Search Results (9)

In vanadium redox flow batteries (VRFBs), simultaneously achieving high proton conductivity, low vanadium-ion permeability, and outstanding chemical stability using electrolyte membranes is a significant challenge. In this study, we report the fabrication of a tri-directional poly(2,5-benzimidazole) (T-ABPBI) membrane using a direct casting method. The direct-cast T-ABPBI (D-T-ABPBI) membrane was fabricated by modifying the microstructure of the membrane while retaining the chemical structure of ABPBI, having outstanding chemical stability. The D-T-ABPBI membrane exhibited lower crystallinity and an expanded free volume compared to the general solvent-cast T-ABPBI (S-T-ABPBI) membrane, resulting in enhanced hydrophilic absorption capabilities. Compared to the S-T-ABPBI membrane, the enhanced hydrophilic absorption capability of the D-T-ABPBI membrane resulted in a decrease in the specific resistance (the area-specific resistance of S-T-ABPBI and D-T-ABPBI membrane is 1.75 and 0.98 Ωcm², respectively). Additionally, the D-T-ABPBI membrane showed lower vanadium permeability (3.40 × 10⁻⁷ cm² min⁻¹) compared to that of Nafion 115 (5.20 × 10⁻⁷ cm² min⁻¹) due to the Donnan exclusion effect. Owing to the synergistic effects of these properties, the VRFB assembled with D-T-ABPBI membrane had higher or equivalent coulomb efficiencies (>97%) and energy efficiencies (70–91%) than Nafion 115 at various current densities (200–40 mA cm⁻²). Furthermore, the D-T-ABPBI membrane exhibited stable performance for over 300 cycles at 100 mA cm⁻², suggesting its outstanding chemical stability against the highly oxidizing VO₂⁺ ions during practical VRFB operation. These results indicate that the newly fabricated D-T-ABPBI membranes are promising candidates for VRFB application. Full article

Proton exchange membranes (PEMs) are an important type of vanadium redox flow battery (VRFB) separator that play the key role of separating positive and negative electrolytes while transporting protons. In order to lower the vanadium ion permeability and improve the proton selectivity of PEMs for enhancing the Coulombic efficiency of VRFBs, herein, various amounts of nano-sized SiO₂ particles were introduced into a previously optimized sulfonated poly(arylene ether) (SPAE) PEMs through the acid-catalyzed sol-gel reaction of tetraethyl orthosilicate (TEOS). The successful incorporation of SiO₂ was confirmed by FT-IR spectra. The scanning electron microscopy (SEM) images revealed that the SiO₂ particles were well distributed in the SPAE membrane. The ion exchange capacity, water uptake, and swelling ratio of the PEMs were decreased with the increasing amount of SiO₂, while the mechanical properties and thermal stability were improved significantly. The proton conductivity was reduced gradually from 93.4 to 76.9 mS cm⁻¹ at room temperature as the loading amount of SiO₂ was increased from 0 to 16 wt.%; however, the VO²⁺ permeability was decreased dramatically after the incorporation of SiO₂ and reached a minimum value of 2.57 × 10⁻¹² m² s⁻¹ at 12 wt.% of SiO_2. As a result, the H⁺/VO²⁺ selectivity achieved a maximum value of 51.82 S min cm⁻³ for the composite PEM containing 12 wt.% of SiO₂. This study demonstrates that the properties of PEMs can be largely tuned by the introduction of SiO₂ with low cost for VRFB applications. Full article

The ion exchange membrane of the Nafion series widely used in vanadium flow batteries (VFBs) is characterized by its high cost and high vanadium permeability, which limit the further commercialization of VFBs. Herein, a thin composite membrane enabled by a low-cost microporous polyethylene (PE) substrate and perfluorosulfonic acid (PFSA) resin is proposed to reduce the cost of the membrane. Meanwhile, the rigid PE substrate limits the swelling of the composite membrane, which effectively reduces the penetration of vanadium ions and improves the ion selectivity of the composite membrane. Benefiting from such a rational design, a VFB assembled with the PE/PFSA composite membrane exhibited a higher coulombic efficiency (CE ≈ 96.8%) compared with commercial Nafion212 at 200 mA cm⁻². Significantly, the energy efficiency maintained stability within 200 cycles with a slow decay rate. In practical terms, the thin PE/PFSA composite membrane with low cost and high ion selectivity can make an ideal membrane candidate in VFBs. Full article

Energy storage systems have aroused public interest because of the blooming development of intermittent renewable energy sources. Vanadium redox flow batteries (VRFBs) are the typical candidates owing to their flexible operation and good cycle durability. However, due to the usage of perfluorinated separator membranes, VRFBs suffer from both high cost and serious vanadium ions cross penetration. Herein, we fabricate a series of low-budget and high-performance blend membranes from polyvinylpyrrolidone (PVP) and cardo-poly(etherketone) (PEKC) for VFRB. A PEKC network gives the membrane excellent mechanical rigidity, while PVP endows the blend membranes with superior sulfonic acid uptake owing to the present N-heterocycle and carbonyl group in PVP, resulting in low area resistance. Meanwhile, blend membranes also display low vanadium ion permeability resulting from the electrostatic repulsion effect of protonated PVP polymer chains towards vanadium ions. Consequently, the 50%PVP-PEKC membrane has a high ionic selectivity of 1.03 × 10⁶ S min cm⁻³, while that of Nafion 115 is nearly 17 times lower (6.03 × 10⁴ S min cm⁻³). The VRFB equipped with 50%PVP-PEKC membrane has high coulombic efficiencies (99.3–99.7%), voltage efficiencies (84.6–67.0%) and energy efficiencies (83.9–66.8%) at current densities of 80–180 mA cm⁻², and possesses excellent cycle constancy, indicating that low-cost x%PVP-PEKC blend membranes have a great application potentiality for VRFBs. Full article

