Search Results (59)

Lightweight steel-framing (LSF) systems have become increasingly prominent in modern construction due to their structural efficiency, design flexibility, and sustainability. However, traditional facade materials such as stone are often cost-prohibitive, and brick veneers—despite their popularity—pose seismic performance concerns. This study introduces an innovative porcelain sheathing system for cold-formed steel (CFS) shear walls. Porcelain has no veins thus it offers integrated and reliable strength unlike granite. Four full-scale CFS shear walls incorporating screwed porcelain sheathing (SPS) were tested under combined cyclic lateral and constant gravity loading. The experimental program investigated key seismic characteristics, including lateral stiffness and strength, deformation capacity, failure modes, and energy dissipation, to calculate the system response modification factor (R). The test results showed that configurations with horizontal sheathing, double mid-studs, and three blocking rows improved performance, achieving up to 21.1 kN lateral resistance and 2.5% drift capacity. The average R-factor was 4.2, which exceeds the current design code values (AISI S213: R = 3; AS/NZS 4600: R = 2), suggesting the enhanced seismic resilience of the SPS-CFS system. This study also proposes design improvements to reduce the risk of brittle failure and enhance inelastic behavior. In addition, the results inform discussions on permissible building heights and contribute to the advancement of CFS design codes for seismic regions. Full article

The present investigation highlights the importance of evaluating the painting process on a composite material, namely the Kevlar validation process. Kevlar, a synthetic fabric, is well known for its remarkable strength and durability. Kevlar is used in the construction of spaceships and airplanes because it is lightweight and five times stronger than steel. This paper will present the methods for measuring paint layer thickness in accordance with EN ISO 2808:2019, confirming that organic coatings have fully cured, and coating thickness will be measured using magnetic currents. This study will also address the topic of determining liquid resistance. The protocols for manufacturing the Kevlar specimen are in accordance with ISO 2812-2:2018 using the water immersion method and structural testing. The investigation also demonstrates the progress of the framing test following immersion in Airbus PTP metal test tubes. Full article

The process of seismic retrofitting for inadequate RC frames is vital for enhancing structural integrity in areas susceptible to earthquakes. This research investigates a novel tube-in-tube (TnT) buckling restrained brace (BRB) system aimed at improving the seismic performance of these substandard RC frames. By targeting significant weaknesses inherent in older RC constructions, the TnT BRB introduces a lightweight, all-steel configuration that eliminates the need for traditional mortar or concrete infill materials. Experimental shake table testing on two one-third scaled RC frame models was conducted to compare the seismic performance of an unretrofitted control frame and a frame retrofitted with the TnT BRB system. Results indicate significant enhancements in lateral strength, ductility, and energy dissipation capacity in the retrofitted frame, demonstrating stable and symmetrical hysteresis loops and reduced stiffness degradation compared to conventional X-braced systems. Analytical modeling corroborated these experimental findings, confirming the TnT BRB’s superior capability in absorbing seismic energy and preventing premature structural failures. This investigation emphasizes both the practical and financial benefits of integrating the TnT BRB into seismic retrofitting strategies while recommending further research to optimize the system, specifically addressing issues related to local denting, frictional wear, and alignment to bolster its effectiveness in practical applications. Full article

The aerospace industry is actively seeking sustainable solutions within the aviation sector to mitigate greenhouse gas (GHG) emissions driven by increasing population demands. This study presents the first environmental life cycle assessment (LCA) of economy-class seating frames, comparing conventional alloy steel with lightweight alternative materials, including magnesium alloy, aluminum alloy, and titanium. Seat frames account for an aircraft’s total weight, making them a critical component for innovation toward more sustainable solutions. Using SolidWorks V3.1, economy-class seat frames were designed and evaluated through a cradle-to-grave assessment of a functional unit (FU) representing the interior of a single aircraft. The analysis was conducted using SimaPro V8.4.0 with the Ecoinvent V3.10 database. The total GHG emissions associated with seat frames composed of alloy steel, titanium, aluminum alloy, and magnesium alloy were 208 kt CO₂ equivalent (eq.), 120 kt CO₂ eq, 71.1 kt CO₂ eq, and 44.9 kt CO₂ eq per FU, respectively. This study identifies alloy steel and titanium to be the most sustainable seat frame materials relative to other considered materials for commercial aircrafts. Full article

