In the paper we consider the pulsed disturbances caused in the ionosphere by an extreme G5-level geomagnetic superstorm on 10 May 2024, and by the X1.0 and M-class solar flares on 8 May 2024, which preceded the storm. Particular attention is paid to the short-term delays and the sequence of disturbance appearance in the ionosphere and geomagnetic field during these extreme events. The results of a continuous Doppler sounding of the ionosphere on an inclined radio path with a sampling frequency of 25 Hz were used, as well as the data of a ground-based mid-latitude fluxgate magnetometer LEMI-008, and an induction magnetometer IMS-008, which operated with a sampling frequency of 66.6 Hz. Ionization of the ionosphere by the intense X-ray and extreme ultraviolet radiation of solar flares was accompanied by the equally sudden and similarly timed disturbances in the Doppler frequency shift (DFS) of the ionospheric signal, which had an amplitude of 2.0–5.8 Hz. The largest pulsed burst in DFS was registered 68 s after an X1.0 flare on 8 May 2024 at the time when the change of the X-ray flux was at its maximum. Following onto the effect in the ionosphere, a disturbance in the geomagnetic field appeared with a time delay of 35 s. This disturbance is a secondary one that arose as a consequence of the ionosphere response to the solar flare. It was likely driven by the contribution of ionospheric currents and electric fields, which modified the Earth’s magnetic field. On 10 May 2024, a G5-level geomagnetic superstorm with a sudden commencement triggered an impulsive reaction in the ionosphere. A response in DFS at the calculated reflection altitude of the sounding radio wave of 267.5 km was detected 58 s after the commencement of the storm. The sudden impulsive changes in Doppler frequencies showed a bipolar character, reflecting complex dynamic transformations in the ionosphere at the geomagnetic storm. Consequently, the DFS amplitude initially rose to 5.5 Hz over 86 s, and then its sharp drop to $-3.2$ Hz followed. Using the instruments that operated in a mode with a high temporal resolution allowed us to identify for the first time the impulsive nature of the ionospheric reaction, the time delays, and the sequence of disturbance appearances in the ionosphere and geomagnetic field in response to the X1.0 solar flare on 8 May 2024 as well as to the sudden commencement of the extreme G5-level geomagnetic storm on 10 May 2024. Full article

The rapid expansion of BeiDou satellite navigation applications has led to a growing demand for real-time high-precision positioning services. Currently, high-precision positioning services face challenges such as a long initialization time and heavy reliance on reference station networks, thereby failing to fulfill the requirements for real-time, wide-area, and centimeter-level positioning. In this study, we consider the multi-frequency signals that are broadcast by a satellite to share a common reference clock and possess identical RF channels and propagation paths with strict temporal, spectral, and spatial coupling between signal components, resulting in strongly coherent propagation delays. Firstly, we accurately establish a multi-frequency signal model that fully exploits those coherent characteristics among the multi-frequency BDS signals. Subsequently, we propose a rapid high-precision ranging technique using the code and carrier phases of multi-frequency signals. The proposed method unitizes multi-frequency signals via a coherent joint processing unit consisting of a joint tracking state estimator and a coherent signal generator. The joint tracking state estimator simultaneously estimates the biased pseudorange and its change rate, ionospheric delay and its change rate, and ambiguities. The coherent signal generator updates the numerically controlled oscillator (NCO) to adjust the local reference signal’s code and carrier replicas of different frequencies, changing them according to the state estimated by the joint tracking state estimator. Finally, the simulation results indicate that the proposed method efficiently diminishes the estimated biased pseudorange and ionospheric delay errors to below 0.1 m. Furthermore, this method reduces the carrier phase errors by more than 60% compared with conventional single-frequency-independent tracking methods. Consequently, the proposed method can achieve rapid centimeter-level results ranging for up to 1 min without using precise atmosphere corrections and provide enhanced tracking sensitivity and robustness. Full article

Measurements of Very-Low-Frequency (VLF) transmitter signals have been widely used to investigate the effects of various space weather events on the D-region ionosphere, including nowcasting solar flares. Previous studies have established a method to nowcast solar flares using VLF measurements, but only using measurements from dayside propagation paths, and there remains limited focus on day–night mixed paths, which are important for method applicability. Between March and May of 2022, the Sun erupted a total of 56 M-class and 6 X-class solar flares, all of which were well captured by our VLF receiver in Antarctica. Using these VLF measurements, we reexamine the capability of the VLF technique to nowcast solar flares by including day–night mixed propagation paths and expanding the path coverage in longitude compared to that in previous studies. The amplitude and phase maximum changes are generally positively correlated with X-ray fluxes, whereas the time delay is negatively correlated. The curve-fitting parameters that we obtain for the X-ray fluxes and VLF signal maximum changes are consistent with those in previous studies for dayside paths, even though different instruments are used, supporting the flare-nowcasting method. Moreover, the present results show that, for day–night mixed paths, the amplitude and phase maximum changes also scale linearly with the logarithm of the flare X-ray fluxes, but the level of change is notably different from that for dayside paths. The coefficients used in the flare-nowcasting method need to be updated for mixed propagation paths. Full article

