The growing vulnerability of residential buildings to seismic activity and dynamic loading underscores the need for robust, real-time Structural Health Monitoring (SHM) systems. This study investigates the feasibility of utilizing piezoelectric sensors integrated with advanced signal processing techniques, including Power Spectral Density (PSD) and Short-Time Fourier Transform (STFT), for vibration-based SHM in residential structures. A scaled three-story building prototype was fabricated and subjected to controlled base excitations at 25 Hz and 0.6 g acceleration to evaluate the response under three structural conditions: healthy, randomly damaged, and thickness-damaged. The experimental results revealed that structural degradation significantly altered sensor outputs, with random damage causing irregular signal dispersion and thickness damage introducing additional frequency harmonics. PSD analysis effectively identified shifts in energy distribution, signifying structural degradation, while STFT provided a detailed time-frequency representation, facilitating real-time damage detection. The findings confirm that piezoelectric sensors, when combined with PSD and STFT, can serve as a low-cost, scalable solution for early damage detection in residential buildings, offering a practical framework for enhancing structural resilience against earthquakes and other dynamic forces. Full article

Distributed Acoustic Sensing (DAS) offers numerous advantages, including resistance to electromagnetic interference, long-range dynamic monitoring, dense spatial sensing, and low deployment costs. We initially deployed a water–land DAS system at the Xinfengjiang (XFJ) Reservoir in Guangdong Province, China, to monitor earthquake events. Environmental noise analysis identified three distinct noise zones based on deployment conditions: periodic 18 Hz signals near surface-laid segments, attenuated low-frequency signals (<10 Hz) in the buried terrestrial sections, and elevated noise at transition zones due to water–cable interactions. The system successfully detected hundreds of teleseismic and regional earthquakes, including a Mw7.3 earthquake in Hualien and a local ML0.5 microseismic event. One year later, the DAS system was upgraded with two types of spiral sensor cables at the end of the submarine cable, extending the total length to 5.51 km. The results of detecting both active (transducer) and passive sources (cooperative vessels) highlight the potential of integrating DAS interrogators with spiral sensor cables for the accurate tracking of underwater moving targets. This field trial demonstrates that DAS technology holds promise for the integrated joint monitoring of underwater acoustics and seismic signals beneath lake or ocean bottoms. Full article

This study presents the results of an experimental investigation conducted on a 2:3 scale model of a two-story stone masonry building. We tested the model on the UniKORE L.E.D.A. lab shake table, simulating the Mw 6.3 earthquake ground motion that struck L’Aquila, Italy, on 6 April 2009, with progressively increasing peak acceleration levels. We installed a network of accelerometric sensors on the model to capture its structural behaviour under seismic excitation. Medium-to lower-cost MEMS accelerometers (classes A and B) were compared with traditional piezoelectric sensors commonly used in Structural Health Monitoring (SHM). The experiment assessed the structural performance and damage progression of masonry buildings subjected to realistic earthquake inputs. Additionally, the collected data provided valuable insights into the effectiveness of different sensor types and configurations in detecting key vibrational and failure patterns. All the sensors were able to accurately measure the dynamic response during seismic excitation. However, not all of them were suitable for Operational Modal Analysis (OMA) in noisy environments, where their self-noise represents a crucial factor. This suggests that the self-noise of MEMS accelerometers must be less than 1 µg/√Hz, or preferably below 0.5 µg/√Hz, to obtain good results from the OMA. Therefore, we recommend ultra-low-noise sensors for detecting differences in the structural behaviour before and after seismic events. Our findings provide valuable insights into the seismic vulnerability of masonry structures and the effectiveness of sensors in detecting damage. The management of buildings in earthquake-prone areas can benefit from these specifications. Full article

Modern, large bridges and tunnels represent important nodes in transportation arteries and have a significant impact on the development of transportation. The health and safety monitoring of these structures has always been a significant concern and is reliant on various types of sensors. Distributed acoustic sensing (DAS) with telecommunication fibers is an emerging technology in the research areas of sensing and communication. DAS provides an effective and low-cost approach for the detection of various resources and seismic activities. In this study, field experiments are elucidated, using DAS for the Hong Kong–Zhuhai–Macao Bridge, and for studying vehicle trajectories, earthquakes, and other activities. The basic signal-processing methods of filtering and normalization are adopted for analyzing the data obtained with DAS. With the proposed DAS technology, the activities on shore, vehicle trajectories on bridges and in tunnels during both day and night, and microseisms within 200 km were successfully detected. Enabled by DAS technology and mass fiber networks, more studies on sensing and communication systems for the monitoring of bridge and tunnel engineering are expected to provide future insights. Full article

