25 pages, 16811 KiB
Article
Force Element Analysis of Vortex-Induced Vibration Mechanism of Three Side-by-Side Cylinders at Low Reynolds Number
by Su-Xiang Guo, Meng-Tian Song, Jie-Chao Lei, Hai-Long Xu and Chien-Cheng Chang
J. Mar. Sci. Eng. 2025, 13(8), 1446; https://doi.org/10.3390/jmse13081446 - 29 Jul 2025
Viewed by 158
Abstract
This study employs a force element analysis to investigate vortex-induced vibrations (VIV) of three side-by-side circular cylinders at Reynolds number Re = 100, mass ratio m* = 10, spacing ratios S/D = 3–6, and reduced velocities Ur = 2–14. The [...] Read more.
This study employs a force element analysis to investigate vortex-induced vibrations (VIV) of three side-by-side circular cylinders at Reynolds number Re = 100, mass ratio m* = 10, spacing ratios S/D = 3–6, and reduced velocities Ur = 2–14. The lift and drag forces are decomposed into three physical components: volume vorticity force, surface vorticity force, and surface acceleration force. The present work systematically examines varying S/D and Ur effects on vibration amplitudes, frequencies, phase relationships, and transitions between distinct vortex-shedding patterns. By quantitative force decomposition, underlying physical mechanisms governing VIV in the triple-cylinder system are elucidated, including vortex dynamics, inter-cylinder interference, and flow structures. Results indicate that when S/D < 4, cylinders exhibit “multi-frequency” vibration responses. When S/D > 4, the “lock-in” region broadens, and the wake structure approaches the patterns of an isolated single cylinder; in addition, the trajectories of cylinders become more regularized. The forces acting on the central cylinder present characteristics of stochastic synchronization, significantly different from those observed in two-cylinder systems. The results can advance the understanding of complex interactions between hydrodynamic and structural dynamic forces under different geometric parameters that govern VIV response characteristics of marine structures. Full article
(This article belongs to the Section Ocean Engineering)
Show Figures

Figure 1

17 pages, 9414 KiB
Article
Influence of High-Speed Flow on Aerodynamic Lift of Pantograph at 400 km/h
by Zhao Xu, Hongwei Zhang, Wen Wang and Guobin Lin
Infrastructures 2025, 10(7), 188; https://doi.org/10.3390/infrastructures10070188 - 17 Jul 2025
Viewed by 268
Abstract
This study examines pantograph aerodynamic lift at 400 km/h, and uncovers the dynamic behaviors and mechanisms that influence pantograph–catenary performance. Using computational fluid dynamics (CFD) with a compressible fluid model and an SST k-ω turbulence model, aerodynamic characteristics were analyzed. Simulation data at [...] Read more.
This study examines pantograph aerodynamic lift at 400 km/h, and uncovers the dynamic behaviors and mechanisms that influence pantograph–catenary performance. Using computational fluid dynamics (CFD) with a compressible fluid model and an SST k-ω turbulence model, aerodynamic characteristics were analyzed. Simulation data at 300, 350, and 400 km/h showed lift fluctuation amplitude increases with speed, peaking near 50 N at 400 km/h. Power spectral density (PSD) energy, dominated by low frequencies, peaked around 10 dB/Hz in the low-frequency band, highlighting exacerbated lift instability. Component analysis revealed the smallest lift-to-drag ratio and most significant fluctuations at the head, primarily due to boundary-layer separation and vortex shedding from its non-streamlined design. Turbulence energy analysis identified the head and base as main turbulence sources; however, base vibrations are absorbed by the vehicle body, while the head causes pantograph–catenary vibrations due to direct contact. These findings confirm that aerodynamic instability at the head is the main cause of contact force fluctuations. Optimizing head design is necessary to suppress fluctuations, ensuring safe operation at 400 km/h and above. Results provide a theoretical foundation for aerodynamic optimization and improved dynamic performance of high-speed pantographs. Full article
(This article belongs to the Special Issue The Resilience of Railway Networks: Enhancing Safety and Robustness)
Show Figures