Spatial and temporal variation in the free electron concentration in the ionosphere affects SAR interferograms, in particular at low radar frequencies. In this work, the identification, estimation, and compensation of ionospheric path delay phases in PALSAR-3 and NISAR-L interferograms are discussed. Both of these L-band sensors simultaneously acquire SAR data in a main spectral band and in an additional, spectrally separated, narrower second band to support the mitigation of ionospheric path delays. The methods presented permit separating the dispersive and the non-dispersive phase terms based on the double-difference interferogram between the two available spectral bands and the differential interferogram of the main band. The applicability of the proposed methods is demonstrated using PALSAR-3-like data that were simulated based on PALSAR-2 SM1 mode data. Full article

In this study, Loran-C signals were collected throughout the day, and the characteristics of the received signals at different propagation distances were analyzed. Because the signal amplitude is small and difficult to recognize at a long distance and there is mutual interference between stations, a linear average method is used to process the received signal. At locations closer to the receiver, clear observations of the time delay and amplitude variation in the one-hop sky wave can be made by using the ground wave as a reference, which can be applied to studying the characteristics and parameter inversion of the lower ionosphere. When the distance is further, the significant enhancement of the sky-wave signal during the night may lead to decreased accuracy in timing and positioning. When the distance is much larger than the propagation range of the ground wave, only the sky-wave signal can be received, and the signal is more stable than when the distance is closer. During the night, multiple amplitude-comparable multi-path signals may appear in the sky wave, making the identification of the one-hop sky wave more difficult. Full article

This paper describes the main updates characterizing the new version of IONORT (IONOsperic Ray Tracing), a software tool developed at Istituto Nazionale di Geofisica e Vulcanologia to determine both the path of a high frequency (HF) radio wave propagating in the ionospheric medium, and the group time delay of the wave itself along the path. One of the main changes concerns the replacement of a regional three-dimensional electron density matrix, which was previously taken as input to represent the ionosphere, with a global one. Therefore, it is now possible to carry out different ray tracings from whatever point of the Earth’s surface, simply by selecting suitable loop cycles thanks to the new ray tracing graphical user interface (GUI). At the same time, thanks to a homing GUI, it is also possible to generate synthetic oblique ionograms for whatever radio link chosen by the user. Both ray tracing and homing GUIs will be described in detail providing at the same time some practical examples of their use for different regions. IONORT software finds practical application in the planning of HF radio links, exploiting the sky wave, through an accurate and thorough knowledge of the ionospheric medium. HF radio waves users, including broadcasting and civil aviation, would benefit from the use of the IONORT software (version 2023.10). Full article

Coherent observations in GNSS reflectometry are prominent in regions with smooth reflecting surfaces and at grazing elevation angles. However, within these lower elevation ranges, GNSS signals traverse a more extensive atmospheric path, and increased ionospheric effects (e.g., delay biases) are expected. These biases can be mitigated by employing dual-frequency receivers or models tailored for single-frequency receivers. In preparation for the single-frequency GNSS-R ESA “PRETTY” mission, this study aims to characterize ionospheric effects under variable parameter conditions: elevation angles in the grazing range (5° to 30°), latitude-dependent regions (north, tropic, south) and diurnal changes (day and nighttime). The investigation employs simulations using orbit data from Spire Global Inc.’s Lemur-2 CubeSat constellation at the solar minimum (F10.7 index at 75) on March, 2021. Changes towards higher solar activity are accounted for with an additional scenario (F10.7 index at 180) on March, 2023. The electron density associated with each reflection event is determined using the Neustrelitz Electron Density Model (NEDM2020) and the NeQuick 2 model. The results from periods of low solar activity reveal fluctuations of up to approximately 300 TECUs in slant total electron content, 19 m in relative ionospheric delay for the GPS L1 frequency, 2 Hz in Doppler shifts, and variations in the peak electron density height ranging from 215 to 330 km. Sea surface height uncertainty associated with ionospheric model-based corrections in group delay altimetric inversion can reach a standard deviation at the meter level. Full article