As a critical fastener connecting steel rails, fish-tail bolts ensure the safety of railway transportation. To improve the efficiency of fish-tail bolt loosening detection, this paper proposes a computer vision-based method for detecting fish-tail bolt looseness under tilted perspectives. The method first identifies bolt positions and coordinates of corner points on rail clamp edges through object detection and key point detection. Then, considering diverse rail clamp dimensions and combining with bolt positions, it employs dual perspective transformations for image rectification. Finally, utilizing the Lightweight OpenPose network, angle recognition of key bolt edges is achieved through Gaussian ring-shaped smooth labels, with loosening determination made by comparing angular variations across temporal frames. In experimental validation, tests were first conducted on a public dial-reading dataset for pointer angle recognition, showing a minimum average error of only 0.8°, which verifies the algorithm’s feasibility. Subsequently, based on fish-tail bolt images captured under various tilted perspectives, we constructed a self-made dataset of bolt key edges and performed loosening detection experiments. For bolt images in boundary postures, after rotation preprocessing, the average detection error was reduced to 0.7°. When the loosening threshold was set to 2.1°, the detection accuracy reached 97%. Experimental results indicate that the proposed method effectively identifies fish bolt loosening, providing crucial technical reference for railway safety maintenance. Full article

Surface defects have a serious detrimental effect on the quality of steel. To address the problems of low efficiency and poor accuracy in the manual inspection process, intelligent detection technology based on machine learning has been gradually applied to the detection of steel surface defects. An improved YOLOv8 steel surface defect detection model called YOLOv8-MGVS is designed to address these challenges. The MLCA mechanism in the C2f module is applied to increase the feature extraction ability in the backbone network. The lightweight GSConv and VovGscsp cross-stage fusion modules are added to the neck network to reduce the loss of semantic information and achieve effective information fusion. The self-attention mechanism is exploited into the detection network to improve the detection ability of small targets. Defect detection experiments were carried out on the NEU-DET dataset. Compared with YOLOv8n from experimental results, the average accuracy, recall rate, and frames per second of the improved model were improved by 5.2%, 10.5%, and 6.4%, respectively, while the number of parameters and computational costs were reduced by 5.8% and 14.8%, respectively. Furthermore, the defect detection generalization experiments on the GC-10 dataset and SDD DET dataset confirmed that the YOLOv8-MGVS model has higher detection accuracy, better lightweight, and speed. Full article

Single-sided formwork supporting systems (SFSSs) play a crucial role in the urban construction of retaining walls using cast-in-place concrete. By supporting the formwork from one side, an SFSS can minimize its spatial footprint, enabling its closer placement to boundary lines without compromising structural integrity. However, existing SFSS designs struggle to achieve a balance between mechanical performance and lightweight construction. To address these limitations, an innovative instrumented SFSS was proposed. It is composed of a panel structure made of a panel, vertical braces, and cross braces and a supporting structure comprising an L-shaped frame, steel tubes, and anchor bolts. These components are conducive to modular manufacturing, lightweight installation, and convenient connections. To facilitate the optimal design of this instrumented SFSS, a physics-constrained generative adversarial network (PC-GAN) approach was proposed. This approach incorporates three objective functions: minimizing material usage, adhering to deformation criteria, and ensuring structural safety. An example application is presented to demonstrate the superiority of the instrumented SFSS and validate the proposed PC-GAN approach. The instrumented SFSS enables individual components to be easily and rapidly prefabricated, assembled, and disassembled, requiring only two workers for installation or removal without the need for additional hoisting equipment. The optimized instrumented SFSS, designed using the PC-GAN approach, achieves comparable deformation performance (from 2.49 mm to 2.48 mm in maxima) and slightly improved component stress levels (from 97 MPa to 115 MPa in maxima) while reducing the total weight by 20.85%, through optimizing panel thickness, the dimensions and spacings of vertical and lateral braces, and the spacings of steel tubes. This optimized design of the instrumented SFSS using PC-GAN shows better performance than the current scheme, combining significant weight reduction with enhanced mechanical efficiency. Full article

