Search Results (30)

The binder jetting additive manufacturing process offers the ability to create three-dimensional parts layer by layer. However, using any powder that contains particles with different sizes, shapes, or densities can lead to powder segregation during the mixing, dispensing, and spreading steps of the binder jetting additive manufacturing process. Powder segregation can often lead to uneven powder distribution across the powder bed, potentially causing defects in final parts. Therefore, it is important to understand powder segregation in mixing, dispensing, and spreading. Reported studies on powder segregation in mixing were conducted primarily on pharmaceutical or food powder that have different properties compared to metal or ceramic powder used in binder jetting additive manufacturing. There is a need for a deep understanding of how mixing speed and mixing time affect powder segregation in the context of binder jetting additive manufacturing. This paper reports an experimental investigation using a two-variable, two-level full-factorial design to examine the main effects and interaction effect of mixing speed and mixing time on powder segregation in the mixing of Powder A and Powder B for binder jetting additive manufacturing. The results reveal that segregation was more severe at the high level of mixing speed and the high level of mixing time. These findings provide useful insights for selecting mixing variables and controlling segregation, essential for achieving high-quality printed parts in binder jetting additive manufacturing. Full article

Radar sensors are critical for obstacle detection and navigation, especially for automated driving. Using the use-case “printing of heating coils on the inside of the front housing (primary radome)” needed for de-icing in winter, it is demonstrated that additive manufacturing (AM) can provide economic and functional benefits for manufacturing of the sensors. AM will allow significant cost reduction by eliminating parts and simplifying the manufacturing process. Different AM technologies for the coils were investigated, first, by applying the conductive traces by fused deposition modeling (FDM), and, second, by printing copper particle-free inks and pastes. The metal layers were electrically and mechanically characterized using a profilometer to measure the trace dimension and a four-point probe to measure the resistance. It was revealed that low-cost conductive filaments with low resistivity and current carrying capacity are commercially still not available. The best option sourced was a copper–polyester-based filament with 6000 µΩcm after printing. Therefore, low-cost particle-free copper inks and commercial copper flake paste were selected to print the heating coil. The Cu particle-free inks were amine-based Cu (II) formate complexes, where the Cu exists in an ionic form. Using contactless printing processes such as ink-jet printing or pneumatic dispensing, the traces could be deposited onto the low-melting temperature (225 °C) polymeric radome structure. After printing, the material needed to be sintered to form the conductive copper traces. To avoid damaging the polymer radome during sintering, two different processes were investigated: low-temperature (<150 °C) sintering in an oven for 30 min or fast laser sintering. The sintered Cu layers achieved the following specific electric resistivities when slowly sintered in the oven: paste 4 µΩcm and ink 8.8 µΩcm. Using laser sintering, the ink achieved 3.2 µΩcm because the locally high temperature provides better sintering. Also, the adhesion was significantly increased to (5 B). Therefore, laser sintering is the preferred technology. In addition, it allows fast processing directly after printing. Commercial equipment is available where printing and laser sintering is integrated. The potential of low-cost copper material and the integration in additive manufacturing of electronic systems using radar sensors as an example are demonstrated in this paper. Full article

Sorting and dispensing distinct numbers of cellular aggregates enables the creation of three-dimensional (3D) in vitro models that replicate in vivo tissues, such as tumor tissue, with realistic metabolic properties. One method for creating these models involves utilizing Drop-on-Demand (DoD) dispensing of individual Multicellular Spheroids (MCSs) according to material jetting processes. In the DoD approach, a droplet dispenser ejects droplets containing these MCSs. For the reliable printing of tissue models, the exact number of dispensed MCSs must be determined. Current systems are designed to detect MCSs in the nozzle region prior to the dispensing process. However, due to surface effects, in some cases the spheroids that are detected adhere to the nozzle and are not dispensed with the droplet as expected. In contrast, detection that is carried out only after the droplet has been ejected is not affected by this issue. This work presents a system that can detect micrometer-sized synthetic or biological particles within free-falling droplets with a volume of about 30 nanoliters. Different illumination modalities and detection algorithms were tested. For a glare point projection-based approach, detection accuracies of an average of 95% were achieved for polymer particles and MCF-7 spheroids with diameters above 75 μm. For smaller particles the detection accuracy was still in the range of 70%. An approach with diffuse white light illumination demonstrated an improvement for the detection of small opaque particles. Accuracies up to 96% were achieved using this concept. This makes the two demonstrated methods suitable for improving the accuracy and quality control of particle detection in droplets for Drop-on-Demand techniques and for bioprinting. Full article

