Gas extraction is the main method to reduce the gas content of a coal seam and prevent coal and gas outburst. The sealing depth is one of the key parameters affecting the sealing effect. The principle of the high-density direct current method is to lay electrodes underground, and by injecting a stable DC current into the underground medium, the potential difference is measured to calculate the apparent resistivity, which reflects the difference in electrical conductivity of the underground rock or coal body, and then inferring the physical characteristics, such as its structure, water content, or stress state. Based on the basic principle of the high-density direct current method, this study analyzed the change rule of resistivity after the secondary stress of the roadway; tested the distribution of the roadway stress field in Juji Mine; and finally, determined the sealing depth of this coal seam. The main conclusions were as follows: The resistivity of the loose crushing zone after the roadway disturbance stress corresponded to the plasticity and destruction stage of the coal body, and the resistivity was larger compared with that of the original rock stress area. The stress concentration zone corresponded to the compression stage, where the destruction of the coal and rock state was smaller, and the resistivity was smaller compared with that of the original rock stress area. The range of the loose circle of the roadway of the coal seam was 6 m, and the range of the stress concentration zone was 6–17.5 m. The range of resistivity changes of the loose crushing zone was larger, and it had a large range of resistance, which had a good effect. The resistivity of the loose broken zone varied widely and was random, while the visual resistivity of the stress concentration zone was basically the same and was stable. Full article

In order to solve the problems of stress concentration in the roadway peripheral rock and poor support effect in a wide range of high-stress areas under the high-stress environment of MaKeng Iron Mine, this study is based on the theory of loose circle support, combined with the calculation of the anchor suspension theory to determine the reasonable length of pipe slit anchors and other key parameters. Through the two methods of punching and bonding, we examined the destructive effect to determine the thickness of the spray concrete and, finally, put forward the pipe slit anchor mesh spraying support technology program. The numerical model was constructed by using three-dimensional numerical simulation software (FLAC3D 5.0), and the support effect analysis of the support scheme was carried out systematically. The research results show the following: under the high-stress environment dominated by external horizontal tectonic stress, the use of pipe slit anchor net spray support technology can significantly improve the distribution characteristics of the plastic zone, stress field and displacement around the roadway; after the support, the deformation and displacement of the surrounding rock around the empty zone are significantly reduced, effectively preventing the destruction of the surrounding rock under the high-stress environment. The program not only unifies the mine support form and support parameters but also specifies the support construction method and construction quality inspection standard, which provides a scientific technical guarantee for mine shaft support and has an important reference value for the support design and construction of a mine roadway under a similar high-stress environment. Full article

Steep surrounding rock significantly challenges tunnel stability by affecting the stress distribution and deformation behavior. The angle of dip in surrounding rock greatly influences these factors, heightening the risk of instability along bedding planes, particularly under high ground stress conditions. This paper presents a comprehensive analysis of steep rock strata mechanical properties based on a railway tunnel in Yunnan Province, China. It incorporates long-term field monitoring and various laboratory tests, including point load, triaxial, and loose circle tests. Using experimental data, this study simulated the failure processes of steep surrounding rock and tunnel structures with a custom finite element method (FEM) integrated with the volume of fluid (VOF) approach. The analysis summarized the deformation patterns, investigated the causes of inverted arch deformation and failure, and proposed countermeasures. The findings reveal that increasing the rock dip angle results in greater deformation and accelerated failure rates, with the surrounding rock’s loose zone stabilizing at approximately 8 m once deformation stabilizes. At a surface deformation of 8 cm, the failure zone extends to 6 m; however, this extension occurs more rapidly with higher lateral pressure coefficients. Additionally, failure zones develop more quickly in thin, soft rock on steep slopes compared to uniform rock formations. The rise of the tunnel floor is attributed to the steeply inclined, thin surrounding rock. To enhance bottom structure stiffness, this study recommends incorporating an inverted arch structure and increasing both the number and strength of the anchor bolts. Full article

