To date, there is little publicly available scientific data on unidentified aerial phenomena (UAP) whose properties and kinematics purportedly reside outside the performance envelope of known phenomena. To address this deficiency, the Galileo Project is designing, building, and commissioning a multi-modal, multi-spectral ground-based observatory to continuously monitor the sky and collect data for UAP studies via a rigorous long-term aerial census of all aerial phenomena, including natural and human-made. One of the key instruments is an all-sky infrared camera array using eight uncooled long-wave-infrared FLIR Boson 640 cameras. In addition to performing intrinsic and thermal calibrations, we implement a novel extrinsic calibration method using airplane positions from Automatic Dependent Surveillance–Broadcast (ADS-B) data that we collect synchronously on site. Using a You Only Look Once (YOLO) machine learning model for object detection and the Simple Online and Realtime Tracking (SORT) algorithm for trajectory reconstruction, we establish a first baseline for the performance of the system over five months of field operation. Using an automatically generated real-world dataset derived from ADS-B data, a dataset of synthetic 3D trajectories, and a hand-labeled real-world dataset, we find an acceptance rate (fraction of in-range airplanes passing through the effective field of view of at least one camera that are recorded) of 41% for ADS-B-equipped aircraft, and a mean frame-by-frame aircraft detection efficiency (fraction of recorded airplanes in individual frames which are successfully detected) of 36%. The detection efficiency is heavily dependent on weather conditions, range, and aircraft size. Approximately 500,000 trajectories of various aerial objects are reconstructed from this five-month commissioning period. These trajectories are analyzed with a toy outlier search focused on the large sinuosity of apparent 2D reconstructed object trajectories. About 16% of the trajectories are flagged as outliers and manually examined in the IR images. From these ∼80,000 outliers and 144 trajectories remain ambiguous, which are likely mundane objects but cannot be further elucidated at this stage of development without information about distance and kinematics or other sensor modalities. We demonstrate the application of a likelihood-based statistical test to evaluate the significance of this toy outlier analysis. Our observed count of ambiguous outliers combined with systematic uncertainties yields an upper limit of 18,271 outliers for the five-month interval at a 95% confidence level. This test is applicable to all of our future outlier searches. Full article

This study addresses the challenges associated with single-system long-baseline real-time kinematic (RTK) navigation, including limited positioning accuracy, inconsistent signal reception, and significant residual atmospheric errors following double-difference corrections. This study explores the effectiveness of long-baseline RTK navigation using an integrated system of the BeiDou Navigation Satellite System (BDS), Global Positioning System (GPS), and Galileo Satellite Navigation System (Galileo). A long-baseline RTK approach that incorporates Kalman filtering and partial ambiguity resolution is applied. Initially, error models are used to correct ionospheric and tropospheric delays. The zenith tropospheric and inclined ionospheric delays and additional atmospheric error components are then regarded as unknown parameters. These parameters are estimated together with the position and ambiguity parameters via Kalman filtering. A two-step method based on a success rate threshold is employed to resolve partial ambiguity. Data from five long-baseline IGS monitoring stations and real-time measurements from a ship were employed for the dual-frequency RTK positioning experiments. The findings indicate that integrating additional GNSSs beyond the BDS considerably enhances both the navigation precision and the rate of ambiguity resolution. At the IGS stations, the integration of the BDS, GPS, and Galileo achieved navigation precisions of 2.0 cm in the North, 5.1 cm in the East, and 5.3 cm in the Up direction while maintaining a fixed resolution exceeding 94.34%. With a fixed resolution of Up to 99.93%, the integration of BDS and GPS provides horizontal and vertical precision within centimeters in maritime contexts. Therefore, the proposed approach achieves precise positioning capabilities for the rover while significantly increasing the rate of successful ambiguity resolution in long-range scenarios, thereby enhancing its practical use and exhibiting substantial application potential. Full article