During the catastrophic M7.8 earthquake in Turkey on 6 February 2023, anomalous effects were revealed in the ionosphere associated with various propagation mechanisms of seismogenic disturbance from the lithosphere up to the height of the ionosphere. Seventeen minutes after the main shock, a co-seismic disturbance was detected by a Doppler ionosonde on an inclined, 3010 km long, two-hop radio path “Kuwait—Institute of Ionosphere (Almaty)”. An appearance of acoustic waves at the height of 232 km in the ionosphere was fixed 568 s after arrival of the surface Rayleigh wave to the sub-ionospheric point, and such a delay agrees with the calculated propagation time of a vertically moving acoustic wave. The disturbance lasted 160 s, and its double amplitude was above 2 Hz, which noticeably exceeds the background fluctuation of Doppler frequency. The best coincidence between the waveforms of the Doppler signal and of the surface seismic wave was observed over the duration of the two leading periods, with correlation coefficients of 0.86 and 0.79, correspondingly. Pre-seismic effects in the ionosphere were revealed 8 days before the main shock both in the variations of the Doppler frequency and of the critical frequency $f0F2$. The probable origination mechanism of the pre-seismic ionospheric disturbances above the region of the earthquake preparation determined by the Dobrovolsky radius may be considered in accordance with the concept of lithospheric–atmospheric–ionospheric coupling. Full article

Reconstruction of reliable plasmaspheric electron density profiles is important for understanding physical processes in the plasmasphere. This paper proposes a technique that can be applied to correct the plasmaspheric electron density profiles using ray tracing by scrutinizing dispersion analyses of lightning whistlers. The Global Core Plasma Model and the International Reference Ionosphere were introduced as a reference electron density profile. Modifications of this electron density profile were then proposed to satisfy the dispersion characteristics of lightning whistlers measured by satellites in the plasmasphere. We first introduce two kinds of functions to modify the electron density: constant and linear, the linear function is more adequate. We applied our method to two lightning whistler events on 14 August 2017, measured by the Plasma Wave Experiment/Waveform Capture aboard the Arase satellite, and analyzed the dispersion of the observed lightning whistlers. We show how the density modification affects the delay time of the ray path and satisfies the dispersion characteristics under the appropriate adjustments. Full article

The super dual auroral radar network (SuperDARN) is an important tool in the remote sensing of ionospheric potential convection in middle and high latitudes, and also a major source of elevation data detection. A reliable elevation angle helps estimate the propagation paths of high-frequency radio signals between scattering spots and radars, which is crucial for determining high-frequency radar target geolocation. The SuperDARN radar uses interferometry to estimate the elevation of the returned signal. However, elevation data are still underutilized owing to the difficulties of phase difference calibration induced by the propagation time delay between two arrays. This paper statistically analyzes the distribution features of the group range-elevation angle and group range-virtual height before and after calibration using elevation data from the ground backscatter echoes of the Zhongshan SuperDARN radar, calculating the root mean square error (RMSE) of the virtual height; the results show that the RMSE after calibration is mostly reduced to within 54% of that before calibration. Furthermore, we validate the calibration factor based on the primary phase data. The data from 2013 to 2015 indicate that this technique can be efficiently used to estimate the daily calibration factor. Finally, we present the statistical distribution of the calibration factor, which provides technical support for the calibration of elevation data in the future. Full article

In this paper, we explored how to more accurately predict the quality of high-frequency links and how to better research and improve the capabilities of high-frequency communication, reconnaissance, and positioning systems. Based on the background electron density generated by the ionospheric assimilation model and 3D ray-tracing technology, more realistic and accurate high-frequency channel parameters with physical meanings were obtained. On this basis, a complete high-frequency channel model that can be used for simulation and prediction was constructed. First, the ionospheric assimilation model, the high-frequency channel model, and the method used for calculating the parameters of the high-frequency channel model based on the background electron density generated by the multi-source ionospheric assimilation model are introduced. Then, the HF oblique sounding experiment and experimental data processing are introduced. Finally, the modeling and simulation of the high-frequency channel are compared with the HF oblique sounding experimental results. The simulation results showed that the modeling results of the high-frequency channel based on the multi-source ionospheric assimilation model proposed in this paper were similar to the HF oblique sounding experimental results. The average deviation of the difference between the simulation results and the experimental ones of the group path, the group path broadening, and the Doppler frequency shift are 29.2200 km, 17.3456 km, and 0.2121 Hz, respectively. The group delay, Doppler frequency shift, and delay broadening results calculated by the high-frequency channel model simulation were relatively accurate and could be used in high-frequency channel quality reporting and prediction, high-frequency reconnaissance and geolocation, and high-frequency radar frequency selection and positioning, etc. Full article