In the process of tunnel construction, problems such as high-stress rockburst, large deformation of soft rock, water inrush and mud gushing, secondary cracking of linings, blasting interference, man-made damage, and mechanical damage are often encountered. These pose a great challenge to the installation of monitoring equipment and line protection. In order to solve these problems, the 2# inclined shaft of Muzhailing Tunnel in the Gansu Province of China, which exists under high stress, water bearing, and bias conditions, was taken as the research object in this paper. By assembling a string, drilling grouting and sealing, and introducing multiple modes of protection, new fiber grating sensor group installation and line protection methods were proposed. The automatic continuous monitoring of the deep deformation of surrounding rock and the automatic continuous monitoring of steel arch stress were realized. The field monitoring results showed that: (1) the fiber grating displacement sensor group could be used to verify the authenticity of the surface displacement results monitored by the total station; (2) the NPR anchor cable coupling support effectively limited the large deformation of soft rock and the expansion of surrounding rock in a loose circle, and the range of the loose circle was stable at about 1 m; and (3) the main influence range of blasting was at a depth of 0~5 m in surrounding rock, and about 25 m away from the working face. In addition, to secure weak links in the steel arch due to the hardening phenomenon, a locking tube was set at the arch foot. In the support design, the fatigue life of the steel was found to be useful as the selection index for the steel arch frame to ensure the stability of the surrounding rock and the long-term safety of the tunnel. The present research adopted a robust method and integrates a variety of sensor technologies to provide a multifaceted view of the stresses and deformations encountered during the tunneling process, and the effective application of the above results could have certain research and reference value for the design and monitoring of high stress, water-bearing, and surrounding rock supports in tunnels. Full article

In the context of a shallow-buried thin coal seam, the surrounding rock deformation in the semi-coal rock roadway is comparatively small, resulting in self-stabilization of the two sides of the roadway without the need for support when the roadway is below a critical width. This study focuses on the transportation roadway of the 2107 working face in the Anzhe Coal Mine, employing a combination of laboratory tests, field tests, theoretical analyses, and numerical simulations. A mechanical model for the layered roof of the semi-coal rock roadway in a shallow-buried thin coal seam is developed, along with a calculation formula for determining the critical width of such roadways. The study also initially examines the correlation between the critical width and factors such as the tensile strength of the roof, the buried depth of the roadway, and the thickness of the immediate roof strata under conditions where the coal sides of the roadway are self-stabilizing. The results showed the following. (1) The calculation formula has good applicability for typical shallow-buried mine roadways in the Niuwu mining area and shallow-buried semi-coal rock roadways with coal thickness below 0.7 m under similar geological conditions. The critical width is related to the tensile strength of the roof, the buried depth of the roadway, and the thickness of the immediate roof strata. The degree of influence is determined by the thickness of the immediate roof strata > the tensile strength of the roof > the buried depth of the roadway. Among these, the tensile strength of the roof, the thickness of the immediate roof strata, and the critical width are basically in a positive exponentially increasing relationship, and the buried depth of the roadway and the critical width are basically in a negative exponentially decreasing relationship. (2) The on-site measurement of the loose circle on both sides of the roadway revealed that the rock mass loose circle had a thickness of 0.2 m, while the coal loose circle had a thickness ranging from 0.6 m to 0.7 m, aligning closely with the results obtained from theoretical calculations. The thickness of the coal loose circle on both sides served as the basis for determining the critical width of the semi-coal rock roadway in the shallow-buried thin coal seam. The calculated critical width of the roadway was 2.9 m, whereas the actual width measured was 2.4 m. Consequently, the two sides of the roadway are deemed capable of self-stabilization in the unsupported state. (3) Following the optimization of the support scheme, engineering analysis indicates that the roof and floor exhibit a maximum convergence of 46.3 mm, while the two sides show a maximum convergence of 18.4 mm. It is observed that the surrounding rock of the roadway satisfies the safety requirements for production. This study can provide theoretical support and a scientific basis for the stability discrimination of two sides and surrounding rock control of semi-coal rock roadways in shallow-buried thin coal seams under similar conditions. Full article