The long convergence time and non-robust positioning accuracy are the main factors limiting the application of precision single-point positioning (PPP) in kinematic vehicle navigation. Therefore, a dual/triple-frequency multi-constellation PPP-RTK method with atmospheric augmentation is proposed to achieve cm-level reliable kinematic positioning. The performance was assessed using a set of static station and kinematic vehicle positioning experiments conducted in Wuhan. In the static experiments, instantaneous convergence within 1 s and centimeter-level positioning accuracy were achieved for PPP-RTK using dual-frequency observation. For the kinematic experiments, instantaneous convergence was also achieved for dual-frequency PPP-RTK in open areas, with RMS of 2.6 cm, 2.6 cm, and 7.5 cm in the north, east, and up directions, respectively, with accuracy similar to short-baseline real-time kinematic positioning (RTK). Horizontal positioning errors of less than 0.1 m and 3D positional errors of less than 0.2 m were 99.54% and 98.46%, respectively. Additionally, after the outage of GNSS and during satellite reduction in obstructed environments, faster reconvergence and greater accuracy stability were realized compared with PPP without atmospheric enhancement. Triple-frequency PPP-RTK was able to further enhance the robustness and accuracy of positioning, with RMS of 2.2 cm, 2.0 cm, and 7.3 cm, respectively. In summary, a performance similar to RTK was achieved based on dual-frequency PPP-RTK, demonstrating that PPP-RTK has the potential for lane-level navigation. Full article

In the past few decades, network real-time kinematic (NRTK) positioning technology has developed rapidly. Generally, in the continuously operating reference stations (CORS) network, within a moderate baseline length, e.g., 80–100 km, atmospheric delay can be effectively processed through regional modeling and, thus, can support almost instantaneous centimeter-level NRTK positioning. However, in long-baseline CORS networks, especially during the active period of the ionosphere, ionospheric delays cannot be fully eliminated through modeling, leading to decreased NRTK positioning accuracy. To address this issue, this study proposes a long-baseline NRTK positioning method considering ionospheric residual interpolation uncertainty (IRIU). The method utilizes the ionospheric residual interpolation standard deviation (IRISTD) calculated during atmospheric delay modeling, then fits an IRISTD-related stochastic model through the fitting of the absolute values of the ionospheric delay modeling residuals and IRISTD. Finally, based on the ionosphere-weighted model, the IRISTD processed by the stochastic model is used to constrain the ionospheric pseudo-observations. This method achieves good comprehensive performance in handling ionospheric delay and model strength, and the advantage is validated through experiments using CORS data with baseline lengths ranging from 54 km to 106 km in western China and from 84 km to 180 km in AUSCORS data. Quantitative results demonstrate that, across the three sets of experiments, the proposed ionosphere-weighted model achieves an average increase in the fixed rate of 16.9% compared to the ionosphere-fixed model and 25.6% compared to the ionosphere-float model. In terms of positioning accuracy, the proposed model yields average improvements of 67.4%, 76.4%, and 66.0% in the N/E/U directions, respectively, compared to the ionosphere-fixed model, and average improvements of 21.0%, 32.0%, and 24.4%, respectively, compared to the ionosphere-float model. Overall, the proposed method can achieve better NRTK positioning performance in situations where ionospheric delay modeling is inaccurate, such as long baselines and ionospheric activity. Full article

The multi-constellation, multi-frequency Global Navigation Satellite System (GNSS) has the potential to empower precise real-time kinematics (RTK) with higher accuracy, availability, continuity, and integrity. However, to enhance the robustness of the nonlinear filter, both the measurement quality and efficiency of parameter estimation need consideration, especially for GNSS challenging or denied environments where outliers and non-Gaussian noise exist. This study proposes a nonlinear Kalman filter with adaptive kernel bandwidth (KBW) based on the maximum correntropy criterion (AMC-KF). The proposed method excavates data features of higher order moments to enhance the robustness against noise. With the wide-lane and ionosphere-free combination, a dual frequency (DF) data-aided ambiguity resolution (AR) method is also derived to improve the measurement quality. The filtering strategy based on the DF data-aided AR method and AMC-KF is applied for multi-GNSS and DF RTK. To evaluate the proposed method, the short baseline test, long baseline test, and triangle network closure test are conducted with DF data from GPS and Galileo. For the short baseline test, the proposed filter strategy could improve the positioning accuracy by more than 30% on E and N components, and 60% on U. The superiority of the proposed adaptive KBW is validated both in efficiency and accuracy. The triangle network closure test shows that the proposed DF data-aided AR method could achieve a success rate of more than 93%. For the long baseline test, the integration of the above methods gains more than 40% positioning accuracy improvement on ENU components. This study shows that the proposed nonlinear strategy could enhance both robustness and accuracy without the assistance of external sensors and is applicable for multi-GNSS and dual-frequency RTK. Full article