A confined plunging liquid jet reactor (CPLJR) is an unconventional efficient and feasible aerator, mixer and brine dispenser that operates under many operating conditions. Such operating conditions could be challenging, and hence, utilizing prediction models built on machine learning (ML) approaches could be very helpful in giving reliable tools to manage highly non-linear problems related to experimental hydrodynamics such as CPLJRs. CPLJRs are vital in protecting the environment through preserving and sustaining the quality of water resources. In the current study, the effects of the main parameters on the air entrainment rate, Q_a, were investigated experimentally in a confined plunging liquid jet reactor (CPLJR). Various downcomer diameters (D_c), jet lengths (L_j), liquid volumetric flow rates (Qj), nozzle diameters (d_n), and jet velocities (V_j) were used to measure the air entrainment rate, Q_a. The non-linear relationship between the air entrainment ratio and confined plunging jet reactor parameters suggests that applying unconventional regression algorithms to predict the air entrainment ratio is appropriate. In addition to the experimental work, machine learning (ML) algorithms were applied to the confined plunging jet reactor parameters to determine the parameter that predicts Q_a the best. The results obtained from ML showed that K-Nearest Neighbour (KNN) gave the best prediction abilities, the proportion of variance in the Q_a that can be explained by the CPLJR parameter was 90%, the root mean square error (RMSE) = 0.069, and the mean absolute error (MAE) = 0.052. Sensitivity analysis was applied to determine the most effective predictor in predicting Q_a. The Qj and V_j were the most influential among all the input variables. The sensitivity analysis shows that the lasso algorithm can create an effective air entrainment rate model with just two of the most crucial variables, Qj and V_j. The coefficient of determination (R²) was 82%. The present findings support using machine learning algorithms to accurately forecast the CPLJR system’s experimental results. Full article

Multi-material additive manufacturing (AM) attempts to utilize the full benefits of complex part production with a comprehensive and complementary material spectrum. In this context, this research article presents new processing strategies in the field of polymer- and metal-based multi-material AM. The investigation highlights the current progress in powder-based multi-material AM based on three successfully utilized technological approaches: additive and formative manufacturing of hybrid metal parts with locally adapted and tailored properties, material-efficient AM of multi-material polymer parts through electrophotography, and the implementation of UV-curable thermosets within the laser-based powder bed fusion of plastics. Owing to the complex requirements for the mechanical testing of multi-material parts with an emphasis on the transition area, this research targets an experimental shear testing set-up as a universal method for both metal- and polymer-based processes. The method was selected based on the common need of all technologies for the sufficient characterization of the bonding behavior between the individual materials. Full article

Hydrogen–gasoline hybrid refueling stations can minimize construction and management costs and save land resources and are gradually becoming one of the primary modes for hydrogen refueling stations. However, catastrophic consequences may be caused as both hydrogen and gasoline are flammable and explosive. It is crucial to perform an effective risk assessment to prevent fire and explosion accidents at hybrid refueling stations. This study conducted a risk assessment of the refueling area of a hydrogen–gasoline hybrid refueling station based on the improved Accident Risk Assessment Method for Industrial Systems (ARAMIS). An improved probabilistic failure model was used to make ARAMIS more applicable to hydrogen infrastructure. Additionally, the accident consequences, i.e., jet fires and explosions, were simulated using Computational Fluid Dynamics (CFD) methods replacing the traditional empirical model. The results showed that the risk levels at the station house and the road near the refueling area were 5.80 × 10⁻⁵ and 3.37 × 10⁻⁴, respectively, and both were within the acceptable range. Furthermore, the hydrogen dispenser leaked and caused a jet fire, and the flame ignited the exposed gasoline causing a secondary accident, considered the most hazardous accident scenario. A case study was conducted to demonstrate the practicability of the methodology. This method is believed to provide trustworthy decisions for establishing safe distances from dispensers and optimizing the arrangement of the refueling area. Full article