We studied fairy circles 20 km west of Sesriem at one of the driest locations of fairy circles in Namibia, at the foot of the popular Sossusvlei dunes. These fairy circles lack the typical hexagonal order of the Namibian fairy circles. After years of drought, their pattern is more similar to that of vegetation rings, due to the sparse vegetation in the area between the circles. Cross-section measurements of the soil water content (SWC) show that the upper layer (12 cm) is very dry (~1%) and much below the wilting point of Stipagrostis ciliata grasses, whereas the deeper soil layer is wetter (4%). The grain size distribution of soil samples taken from inside and outside the fairy circles reveals considerable heterogeneity in the size fractions due to aeolian (wind-driven) sand sorting. The bare soil inside the fairy circles contains coarser grains, and the ground surface is covered by sand megaripples. There is a linear trend between the vertical soil moisture gradient and the median grain diameter. Fine particles trapped on the vegetated edges of the fairy circle result in small nebkhas that increase the soil water retention at the surface. The dry and loose coarser topsoil inside the fairy circles may prevent the recolonization of new seedlings with short root lengths inside the fairy circles. Our results highlight the role of aeolian sand transport and deposition in desert vegetation environments and seem to support the notion that fairy circle formation may be affected by the interplay between sand sorting and soil moisture gradients. Full article

Soft broken surrounding rock exhibits obvious rheological properties and time-dependent weakening effects under the action of deep high-ground stress, leading to the increasingly prominent problem of sustained large deformation in deep roadways. In this study, with the II5 Rail Rise in Zhuxianzhuang Coal Mine as an example, the mechanism and control technology of time-dependent damage and instability in a deep soft-rock roadway were explored through a field observation and numerical simulation. The research results show that the range of the loose circle in the deep fractured surrounding rock can reach 3.0 m. The expansion of shallow and deep cracks causes the primary plastic deformation and secondary rheological deformation of the surrounding rock, with the rheological deformation rate increasing by 21.4% every 55 days on average, which ultimately induces the instability and failure of the surrounding rock. Based on the mechanism of roadway instability, a control technology of high-preload bolt + deep- and shallow-borehole crack filling was proposed. The technology reduces deformation and ensures the stability of the roadway surrounding rock by inhibiting the propagation of deep and shallow cracks and reinforcing the surrounding rock. Full article

The control difficulty of whole coal cavern groups is greatly increased due to the characteristics of soft rock with low strength, large sections, and the mutual influence of crossed cavern groups. The large section gas storage cavern group is taken as the research background. In this paper, the equivalent circle method is used to solve the loose circle of a rectangular roadway, and numerical calculation is used to obtain the deformation and stress distribution laws of the surrounding rock under the excavation conditions of large section whole coal cavern groups (WCCG). The deformation and failure mechanisms of the surrounding rock are revealed under the linkage impact between large section whole coal cavern groups. The stratified reinforcement ring concept of “long cable-bolt-grouting” (LBG) was proposed for the stability control of surrounding rock in the WCCG. On the roof of whole coal cavern groups, the supporting configuration of a high-strength bolt with a high pre-tightening force and the high-strength anchor with a high pre-tightening force were determined. On the two sides and floor of the WCCG, the grouting scheme was determined. These two supporting configurations in both the roof and sidewalls were applied to the large section gas storage cavern group. The results show that the surrounding rock presents asymmetric deformation and failure characteristics due to the large excavation area and complex structure. Tensile failure and mixed tensile-shear failure mainly occur in the shallow part of the surrounding rock, while shear failure mainly occurs in the deep part of the surrounding rock. The roof displacement curves show a symmetric distribution and saddle distribution in the low- and high-negative pressure caverns, respectively. The maximum displacements are on the left and right sides of the cavern roof. The range of the loose rings is 3.34 m and 2.54 m, respectively, on the roof and the two ribs. The stratified reinforcement ring support technology of LBG can effectively reduce the failure depth of surrounding rock, and the surrounding rock is in a stable state. The study can provide a theoretical basis for the layout of large section cavern groups and the stability control of surrounding rock. Full article