Until now, RTK (real-time kinematic) and NRTK (Network-based RTK) have been the most popular cm-level accurate positioning approaches based on Global Navigation Satellite System (GNSS) signals in real-time. The tropospheric delay is a major source of RTK errors, especially for medium and long baselines. This source of error is difficult to quantify due to its reliance on highly variable atmospheric humidity. In this paper, we use the NRTK approach to estimate double-differenced zenith tropospheric delays alongside ambiguities and positions based on a complete set of multi-GNSS data in a sample 6-station network in Europe. The ZTD files published by IGS were used to validate the estimated ZTDs. The results confirmed a good agreement, with an average Root Mean Squares Error (RMSE) of about 12 mm. Although multiplying the unknowns makes the mathematical model less reliable in correctly fixing integer ambiguities, adding a priori interpolated ZTD as quasi-observations can improve positioning accuracy and Integer Ambiguity Resolution (IAR) performance. In this work, weighted least-squares (WLS) were performed using the interpolation of ZTD values of near reference stations of the IGS network. When using a well-known Kriging interpolation, the weights depend on the semivariogram, and a higher network density is required to obtain the correct covariance function. Hence, we used a simple interpolation strategy, which minimized the impact of altitude variability within the network. Compared to standard RTK where ZTD is assumed to be unknown, this technique improves the positioning accuracy by about 50%. It also increased the success rate for IAR by nearly 1. Full article

The BeiDou Navigation Satellite System (BDS) is fully operational and provides positioning, navigation, and timing services to users worldwide. To comprehensively evaluate the BeiDou-3 Navigation Satellite System (BDS-3) global real-time kinematic (RTK) positioning performance, five sets of IGS/MEGX stations with different baseline lengths are selected in this research, and the visibility of current BDS-3, BDS-2+BDS-3, and Global Positioning System (GPS) system satellites are analyzed. The single frequency, dual-frequency, and triple-frequency positioning accuracy as well as ambiguity fixing rate under short baseline and long baseline are also analyzed. The experimental results show that the positioning accuracies of B1C, BII, L1, and B3I single-frequency bands were about the same, while for band B2a it was lower. For the short baseline dual-frequency RTK positioning mode, the accuracy of BDS-3 (B1C/B2a), BDS-3 (B1I/B3I), triple-frequency BDS-3 (B1C/B2a/B3I), and GPS (L1L2) is comparable and slightly better than that of BDS-3 (B1I/B3I). With the increase in baseline length, the advantages of dual-frequency BDS-3 (B1C/B2a) and triple frequency BDS (B1C/B2a/B3I) are more obvious, with triple-frequency BDS-3 (B1C/B2a/B3I) having the best positioning accuracy. In terms of ambiguity fixing performance, dual-frequency BDS-2+BDS-3 (B1I/B3I) and dual-frequency GPS (L1L2) have the highest ambiguity fixing rate. The ambiguity fixing rate of dual-frequency BDS-3 (B1C/B2a) and triple-frequency BDS-3 (B1C/B2a/B3I) can be higher than 90% within 100 km. In the case of positioning using only the BDS-3 system, the triple-frequency BDS-3 (B1C/B2a/B3I) is superior to both the dual-frequency BDS-3 (B1I/B3I) and dual-frequency BDS-3 (B1C/B2a) in terms of both positioning accuracy and ambiguity fixing rate. The BDS-2+BDS-3 (B1I/B3I) dual-frequency RTK, which has reached a level comparable to GPS, can provide global users with real-time centimeter-level differential positioning services. Full article