Glass Fiber-Reinforced Composite (GFRP) has found widespread use in engineering structures due to its lightweight construction, high strength, and design flexibility. However, pure GFRP beams exhibit weaknesses in terms of stiffness, stability, and local compressive strength, which compromise their bending properties. In addressing these limitations, this study introduces innovative square GFRP beams infused with gypsum-based composites (GBIGCs). Comprehensive experiments and theoretical analyses have been conducted to explore their manufacturing process and bending characteristics. Initially, four types of GBIGC—namely, hollow GFRP beams, pure gypsum, steel-reinforced gypsum, and fiber-mixed gypsum-infused beams—were designed and fabricated for comparative analysis. Material tests were conducted to assess the coagulation characteristics of gypsum and its mechanical performance influenced by polyvinyl acetate fibers (PVAs). Subsequently, eight GFRP square beams (length: 1.5 m, section size: 150 mm × 150 mm) infused with different gypsum-based composites underwent four-point bending tests to determine their ultimate bending capacity and deflection patterns. The findings revealed that a 0.12% dosage of protein retarder effectively extends the coagulation time of gypsum, making it suitable for specimen preparation, with initial and final setting times of 113 min and 135 min, respectively. The ultimate bending load of PVA-mixed gypsum-infused GFRP beams is 203.84% higher than that of hollow beams, followed by pure gypsum and steel-reinforced gypsum, with increased values of 136.97% and 186.91%, respectively. The ultimate load values from the theoretical and experimental results showed good agreement, with an error within 7.68%. These three types of GBIGCs with significantly enhanced flexural performance can be filled with different materials to meet specific load-bearing requirements for various scenarios. Their improved flexural strength and lightweight characteristics make GBIGCs well suited for applications such as repairing roof beams, light prefabricated frames, coastal and offshore buildings. Full article

Cellular materials such as aluminum and polyurethane foams are recognized for their effectiveness in energy absorption. They commonly serve as crushable cores in sacrificial cladding for blast mitigation purposes. This study delves into the effectiveness of autoclaved aerated concrete (AAC), a lightweight, porous material known for its energy-absorbing properties as a crushable core in sacrificial cladding. The experimental set-up features a rigid frame made of steel measuring 1000 × 1000 × 15 mm³ with a central square opening (300 × 300 mm²) holding a 2 mm thick aluminum plate representing the structure. The dynamic response of the aluminum plate is captured using two high-speed cameras arranged in a stereoscopic configuration. Three-dimensional digital image correlation is used to compute the transient deformation fields. Blast loading is achieved by detonating 20 g of C4 explosive set at 250 mm from the plate’s center. The study assesses the mineral foam’s absorption capacity by comparing out-of-plane displacement and mean permanent deformation of the aluminum plate with and without the protective solution. Six foam configurations (A to F) are tested experimentally and numerically, varying in the foam’s free space for expansion relative to its total volume. Results show positive protective effects, with configuration F reducing maximum deflection by at least 30% and configuration C by up to 70%. Foam configuration influences energy dissipation, with an optimal lateral surface-to-volume ratio (ζ) enhancing protective effects, although excessive ζ leads to non-uniform foam crushing. To address the influence of front skin deformability, a non-deformable front skin has been adopted. The latter demonstrates an increased effectiveness of the sacrificial cladding, particularly for ζ values above the optimal value obtained when using a deformable front skin. Notably, using a non-deformable front skin increases maximum deflection reduction and foam energy absorption by up to approximately 30%. Full article

