Hard roofs in longwall mining may form large, suspended strata, which induce strong abutment stress redistribution. Therefore, a rational face support design is essential for ground control. This study develops an analytical numerical framework to evaluate support roof interaction under hard roof conditions. A segmented beam foundation model is established for the support roof system, and an equivalent variable foundation modulus is introduced to represent the reduced bearing capacity of yielded coal ahead of the working face. The analytical results are checked against a Particle Flow Code (PFC) and Fast Lagrangian Analysis of Continua (FLAC) coupled model, showing good agreement in the magnitude and location of the peak abutment stress. Parametric analyses are then conducted to examine the effects of support intensity and support distance on roof deflection, rotation, bending moment, shear force, strain energy density, and abutment stress. The results show that increasing support capacity reduces roof deformation and coal wall stress, while redistributing the same capacity over a longer support distance more effectively lowers roof strain energy concentration and inclined fracture development. However, the longer distance, lower density arrangement may transfer stress deeper into the coal seam and increase peak stress fluctuation during face advance. The proposed study provides a practical method for comparing face support schemes under low position hard roof conditions. Full article

To investigate the dynamic instability mechanism of surrounding rock in deep, rockburst-prone coal seams, a Split Hopkinson Pressure Bar (SHPB) system was utilized to carry out dynamic impact compression tests on Rock–Coal–Rock (RCR) composites featuring four different seam dip angles, namely 0°, 15°, 30°, and 45°. We systematically analyze incorporating high-speed imaging, the mechanical properties, energy evolution, and progressive failure characteristics of the composites under various strain rates. The results indicate that the dynamic compressive strength and elastic modulus of the composites exhibit a significant strain-rate hardening effect. With the increase in the dip angle of the coal seam, the compressive strength of the specimen decreases accordingly. Specifically, the range of 15–30° is identified as a critical transition zone where the failure mode shifts from matrix-dominated bearing to interfacial slip instability. At an impact pressure of 0.12 MPa, the compressive strength drops by 36.9% within this interval. Furthermore, the energy distribution is profoundly modulated by the geometric characteristics of the interface. As the dip angle increases, the degree of wave impedance mismatch at the coal–rock interface intensifies, leading to a sharp rise in the reflected energy ratio (up to 80.7%) and a pronounced attenuation of transmitted energy. Notably, the dissipation energy per unit volume increases with the dip angle, revealing that interfacial sliding and frictional work become the primary energy dissipation pathways under large-inclination conditions. High-speed camera monitoring confirms that the instability mechanism shifts from axial splitting/tension to an interfacial shear-slip mode as the dip angle increases. These findings provide a scientific reference for the stability evaluation of roadway surrounding rock and the prevention of dynamic disasters. Full article

Mining above confined aquifers fundamentally depends on understanding the evolution of floor permeability for water hazard control and water conservation mining. A mechanical model was developed to characterize the coordinated deformation of floor aquiclude strata, accounting for non-uniform distributions of stress and water pressure. The competing mechanisms whereby neutral plane strain and flexural deflection dominantly control permeability at different dip angles were elucidated, and the influence of dip angle on the stability of the water-resistant key strata was quantified. On this basis, a quantitative method for assessing the feasibility of in situ water conservation mining above confined aquifers was developed and its effectiveness was verified through field application. The main findings are as follows: The deflection of the floor aquiclude increases with water pressure, advance distance, and panel length. Larger coal seam dip angles correspond to smaller aquiclude deflection, with a strong dependence on the water pressure treatment method. The equivalent permeability of the floor increases with water pressure, panel length, and advance distance, and its variation is most pronounced with water pressure. As the dip angle increases, the equivalent permeability exhibits a trend of first rising and then decreasing; the transition between deflection-dominated and neutral plane strain-dominated control occurs at a dip angle of 35°. Lithological assemblage is found to govern the position of the neutral plane and the bending stiffness matrix, while a soft–hard interbedded floor is effective in suppressing deformation and mitigating the increase in the equivalent permeability. For inclined aquiclude key strata, the ranking of zones most prone to failure and water inrush is as follows: lower end > upper end > coal wall position > behind the goaf. A quadratic multi-parameter response model for the mining-induced equivalent permeability at the Fenyuan Coal Mine is established, yielding the sensitivity ranking under single factor and interaction effects as follows: water pressure > panel length > advance distance > water pressure (quadratic) > water pressure × panel length interaction. The higher the water pressure, the stronger the influence of dip angle on the equivalent permeability. Groundwater ion evolution is dominated by dissolution/leaching, with sulfate (SO₄²⁻) serving as a diagnostic ion for source identification. The stepwise criteria and grouting-reinforcement parameters for in situ protection of confined aquifers are proposed. Using water quality and quantity as evaluation metrics, Working Face 5-103 at the Fenyuan Coal Mine, which is a large-inclination-angle and high-pressure working face, has achieved in situ protection of the floor water. Full article