Figure 1

26 pages, 6535 KiB
Article
Aerodynamic Optimization of Morphing Airfoil by PCA and Optimization-Guided Data Augmentation
by Ao Guo, Jing Wang, Miao Zhang and Han Wang
Aerospace 2025, 12(7), 599; https://doi.org/10.3390/aerospace12070599 - 1 Jul 2025
Viewed by 325
Abstract
An aircraft that has been carefully optimized for a single flight condition will tend to perform poorly at other flight conditions. For aircraft such as long-haul airliners, this is not necessarily a problem, since the cruise condition so heavily dominates a typical mission. [...] Read more.
An aircraft that has been carefully optimized for a single flight condition will tend to perform poorly at other flight conditions. For aircraft such as long-haul airliners, this is not necessarily a problem, since the cruise condition so heavily dominates a typical mission. However, other aircraft, such as Unmanned Aerial Vehicles (UAVs), may be expected to perform well at a wide range of flight conditions. Morphing systems may be a solution to this problem, as they allow the aircraft to adapt its shape to produce optimum performance at each flight condition. This study proposes an aerodynamic optimization framework for morphing airfoils by integrating Principal Component Analysis (PCA) for geometric dimensionality reduction and deep learning (DL) for surrogate modeling, alongside an optimization-guided data augmentation strategy. By employing PCA, the geometric dimensionality of airfoil surfaces is reduced from 24 to 18 design variables while preserving 100% shape fidelity, thus establishing a compressed morphing parameterization space. A Multi-Island Genetic Algorithm (MIGA) efficiently explores the reduced design space, while iterative retraining of the surrogate model enhances prediction accuracy, particularly in high-performance regions. Additionally, Shapley Additive Explanation (SHAP) analysis reveals interpretable correlations between principal component modes and aerodynamic performances. Experimental results show that the optimized airfoil achieves a 54.66% increase in low-speed cruise lift-to-drag ratio and 10.90% higher climb lift compared to the baseline. Overall, the proposed framework not only enhances the adaptability of morphing airfoils across various low-speed flight conditions but also facilitates targeted surrogate refinement and efficient data acquisition in high-performance regions. Full article
(This article belongs to the Section Aeronautics)
Show Figures

Figure 1

20 pages, 7193 KiB
Article
Optimization of Trailing-Edge Unloading for Lambda-Wing UAV Using B-Spline Trailing-Edge Twist Method
by Chengen Yuan, Dongli Ma, Yuhong Jia and Liang Zhang
Drones 2025, 9(7), 462; https://doi.org/10.3390/drones9070462 - 28 Jun 2025
Viewed by 242
Abstract
As a commonly used configuration for advanced unmanned aerial vehicles (UAVs), the flying-wing configuration suffers from pitching moment trimming issues due to the lack of horizontal tail. The UAV either needs to unload lift at the trailing edge or needs to increase the [...] Read more.
As a commonly used configuration for advanced unmanned aerial vehicles (UAVs), the flying-wing configuration suffers from pitching moment trimming issues due to the lack of horizontal tail. The UAV either needs to unload lift at the trailing edge or needs to increase the wingtip twist angle at the cost of losing the lift-to-drag ratio. The commonly used methods for solving pitching moment trimming issues are compared and analyzed in this paper, and it is found that the method of trailing-edge twist has advantages under cruising lift coefficient. Furthermore, a trailing-edge twist deformation parameterized model that can deform multiple critical sections is designed with relevant grids. The multi-objective genetic algorithm is used to optimize the parameterized model and obtain the optimized results. Through comparative analysis, it is found that the optimized trailing-edge twist model has an advantage in distributing the pitching moment. By optimizing the distribution of aerodynamic forces and moments, cruise trim is achieved with only a 1.43% cost to the cruise lift-to-drag ratio compared to the initial model. Full article
(This article belongs to the Section Drone Design and Development)
Show Figures