Massive construction systems have always characterized traditional architecture and are currently the most prevalent, straightforward, and cost-effective in many Mediterranean countries. However, in recent years, the construction industry has gradually shifted towards using lightweight, dry construction techniques. This study aims to assess the effects on energy consumption, comfort levels, and environmental sustainability resulting from the adoption of five high-performance construction systems in a multi-family residential building: (i) reinforced concrete structure with low-transmittance thermal block infill; (ii) reinforced concrete structure with light-clay bricks and outer thermal insulation; (iii) steel frame; (iv) cross-laminated timber (CLT); (v) timber-steel hybrid structure. To achieve this goal, a multidisciplinary approach was employed, including the analysis of thermal parameters, the evaluation of indoor comfort through the adaptive model and Fanger’s PMV, and the quantification of environmental and economic impacts through life cycle assessment and life cycle cost applied in a long-term analysis (ranging from 30 to 100 years). The results highlight that heavyweight construction systems are the most effective in terms of comfort, cost, and long-term environmental impact (100 years), while lightweight construction systems generally have higher construction costs, provide lower short-term environmental impacts (30 years), and offer intermediate comfort depending on the thermal mass. Full article

The use of hybrid materials as a combination of fibre-reinforced plastic (FRP) and metal is of great interest in order to meet the increasing demands for sustainability, efficiency, and emission reduction based on the principle of lightweight design. These two components can therefore be joined using the intrinsic joining technique, which is formed by curing the matrix of the FRP component. In this study, for the hybrid joint, unidirectionally pre-impregnated semi-finished products (prepregs) with duromer matrix resin and micro-alloyed HC340LA steel were used. In order to conduct a detailed investigation, the damage mechanisms of intrinsically produced fibre metal laminates (FMLs), a new clamping device, and a novel pressing tool were designed and put into operation. The prepregs were prestressed by applying a preloading force using a specially designed prestressing frame. Hybrid specimens were then produced and subjected to nanoindentation and a shear tensile test. In particular, the effect of the residual stress state by varying the defined prestressing force on the damage mechanisms was studied. The results showed that no fracture patterns occurred in the interface of the specimens without preloading as a result of curing at 120 °C, whereas specimens with preloading failed at the boundary layer in the tensile range. Nevertheless, all specimens cured at 160 °C failed at the boundary layer in the tensile range. Furthermore, it was proven that the force and displacement of the preloaded specimens were promisingly higher than those of the unpreloaded specimens. Full article

Given the widespread use of lightweight composite wall panels in building structures, it is crucial to comprehend their seismic performance. This paper proposes a new lightweight concrete composite exterior wallboard (LCEW) featuring truss-type thermal barrier connectors (TBCs). Through the proposed static test, the damage morphology and hysteresis curve of the specimen are obtained; the hysteresis characteristics, skeleton curve, stiffness degradation, etc., are investigated; and the damage modes are summarized. The results demonstrate that the steel frame structure can effectively adapt to the use of LCEW, resulting in an approximately 20% increase in the frame structure’s bearing capacity. Second, the wall panels with a uniform transverse arrangement of TBCs could not perform as well, as they could only delay the crack opening. To give full play to its effect, it should be combined with the direction of the main tensile zone of the wall panels. Meanwhile, the sliding gusset connections effectively released the frame action at the system level. Full article