With the growing demand for infrastructure and transportation facilities, the need for advanced structural health monitoring (SHM) systems is critical. This study introduces two innovative, cost-effective, standalone, and open-source data acquisition devices designed to enhance SHM through the latest sensing technologies. The first device, termed CEDAS_acc, integrates the ADXL355 MEMS accelerometer with a RaspberryPi mini-computer, ideal for measuring strong ground motions and assessing structural modal properties during forced vibration tests and structural monitoring of mid-rise buildings. The second device, CEDAS_geo, incorporates the SM24 geophone sensor with a Raspberry Pi, designed for weak ground motion measurements, making it suitable for seismograph networks, seismological research, and early warning systems. Both devices function as acceleration/velocity Data Acquisition Systems (DAS) and standalone data loggers, featuring hardware components such as a single-board mini-computer, sensors, Analog-to-Digital Converters (ADCs), and micro-SD cards housed in protective casings. The CEDAS_acc includes a triaxial MEMS accelerometer with three ADCs, while the CEDAS_geo uses horizontal and vertical geophone elements with an ADC board. To validate these devices, rigorous tests were conducted. Offset Test, conducted by placing the sensor on a leveled flat surface in six orientations, demonstrating the accelerometer’s ability to provide accurate measurements using gravity as a reference; Frequency Response Test, performed at the Gebze Technical University Earthquake and Structure Laboratory (GTU-ESL), comparing the devices’ responses to the GURALP-5TDE reference sensor, with CEDAS_acc evaluated on a shaking table and CEDAS_geo’s performance assessed using ambient vibration records; and Noise Test, executed in a low-noise rural area to determine the intrinsic noise of CEDAS_geo, showing its capability to capture vibrations lower than ambient noise levels. Further field tests were conducted on a 10-story reinforced concrete building in Gaziantep, Turkey, instrumented with 8 CEDAS_acc and 1 CEDAS_geo devices. The building’s response to a magnitude 3.2 earthquake and ambient vibrations was analyzed, comparing results to the GURALP-5TDE reference sensors and demonstrating the devices’ accuracy in capturing peak accelerations and modal frequencies with minimal deviations. The study also introduced the Record Analyzer (RECANA) web application for managing data analysis on CEDAS devices, supporting various data formats, and providing tools for filtering, calibrating, and exporting data. This comprehensive study presents valuable, practical solutions for SHM, enhancing accessibility, reliability, and efficiency in structural and seismic monitoring applications and offering robust alternatives to traditional, costlier systems. Full article

In this paper, a low-cost solution for Structural Health Monitoring is proposed, exploiting a dedicated embedded sensing system. Signals provided by the sensor node have been processed by Continuous Wavelet Transform. The node behavior to seismic-like solicitations and has been assessed in the case of frequency sweeps. The results demonstrate the system’s suitability for use in Early Warning frameworks. Full article

Seismic networks in urban areas today represent key infrastructure to better address the tasks of earthquake preparation and mitigation in the pre-event phase, and are an important knowledge tool supporting disaster risk management during seismic crises and post-disaster recovery. In the last fifteen years, a decrease in instrumentation costs and the development of new low-cost devices have enhanced the deployment of several monitoring and experimental networks worldwide. This paper conducts a review of scientific work that refer to the deployment of Urban Seismic Networks (USN) in order to define the current state of the art. We collected a list of more than one hundred USNs worldwide that were operative within the period from 1994–2023. For each USN, we report the locations and objectives along with information about the timing, coverage, geometry, and technical characteristics (sensors and transmission). By reviewing all these aspects, this paper offers important insights to provide guidelines for new implementations, bearing in mind that the interest in monitoring urban areas is expected to continue to increase in the near future driven by population growth in urbanized areas. Full article

This manuscript describes the design, development, and implementation of a prototype system based on seismogeodetic techniques, consisting of a low-cost MEMS seismometer/accelerometer, a biaxial inclinometer, a multi-frequency GNSS receiver, and a meteorological sensor, installed at the Doñana Biological Station (Huelva, Spain) that transmits multiparameter data in real and/or deferred time to the control center at the University of Cadiz. The main objective of this system is to know, detect, and monitor the tectonic activity in the Gulf of Cadiz region and adjacent areas in which important seismic events occur produced by the interaction of the Eurasian and African plates, in addition to the ability to integrate into a regional early warning system (EWS) to minimize the consequences of dangerous geological phenomena. Full article