The characteristics of plastic zone are a critical basis for the control and stability analysis of the surrounding rock of roadways. This paper aims to investigate the rationality and applicability of the numerical methods for the plastic zone analysis of deep jointed rock roadways. Based on the detailed investigation and experiments, The plastic zone distribution of roadway surrounding rock under different GSI values and different buried depths was analyzed by analytical methods, parameter reduction, and equivalent rock mass technology, and then the acoustic wave measurement method was used to carry out the field measurement and was compared with the simulation results. The results show that when GSI is large, the difference between the results is not obvious. When GSI is small, the results obtained by the parameter reduction method and the analytical method show a more drastic increase and the discreteness increases. The results obtained by the equivalent rock mass technique are generally close to the measured values, and the growth rate is more uniform. According to the convenience of the calculation parameters and the accuracy of the calculation, the suitable calculation methods for different working conditions were suggested. Full article

Loosened rock circle is formed around the tunnel when the tunnel is constructed by the drilling and blasting method. The size of the loosened rock circle around the tunnel and the degree of internal rock fragmentation has an important influence on the support parameters, durability, and safety of the tunnel. Firstly, referencing an existing tunnel project, blasting tests using nonelectronic and electronic detonators were carried out to determine the influence of blasting construction on the scope of the rock loose circle and the degree of rock fragmentation. Then, a numerical simulation was used to study the contribution of the blasting impact and surrounding rock stress redistribution on the loosened rock circle around the tunnel. The results showed that the range of the loosened rock circle around the tunnel generated by the normal blasting of nonelectronic detonators was 1.5~2.3 m, and the wave velocity of the rock mass in the loosened rock circle around the tunnel decreased to 23~36%. The size of the loosened rock circle around the tunnel generated by the blasting impact was 0.66 m, accounting for 33% of the range of the loosened rock circle around the tunnel. The range of the loosened rock circle around the tunnel produced by electronic detonator blasting was 0~1.4 m. The wave velocity of the rock mass in the loosened rock circle around the tunnel decreased to 12~17%. The range of the loosened rock circle around the tunnel was approximately 60~76% of that of detonator blasting, and the broken degree of the surrounding rock in the loosened rock circle around the tunnel was small. The research results can provide a reference for the optimization design of preliminary support parameters of tunnels, such as anchors and steel arches in blasting construction. Full article

The newly built shaft in the western region needs to pass through the deep Cretaceous stratum, where the pores and fissures are developed, the cementation ability is poor, and the surrounding rock is rich in water. Under the coupling effect of the stress field and seepage field, the surrounding rock is easy to deteriorate and loses stability. The hydraulic coupling test of Cretaceous red sandstone was carried out by using the TAW-2000 rock mechanics testing system, and the characteristic strength evolution law of red sandstone was analyzed; Mohr’s circle and strength envelope were obtained by the M–C criterion, and the influence mechanism seepage pressure on red sandstone was explored; and combined with the effective stress principle and M–C strength criterion, a constitutive model under hydraulic coupling was established. Confining pressure limits the development of cracks and strengthens the mechanical properties. The results revealed that red sandstone has the characteristics of low less clay, loose particles, and weak cementation capacity; under the action of water pressure, the cement between particles disintegrates and loses the cementation strength, resulting in a significant decrease in cohesion, and the loss of cementation strength is the internal reason for the softening of red sandstone. The constitutive model based on the effective principle and M–C criterion can better reflect the mechanical behavior of red sandstone under hydraulic coupling. This paper provides a research basis for understanding the microscopic characteristics and hydraulic coupling characteristics of Cretaceous weakly cemented sandstone. Full article

