To mitigate and control the seismic damage risk of high-speed railway bridges and enhance their post-earthquake reparability, a prefabricated multi-layer parallel-connected slit steel plate shear damper is proposed by utilizing the energy absorption capacity of flexure–shear coupled deformation in dampers. A theoretical model for calculating the stiffness and load-bearing capacity of the proposed damper was established and validated through detailed finite element simulations. The results demonstrate that the damper exhibits stable energy dissipation efficiency under cyclic loading, along with a gradual reduction in post-yield stiffness. Subsequently, a numerical model of the high-speed railway track–bridge-damper systems (HSRTBDS) was developed, incorporating the contribution of the proposed damper to quantify its control over the seismic response of the HSRTBDS. The findings indicate that the damper effectively reduces the seismic responses of the girders, rail fasteners, and track slabs, with a maximum deformation reduction exceeding 30% in the supporting structures. However, the deformation and damage of the bridge piers slightly increased, though they remained within acceptable safety limits. The damper showed limited influence on the damage to rails, fasteners, and shear key slots. Overall, the effectiveness of the proposed damper in controlling the structural response of HSRTBD has been demonstrated and validated, providing insights for the seismic design of high-speed railway bridges in high-intensity seismic zones. Full article

Bridges are generally affected by thermal loads which include the daily cycle, seasonal cycle and annual cycle. Thermal loads mode and thermal effects on bridges, especially for concrete girders, are quite essential but complicated. To investigate the temperature field and thermal stress in the thickness direction of a concrete box girder, the temperature field of a prestressed concrete continuous box girder bridge is monitored, and the temperature distribution in the thickness direction of the concrete box girder is analyzed. Finite element simulation, utilizing air elements specifically designed for concrete box girders, is employed to analyze the temperature field and thermal stress profiles along the thickness of the slab. The findings indicate a variation in temperature along the thickness of the concrete box girder slab. The most significant temperature differential, reaching up to 10.7 °C, is observed along the thickness of the top slab, followed by the bottom plate, with the web exhibiting relatively smaller differentials. Temperature in the full thickness range has a significant impact on the top plate, while the web plate and bottom plate are greatly influenced by temperature ranging from the outer surface to the center of the plate thickness. The temperature difference between the center of the plate thickness and the inner surface is approximately 0. The variation in temperature due to the variation in thickness direction is a temporal factor, wherein the outer layer of the roof is primarily compressed, while the inner layer is subjected to tension. The external surface of the web is mainly compressed. The stress exerted by the internal surface temperature is minimal. The internal and external surface effects of the floor are similar, and as time passes, tensile and compressive stresses appear. Full article

A lightweight design optimization algorithm is proposed to optimize the design parameters of stiffened double-layer steel girder bridges, the aim of which is to improve structural safety and reduce superstructure works. Taking a top-stiffened double-layer steel truss bridge as the reference project, a multiscale mixed-element model of the initial design parameters is established, and its computational accuracy is verified. Considering the structural configuration and loading characteristics of the bridge, the elastic modulus of steel, the deck plate thickness, the stiffening vertical bar height, and the relative distance between the double-layer main girders are selected as the design parameters for optimization. The mid-span vertical deflection, the axial forces in the stiffeners, the bottom plate of the deck, the compressed web tube at the pier top, and the quantity of superstructure works are chosen as the objective functions to be minimized. A lightweight calculation equation reflecting the relationship between the optimization parameters and the objective functions is established using the response surface method (RSM). Subsequently, an improved weighted particle swarm optimization (WPSO) model is employed to perform the multi-objective optimization of the design parameters for the bridge, and the results are compared with those obtained from the multi-objective genetic algorithm NSGA-II. The results show that the RSM accurately fits the numerical relationship between the optimization parameters and the objective response functions. When minimizing the quantity of superstructure works as the primary control objective and minimizing the mid-span vertical deflection and the axial forces in the compressed web tube at the pier top as secondary control objectives, the optimization results achieved by WPSO outperform those obtained by NSGA-II. The optimized results lead to reductions of 11.09%, 3.92%, 7.56%, 4.45%, and 8.38% in the respective objective function values of the structure. This method has important theoretical significance for the optimization of structural design parameters. Full article

This study aims to provide an effective method to study the behavior of a steel–concrete composite deck. First, the structural characteristics of the composite deck and the challenges arising in the computational analysis of the structure using general software are described. Then, an LPGE element that combines the plate element and the girder element into one element to conveniently construct the model with high computation efficiency is proposed. Based on the principle of multivariate field function, the constraint matrix for the plate and girder and the stiffness matrix for the LPGE are derived. The LPGE method is used to study the behavior of the composite deck through the computation of a steel truss arch bridge. The computation results are compared with the results obtained in ANSYS and the test results to verify the correctness and effectiveness of the LPGE method. The results of the paper offer references for the analysis of steel–concrete composite decks. Full article

The objective of this paper is to present the application of equivalent single layer (ESL) approach for the ultimate strength assessment of ship hull girder in the context of numerical finite element (FE) simulations. In the ESL approach, the stiffened panel is replaced with a single plate, which has the equivalent stiffness of the original panel. Removal of tertiary stiffening elements from the numerical model facilitates time-savings in pre-processing and FE analysis stage. The applicability of ESL approach is demonstrated with two case studies, one compartment model and full-sized double hull tanker model in intact and damaged conditions. The damage extents are determined based on the international association of classification societies from common structural rules (IACS-CSR) for oil tanker. Ship hull girder is exposed to distributed pressure with the sinusoidal shape that bends the hull girder. This pressure load is applied separately to bottom and side structures to obtain the vertical and horizontal bending moments of the hull girder, respectively. Ultimate strength predictions obtained from ESL approach are compared to full three-dimensional finite element method (3D FEM) and IACS incremental-iterative method. The comparison between different methods is provided in terms of longitudinal bending moment and cross sectional stress distribution. Overall, ESL approach yields good agreement compared to the 3D FEM results in predicting the ultimate strength of ship hull girder while providing up to 3 times computational efficiency and ease of modeling. Full article

This paper examines the effect of structural deformation on the unit slab-type ballastless track structure of high-speed railway. The principle of stationary potential energy was used to map the relation between girder vertical deformation and rail deformation considering the effect of subgrade boundary conditions and the nonlinear contact of interlayer. The theoretical model was verified by comparing with the finite element analysis and experimental results. The theoretical model was used to analyze the effects of several key parameters on the rail deformation, such as vertical deformation amplitude, elastic modulus of the mortar layer, and vertical stiffness of the fasteners. The results show that the track slabs suffered significant disengagement, which makes the deformation of the track structure at the position of the beam joint tend to be gentle when nonlinear contact between the mortar layer and the track slabs was considered. The track slabs disengagement mainly occurs near the beam joints (the side of the deformed beam). As the deflection amplitude of the girder increases, the track deformation, the fastener forces and the disengagement length of the track slabs are obviously nonlinear. When the vertical stiffness of the fastener and/or the elastic modulus of the mortar layer increase, the fastener force and the track plate disengagement length increase monotonically and nonlinearly, which will adversely affect the life and safety of the track structure. Full article