Xinjiang is a region of China that suffers severe energy resource loss and air pollution resulting from long-term coalfield fires in near-surface inclined coal seams. Beneath these fire areas, abandoned mined-out goaf is common. Accidents easily occur during the treatment of such fire areas owing to the instability of strata overlying the goaf. Here, we carried out non-destructive exploration of the goaf below a fire area using the airborne transient electromagnetic method, accurately identifying the locations and sizes of 21 goaf areas. We then established a stratigraphic model using the thermal-solid coupling function in UDEC software. Our simulations showed that under the combined action of high temperature generated by coal combustion and high pressure generated by fire-fighting machinery, the maximum displacement and vertical stress in strata overlying the goaf were 1.42 m and 36 MPa, respectively. Such large displacement and stress values inevitably lead to the destabilization of overlying strata via turning, sliding, and tipping, seriously threatening the safety of mining personnel and machinery. In the field, the rock layer above the goaf was first accurately blasted, and then fire extinguishing was carried out after the overlying rock had collapsed and compacted. Full article

Hard roof top-cutting and gob-side roadway retention is an effective way to improve the panel recovery ratio and reduce ground pressure. Based on the condition of Pingmei No.2 Mine, this paper establishes a stability mechanics model for the roof in a trapezoidal top-cutting roadway with inclined coal seam, in order to analyze the factors influencing the stability of the roof. This paper studies the deformation characteristics and control mechanism of the surrounding rock in a trapezoidal top-cutting roadway, and proposes targeted stability control technologies for the surrounding rock. The results showed that: (1) in a trapezoidal top-cutting roadway in the hard roof with inclined coal seam, the tensile stress of the uncut roof was inversely proportional to the coal seam dip angle, roof thickness and top-cutting height, while it was proportional to the top-cutting angle. According to actual engineering conditions, the top-cutting angle and height of the roof of the 21,100-panel were determined to be 10° and 5.0 m, respectively; (2) the special structure of the trapezoidal roadway led to asymmetric stress distribution in the surrounding rock, especially in the roof and rib. Using top-cutting, the pressure relief reduced the roof stress from 6.73 MPa to 2.04 MPa, the high stress zone moved to the inside of the solid coal, and the roof slid and deformed along the top line, showing characteristics of a “large deformation on the top side”; and (3) high-strength long anchor cables were used to reinforce the roof on the cut top side. Telescopic U-shaped steel and windshield cloth were used to block gangue and prevent wind leakage in the roadway. The on-site industrial test measured the maximum subsidence of the roof at 120 mm, and the maximum layer separation was 29 mm. Relative to non-top-cutting methods, the roof and sides showed significantly reduced deformation throughout the mining operations, which verified the reliability of the control technology. Full article