Patras Gulf pockmark field (Western Greece) is a tectonically controlled field that has been activated at least twice by strong earthquakes (M5.4, 14 July 1993 and M6.4, 8 June 2008), and episodic gas seepages have been recorded in the past using geophysical means. A distributed temperature sensor (DTS) system was deployed inside a shallow pockmark and along an active fault at the northern end of the field. This ongoing experiment represents the first long-term monitoring ever conducted on gas-bearing pockmarks and active faults by the DTS system. For now, we have acquired and analyzed data regarding about 1.56 years. One of the primary objectives of this study is to establish methodological queues for data processing and analysis, including spectral analysis and incomplete data treatment techniques, to be standardized for use in further stages of the experiment. Spectral analysis was proven capable of separating the temperature footprint of background environmental components, such as sea-atmosphere heat flux, tides, and winds/waves, from high-frequency temperature residuals. Those residuals represent unusual events that might be correlated to seismicity. Monitoring the causal relationship between seismic activity and seabed water temperature changes in the field was thus attempted. No significant local earthquakes occurred during the monitoring period. Although the relation between seismicity and irregular seabed water temperature events was not systematic, we postulate that four thermal events have a causative link with the local seismicity. The DTS system constitutes a low-cost monitoring system, and the promising preliminary results of this experiment suggest that it is worth testing for a longer period. Full article

The importance of monitoring earthquakes for disaster management, public safety, and scientific research can hardly be overstated. The emergence of low-cost seismic sensors offers potential for widespread deployment due to their affordability. Nevertheless, vehicular noise in low-cost seismic sensors presents as a significant challenge in urban environments where such sensors are often deployed. In order to address these challenges, this work proposes the use of an amalgamated deep neural network constituent of a DNN trained on earthquake signals from professional sensory equipment as well as a DNN trained on vehicular signals from low-cost sensors for the purpose of earthquake identification in signals from low-cost sensors contaminated with vehicular noise. To this end, we present low-cost seismic sensory equipment and three discrete datasets that—when the proposed methodology is applied—are shown to significantly outperform a generic stochastic differential model in terms of effectiveness and efficiency. Full article

This paper explores the potential of a low-cost, advanced video-based technique for the assessment of structural damage to buildings caused by seismic loading. A low-cost, high-speed video camera was utilized for the motion magnification processing of footage of a two-story reinforced-concrete frame building subjected to shaking table tests. The damage after seismic loading was estimated by analyzing the dynamic behavior (i.e., modal parameters) and the structural deformations of the building in magnified videos. The results using the motion magnification procedure were compared for validation of the method of the damage assessment obtained through analyses of conventional accelerometric sensors and high-precision optical markers tracked using a passive 3D motion capture system. In addition, 3D laser scanning to obtain an accurate survey of the building geometry before and after the seismic tests was carried out. In particular, accelerometric recordings were also processed and analyzed using several stationary and nonstationary signal processing techniques with the aim of analyzing the linear behavior of the undamaged structure and the nonlinear structural behavior during damaging shaking table tests. The proposed procedure based on the analysis of magnified videos provided an accurate estimate of the main modal frequency and the damage location through the analysis of the modal shapes, which were confirmed using advanced analyses of the accelerometric data. Consequently, the main novelty of the study was the highlighting of a simple procedure with high potential for the extraction and analysis of modal parameters, with a special focus on the analysis of the modal shape’s curvature, which provides accurate information on the location of the damage in a structure, while using a noncontact and low-cost method. Full article

Earthquake early warning systems are used as important tools in earthquake risk management, providing timely information to residents and both public and private emergency managers. By doing this, the potential impact of large magnitude seismic events is significantly reduced. These systems use seismic sensors in order to acquire real-time data for the weaker but fast moving P wave (usually the first 3–5 s of the earthquake) and specific algorithms to predict the magnitude and the arrival time of the slower but more destructive surface waves. Most of these projection algorithms make use only of the vertical component of the acceleration and need extensive training in earthquake simulators in order to enhance their performance. Therefore, a low-inertial-mass uniaxial shaking table is proposed and analyzed in terms of frequency response in this paper, providing an effective cost/control ratio and high daily duty cycle. Furthermore, with the large variety of prediction algorithms, which use different frequency ranges, a new concept of selective frequency band error is also introduced and discussed in this paper as being a necessary tool for the final assessment of magnitude estimation algorithm error. Full article