Figure 1

15 pages, 3316 KiB
Article
Optimization of NACA 6412 Using Taguchi Method and Computational Fluid Dynamics Analysis
by Beytullah Erdoğan and Güneyhan Taşkaya
Sustainability 2025, 17(13), 5861; https://doi.org/10.3390/su17135861 - 25 Jun 2025
Viewed by 494
Abstract
In this study, the aerodynamic performance of the NACA 6412 wing, which is widely used in aerodynamic systems with its high-performance ratio feature, is optimized using the Taguchi Method to simultaneously evaluate the effects of multiple parameters and to reduce the number of [...] Read more.
In this study, the aerodynamic performance of the NACA 6412 wing, which is widely used in aerodynamic systems with its high-performance ratio feature, is optimized using the Taguchi Method to simultaneously evaluate the effects of multiple parameters and to reduce the number of Computational Fluid Dynamics (CFD) experiments to an optimum level. Within the framework of the Design of Experiments (DOE) methodology, the analyses were carried out in the Reynolds number range Re = 100,000–200,000 to determine the optimum design conditions by considering five main factors: maximum camber (bmax), maximum camber position (x), angle of attack (α), maximum thickness (tmax), and free-flow velocity (V). In this direction, CFD simulations based on the Taguchi L16 orthogonal array were performed and the data obtained were statistically evaluated using Analysis of Variance (ANOVA). The lift-to-drag ratio (CL/CD) obtained from the optimum experimental parameter combination (NACA5310) determined by the Taguchi method is compared with the basic NACA 6412 airfoil and 16 other configurations included in the analysis. The results show that the optimized airfoil provides an improvement in performance of approximately 17% compared to the NACA 6412 airfoil. Full article
(This article belongs to the Section Environmental Sustainability and Applications)
Show Figures

Figure 1

22 pages, 4482 KiB
Article
RCS Special Analysis Method for Non-Cooperative Aircraft Based on Inverse Reconfiguration Coupled with Aerodynamic Optimization
by Guoxu Feng, Chuan Wei, Jie Huang, Juyi Long and Yang Bai
Aerospace 2025, 12(7), 573; https://doi.org/10.3390/aerospace12070573 - 24 Jun 2025
Viewed by 362
Abstract
To address the challenge of evaluating a radar cross-section (RCS) for a non-cooperative aircraft with limited aerodynamic shape information, this paper presents a multi-source, data-driven inverse reconstruction method. This approach integrates data fusion techniques to facilitate an initial shape reconstruction, followed by an [...] Read more.
To address the challenge of evaluating a radar cross-section (RCS) for a non-cooperative aircraft with limited aerodynamic shape information, this paper presents a multi-source, data-driven inverse reconstruction method. This approach integrates data fusion techniques to facilitate an initial shape reconstruction, followed by an iterative optimization process that utilizes computational fluid dynamics (CFD) to enhance the shape, accounting for the aerodynamic performance. Additionally, an inverse deduction analysis is effectively employed to ascertain the characteristics of the power system, leading to the design of a double S-curved tail nozzle layout with stealth capabilities. An aerodynamic analysis demonstrates that at Mach 0.6, the lift-to-drag ratio peaks at 27.3 for the attack angle of 4°, after which it declines as the angle increases. At higher angles of attack, complex flow separation occurs and expands with the increasing angle. The electromagnetic simulation results indicate that under vertical polarization, the omnidirectional RCS reaches its peak as the incident angle is deflected downward by 10° and reduces with the growth of the angle, demonstrating angular robustness. Conversely, under horizontal polarization, the RCS is more sensitive to edge-induced rounding. The findings illustrate that this methodology enables accurate shape modeling for non-cooperative targets, thereby providing a fairly solid basis for stealth performance evaluation and the assessment of surprise effectiveness. Full article
(This article belongs to the Section Aeronautics)
Show Figures

