We have studied the effect of BITh molecules on the work functions of Ag and Au, with and without quartz lamp illumination. Silver and gold films coated with BITh molecules were fabricated and studied in reflection and Kelvin Probe experiments. The deposition of BITh films on Ag and Au reduced their work functions (in agreement with our recent study, wherein a similar reduction was caused by the deposition of a PMMA polymer). Illumination of the BITh-coated samples with a quartz lamp caused reductions in work functions by several tens of meV, which (almost) returned to their original values when the light was turned off. The characteristic time of this process (~15 min) was much shorter than that of photopolymerization (~180 min), suggesting that these two phenomena are nearly independent of each other. The effects of the Au substrates were qualitatively similar to those of the Ag substrates. Our findings pave the way to fundamental studies and applications of light–matter interactions. Full article

The integration of microstructured current collectors offers a potential pathway to enhance interface properties in solid-state battery architectures. In this work, we investigate the influence of surface morphology on the electrochemical performance of Zn/Na_2.99Ba_0.005OCl/Cu electrodeless pouch cells by fabricating copper thin films on microstructured parylene-C substrates using a combination of colloidal lithography and reactive ion etching. O₂ plasma etching times ranging from 0 to 15 min were used to tune the surface topography, resulting in a systematic increase in root-mean-square roughness and a surface area enhancement of up to ~30% for the longest etching duration, measured via AFM. Kelvin probe force microscopy-analyzed surface potential showed maximum differences of 270 mV between non-etched and 12-minute-etched Cu collectors. The results revealed that the chemical potential is the property that relates the surface of the Cu current collector/electrode with the cell’s ionic transport performance, including the bulk ionic conductivity, while four-point sheet resistance measurements confirmed that the copper layers’ resistivity maintained values close to those of bulk copper (1.96–4.5 µΩ.cm), which are in agreement with electronic mobilities (−6 and −18 cm²V⁻¹s⁻¹). Conversely, the charge carrier concentrations (−1.6 to −2.6 × 10²³ cm⁻³) are indirectly correlated with the performance of the cell, with the samples with lower CCC_bulk (fewer free electrons) performing better and showing higher maximum discharge currents, interfacial capacitance, and first-cycle discharge plateau voltage and capacity. The data were further consolidated with Scanning Electron Microscopy and X-ray Photoelectron Spectroscopy analyses. These results highlight that the correlation between the surface morphology and the cell is not straightforward, with the microstructured current collectors’ surface chemical potential and the charge carriers’ concentration being determinant in the performance of all-solid-state electrodeless sodium battery systems. Full article

The blocking layer is crucial for inhibiting recombination processes in photovoltaics that utilize oxide semiconductors, such as dye-sensitized solar cells (DSSCs), quantum-dot-sensitized solar cells (QDSSCs), and perovskite solar cells. However, its effectiveness strongly depends on the chosen deposition method. This study systematically evaluates the most suitable approach for obtaining a uniform, pinhole-free titanium dioxide (TiO₂) blocking layer by using three deposition methods: radio-frequency sputtering, spin-coating, and chemical bath deposition. The electrochemical, optical, and morphological properties of blocking layers were characterized using cyclic voltammetry (CV), electrochemical impedance spectroscopy (EIS), UV-VIS spectroscopy, scanning electron microscopy (SEM), atomic force microscopy (AFM), and Kelvin probe force microscopy (KPFM). KPFM analysis, together with CV and EIS, revealed that the lower R_ct values and higher CV currents observed in spin-coated (SC_11-33) and vertically deposited CBD films (CB_5, CB_6) resulted from incomplete FTO coverage. In contrast, sputtered (SP_21-24) and horizontally deposited CBD films (CB_1, CB_2) demonstrated significantly higher R_ct values and improved surface coverage. Full DSSCs fabricated with SP_23, SC_33, and CB_2 confirmed the correlation between interfacial properties and photovoltaic performance. This combined approach offers a fast, material-efficient, and environmentally conscious screening method for optimizing blocking layers in solar cell technologies. Full article