The efficient extraction, storage, and visualization of geometric and semantic information is a key foundation for the operation of the building information modeling (BIM) platform. This study aims to develop a lightweight BIM system and optimize the system’s performance according to the specific characteristics of steel structures. This study proposes several novel techniques for extracting and decoupling the geometric and semantic information of components from industry foundation class (IFC) files. A redundancy removal approach combining the principal content analysis (PCA) algorithm and the Hausdorff-based comparison algorithm is proposed to identify standardized steel components, and a lightweight visualization method on Web3D for redundant instances is also presented. A loading mechanism of the level of detail (LOD) model based on a mesh simplification algorithm is presented to optimize the display efficiency. The developed system is evaluated by three steel structural models. Using the redundancy removal approach, the number of instances is decreased by 96.46% in less than 30 s and over 30 FPS (frame per second) is kept when rendering. Using the LOD loading mechanism, 95.38% of vertices and 98.46% of patches are eliminated under 50 mm precision. The experiment results indicate that users can quickly load large BIM models and fetch sufficient information from the website. Full article

The airport waiting chair frames, as an important part of the overall seating, must be designed to provide comfort, safety, and aesthetic appeal. While the airport furniture industry has made progress in terms of sustainability, more efforts are needed to improve material selection, manufacturing processes, and supply chain management to support the development of sustainable furniture. This study proposes innovative ideas for the lightweight design of the frame, based on the limitations of the existing design. Firstly, structural innovations are discussed, non-traditional mesh panels and curved rounded designs are discussed, and non-introduced mesh panels and curved designs are used to enhance the strength and stability of airport waiting chairs and enhance their overall performance. Secondly, innovations in lightweighting have focused on adjusting the thickness dimensions to enhance comfort, material utilization, and sustainability as well as to achieve a lightweight and thin appearance effect. In order to determine the optimal ranges of values for the thickness of the seat surface support strip (P5), the thickness of the backrest strip (P3), and the thickness of the seat panel (P1), nine groups of chairs with different frame sizes were tested using an orthogonal experimental method. Based on the experimental results for size and topology optimization, NX2312 software modeling will be imported into ANSYS Workbench for static analysis. Using the optimized results, the use of 2.842 kg of steel was successfully reduced by 34.8% to ensure the seat’s stability. This provides a reference and idea for the digital and standardized innovative design of airport waiting chair furniture structure in the future. Through digital design and lightweight optimization, material savings and effective use of resources can be achieved, promoting the goal of sustainable development. Full article

The accurate evaluation of the thermal performance of building envelope components (e.g., facade walls) is crucial for the reliable evaluation of their energy efficiency. There are several methods available to quantify their thermal resistance, such as analytical formulations (e.g., ISO 6946 simplified calculation method), numerical simulations (e.g., using finite element method), experimental measurements under lab-controlled conditions or in situ. Regarding measurements, when using the heat flow meter (HFM) method, very often, the measured value is based on surface conditions (e.g., temperature and heat flux), achieving in this way the so-called surface-to-surface or conductive thermal resistance ($R_{cond}$). When the building components are made of homogeneous layers, their $R_{cond}$ values are constant, regardless of their internal and external surface boundary conditions. However, whenever this element is composed of inhomogeneous layers, such as in lightweight steel-framed (LSF) walls, their $R_{cond}$ values are no longer constant, depending on their thermal surface resistance. In the literature, such systematic research into how these $R_{cond}$ values vary is not available. In this study, the values of four LSF walls were computed, with different levels of thermal conductivity inhomogeneity, making use of four finite elements’ numerical simulation tools. Six external thermal surface resistances ($R_{\mathrm{s}\mathrm{e}}$) were modelled, ranging from 0.00 up to 0.20 m²·K/W. The average temperature of the partition LSF walls is 15 °C, while for the facade LSF walls it is 10 °C. It was found that the accuracy values of all evaluated numerical software are very high and similar, the $R_{cond}$ values being nearly constant for walls with homogeneous layers, as expected. However, the variation in the $R_{cond}$ value depends on the level of inhomogeneity in the LSF wall layers, increasing up to 8%, i.e., +0.123 m²·K/W, for the evaluated $R_{\mathrm{s}\mathrm{e}}$ values. Full article