The use of carrier phase data is the main driver for high-precision Global Navigation Satellite Systems (GNSS) positioning solutions, such as Real-Time Kinematic (RTK). However, carrier phase observations are ambiguous by an unknown number of cycles, and their use in RTK relies on the process of mapping real-valued ambiguities to integer ones, so-called Integer Ambiguity Resolution (IAR). The main goal of IAR is to enhance the position solution by virtue of its correlation with the estimated integer ambiguities. With the deployment of new GNSS constellations and frequencies, a large number of observations is available. While this is generally positive, positioning in medium and long baselines is challenging due to the atmospheric residuals. In this context, the process of solving the complete set of ambiguities, so-called Full Ambiguity Resolution (FAR), is limiting and may lead to a decreased availability of precise positioning. Alternatively, Partial Ambiguity Resolution (PAR) relaxes the condition of estimating the complete vector of ambiguities and, instead, finds a subset of them to maximize the availability. This article reviews the state-of-the-art PAR schemes, addresses the analytical performance of a PAR estimator following a generalization of the Cramér–Rao Bound (CRB) for the RTK problem, and introduces Precision-Driven PAR (PD-PAR). The latter constitutes a new PAR scheme which employs the formal precision of the (potentially fixed) positioning solution as selection criteria for the subset of ambiguities to fix. Numerical simulations are used to showcase the performance of conventional FAR and FAR approaches, and the proposed PD-PAR against the generalized CRB associated with PAR problems. Real-data experimental analysis for a medium baseline complements the synthetic scenario. The results demonstrate that (i) the generalization for the RTK CRB constitutes a valid lower bound to assess the asymptotic behavior of PAR estimators, and (ii) the proposed PD-PAR technique outperforms existing FAR and PAR solutions as a non-recursive estimator for medium and long baselines. Full article

Although ionosphere-free (IF) combination is usually employed in long-range precise positioning, in order to employ the knowledge of the spatiotemporal ionospheric delays variations and avoid the difficulty in choosing the IF combinations in case of triple-frequency data processing, using uncombined observations with proper ionospheric constraints is more beneficial. Yet, determining the appropriate power spectral density (PSD) of ionospheric delays is one of the most important issues in the uncombined processing, as the empirical methods cannot consider the actual ionosphere activities. The ionospheric delays derived from actual dual-frequency phase observations contain not only the real-time ionospheric delays variations, but also the observation noise which could be much larger than ionospheric delays changes over a very short time interval, so that the statistics of the ionospheric delays cannot be retrieved properly. Fortunately, the ionospheric delays variations and the observation noise behave in different ways, i.e., can be represented by random-walk and white noise process, respectively, so that they can be separated statistically. In this paper, we proposed an approach to determine the PSD of ionospheric delays for each satellite in real-time by denoising the ionospheric delay observations. Based on the relationship between the PSD, observation noise and the ionospheric observations, several aspects impacting the PSD calculation are investigated numerically and the optimal values are suggested. The proposed approach with the suggested optimal parameters is applied to the processing of three long-range baselines of 103 km, 175 km and 200 km with triple-frequency BDS data in both static and kinematic mode. The improvement in the first ambiguity fixing time (FAFT), the positioning accuracy and the estimated ionospheric delays are analysed and compared with that using empirical PSD. The results show that the FAFT can be shortened by at least 8% compared with using a unique empirical PSD for all satellites although it is even fine-tuned according to the actual observations and improved by 34% compared with that using PSD derived from ionospheric delay observations without denoising. Finally, the positioning performance of BDS three-frequency observations shows that the averaged FAFT is 226 s and 270 s, and the positioning accuracies after ambiguity fixing are 1 cm, 1 cm and 3 cm in the East, North and Up directions for static and 3 cm, 3 cm and 6 cm for kinematic mode, respectively. Full article

To enable Global Navigation Satellite System (GNSS)-based precise relative positioning, real-time kinematic (RTK) systems have been widely used. However, an RTK system often suffers from a wrong integer ambiguity fix in the GNSS carrier phase measurements and may take a long initialization time over several minutes, particularly when the number of satellites in view is small. To facilitate a reliable GNSS carrier phase-based relative positioning with a small number of satellites in view, this paper introduces a novel GNSS carrier phase-based precise relative positioning method that uses a fixed baseline length as well as heading measurements in the beginning of the operation, which allows the fixing of integer ambiguities with rounding schemes in a short time. The integer rounding scheme developed in this paper is an iterative process that sequentially resolves integer ambiguities, and the sequential order of the integer ambiguity resolution is based on the required averaging epochs that vary for each satellite depending on the geometry between the baseline and the double difference line-of-sight vectors. The required averaging epochs with respect to various baseline lengths and heading measurement uncertainties were analyzed through simulations. Static and dynamic field tests with low cost GNSS receivers confirmed that the positioning accuracy of the proposed method was better than 10 cm and significantly outperformed a conventional RTK solution in a GNSS harsh environment. Full article