To investigate the evolution characteristics of overlying rock fractures, based on a geological prototype of a large-height comprehensive mining face in Shanxi, a three-dimensional large-scale physical similarity model was established. The experiments were carried out using microseismic monitoring and physical model cutting methods to study the activity and fissure evolution of the overburden rock. Model cutting revealed that, approximately 65 m from the bottom of the coal seam, delamination occurred, marking the top of the overburden rock fissure zone and the bottom of the bending and sinking zone. At 25 m from the coal seam bottom, the rock layer was highly fragmented, forming the collapse zone, which was 4.8 times the mining height. Between 25 and 65 m from the bottom, a fissure zone existed, which was 12.5 times the mining height, with abundant delamination fissures at the top of the fissure zone. Significant microseismic events were observed as the coal face advanced to 45 m, with notable increases in the concentrations and distribution ranges of these events in both the strike and height directions of the coal seam. The subsidence range of the overlying rock layer expanded from the top to the bottom, with the subsidence slope area extending gradually and the central compaction area remaining relatively flat. The overall shape presented an irregular ellipse, with peripheral uplift phenomena observed in the subsidence area. At 39 m from the coal seam bottom, the maximum subsidence of the rock stratum was 4.0 m, with subsidence amounts decreasing with increasing stratum height. Fissure density along the coal seam inclination and direction exhibited a double hump pattern, with fissure areas on both sides showing high densities and the central compaction areas having low densities. Coal seam mining caused stress redistribution in the surrounding rock layer, and the stress in front of the work was divided into the stress reduction zone, dynamic influence zone, mining influence zone, and unaffected zone. Coal rock porosity under high stress was less sensitive to stress changes, resulting in smaller changes in fissure permeability and fissures remaining mostly closed. Full article

This research aimed to examine shortcomings such as low efficiency and unstable coal release of 2313 large inclined-angle comprehensively released working faces in 230 mining areas of a mine in Shandong. Through the study of the actual working conditions of the large inclined-angle comprehensive release working face, it is concluded that the mining efficiency of the large inclined-angle coal seam is mainly related to the sequence of coal release, the step distance of the coal release, the distance between the end faces, the mining height, the working resistance of the hydraulic bracket and other factors. Taking ZF5600/16.5/26 hydraulic support as an example, simulation software was used to study the influencing factors of coal release efficiency, and the most efficient coal release method was found through the control variable method, so as to improve the mining recovery efficiency of the overall working face of the large inclined-angle coal seam, and after optimizing the working conditions of the hydraulic support, the top coal recovery efficiency was increased by 14.3% compared with the previous one after the actual statistics of the field situation. Full article

An intelligent, vision-guided welding robot is highly desired in machinery manufacturing, the ship industry, and vehicle engineering. The performance of the system greatly depends on the effective identification of weld seam features and the three-dimensional (3D) reconstruction of the weld seam position in a complex industrial environment. In this paper, a 3D visual sensing system with a structured laser projector and CCD camera is developed to obtain the geometry information of fillet weld seams in robot welding. By accounting for the inclination characteristics of the laser stripe in fillet welding, a Gaussian-weighted PCA-based laser center line extraction method is proposed. Smoother laser centerlines can be obtained at large, inclined angles. Furthermore, an improved chord-to-point distance accumulation (CPDA) method with polygon approximation is proposed to identify the feature corner location in center line images. The proposed method is validated numerically with simulated piece-wise linear laser stripes and experimentally with automated robot welding. By comparing this method with the grayscale gravity method, Hessian-matrix-based method, and conventional CPDA method, the proposed improved CPDA method with PCA center extraction is shown to have high accuracy and robustness in noisy welding environments. The proposed method meets the need for vision-aided automated welding robots by achieving greater than 95% accuracy in corner feature point identification in fillet welding. Full article

Coal is the main energy source in China. As flat and shallow coal seams are being depleted, adverse coal seams such as inclined and steeply inclined coal seams account for larger proportion of seams that are mined. For these coal seams, instability such as slip and tipping of mining equipment due to the large inclination is a significant challenge for the productive operation of intelligent or smart mines. Therefore, this paper serves to provide some insights into improving their stability. In this paper, research on the anti-tipping and anti-slip technology of shields is carried out on an intelligent working face with a large dip angle. A mechanical model of “support-surrounding rock” was established. Through the analysis of the influence of the self-weight of the support on its stability and through theoretical analysis and field practice, it was found that the critical tipping angle of the support in the free state is 27.8, the critical slip angle is 16, and the support is more prone to slip in the free state; the shields in the middle of the working face are the key area for stability control. Suitable technical measures are taken to ensure the stability of the supports, which provides the management and practical basis for safe and efficient mining in the intelligent working face with a large dip angle. Full article