In this study, blended anion exchange membranes were prepared using polyphenylene oxide containing quaternary ammonium groups and polyvinylidene fluoride. A polyvinylidene fluoride with high hydrophobicity was blended in to lower the vanadium ion permeability, which increased when the hydrophilicity increased. At the same time, the dimensional stability also improved due to the excellent physical properties of polyvinylidene fluoride. Subsequently, permeation of the vanadium ions was prevented due to the positive charge of the anion exchange membrane, and thus the permeability was relatively lower than that of a commercial proton exchange membrane. Due to the above properties, the self-discharge of the blended anion exchange membrane (30.1 h for QA–PPO/PVDF(2/8)) was also lower than that of the commercial proton exchange membrane (27.9 h for Nafion), and it was confirmed that it was an applicable candidate for vanadium redox flow batteries. Full article

Composite anion-exchange membranes (AEMs) consisting of a porous substrate and a vinyl imidazolium poly(phenylene oxide) (VIMPPO)/acrylamide copolymer layer were fabricated in a straightforward process, for use in redox flow batteries. The porous substrate was coated with a mixture of VIMPPO and acrylamide monomers, then subsequently exposed to UV irradiation, in order to obtain a radically cured ion-exchange coating. Combining VIMPPO with low-value reagents allowed to significantly reduce the amount of synthesized ionomer used to fabricate the mem- brane down to 15%. Varying the VIMPPO content also allowed tuning the ionic transport properties of the resulting AEM. A series of membranes with different VIMPPO/acrylamides ratios were prepared to assess the optimal composition by studying the changes of membranes properties—water uptake, area resistivity, permeability, and chemical stability. Characterization of the membranes was followed by cycling experiments in a vanadium RFB (VRFB) cell. Among three composite membranes, the one with VIMPPO 15% w/w—reached the highest energy efficiency (75.1%) matching the performance of commercial ion-exchange membranes (IEMs) used in VRFBs (Nafion^® N 115: 75.0% and Fumasep^® FAP 450: 73.0%). These results showed that the proposed composite AEM, fabricated in an industrially oriented process, could be considered to be a lower-cost alternative to the benchmarked IEMs. Full article

A series of poly(vinylidene difluoride)-based amphoteric ion exchange membranes (AIEMs) were prepared by preirradiation-induced graft copolymerization of styrene and dimethylaminoethyl methacrylate in an aqueous emulsion media followed by solution casting, sulfonation, and protonation. The effects of absorbed dose and comonomer concentration on grafting yield (GY) were investigated. The highest GY of 44.5% at a low comonomer concentration of 0.9 M could be achieved. FTIR, TGA, and X-ray photoelectron spectroscopy (XPS) confirmed the successful grafting and sulfonation of the as-prepared AIEMs. Properties of the AIEMs such as water uptake, ion exchange capacity (IEC), ionic conductivity, and crossover behavior of VO²⁺ ions prepared by this novel technique were systematically investigated and compared with those of the commercial Nafion 115 membrane. It was found that at a GY of 28.4%, the AIEMs showed higher IEC and conductivity, lower permeability of VO²⁺ ions, and a longer time to maintain open circuit voltage than Nafion 115, which was attributed to their high GY and elaborate amphoteric structure. Consequently, this work has paved the way for the development of green and low-cost AIEMs with good performance for vanadium redox flow battery applications. Full article

A novel amphoteric ion exchange membrane (AIEM) was successfully prepared by one-step radiation grafting of sodium styrene sulfonate (SSS) and dimethylaminoethyl methacrylate (DMAEMA) onto ethylene-vinylalcohol copolymer (EVOH) powder and sequent transferring into film by casting method. Fourier transform infrared spectrometry (FT-IR), thermal gravimetric analyzer (TGA) and elemental analysis testified SSS and DMAEMA were successfully grafted onto EVOH. The ion exchange capacity, water uptake and proton conductivity of the resulting AIEM increased with grafting yield (GY). At the GY of 40.9%, the permeability of vanadium ions of AIEM was 3.98 × 10⁻⁷ cm² min⁻¹, which was better than Nafion117 membrane. Furthermore, the cost of this AIEM is much lower than that of Nafion117 membrane. This work provided a low cost and simple method for fabrication of the ion exchange membrane for vanadium redox flow battery (VRFB). Meanwhile, it also provided a new direction for the application of EVOH. Full article

The promotion of strengthening of vanadium oxidation by compound additive of sodium salts is described from the changes of the vanadium valence state and mineral phase. The results are as follows: during the roasting process, dehydroxy mica converts to the melt, which the composite system mainly contains Na, K, Al, Si, and O. Under the action of NaCl-Na₂CO₃, ion exchange between sodium and potassium promotes the crystallization of albite from the melt. Na₂CO₃ enhances the reactivity of quartz. The albite reacts with activated quartz, which promotes the migration of sodium ions and the generation of vanadate. Under the action of NaCl-Na₂SO₄, The crystallization of spinel in the melt is promoted and that of the albite is inhibited. Under the action of Na₂SO₄-Na₂CO₃, the permeability of ore is deteriorated. The ion exchange process and the vanadium oxidation is inhibited from the melt. The composite additive with three sodium salts shows a stronger promoting effect on vanadium oxidation. The contribution of NaCl and Na₂CO₃ to V(V) in roasted slag was the highest among three sodium salts. With a certain ratio of NaCl and Na₂CO₃, the low content of Na₂SO₄ did not significantly affect the V(V) content in roasted slag. Full article