Thin TiO₂–SnO₂ nanocomposite films with high gas sensitivity to NO₂ were synthesized by oxidative pyrolysis and comprehensively studied. The composite structure and quantitative composition of the obtained film nanomaterials have been confirmed by X-ray photoelectron spectroscopy, high-resolution transmission electron microscopy, and energy dispersive X-ray spectroscopy, which causes the presence of n-n heterojunctions and provides improved gas-sensitive properties. The sensor based on the 3TiO₂–97SnO₂ film has the maximum responses, which is explained by the existence of a strong surface electric field formed by large surface potentials in the region of TiO₂–SnO₂ heterojunctions detected by the Kelvin probe force microscopy method. Exposure to low-intensity radiation (no higher than 0.2 mW/cm², radiation wavelength—400 nm) leads to a 30% increase in the sensor response relative to 7.7 ppm NO₂ at an operating temperature of 200 °C and a humidity of 60% RH. At room temperature (20 °C), under humidity conditions, the response is 1.8 when exposed to 0.2 ppm NO₂ and 85 when exposed to 7.7 ppm. The lower sensitivity limit is 0.2 ppm NO₂. The temporal stability of the proposed sensors has been experimentally confirmed. Full article

The removal of surface residues from single-layer graphene (SLG), including poly(methyl methacrylate) (PMMA) polymers and Cl⁻ ions, during the transfer process remains a significant challenge with regard to preserving the intrinsic properties of SLG, with the process often leading to unintended doping and reduced electronic performance capabilities. This study presents a rapid and efficient surface treatment method that relies on an aqueous sodium nitrite (NaNO₂) solution to remove such contaminants effectively. The NaNO₂ solution rinse leverages reactive nitric oxide (NO) species to neutralize ionic contaminants (e.g., Cl⁻) and partially oxidize polymer residues in less than 10 min, thereby facilitating a more thorough final cleaning while preserving the intrinsic properties of graphene. Characterization techniques, including atomic force microscopy (AFM), Kelvin probe force microscopy (KPFM), and X-ray photoelectron spectroscopy (XPS), demonstrated substantial reductions in the levels of surface residues. The treatment restored the work function of the SLG to approximately 4.79 eV, close to that of pristine graphene (~4.5–4.8 eV), compared to the value of nearly 5.09 eV for conventional SLG samples treated with deionized (DI) water. Raman spectroscopy confirmed the reduced doping effects and improved structural integrity of the rinsed SLG. This effective rinsing process enhances the reproducibility and performance of SLG, enabling its integration into advanced electronic devices such as organic light-emitting diodes (OLEDs), photovoltaic (PV) cells, and transistors. Furthermore, the technique is broadly applicable to other two-dimensional (2D) materials, paving the way for next-generation (opto)electronic technologies. Full article

In this study, Fe₆₀Co_10−xNi₁₅Cr₁₅Si_x (x = 0, 4, and 8) powders were successfully prepared using the aerosol method and employed to produce high-entropy coatings on Q235 steel via laser cladding. The microstructure and phase composition of the coatings were analyzed using scanning electron microscopy, energy-dispersive X-ray spectroscopy, and X-ray diffraction. Corrosion resistance and potential were evaluated through electrochemical analysis and Kelvin probe force microscopy. The results show that the Fe₆₀Co_10−xNi₁₅Cr₁₅Si_x coatings exhibit excellent metallurgical bonding with no visible porosity or cracks. The coating primarily consists of an FCC structure; however, as the Si content increases, the structure transitions to a mixed FCC + BCC phase. The addition of Si also refines the grain size in the alloy system. Electrochemical analysis reveals that the Si0 and Si4 coatings exhibit similar corrosion behavior, while the Si8 coating shows a significant drop in corrosion potential, reducing its corrosion resistance. As the Si content increases, grain refinement leads to more grain boundaries, but the corrosion resistance decreases due to the lower corrosion performance of Si compared to Co. Considering both cost and corrosion resistance, the Si4 coating offers a balance of low cost and excellent corrosion resistance. Full article