In Sichuan Province, China, most coal seams that are mined are steeply inclined; their roadways’ surrounding rocks are asymmetric, with non-equilibrium deformations and unstable anchorage structures, thus making major safety hazards highly likely. Using field observations and a universal distinct element code (UDEC) numerical simulation method, this paper analyzed the time-dependent failure of the ventilation roadway of Working Face 1961 of the Zhaojiaba Mine, revealing the preconditions for such damage and a bidirectional deterioration mechanism for the deformation as well as stress of surrounding rocks. Moreover, this paper built an anchorage mechanical model for the thick layer of the roadway roof and proposed a cross-boundary anchor-grouting (CBAG) differential support technique. Calculations proved that the new support was particularly effective in restraining the expansion of tension cracks, thus preventing the slipping and dislocation deformations of rock masses on the curved roof side. The feedback of engineering applications showed that the maximum development depths of cracks in the arc roof and straight inclined roof of the roadway 150 m behind the working face are only 1.5 m and 1.10 m, decreasing by 61.3% and 47.6%, respectively, compared with the primary support. The proposed technology offers an overall thick-layer bearing structure for the surrounding rocks of roadways, effectively restraining the non-equilibrium large deformations of roadways in steeply inclined coal seams. Full article

Crossing borehole is an effective means to eliminate the outburst risk of coal and gas. The influence of borehole inclination angle, borehole diameter, and drainage time on the effective radius of gas drainage are studied by numerical simulation and engineering example verification. The study shows that the effective radius changes in a “U” shape with the increase in borehole inclination angle. When the angle α of the borehole and coal seam plane decreases, the effective radius increases. Furthermore, the coal mass around the borehole is broken by shear deformation, which is consistent with the results of the inner peephole. The effective radiuses are different in coal seam dip X and strike Y. When α is small, the effective radius in the X direction is generally wider. When α is large (α ≤ 90°), the effective radiuses in the X and Y directions are close. The effective radius is positively correlated with the borehole diameter and is more significantly influenced by increasing borehole diameter when α is small. The effective radius increases as a negative exponential function with time and eventually converges to a constant. The study has practical implications for the design of crossing borehole in the coal seam floor. Full article

Numerous historical buildings exist in Shanxi Province, a major coal producing area in China, so there exist many overlapping areas between ancient wooden buildings and coal mining. Coal mining in overlapping areas will lead to surface subsidence, which will have an impact on historical buildings. Based on the distribution of historical buildings and the distribution and mining of coal resources in Shanxi Province, this paper concludes that the overlapping areas of coal mining and ancient wooden buildings in Shanxi Province are mainly concentrated in Changzhi City, and the Lu’an mining area in Changzhi City is selected as the research object. In addition, using the gray correlation analysis method, the surface subsidence coefficient, which characterizes the intensity of mining subsidence, is used as the reference sequence. Seven factors selected from the geological conditions and mining conditions of the Lu’an mining area are used as the comparison sequence to calculate the gray correlation between each influencing factor and the surface subsidence coefficient, and to obtain that geological factors such as the nature of the overlying rock layer, bedrock thickness and dip angle of the coal seam, and mining factors such as mining height, average mining depth and working face size largely determine the surface subsidence coefficient. The surface subsidence in the overlap area could largely be influenced by geological factors such as the nature of the overlying rock layer, bedrock thickness and coal seam inclination, and mining factors such as mining height, average mining depth and working face size. Finally, we investigate the possible effects of surface subsidence on ancient wooden buildings in the overlapping area with the surface subsidence and formation mechanism and propose technical measures to reduce the effects of surface subsidence due to coal mining on historical buildings in the overlapping area. Full article