This paper presents a PREcise and Fast Method of Ambiguity Reinitialization/Resolution (PREFMAR) for L1 and L2 in GPS measurements. The method determines NL1 and NL2 ambiguities based on the ambiguity functions: Ψ(NL1)NL1NL2 and Ψ(NL2)NL2NL1. These ambiguity functions have been described in detail in this work. The developed method of ambiguity initialization and reinitialization in relative positioning can use Global Positioning System (GPS) measurements from only two satellites and one measurement epoch. To resolve NL1 and NL2 ambiguities, a variance-covariance (VC) matrix of the float solution is not needed. The size of the search area in the PREFMAR method depends on code and phase accuracy as well as on the GNSS signal frequencies. Therefore, the search area is specific for every double or triple Global Navigation Satellite Systems (GNSS) data frequency. However, this part of the research only presents the ambiguity search area for L1 and L2 of GPS measurements. Additionally, a numerical example has been analyzed in detail with the use of the PREFMAR method and a float solution (NL1, NL2). Finally, the elaborated algorithms were successfully tested on real L1 and L2 GPS measurements for instantaneous ambiguity reinitialization. The PREFMAR method allows instantaneous ambiguity reinitialization if all satellites lose contact with a GNSS antenna, for short and long baselines. Therefore, the PREFMAR has a great potential for precise real-time kinematic GNSS navigation. Full article

The Global Navigation Satellite Systems (GNSS) becomes the primary choice for device localization in outdoor situations. At the same time, many applications do not require precise absolute Earth coordinates, but instead, inferring the geometric configuration information of the constituent nodes in the system by relative positioning. The Real-Time Kinematic (RTK) technique shows its efficiency and accuracy in calculating the relative position. However, when the cycle slips occur, the RTK method may take a long time to obtain a fixed ambiguity value, and the positioning result will be a “float” solution with a low meter accuracy. The novel method presented in this paper is based on the Relative GNSS Tracking Algorithm (Regtrack). It calculates the changes in the relative baseline between two receivers without an ambiguity estimation. The dead reckoning method is used to give out the relative baseline solution while a parallel running Extended Kalman Filter (EKF) method reinitiates the relative baseline when too many validation failures happen. We conducted both static and kinematic tests to assess the performance of the new methodology. The experimental results show that the proposed strategy can give accurate millimeter-scale solutions of relative motion vectors in adjacent two epochs. The relative baseline solution can be sub-decimeter level with or without the base station is holding static. In the meantime, when the initial tracking point and base station coordinates are precisely obtained, the tracking result error can be only 40 cm away from the ground truth after a 25 min drive test in an urban environment. The efficiency test shows that the proposed method can be a real-time method, the time that calculates one epoch of measurement data is no more than 80 ms and is less than 10 ms for best results. The novel method can be used as a more robust and accurate ambiguity free tracking approach for outdoor applications. Full article

Tropospheric delay is a major error source that affects the initialization and re-initialization speed of the Global Navigation Satellite System’s (GNSS) medium-/long-range baseline in Network Real-Time Kinematic (NRTK) positioning. Fusing the meteorological data from the Numerical Weather Prediction (NWP) model to estimate the zenith tropospheric delay (ZTD) is one of the current research hotspots. However, research has shown that the ZTD derived from NWP models is still not accurate enough for high-precision GNSS positioning applications without the estimation of the residual tropospheric delay. To date, General Regression Neural Network (GRNN) has been applied in many fields. It has a high learning speed and simple structure, and can approximate any function with arbitrary precision. In this study, we developed a regional NWP tropospheric delay inversion method based on a GRNN model to improve the accuracy of the tropospheric delay derived from the NWP model. The accuracy of the tropospheric delays derived from reanalysis data of the European Center for Medium-Range Weather Forecasts (ECMWF) and the US National Centers for Environmental Prediction (NCEP) was assessed through comparisons with the results of the International GPS Service (IGS). The variation characteristics of the residual of the ZTD inverted by NWP data were analyzed considering the factors of temperature, humidity, latitude, and season. To evaluate the performance of this new method, the National Center Atmospheric Research (NCAR) troposphere data of 650 stations in Japan in 2005 were collected as a reference to compare the accuracy of the ZTD before and after using the new method. The experimental results showed that the GRNN model has obvious advantages in fitting the NWP ZTD residual. The mean residual and the root mean square deviation (RMSD) of the ZTD inverted using the method of this study were 9.5 mm and 12.7 mm, respectively, showing reductions of 20.8% and 19.1%, respectively, as compared to the standard NWP model. For long-range baseline (155 km and 207 km), the corrected NWP-constrained RTK showed a reduction of over 43% in the initialization time compared with the standard RTK, and showed a reduction of over 24% in the initialization time compared with the standard NWP-constrained RTK. Full article