This study presents the fabrication possibilities of ultra-high-temperature ceramics of ZrB₂-30 vol.%SiC and (ZrB₂-HfB₂)-30 vol.% SiC composition using the reaction spark plasma sintering of composite powders ZrB₂(HfB₂)-(SiO₂-C) under two-stage heating conditions. The phase composition and microstructure of the obtained ceramic materials have been subjected to detailed analysis, their electrical conductivity has been evaluated using the four-contact method, and the electron work function has been determined using Kelvin probe force microscopy. The thermal analysis in the air, as well as the calcination of the samples at temperatures of 800, 1000, and 1200 °C in the air, demonstrated a comparable behavior of the materials in general. However, based on the XRD data and mapping of the distribution of elements on the oxidized surface (EDX), a slightly higher oxidation resistance of the ceramics (ZrB₂-HfB₂)-30 vol.% SiC was observed. The I-V curves of the sample surfaces recorded with atomic force microscopy demonstrated that following oxidation in the air at 1200 °C, the surfaces of the materials exhibited a marked reduction in current conductivity due to the formation of a dielectric layer. However, data obtained from Kelvin probe force microscopy indicated that (ZrB₂-HfB₂)-30 vol.% SiC ceramics also demonstrated enhanced resistance to oxidation. Full article

The ternary blending strategy is a fundamental approach that is widely recognized in the field of organic optoelectronics. In our investigation, leveraging the inherent advantages of the ternary component blending methodology, we introduced an innovative design for organic photodetectors (OPDs) aimed at reducing the dark current density (J_d) under reverse bias. This pioneering effort involved combining two distinct conjugated molecules (IT-4F and IEICO-4F) with a conjugated polymer (PM7), resulting in a composite material characterized by a well-defined vertical phase separation. To thoroughly explore device performance variations, we utilized a comprehensive array of analytical techniques, including atomic force microscopy (AFM) cross-section methodologies and Kelvin probe force microscopy (KPFM). Through the optimization of the blend ratio (PM7:IT-4F: IEICO-4F at 1:0.8:0.2), we achieved significant advancements. The resulting OPD demonstrated an exceptional reduction in JD, reaching a remarkably low value of 4.95 × 10⁻¹⁰ A cm⁻², coupled with an ultra-high detectivity of 4.95 × 10¹³ Jones and an outstanding linear dynamic range exceeding 100 dB at 780 nm under a bias of −1V. Furthermore, the attained cutoff frequency reached an impressive 220 kHz, highlighting substantial improvements in device performance metrics. Of particular significance is the successful translation of this technological breakthrough into real-world applications, such as in heart rate sensing, underscoring its tangible utility and expanding its potential across various fields. This demonstrates its practical relevance and underscores its versatility in diverse settings. Full article

The crystal structure has a great influence on the dielectric and piezoelectric performance of poly(vinylidene fluoride) (PVDF). In this work, we prepared PVDF films with two typical crystalline phases (α and β). In situ Kelvin probe force microscopy (KPFM) and Piezoelectric force microscopy (PFM) were employed to investigate the responses of different PVDF crystalline phases to charge mobility, polarization, and piezoelectric properties. We used a homemade Kelvin probe force microscope (KPFM) to inject charges into the two crystalline phases to investigate the differences in the response of different crystalline phases of PVDF to electrical excitation on a microscopic scale. It was found that the α-phase has a lower charge injection barrier and is more susceptible to charge injection and that the α-phase is accompanied by a faster charge dissipation rate, which makes it easier to accumulate charge at the interface between the α-phase and β-phase PVDF. Moreover, the PFM polarization manipulation showed no change in the amplitude and phase diagram of the α-phase under ±10 V bias. In contrast, the β-phase showed a clear polarization reversal phenomenon and a significant increase in piezoelectric amplitude, which is consistent with its polar intrinsic properties. This study provides valuable insights into the multiphase contributions and a reference for designing advanced PVDF dielectrics. Full article