The pre-drainage of coalbed methane through boreholes in the bottom drainage roadway (BDR) is the key measure to prevent and control coal and gas outburst. Different arrangement layers in the BDR will make a difference in the range of drilling angle and affect the gas extraction effect. In this paper, the mathematical model of the rock loose circle area around elliptical drilling was constructed. Meanwhile, the fluid–solid coupling model is constructed by using COMSOL software, the dynamic response of coal permeability and volumetric strain with gas pressure and the Klinkenberg effect of gas are considered, and the effect of the change of the elliptical drilling angle on the pressure relief effect of the coal seam is studied. The results showed that the distance between the layer in the BDR and the pre-drainage coal seam would decrease, and the effective extraction length at the same point of gas extraction in the coal seam increases. The area of the rock loose circle and permeability around the drilling decayed negatively and exponentially with the increase in drilling angle. As the drilling angle decreased, the stress in the major axis of the ellipse at the drilling cross-section increased, so the drilling was prone to collapse, and the gas extraction was hindered. Finally, an optimal method of determining the layer in the BDR under the coupling effect of multiple factors was established by combining the measured ground stress. Through field measurement, the drilling extraction rate of the optimized scheme is 60% higher than that of the original scheme. Full article

To understand the fracture features of zonal disintegration and reveal the failure mechanisms of circle tunnels excavated in deep jointed rock masses, a series of three-dimensional heterogeneous models considering varying joint dip angles are established. The strength reduction method is embedded in the RFPA method to achieve the gradual fracture process, macro failure mode and safety factor, and to reproduce the characteristic fracture phenomenon of deep rock masses, i.e., zonal disintegration. The mechanical mechanisms and acoustic emission energy of surrounding rocks during the different stages of the whole formation process of zonal disintegration affected by different-dip-angle joints and randomly distributed joints are further discussed. The results demonstrate that the zonal disintegration process is induced by the stress redistribution, which is significantly different from the formation mechanism of traditional surrounding rock loose zone; the dip angle of joint set has a great influence on the stress buildup, stress shadow and stress transfer as well as the failure mode of surrounding rock mass; the existence of parallel and random joints lead the newly formed cracks near the tunnel surface to developing along their strikes; the random joints make the zonal disintegration pattern much more complex and affected by the regional joint composition. These will greatly improve our understanding of the zonal disintegration in deep engineering. Full article

The application of roof-cutting and pressure-relief gob-side entry retention plays a critical role in controlling the stability of the surrounding rock at the entry, easing continuity tension and improving resource recovery ratio. The excavation of the 360,803 airway in Xinji No. 1 Mine is affected by intense mining of the 360,805 working face. Hence, to address the stability problem of surrounding rock in the 360,803 airway, rock mass blast weakening theory was used in this study to analyze the blasting stress of columnar charged rock mass and obtain the radiuses of crushed, fractured, and vibration zones under uncoupled charging conditions. The reasonable array pitch, length, and dip angle of boreholes were determined according to the pressure-relief range of the blasting fracture. The migration laws of roof strata were explored based on a mechanical model of overlying roof strata structure on the working face. Subsequently, the horizon, breaking span, and caving sequence of hard roof strata were obtained to determine the roof-cutting height of this entry. On the basis of the theory of key stratum, the number of sequences at the roof caving limit stratum and hanging roof length in the goaf were calculated, the analytical solution to critical coal pillar width was acquired, the evaluation indexes for the stability of entry-protecting coal pillars were determined, and the engineering requirements for the 25 m entry-protecting coal pillars in the 360,803 airway were met. Moreover, various indexes such as roof separation fracture, displacement of surrounding rock, and loose circle of surrounding rock in the gob-side entry were analyzed. The stability and cementation status of surrounding rock in the 360,803 airway were evaluated, and tunneling safety was ensured. Full article
