natural logarithm function in the simulation. The correlation between the fitting results of the experimental data and the simulation fitting function is analyzed using the Pearson coefficient. The Pearson coefficient in the direction of Bx is ρx = 0.91386. The Pearson coefficient of the Bz direction is ρz = 0.98597, the peak-to-peak value of Bx and Bz direction is positively correlated with the depth of damage and the fitting effect of the Bz direction is better than that of the Bx direction. Full article

To provide spectroscopic data for W${}^{13+}$, the present work is focused on the analysis of spectra observed in the visible range, using a compact electron beam ion trap (CoBIT). Line identification is done by using a collisional radiative model, along with sophisticated structure calculations from FAC and GRASP2018. Most of the identified lines belong to magnetic dipole (M1) transitions between the levels of the $4f^{12}5p^1$ and $4f^{13}$ configurations. Full article