Figure 1

21 pages, 38213 KiB
Article
Aerodynamic Analysis and Application of the Channel Wing Configuration Based on the Actuator Disk Model
by Mingzhi Cao, Kun Liu and Jingbo Wei
Drones 2025, 9(6), 443; https://doi.org/10.3390/drones9060443 - 18 Jun 2025
Viewed by 494
Abstract
The channel wing offers unique advantages in the short take-off and landing (STOL) application of Unmanned Aerial Vehicles (UAVs). To investigate its aerodynamic performance, an individual propeller was simulated using the actuator disk model. The computed values were in close agreement with the [...] Read more.
The channel wing offers unique advantages in the short take-off and landing (STOL) application of Unmanned Aerial Vehicles (UAVs). To investigate its aerodynamic performance, an individual propeller was simulated using the actuator disk model. The computed values were in close agreement with the experimental data. To conduct an initial assessment of the aerodynamic advantages offered by the channel wing, this study compared three configurations: a clean wing, a wing with a forward propeller, and a channel wing. The analysis revealed that the channel wing exhibits a better lift-to-drag ratio than the wing with a forward propeller. Further analysis investigated how propeller-to-wing clearance, axial placement relative to the wing’s leading edge, and changes in propeller diameter influence the channel wing aerodynamic characteristics. To validate the simulation results, a test platform was designed, and the calculated results were qualitatively verified. The findings indicated that reducing the propeller-to-wing clearance enhances the channel wing’s lift force and contributes to a higher lift-to-drag ratio. Altering the propeller’s installation position along the chordwise direction of the channel wing significantly influences its aerodynamic performance. Finally, the channel wing configuration was applied to a lifting-fuselage tandem-wing drone. A comparison with the conventional forward propeller configuration demonstrated that the drone with the channel wing achieves a higher lift-to-drag ratio, with a maximum value of 18.6. Compared with “forward propeller” configuration, the lift-to-drag ratio exhibits an improvement of 97.8% under the optimal configuration. Full article
(This article belongs to the Section Drone Design and Development)
Show Figures

Figure 1

12 pages, 2401 KiB
Proceeding Paper
Winglet Design for Class I Mini UAV—Aerodynamic and Performance Optimization
by Eleftherios Nikolaou, Eleftherios Karatzas, Spyridon Kilimtzidis and Vassilis Kostopoulos
Eng. Proc. 2025, 90(1), 111; https://doi.org/10.3390/engproc2025090111 - 7 May 2025
Viewed by 446
Abstract
The aerodynamic performance of an aircraft can be enhanced by incorporating wingtip devices, or winglets, which primarily reduce lift-induced drag created by wingtip vortices. This study outlines an optimization procedure for implementing winglets on a Class I fixed-wing mini-UAV to maximize aerodynamic efficiency [...] Read more.
The aerodynamic performance of an aircraft can be enhanced by incorporating wingtip devices, or winglets, which primarily reduce lift-induced drag created by wingtip vortices. This study outlines an optimization procedure for implementing winglets on a Class I fixed-wing mini-UAV to maximize aerodynamic efficiency and performance. After the Conceptual and Preliminary design phases, a baseline UAV was developed without winglets, adhering to specific layout constraints (e.g., wingspan, length). Various winglet designs—plate and blended types with differing heights, cant angles, and sweep angles—were then created and assessed. A Computational Fluid Dynamics (CFD) analysis was conducted to evaluate the flow around both the winglet-free UAV and configurations with each winglet design. The simulations employed Reynolds-Averaged Navier-Stokes (RANS) equations coupled with the Spalart-Allmaras turbulence model, targeting the optimal winglet configuration for enhanced aerodynamic characteristics during cruise. Charts of lift, drag, pitching moment coefficients, and lift-to-drag ratios are presented, alongside flow contours illustrating vortex characteristics for both baseline and optimized configurations. Additionally, dynamic stability analyses examined how winglets impact the UAV’s stability and control. The results demonstrated a significant improvement in aerodynamic coefficients (CLmax, L/Dmax, CLa, Cma), leading to an increase in both range and endurance. Full article
Show Figures