Trapezoidal roadways in large inclination coal seams show asymmetrical tectonic characteristics, while there is still a lack of theoretical results on stress, deformation, and efficient and effective supporting methods on high walls. In this paper, based on the geological characteristics of a large, inclined coal seam roadway, a mechanical model for stress–deformation analysis of trapezoidal section roadway was established. Complex analysis and a comfort map were employed to investigate the stress and deformation distribution on the roadway surface, and a novel yielding prop with high load capacity and constant working resistance was employed to support a high wall side based on analytical results. The results are as follows: (1) The deformation of the high wall is larger than that of the low wall, and the deformation of the roof is larger than that of the floor. The overall deformation of the surrounding rock shows that the rib closure is larger than the roof-to-floor closure. (2) The stress of the surrounding rock shows that both horizontal and vertical stresses are highest in the upper corner, indicating that the broken zone is most likely to occur at this location. (3) A new support employed with a high-yielding prop and a high-strength cable in a large, inclined angle roadway is proposed. On-site experiments were conducted in a large 5-1081 roadway of a coal mine in Shanxi, China. Under the influence of mining disturbance, the deformations at the top corner decreased by 40% compared with before. The test results show that the new support scheme can effectively control the development of roadway deformation and damage during the mining process. The new support also shows friendly environmental support and fast installation. Full article

Mining activities conducted above aquifers run the risk of groundwater outburst through fractured floor strata. However, the failure mechanism of the seam floor and the variability in its stability with varying dips remain unclear. Considering the influence of excavation-induced pressure, hydraulic pressure and strata dip, two kinds of analytical models were proposed in this study, which mainly included the hydraulic mechanical model and the key stratum model. These models were applied to comparatively investigate the failure characteristics and inrush risk of horizontal and inclined floors, and then confirmed by numerical simulation. The theoretical calculations reveal that the vertical failure ranges of horizontal and inclined floor strata exhibit approximate “inverted saddle” shapes along the inclination, and have the characteristics of symmetrical distribution and “lower-large/upper-small”, respectively, which is generally consistent with the simulated and measured observations. The theoretical maximum depths of damage within horizontal and inclined floor strata are roughly 12 m and 15 m, slightly lower than the result of numerical simulation. Compared with the remaining horizontal layer, the zone close to the lower boundary of the inclined key strata beneath the goaf incurs the most damage, which corresponds well to the distribution of vertical disturbance ranges. Therefore, the theoretical risk of groundwater outburst from the inclined floor after coal extraction is relatively higher than that from the horizontal floor. The mechanical models established in this study could elucidate the mechanism inducing floor failure and water inrush above a confined aquifer, and thus provide valuable insights for the risk assessment of water-related disasters in underground engineering. Full article

In view of the occurrence conditions of inclined coalbed, the deformation and failure characteristics of the main roof will affect the safe production of the working face. Therefore, the study of the deformation and failure characteristics of the main roof in the inclined coalbed has guiding significance for the control of surrounding rock. This paper takes the II1042 working face of Taoyuan Coal Mine as the research background, adopts the methods of theoretical analysis, numerical calculation, and field practice to analyze the evolutionary characteristics of the initial failure of the main roof of the working face under the background of the inclined coalbed, and explores the mechanical behavior characteristics of the working face roof during the mining of inclined coalbed. Based on the elastic thin plate theory, a mechanical model of the overlying rock roof of a large-angle coal seam is established, and the mechanical characteristics of the surrounding rock under the initial failure of the main roof under the unbalanced load are studied. The stress distribution characteristics of the lower surface are summarized, and the evolution law of the initial fracture of the main roof is summarized. According to the actual geological conditions of the II1042 working face of Taoyuan Coal Mine, the failure characteristics of the main roof and the initial breaking step distance are obtained by analysis, and the analysis results are verified by monitoring the mine pressure of each part of the target working face on site. The research results show that: ① Under the unbalanced load of the inclined coalbed, the deflection surface of the main roof of the coal seam is asymmetrical with respect to the arrangement direction of the working face, and the maximum deflection point is located at the upper middle position of the working face, namely (a/2, 1.836 b/π), and the main roof of the working face breaks for the first time when it advances to 35 m. ② With the advancement of the working face, the two long sides of the roof break first. With the deflection and deformation of the roof, the tensile stress in the middle of the main roof reaches the tensile strength of the rock and breaks, and then the two short sides of the roof break under the action of the breaking and turning of the rock, and the upper short side will break before the lower one. ③ According to the monitoring and analysis of the rock pressure at each part of the working face, it is judged that the initial pressure step distance is between 28.2 m and 34.6 m, which is consistent with the theoretical analysis results. Full article