A gallium nitride (GaN) semiconductor is one of the most promising materials integrated into biomedical devices to play the roles of connecting, monitoring, and manipulating the activity of biological components, due to its excellent photoelectric properties, chemical stability, and biocompatibility. In this work, it was found that the photogenerated free charge carriers of the GaN substrate, as an exogenous stimulus, served to promote neural stem cells (NSCs) to differentiate into neurons. This was observed through the systematic investigation of the effect of the persistent photoconductivity (PPC) of GaN on the differentiation of primary NSCs from the embryonic rat cerebral cortex. NSCs were directly cultured on the GaN surface with and without ultraviolet (UV) irradiation, with a control sample consisting of tissue culture polystyrene (TCPS) in the presence of fetal bovine serum (FBS) medium. Through optical microscopy, the morphology showed a greater number of neurons with the branching structures of axons and dendrites on GaN with UV irradiation. The immunocytochemical results demonstrated that GaN with UV irradiation could promote the NSCs to differentiate into neurons. Western blot analysis showed that GaN with UV irradiation significantly upregulated the expression of two neuron-related markers, βIII-tubulin (Tuj-1) and microtubule-associated protein 2 (MAP-2), suggesting that neurite formation and the proliferation of NSCs during differentiation were enhanced by GaN with UV irradiation. Finally, the results of the Kelvin probe force microscope (KPFM) experiments showed that the NSCs cultured on GaN with UV irradiation displayed about 50 mV higher potential than those cultured on GaN without irradiation. The increase in cell membrane potential may have been due to the larger number of photogenerated free charges on the GaN surface with UV irradiation. These results could benefit topical research and the application of GaN as a biomedical material integrated into neural interface systems or other bioelectronic devices. Full article

The demand for more efficient and sustainable electrical systems has driven research in the quest for innovative materials that enhance the properties of electrical conductors. This study investigated the influence of copper (Cu) coating and multi-walled carbon nanotubes (MWCNTs) on aluminum metal substrate through the pulsed electrodeposition technique. Parameters such as the concentration of chemical elements, current, voltage, temperature, time, and electrode spacing were optimized in search of improving the nanocomposite coating. The metallic substrate underwent anodization as surface preparation for coating. Characterization techniques employed included Field Emission Gun—Scanning Electron Microscopy (FEG-SEM) for analyzing coating morphology, Energy-Dispersive X-Ray Spectroscopy (EDS), Raman spectroscopy, and Kelvin probe for obtaining surface electrical conductivity values. Homogeneous dispersion of the Cu-MWCNTs film coating was achieved across the entire surface of the aluminum plate, creating a complex morphology. The doping effect was highlighted by changes in the vibrational characteristics of the nanocomposite, which affected the Raman spectrum dispersion bands. An increase in surface electrical conductivity by ≈52.33% compared to the control sample was obtained. Therefore, these results indicate that the improvement in the material’s electrical properties is intrinsically related to the complex morphology achieved with the adopted Cu-MWCNT nanocomposite coating process. Full article

The optical characteristics and electrical behavior of zinc oxide nanorods (ZnO-NRs) and silver nanoparticles (Ag-NPs) were investigated using advanced scanning probe microscopy techniques. The study revealed that the ZnO nanorods had a length of about 350 nm, while the Ag nanoparticles were spherical with heights ranging from 5 to 14 nm. Measurements with Kelvin probe force microscopy (KPFM) showed that the work functions of ZnO nanorods were approximately 4.55 eV, higher than that of bulk ZnO, and the work function of Ag nanoparticles ranged from 4.54 to 4.56 eV. The electrical characterization of ZnO nanorods, silver nanoparticles, and their hybrid was also conducted using conductive atomic force microscopy (C-AFM) to determine the local current-voltage (I-V) characteristics, which revealed a characteristic similar to that of a Schottky diode. The current-voltage characteristic curves of ZnO nanorods and Ag nanoparticles both showed an increase in current at around 1 V, and the hybrid ZnONRs/AgNP exhibited an increase in turn-on voltage at around 2.5 volts. This suggested that the presence of Ag nanoparticles enhanced the electrical properties of ZnO nanorods, improving the charge carrier mobility and conduction mechanisms through a Schottky junction. The investigation also explored the optical properties of ZnO-NRs, AgNPs, and their hybrid, revealing absorption bands at 3.11 eV and 3.18 eV for ZnO-NRs and AgNPs, respectively. The hybrid material showed absorption at 3.13 eV, indicating enhanced absorption, and the presence of AgNP affected the optical properties of ZnO-NR, resulting in increased photoluminescence intensity and slightly changes in peak positions. Full article