Figure 1

15 pages, 6173 KiB
Article
Aerodynamics of Flight Formations in Birds: A Quest for Energy Efficiency
by Fabien Beaumont, Sébastien Murer, Fabien Bogard and Guillaume Polidori
Birds 2025, 6(2), 15; https://doi.org/10.3390/birds6020015 - 24 Mar 2025
Viewed by 1978
Abstract
While the formation flight of birds offers numerous benefits, such as reduced predation risk, improved orientation, and enhanced communication, the aerodynamic interactions between birds are not fully understood due to their inherent complexity. This study explores the wake vortex dynamics of two flying [...] Read more.
While the formation flight of birds offers numerous benefits, such as reduced predation risk, improved orientation, and enhanced communication, the aerodynamic interactions between birds are not fully understood due to their inherent complexity. This study explores the wake vortex dynamics of two flying birds and their influence on aerodynamic forces, based on their relative positions in a group. Using a computational finite volume method, the 3D vortex patterns in the wake of Canada Geese (Branta canadensis) flying at 1000 m altitude and 13.9 m/s airspeed were modeled. The results reveal a complex, undulating vortex structure shaped by the wingbeat amplitude and frequency. The analysis shows that trailing birds positioning their wingtips within the upwash region of vortices that are generated by a leading bird significantly reduce drag and enhance lift, achieving up to a 32% improvement in aerodynamic efficiency, calculated as the lift-to-drag ratio. An optimal separation distance of approximately one wavelength (3.47 m) between birds has been identified, leading to a 7% reduction in both mean drag force and aerodynamic power requirements. These findings, extrapolated to larger bird groups, offer valuable insights into the organization and optimal positioning of birds flying in V-formations, advancing our understanding of collective flight dynamics. Full article
Show Figures

Figure 1

19 pages, 18271 KiB
Article
Active Flow Control Technology Based on Simple Droop Devices and a Co-Flow Jet for Lift Enhancement
by Jin Jiao, Cheng Chen, Bo Wang, Pei Ying, Qiong Wei and Shengyang Nie
Aerospace 2025, 12(3), 198; https://doi.org/10.3390/aerospace12030198 - 28 Feb 2025
Viewed by 895
Abstract
The missions of modern aircraft require multiple abilities, such as highly efficient taking-off and landing, fast arrival, and long-endurance hovering. It is difficult to achieve all technical objectives using traditional aircraft design technology. The active flow control technology using the concept of a [...] Read more.
The missions of modern aircraft require multiple abilities, such as highly efficient taking-off and landing, fast arrival, and long-endurance hovering. It is difficult to achieve all technical objectives using traditional aircraft design technology. The active flow control technology using the concept of a co-flow jet (CFJ) is a flow control method without a mass source that does not require air from the engine. It has strong flow control ability in low-speed flow, can greatly improve the stall angle of the aircraft, and can obtain large lift enhancement. At transonic conditions, it can lead to a larger lift–drag ratio with a small expense. CFJ technology has great application potential for aircraft due to its flexible control strategy and remarkable control effect. In this paper, the concept of a combination of CFJ and variable camber technology is proposed which realizes the change of airfoil camber to meet different task requirements with the movable droop head. By using the built-in ducted fan, air is blown and sucked in the jet channel so as to realize CFJ flow control. In a state of high-speed flight, complete geometric restoration is achieved by closing the channel and retracting the droop head. In this paper, the design and aerodynamic analysis of a CFJ device with variable camber based on a supercritical airfoil with small camber and a small leading-edge radius are carried out using the computational fluid dynamics (CFD) method. Comparative studies are conducted for different schemes on the taking off and landing performances, and discussions are had on core technical parameters such as power consumption. The results indicate that by utilizing the CFJ technology with more than 10 degrees of droop device, the maximum lift coefficient of a supercritical airfoil with a small camber and leading-edge radius, which is suitable for transonic flight, can be increased to a value larger than 4.0. Full article
Show Figures