In this study, a compliant amplifier powered by a piezoelectric stack is designed to meet high-performance dispensing operation requirements. By studying the issue of low frequency bandwidth on the traditional bridge-type amplifier mechanism, we propose a displacement amplifier mechanism, hybrid bridge-lever-bridge (HBLB), that enhances its dynamic performance by combining the traditional bridge-type and lever mechanism. A guiding beam is added to further improve its output stiffness with a guaranteed large amplification ratio. An analytical model has been developed to describe the full elastic deformation behavior of the HBLB mechanism that considers the lateral displacement loss of the input end, followed by a verification through a finite element analysis (FEA). Results revealed that the working principle of the HBLB optimizes the structural parameters using the finite element method. Finally, a prototype of the displacement amplifier was fabricated for performance tests. Static and dynamic test results revealed that the proposed mechanism can reach a travel range of 223.2 $\mathsf{\mu }$m, and the frequency bandwidth is 1.184 kHz, which meets the requirements of a high-performance piezo jet dispenser. Full article

In this article, we present an approach to fabricate conductive tracks on polymer substrates. Here, a digital printing process is used together with subsequent processing by a laser. For this purpose, a silver flake-based composite is printed onto a polycarbonate substrate using a jet-dispensing process. The printed tracks are then cured using a pyrometer-controlled laser beam source. The fabricated samples are analyzed for electrical resistivity and the cross-sectional area of the conductive tracks and compared to conventionally oven-cured samples. Four-point measurements and an optical measurement method are used for this purpose. Based on the resulting resistance, two different process regimes can be observed for the laser curing process. By using a laser instead of an oven for post-treatment, the achieved resistance of the conductive tracks can be reduced by a factor of 2. Moreover, the tracks produced in this way are more reproducible in terms of the resistance that can be achieved. Full article

The need for effective heating and cooling systems in the automotive, chemical, and aerospace industries is driving a rapid proliferation of heat-transfer technology. In recent times, GO (Graphene Oxide) has been emerging as one of the most promising nanoparticles because of its uninterrupted behavior of electrical conductivity even at a minimum carrier concentration. Due to this incentive, the behavior of jet flow with heat and mass transfer features of electrically conducting based kerosene oil (KO) fluid dispensed by graphene nanoparticles was studied. In addition, the activation energy, irregular heat source/sink, thermophoretic particle deposition, and chemical reaction are also provoked. In order to provide numerical results, the boundary value problem of fourth-order (bvp4c) solver was used. The graphs were used to illustrate the effects of relevant parameters on the fluid flow, heat, and mass transfer rates. The incorporation of graphene nanoparticles significantly improves heat conductivity. Additionally, the nanoparticle volume fraction augments the temperature and concentration profile while the velocity profile declines. Moreover, the temperature enhances due to the heat source, whilst the contrary behavior is observed in the presence of the heat sink. Furthermore, the shear stress increases up to 12.3%, the Nusselt number increases up to 0.119%, and the Sherwood number increases up to 0.006% due to the presence of nanofluid. Finally, we can conclude that the latest work will be useful for thermal cooling systems, including cooling for engines and generators, nuclear systems, aviation refrigeration systems, and other systems. Full article