The development of efficient and environmentally friendly photocatalysts is crucial for addressing global energy and environmental challenges. Perylene diimide, an organic supramolecular material, holds great potential for applications in mineralized phenol. In this study, through the integration of different mass ratios of unmodified perylenimide (PDI-NH) into the self-assembly of amino acid-substituted perylenimide (PDI-COOH), a novel supramolecular organic heterojunction (PDICOOH/PDINH) was fabricated. The ensuing investigation focuses on its visible-light mineralized phenol properties. The results show that the optimal performance is observed with a composite mass fraction of 10%, leading to complete mineralization of 5 mg/L phenol within 5 h. The reaction exhibits one-stage kinetics with rate constants 13.80 and 1.30 times higher than those of PDI-NH and PDI-COOH, respectively. SEM and TEM reveal a heterogeneous interface between PDI-NH and PDI-COOH. Photoelectrochemical and Kelvin probe characterization confirm the generation of a built-in electric field at the interface, which is 1.73 times stronger than that of PDI-COOH. The introduction of PDI-NH promotes π-π stacking of PDI-COOH, while the built-in electric field facilitates efficient charge transfer at the interface, thereby enhancing phenol decomposition. The finding demonstrates that supramolecular heterojunctions have great potential as highly effective photocatalysts for environmental remediation applications. Full article

An increase in the number of small electronics is anticipated, requiring the preparation of an adequate powering method. A triboelectric nanogenerator, capable of scavenging ambient mechanical energy, is proposed as an efficient means to reduce power consumption for self-sustainable sensors, although its electrical output needs enhancement to broaden its technological applicability. In this work, a magnetic composite comprising iron oxide and polyaniline was synthesized to augment triboelectricity through the modulation of magnetic field intensity using physical chemistry. The crystallinity of the composite, chemical bonding, and structure of the surface are analyzed. The surface potential of the composite, embedded into polydimethylsiloxane, is quantitatively evaluated by using Kelvin probe force microscopy. By amalgamating magnetic flux density and triboelectric outputs, the optimization of the triboelectric layer is achieved, yielding output values of 93.86 V, 6.9 µA, and 127.5 µW. Following a reduction in surface adhesion after the powder coating process, a wind-based triboelectric nanogenerator is fabricated. Its excellent sensitivity to wind and exceptional long-term endurance are assessed, confirming its suitability as a sensor. The practicality of employing this device in intrusion detection, leveraging a wireless door-opening sensor, is demonstrated using synthesized composite materials. Full article

Copolymers based on vinylidene fluoride are potential materials for ferroelectric memory elements. The trend in studies showing that a decrease in the degree of crystallinity can lead to an unexpected increase in the electric breakdown field is noted. An analysis of the literature data reveals that in fluorine-containing ferroelectric polymers, when using a bipolar triangular field, the hysteresis loop has an unclosed shape, with each subsequent loop being accompanied by a decrease in the dielectric response. In this work, the effect of the structure of self-polarized films of copolymers of vinylidene fluoride with tetrafluoroethylene and hexafluoropropylene on breakdown processes was studied. The structure of the polymer films was monitored using infrared spectroscopy (IR) and X-ray diffraction. Kelvin probe force microscopy (KPFM) was applied to characterize the local electrical properties of the polymers. For the films of the first copolymer, which crystallize in the polar β-phase, asymmetry in the dielectric response was observed at fields greater than the coercive field. For the films of the copolymers of vinylidene fluoride with hexafluoropropylene, which crystallize predominantly in the nonpolar α-phase, polarization switching processes have also been observed, but at lower electric fields. The noted phenomena will help to identify the influence of the structure of ferroelectric polymers on their electrical properties. Full article