Figure 1

27 pages, 12035 KiB
Article
Numerical Study on Hydrodynamic Performance and Vortex Dynamics of Multiple Cylinders Under Forced Vibration at Low Reynolds Number
by Fulong Shi, Chuanzhong Ou, Jianjian Xin, Wenjie Li, Qiu Jin, Yu Tian and Wen Zhang
J. Mar. Sci. Eng. 2025, 13(2), 214; https://doi.org/10.3390/jmse13020214 - 23 Jan 2025
Cited by 1 | Viewed by 943
Abstract
Flow around clustered cylinders is widely encountered in engineering applications such as wind energy systems, pipeline transport, and marine engineering. To investigate the hydrodynamic performance and vortex dynamics of multiple cylinders under forced vibration at low Reynolds numbers, with a focus on understanding [...] Read more.
Flow around clustered cylinders is widely encountered in engineering applications such as wind energy systems, pipeline transport, and marine engineering. To investigate the hydrodynamic performance and vortex dynamics of multiple cylinders under forced vibration at low Reynolds numbers, with a focus on understanding the interference characteristics in various configurations, this study is based on a self-developed radial basis function iso-surface ghost cell computing platform, which improves the implicit iso-surface interface representation method to track the moving boundaries of multiple cylinders, and employs a self-constructed CPU/GPU heterogeneous parallel acceleration technique for efficient numerical simulations. This study systematically investigates the interference characteristics of multiple cylinder configurations across various parameter domains, including spacing ratios, geometric arrangements, and oscillation modes. A quantitative analysis of key parameters, such as aerodynamic coefficients, dimensionless frequency characteristics, and vorticity field evolution, is performed. This study reveals that, for a dual-cylinder system, there exists a critical gap ratio between X/D = 2.5 and 3, which leads to an increase in the lift and drag coefficients of both cylinders, a reduction in the vortex shedding periodicity, and a disruption of the wake structure. For a three-cylinder system, the lift and drag coefficients of the two upstream cylinders decrease with increasing spacing. On the other hand, this increased spacing results in a rise in the drag of the downstream cylinder. In the case of a four-cylinder system, the drag coefficients of the cylinders located on either side of the flow direction are relatively high. A significant increase in the lift coefficient occurs when the spacing ratio is less than 2.0, while the drag coefficient of the downstream cylinder is minimized. The findings establish a comprehensive theoretical framework for the optimal configuration design and structural optimization of multicylinder systems, while also providing practical guidelines for engineering applications. Full article
(This article belongs to the Section Ocean Engineering)
Show Figures

Figure 1

18 pages, 6503 KiB
Article
Aerodynamic Design and Performance Analysis of a Large-Scale Composite Blade for Wind Turbines
by Semyoung Lim, Sungjin Ahn and Hyunbum Park
Appl. Sci. 2025, 15(2), 928; https://doi.org/10.3390/app15020928 - 18 Jan 2025
Cited by 1 | Viewed by 1505
Abstract
In this study, we determined an aerodynamic configuration to design structures applying composites for large-scale horizontal-axis wind turbine blades. A new aerodynamic and structural design method for large wind turbine blades is presented. The rated power of the wind turbine blade is 25 [...] Read more.
In this study, we determined an aerodynamic configuration to design structures applying composites for large-scale horizontal-axis wind turbine blades. A new aerodynamic and structural design method for large wind turbine blades is presented. The rated power of the wind turbine blade is 25 MW class. The tip speed ratio is 7. The diameter of the designed blade is 260 m. Therefore, thick airfoils were selected to design large-scale wind turbine blades considering structural stiffness and maximum lift coefficients. For the aerodynamic design method, it was designed with the optimal angle of attack having the maximum lift-to-drag ratio. The blade element theory and vortex theory were applied to aerodynamic design. For the aerodynamic design results, its validity was investigated via aerodynamic performance analysis. As a result of analyzing aerodynamic performance, it was confirmed that higher power was generated. At 12.5 m/s of rated wind speed, electrical power was 28.32 MW. The structural design considering the aerodynamic design results was carried out. The composite laminate theory was adopted. Structural safety was evaluated for the designed blades. Finally, the structural design results were analyzed as sufficiently valid. Full article
Show Figures