Strong radiation from solar X-ray flares can produce increased ionization in the terrestrial D-region and change its structure. Moreover, extreme solar radiation in X-spectral range can create sudden ionospheric disturbances and can consequently affect devices on the terrain as well as signals from satellites and presumably cause numerous uncontrollable catastrophic events. One of the techniques for detection and analysis of solar flares is studying the variations in time of specific spectral lines. The aim of this work is to present our study of solar X-ray flare effects on D-region using very low-frequency radio signal measurements over a long path in parallel with the analysis of X-spectral radiation, and to obtain the atmospheric parameters (sharpness, reflection height, time delay). We introduce a novel modelling approach and give D-region coefficients needed for modelling this medium, as well as a simple expression for electron density of lower ionosphere plasmas. We provide the analysis and software on GitHub. Full article

Based on the results of mathematical modeling, we consider the possibility to estimate the plasma frequency F2 layer maximum of the polar ionosphere (critical frequency, foF2) using frequency-sweeping radiation from a highly elliptical spacecraft orbit in the Arctic zone. Our modeling concerning the energy problem of radio sensing consisted of analyzing wave field parameters, received field strength, and SNR on two radio paths with the distances 1900 and 2500 km along the earth’s surface, with the satellite height varying from 10,000 to 30,000 km. Radio path orientations were selected to be close to the classical limit cases of radio wave propagation in the anisotropic ionospheric plasma: quasi-longitudinal approximation and, to a large extent, the quasi-transversal one for the quiet midday and midnight conditions. As a result of these simulations and following specific spacecraft conditions, working with an optimal probing signal was proposed for the appropriate emission power for the onboard transmitter. In the inverse problem of radio sounding of an ionized media, common mathematical inaccuracy in foF2 calculated from the transionogram, frequency dependence of the probing signals magneto-ionic group delay, was estimated. Considering and founding a possible realization of the method, physical prerequisites are discussed based on the experimental data of radio waves passing the 16,000 km long radio path for Moscow–Antarctica (UAS Vernadsky). Full article

Observable-specific bias (OSB) parameterization allows observation biases belonging to various signal types to be flexibly addressed in the estimation of ionosphere and global navigation satellite system (GNSS) clock products. In this contribution, multi-GNSS OSBs are generated by two different methods. With regard to the first method, geometry-free (GF) linear combinations of the pseudorange and carrier-phase observations of a global multi-GNSS receiver network are formed for the extraction of OSB observables, and global ionospheric maps (GIMs) are employed to correct ionospheric path delays. Concerning the second method, satellite and receiver OSBs are converted directly from external differential code bias (DCB) products. Two assumptions are employed in the two methods to distinguish satellite- and receiver-specific OSB parameters. The first assumption is a zero-mean condition for each satellite OSB type and GNSS signal. The second assumption involves ionosphere-free (IF) linear combination signal constraints for satellites and receivers between two signals, which are compatible with the International GNSS Service (IGS) clock product. Agreement between the multi-GNSS satellite OSBs estimated by the two methods and those from the Chinese Academy of Sciences (CAS) is shown at levels of 0.15 ns and 0.1 ns, respectively. The results from observations spanning 6 months show that the multi-GNSS OSB estimates for signals in the same frequency bands may have very similar code bias characteristics, and the receiver OSB estimates present larger standard deviations (STDs) than the satellite OSB estimates. Additionally, the variations in the receiver OSB estimates are shown to be related to the types of receivers and antennas and the firmware version. The results also indicate that the root mean square (RMS) of the differences between the OSBs estimated based on the CAS- and German Aerospace Center (DLR)-provided DCB products are 0.32 ns for the global positioning system (GPS), 0.45 ns for the BeiDou navigation satellite system (BDS), 0.39 ns for GLONASS and 0.22 ns for Galileo. Full article

The next generation of satellite-based augmentation systems (SBAS) will support aviation receivers that take advantage of the ionosphere-free dual-frequency combination. By combining signals of the L1 and L5 bands, about 99% of the ionospheric refraction effects on the GNSS (Global Navigation Satellite Systems) signals can be removed in the user receivers without additional SBAS corrections. Nevertheless, even if most of the negative impacts on GNSS signals are removed by the ionospheric-free combination, some residuals remain and have to be taken into account by overbounding models in the integrity computation conducted by safety-of-live (SoL) receivers in airplanes. Such models have to overbound residuals as well, which result from the most rare extreme ionospheric events, e.g., such as the famous “Halloween Storm”, and should thus include the tails of the error distribution. Their application shall lead to safe error bounds on the user position and allow the computation of protection levels for the horizontal and vertical position errors. Here, we propose and justify such an overbounding model for residual ionospheric delays that remain after the application of the ionospheric-free linear combination. The model takes into account second- and third-order ionospheric refraction effects, excess path due to ray bending, and increased ionospheric total electron content (TEC) along the signal path due to ray bending. Full article