Glass frit bonding is a widely used technology to cap and seal micro-electromechanical systems on the wafer level using a low melting point glass. Screen printing is the main method to apply glass frit paste on wafers. Screen printing of glass frit paste is usually performed on less sensitive, less critical wafers, normally the capping wafer, because screen printing is a rough process involving the mechanical contact of the screen printing mesh and the wafer. However, for some applications in which contactless patterning of glass frit materials on the device wafers are preferred (e.g., 3D topographies, micro-lens and optics integration) jet dispensing could be a promising approach. Consequently, in this study, wafer-level jetting of glass frit materials on silicon wafers was proposed and investigated. The jetting parameters such as jetting distance, power and temperature were optimized for a glass frit paste. Additionally, the effect of jetted pitch size on the bond-line thickness was assessed. The wafers with jetted glass frit pastes were conclusively bonded in low vacuum and characterized. As a single-step (non-contact) additive approach, the jet printing of glass frit was revealed to be a straightforward, cost-effective and flexible approach with several implications for hermetic packaging. Full article

Green liquid hydrogen (LH2) could play an essential role as a zero-carbon aircraft fuel to reach long-term sustainable aviation. Excluding challenges such as electrolysis, transportation and use of renewable energy in setting up hydrogen (H₂) fuel infrastructure, this paper investigates the interface between refueling systems and aircraft, and the impacts on fuel distribution at the airport. Furthermore, it provides an overview of key technology design decisions for LH2 refueling procedures and their effects on the turnaround times as well as on aircraft design. Based on a comparison to Jet A-1 refueling, new LH2 refueling procedures are described and evaluated. Process steps under consideration are connecting/disconnecting, purging, chill-down, and refueling. The actual refueling flow of LH2 is limited to a simplified Reynolds term of v · d = 2.35 m²/s. A mass flow rate of 20 kg/s is reached with an inner hose diameter of 152.4 mm. The previous and subsequent processes (without refueling) require 9 min with purging and 6 min without purging. For the assessment of impacts on LH2 aircraft operation, process changes on the level of ground support equipment are compared to current procedures with Jet A-1. The technical challenges at the airport for refueling trucks as well as pipeline systems and dispensers are presented. In addition to the technological solutions, explosion protection as applicable safety regulations are analyzed, and the overall refueling process is validated. The thermodynamic properties of LH2 as a real, compressible fluid are considered to derive implications for airport-side infrastructure. The advantages and disadvantages of a subcooled liquid are evaluated, and cost impacts are elaborated. Behind the airport storage tank, LH2 must be cooled to at least 19K to prevent two-phase phenomena and a mass flow reduction during distribution. Implications on LH2 aircraft design are investigated by understanding the thermodynamic properties, including calculation methods for the aircraft tank volume, and problems such as cavitation and two-phase flows. In conclusion, the work presented shows that LH2 refueling procedure is feasible, compliant with the applicable explosion protection standards and hence does not impact the turnaround procedure. A turnaround time comparison shows that refueling with LH2 in most cases takes less time than with Jet A-1. The turnaround at the airport can be performed by a fuel truck or a pipeline dispenser system without generating direct losses, i.e., venting to the atmosphere. Full article

Polymer composites containing ferromagnetic fillers are promising for applications relating to electrical and electronic devices. In this research, the authors modified an ultraviolet light (UV) curable prepolymer to additionally cure upon heating and validated a permanent magnet-based particle alignment system toward fabricating anisotropic magnetic composites. The developed dual-cure acrylate-based resin, reinforced with ferromagnetic fillers, was first tested for its ability to polymerize through UV and heat. Then, the magnetic alignment setup was used to orient magnetic particles in the dual-cure acrylate-based resin and a heat curable epoxy resin system in a polymer casting approach. The alignment setup was subsequently integrated with a material jetting 3D printer, and the dual-cure resin was dispensed and cured in-situ using UV, followed by thermal post-curing. The resulting magnetic composites were tested for their filler loading, microstructural morphology, alignment of the easy axis of magnetization, and degree of monomer conversion. Magnetic characterization was conducted using a vibrating sample magnetometer along the in-plane and out-of-plane directions to study anisotropic properties. This research establishes a methodology to combine magnetic field induced particle alignment along with a dual-cure resin to create anisotropic magnetic composites through polymer casting and additive manufacturing. Full article