Figure 1

19 pages, 5848 KiB
Article
Aerodynamic Optimization Method for Propeller Airfoil Based on DBO-BP and NSWOA
by Changjing Guo, Zhiling Xu, Xiaoyan Yang and Hao Li
Aerospace 2024, 11(11), 931; https://doi.org/10.3390/aerospace11110931 - 11 Nov 2024
Cited by 3 | Viewed by 1643
Abstract
To address the issues of tedious optimization processes, insufficient fitting accuracy of surrogate models, and low optimization efficiency in drone propeller airfoil design, this paper proposes an aerodynamic optimization method for propeller airfoils based on DBO-BP (Dum Beetle Optimizer-Back-Propagation) and NSWOA (Non-Dominated Sorting [...] Read more.
To address the issues of tedious optimization processes, insufficient fitting accuracy of surrogate models, and low optimization efficiency in drone propeller airfoil design, this paper proposes an aerodynamic optimization method for propeller airfoils based on DBO-BP (Dum Beetle Optimizer-Back-Propagation) and NSWOA (Non-Dominated Sorting Whale Optimization Algorithm). The NACA4412 airfoil is selected as the research subject, optimizing the original airfoil at three angles of attack (2°, 5° and 10°). The CST (Class Function/Shape Function Transformation) airfoil parametrization method is used to parameterize the original airfoil, and Latin hypercube sampling is employed to perturb the original airfoil within a certain range to generate a sample space. CFD (Computational Fluid Dynamics) software (2024.1) is used to perform aerodynamic analysis on the airfoil shapes within the sample space to construct a sample dataset. Subsequently, the DBO algorithm optimizes the initial weights and thresholds of the BP neural network surrogate model to establish the DBO-BP neural network surrogate model. Finally, the NSWOA algorithm is utilized for multi-objective optimization, and CFD software verifies and analyzes the optimization results. The results show that at the angles of attack of 2°, 5° and 10°, the test accuracy of the lift coefficient is increased by 45.35%, 13.4% and 49.3%, and the test accuracy of the drag coefficient is increased by 12.5%, 39.1% and 13.7%. This significantly enhances the prediction accuracy of the BP neural network surrogate model for aerodynamic analysis results, making the optimization outcomes more reliable. The lift coefficient of the airfoil is increased by 0.04342, 0.01156 and 0.03603, the drag coefficient is reduced by 0.00018, 0.00038 and 0.00027, respectively, and the lift-to-drag ratio is improved by 2.95892, 2.96548 and 2.55199, enhancing the convenience of airfoil aerodynamic optimization and improving the aerodynamic performance of the original airfoil. Full article
(This article belongs to the Section Aeronautics)
Show Figures