Rapid post-earthquake damage assessment forms a critical element of resilience, ensuring a prompt and functional recovery of the built environment. Monitoring-based approaches have the potential to significantly improve upon current visual inspection-based condition assessment that is slow and potentially subjective. The large variety of sensing solutions that has become available at affordable cost in recent years allows the engineering community to envision permanent-monitoring applications even in conventional low-to-mid-rise buildings. When combined with adequate structural health monitoring (SHM) techniques, sensor data recorded during earthquakes have the potential to provide automated near-real-time identification of earthquake damage. Near-real time building assessment relies on the tracking of damage-sensitive features (DSFs) that can be directly and rapidly derived from dynamic monitoring data and scaled with damage. We here offer a comprehensive review of such damage-sensitive features in an effort to formally assess the capacity of such data-driven indicators to detect, localize and quantify the presence of nonlinearity in seismic-induced structural response. We employ both a parametric analysis on a simulated model and real data from shake-table tests to investigate the strengths and limitations of purely data-driven approaches, which typically involve a comparison against a healthy reference state. We present an array of damage-sensitive features which are found to be robust with respect to noise, to reliably detect and scale with nonlinearity, and to carry potential to localize the occurrence of nonlinear behavior in conventional structures undergoing earthquakes. Full article

The application of the horizontal-to-vertical spectral ratio (HVSR) modeling and inversion techniques is becoming more and more widespread for assessing the seismic response and velocity model of soil deposits due to their effectiveness, environmental friendliness, relative simplicity and low cost. Nevertheless, a number of issues related to the use of these techniques in difficult natural conditions, such as in the shelf areas of the Arctic seas, where the critical structures are also designed, remain poorly understood. In this paper, we describe the features of applying the HVSR modeling and inversion techniques to seismic records obtained by ocean-bottom seismographs (OBS) on the outer shelf of the Laptev Sea. This region is characterized by high seismotectonic activity, as well as sparse submarine permafrost distribution and the massive release of bubble methane from bottom sediments. The seismic stations were installed for one year and their period of operation included periods of time when the sea was covered with ice and when the sea was ice-free. The results of processing of the recorded ambient seismic noise, as well as the wave recorder data and ERA5 and EUMETSAT reanalysis data, showed a strong dependence of seafloor seismic noise on the presence of sea ice cover, as well as weather conditions, wind speed in particular. Wind-generated gravity waves, as well as infragravity waves, are responsible for the increase in the level of ambient seismic noise. The high-frequency range of 5 Hz and above is strongly affected by the coupling effect, which in turn also depends on wind-generated gravity waves and infragravity waves. The described seafloor seismic noise features must be taken into account during HVSR modeling and interpretation. The obtained HVSR curves plotted from the records of one of the OBSs revealed a resonant peak corresponding to 3 Hz, while the curves plotted from the records of another OBS did not show clear resonance peaks in the representative frequency range. Since both OBSs were located in the area of sparse distribution of submarine permafrost, the presence of a resonance peak may be an indicator of the presence of a contrasting boundary of the upper permafrost surface under the location of the OBS. The absence of a clear resonant peak in the HVSR curve may indicate that the permafrost boundary is either absent at this site or its depth is beyond the values corresponding to representative seismic sensor frequency band. Thus, HVSR modeling and inversion techniques can be effective for studying the position of submarine permafrost. Full article

The Internet of things concept empowered by low-cost sensor technologies and headless computers has upscaled the applicability of vibration monitoring systems in recent years. Raspberry Shake devices are among those systems, constituting a crowdsourcing framework and forming a worldwide seismic network of over a thousand nodes. While Raspberry Shake devices have been proven to densify seismograph arrays efficiently, their potential for structural health monitoring (SHM) is still unknown and is open to discovery. This paper presents recent findings from existing buildings located in Bucharest (Romania) equipped with Raspberry Shake 4D (RS4D) devices, whose signal recorded under multiple seismic events has been analyzed using different modal identification algorithms. The obtained results show that RS4D modules can capture the building vibration behavior despite the short-duration and low-amplitude excitation sources. Based on 15 RS4D device readings from five different multistorey buildings, the results do not indicate damage in terms of modal frequency decay. The findings of this research propose a baseline for future seismic events that can track the changes in vibration characteristics as a consequence of future strong earthquakes. In summary, this research presents multi-device, multi-testbed, and multi-algorithm evidence on the feasibility of RS4D modules as SHM instruments, which are yet to be explored in earthquake engineering. Full article