Precise real-time kinematic (RTK) Global Navigation Satellite System (GNSS) positioning requires fixing integer ambiguities after a short initialization time. Originally, it was assumed that it was only possible at a relatively short distance from a reference station (<10 km), because otherwise the atmospheric effects prevent effective ambiguity fixing. Nowadays, through the use of VRS, MAC, or FKP corrections, the distances to the closest reference station have been increased to around 35 km. However, the baselines resolved in real time are not as far as in the case of static positioning. Further extension of the baseline requires the use of an ionosphere-weighted model with ionospheric delay corrections available in real time. This solution is now possible thanks to the Radio Technical Commission for Maritime (RTCM) stream of SSR corrections from, for example, Centre National d’Études Spatiales (CNES), the first analysis center to provide it in the context of the International GNSS Service. Then, ionospheric delays are treated as pseudo-observations that have a priori values from the CLK RTCM stream. Additionally, satellite orbit and clock errors are properly considered using space-state representation (SSR) real-time radial, along-track, and cross-track corrections. The following paper presents the initial results of such RTK positioning. Measurements were performed in various field conditions reflecting realistic scenarios that could have been experienced by actual RTK users. We have shown that the assumed methodology was suitable for single-epoch RTK positioning with up to 82 km baseline in solar minimum (30 March 2019) mid and high latitude (Olsztyn, Poland) conditions. We also confirmed that it is possible to obtain a rover position at the level of a few centimeters of precision. Finally, the possibility of using other newer experimental IGS RT Global Ionospheric Maps (GIMs), from Chinese Academy of Sciences (CAS) and Universitat Politècnica de Catalunya (UPC) among CNES, is discussed in terms of their recent performance in the ionospheric delay domain. Full article

It is widely known that in real-time kinematic (RTK) solution, the convergence and ambiguity-fixed speeds are critical requirements to achieve centimeter-level positioning, especially in medium-to-long baselines. Recently, the current status of the global navigation satellite systems (GNSS) can be improved by employing low earth orbit (LEO) satellites. In this study, an initial assessment is applied for LEO constellations augmented GNSS RTK positioning, where four designed LEO constellations with different satellite numbers, as well as the nominal GPS constellation, are simulated and adopted for analysis. In terms of aforementioned constellations solutions, the statistical results of a 68.7-km baseline show that when introducing 60, 96, 192, and 288 polar-orbiting LEO constellations, the RTK convergence time can be shortened from 4.94 to 2.73, 1.47, 0.92, and 0.73 min, respectively. In addition, the average time to first fix (TTFF) can be decreased from 7.28 to 3.33, 2.38, 1.22, and 0.87 min, respectively. Meanwhile, further improvements could be satisfied in several elements such as corresponding fixing ratio, number of visible satellites, position dilution of precision (PDOP) and baseline solution precision. Furthermore, the performance of the combined GPS/LEO RTK is evaluated over various-length baselines, based on convergence time and TTFF. The research findings show that the medium-to-long baseline schemes confirm that LEO satellites do helpfully obtain faster convergence and fixing, especially in the case of long baselines, using large LEO constellations, subsequently, the average TTFF for long baselines has a substantial shortened about 90%, in other words from 12 to 2 min approximately by combining with the larger LEO constellation of 192 or 288 satellites. It is interesting to denote that similar improvements can be observed from the convergence time. Full article