Figure 1

25 pages, 19367 KiB
Article
Force Element Analysis in Vortex-Induced Vibrations of Side-by-Side Dual Cylinders: A Numerical Study
by Mengtian Song, Suxiang Guo, Hailong Xu, Weijian Tao, Jiechao Lei and Chien-Cheng Chang
J. Mar. Sci. Eng. 2024, 12(9), 1529; https://doi.org/10.3390/jmse12091529 - 3 Sep 2024
Cited by 4 | Viewed by 1230
Abstract
A numerical investigation was conducted in this study utilizing Force Element Analysis to explore the vortex-induced vibration (VIV) mechanism of side-by-side dual cylinders under the conditions of Reynolds number Re = 100, mass ratio m* = 10, and spacing ratios L/ [...] Read more.
A numerical investigation was conducted in this study utilizing Force Element Analysis to explore the vortex-induced vibration (VIV) mechanism of side-by-side dual cylinders under the conditions of Reynolds number Re = 100, mass ratio m* = 10, and spacing ratios L/D ranging from 3 to 6. The hydrodynamic forces by force element formulas were incorporated into the vibration response calculations of elastically supported rigid cylinders using a User-Defined Function (UDF) and the fourth-order Runge–Kutta method. A comprehensive analysis was performed to elucidate the combined effects of the spacing ratio L/D and reduced velocity Ur on the vibration responses, quantifying the hydrodynamic forces involved in the mutual interaction during VIV for side-by-side dual cylinders. The influence mechanisms of inter-cylinder interaction and their effects on the resultant hydrodynamic phenomena were discussed. It was revealed that for side-by-side arranged dual cylinders outside the “lock-in region”, the lift and drag forces are predominantly supplied by the volume vorticity forces in conjunction with surface vortices (including frictional) forces. However, within the “lock-in region”, the surface acceleration lift forces provide greater force contributions, and the volume vorticity lift force contributes significantly to negative values. Notably, alterations to the spacing ratio do not change the proportion of force element components. The amplitudes of the cylinders’ mutual interaction forces are identical in magnitude but opposite in phase. Additionally, the “slapping” phenomenon near the “lock-in region” leads to “bounded” trajectories of cylinders. Full article
(This article belongs to the Section Ocean Engineering)
Show Figures

Figure 1

29 pages, 11064 KiB
Article
Water Injection for Cloud Cavitation Suppression: Analysis of the Effects of Injection Parameters
by Wei Wang, Zhijian Li, Xiang Ji, Yun Wang and Xiaofang Wang
J. Mar. Sci. Eng. 2024, 12(8), 1277; https://doi.org/10.3390/jmse12081277 - 29 Jul 2024
Cited by 4 | Viewed by 1371
Abstract
This study investigates cloud cavitation suppression around a model-scale NACA66 hydrofoil using active water injection and explores the effect of multiple injection parameters. Numerical simulations and a mixed-level orthogonal test method are employed to systematically analyze the impact of jet angle αjet [...] Read more.
This study investigates cloud cavitation suppression around a model-scale NACA66 hydrofoil using active water injection and explores the effect of multiple injection parameters. Numerical simulations and a mixed-level orthogonal test method are employed to systematically analyze the impact of jet angle αjet, jet location Ljet, and jet velocity Ujet on cavitation suppression efficiency and hydrofoil energy performance. The study reveals that jet location has the greatest influence on cavitation suppression, while jet angle has the greatest influence on hydrofoil energy performance. The optimal parameter combination (Ljet = 0.30C, αjet = +60 degrees, Ujet = 3.25 m/s) effectively balances energy performance and cavitation suppression, reducing cavitation volume by 49.34% and improving lift–drag ratio by 8.55%. The study found that the jet’s introduction not only enhances vapor condensation and reduces the intensity of the vapor–liquid exchange process but also disrupts the internal structure of cavitation clouds and elevates pressure on the hydrofoil suction surface, thereby effectively suppressing cavitation. Further analysis shows that positive-going horizontal jet components enhance the lift–drag ratio, while negative-going components have a detrimental effect. Jet arrangements near the trailing edge negatively impact both cavitation suppression and energy performance. These findings provide a valuable reference for selecting optimal injection parameters to achieve a balance between cavitation suppression and energy performance in hydrodynamic systems. Full article
(This article belongs to the Special Issue Cavitation Control in Marine Engineering: Modelling and Experiment)
Show Figures

Figure 1