The commercialization of eco-friendly hydrogen vehicles has elicited attempts to expand hydrogen refueling stations in urban areas; however, safety measures to reduce the risk of jet fires have not been established. The RISKCURVES software was used to evaluate the individual and societal risks of hydrogen refueling stations in urban areas, and the F–N (Frequency–Number of fatalities) curve was used to compare whether the safety measures satisfied international standards. From the results of the analysis, it was found that there is a risk of explosion in the expansion of hydrogen refueling stations in urban areas, and safety measures should be considered. To lower the risk of hydrogen refueling stations, this study applied the passive and active independent protection layers (IPLs) of LOPA (Layer of Protection Analysis) and confirmed that these measures significantly reduced societal risk as well as individual risk and met international standards. In particular, such measures could effectively reduce the impact of jet fire in dispensers and tube trailers that had a high risk. Measures employing both IPL types were efficient in meeting international standard criteria; however, passive IPLs were found to have a greater risk reduction effect than active IPLs. The combination of RISKCURVES and LOPA is an appropriate risk assessment method that can reduce work time and mitigate risks through protective measures compared to existing risk assessment methods. This method can be applied to risk assessment and risk mitigation not only for hydrogen facilities, but also for hazardous materials with high fire or explosion risk. Full article

Here, we propose a novel and simple method to efficiently capture the diffusion of fluorescein isothiocyanate (FITC)-dextran from a biocompatible substance and load the drug only to the tip of DNA microneedles. A dispensing and suction method was chosen to fabricate the designed microneedles with efficient amounts of FITC as the drug model. Importantly, the vacuum process, which could influence the capturing of FITC diffusion from the tip, was evaluated during the manufacturing process. In addition, the simulations were consistent with the experimental results and showed apparent diffusion. Moreover, dextrans of different molecular weights labeled with FITC were chosen to fabricate the tip of microneedles for demonstrating their applicability. Finally, a micro-jetting system with a micro-nozzle (diameter: 80 μm) was developed to achieve the accurate and rapid loading of small amounts of FITC using the anti-diffusion and micro-jetting methods. Our method not only uses a simple and fast manufacturing process, but also fabricates the tips of microneedles more efficiently with FITC compared with the existing methods. We believe that the proposed method is essential for the clinical applications of the microneedle drug delivery platform. Full article

Magnetic composites play a significant role in various electrical and electronic devices. Properties of such magnetic composites depend on the particle microstructural distribution within the polymer matrix. In this study, a methodology to manufacture magnetic composites with isotropic and anisotropic particle distribution was introduced using engineered material formulations and manufacturing methods. An in-house developed material jetting 3D printer with particle alignment capability was utilized to dispense a UV curable resin formulation to the desired computer aided design (CAD) geometry. Formulations engineered using additives enabled controlling the rheological properties and the microstructure at different manufacturing process stages. Incorporating rheological additives rendered the formulation with thixotropic properties suitable for material jetting processes. Particle alignment was accomplished using a magnetic field generated using a pair of permanent magnets. Microstructure control in printed composites was observed to depend on both the developed material formulations and the manufacturing process. The rheological behavior of filler-modified polymers was characterized using rheometry, and the formulation properties were derived using mathematical models. Experimental observations were correlated with the observed mechanical behavior changes in the polymers. It was additionally observed that higher additive content controlled particle aggregation but reduced the degree of particle alignment in polymers. Directionality analysis of optical micrographs was utilized as a tool to quantify the degree of filler orientation in printed composites. Characterization of in-plane and out-of-plane magnetic properties using a superconducting quantum interference device (SQUID) magnetometer exhibited enhanced magnetic characteristics along the direction of field structuring. Results expressed in this fundamental research serve as building blocks to construct magnetic composites through material jetting-based additive manufacturing processes. Full article
