Search Results (36)

This paper proposes a Takagi–Sugeno–Kang Elliptic Type-2 Fuzzy Brain-Imitated Neural Network (TET2FNN)-based decoupling control strategy for nonlinear underactuated mechanical systems subject to uncertainties. A sliding-mode framework is employed to construct a decoupled control architecture, in which an intermediate variable is introduced to separate two second-order sliding surfaces, thereby forming a decoupled slip surface. The TET2FNN acts as the main controller and approximates the ideal control law online, while a robust compensator is incorporated to suppress approximation errors and guarantee closed-loop stability. Simulation studies conducted on a double inverted pendulum system demonstrate that the proposed method achieves improved tracking accuracy and disturbance rejection compared with representative state-of-the-art controllers. Furthermore, the computational burden remains reasonable, indicating that the proposed scheme is suitable for real-time implementation and practical nonlinear control applications. Full article

This paper addresses the problem of stabilizing an inverted pendulum actuated by a reaction wheel, a system relevant for robotic balancing platforms and aerospace applications. The study compares several state-space representations of the system and examines their implications for controller synthesis and parameter identification. A unified nonlinear model formulation is introduced, enabling a structural Lyapunov-based robustness analysis that reveals how variations in the gravitational gain affect closed-loop stability. Control strategies based on pole placement and Linear Quadratic Regulator (LQR) design are implemented and compared across the different representations. The analysis highlights a robustness–fidelity trade-off between model complexity and sensitivity to parameter uncertainty, providing insight that extends beyond the specific laboratory setup. Theoretical results are validated on a real laboratory platform. The controllers are evaluated in both upright and downward equilibrium configurations, and the influence of parameter shifts is assessed experimentally using global identification and performance indices. The work offers general modeling and robustness guidelines for reaction-wheel-based stabilization systems and related underactuated nonlinear mechanisms. Full article

Attempting to make machines mimic human walking, grasping, balancing, and other behaviors is a deep exploration of cognitive science and biological principles. Due to the existing prediction lag problem, an error compensation mechanism that integrates historical motion data is proposed. By constructing a humanoid autonomous walking control system, this paper aims to use a three-dimensional linear inverted pendulum model to plan the general framework of motion. Firstly, the landing point coordinates of the single foot support period are preset through gait cycle parameters. In addition, it is substituted into dynamic equation to solve the centroid (COM) trajectory curve that conforms to physical constraints. A hierarchical whole-body control architecture is designed, with a task priority based on quadratic programming solver used at the bottom to decompose high-level motion instructions into joint space control variables and fuse sensor data. Furthermore, the numerical iterative algorithm is used to solve the sequence of driving angles for each joint, forming the control input parameters for driving the robot’s motion. This algorithm solves the limitations of traditional inverted pendulum models on vertical motion constraints by optimizing the centroid motion trajectory online. At the same time, it introduces a contact phase sequence prediction mechanism to ensure a smooth transition of the foot trajectory during the switching process. Simulation results demonstrate that the proposed framework improves disturbance rejection capability by over 30% compared to traditional ZMP tracking and achieves a real-time control loop frequency of 1 kHz, confirming its enhanced robustness and computational efficiency. Full article

This work will present an algorithmic approach for robust control focusing on hydraulic–mechanical systems. The approach is applied to a hydraulic actuator driving a cart with an inverted pendulum. The algorithmic approach aims to satisfy two robust control requirements for single input single output (SISO) linear systems with nonlinear uncertain structure. The first control requirement is robust stabilization, and the second is robust asymptotic command following for arbitrary reference signals. The approach is analyzed in two stages. In the first stage, the stability regions of the controller parameters are identified. In the second stage, a Particle Swarm Optimization Algorithm (PSO) is applied to find suboptimal solutions for the controller parameters in these regions, with respect to a suitable performance cost function. The application of the approach to a hydraulic actuator, driving a cart with an inverted pendulum, satisfies the goal of achieving precise control of the pendulum angle, despite the system’s inherent physical uncertainties. Full article

Jumping is a fundamental capability for wheeled-bipedal robots (WBRs) navigating unstructured terrains, with jump height and stability serving as indicators of the robot’s environmental adaptability. However, existing trajectory planning methods demand high output capacity from the joints and fail to balance computational load with trajectory tracking performance. This limitation hinders most robots from experimental validation. To address these challenges, this study presents an optimized virtual model, trajectory planning strategy, and control method. These solutions enhance both the height and stability of jumps while ensuring real-time execution on physical robots. Firstly, inspired by the human jumping mechanism, a Nonlinear Wheel-Spring-Loaded Inverted Pendulum (NW-SLIP) model was originally proposed as the virtual model for trajectory planning. The jump height is increased by 3.4 times compared to the linear spring model. Then, cost functions are established based on this virtual model, and the trajectory for each stage is iteratively optimized using Quadratic Programming (QP) and a bisection method. This leads to a 21.5% increase in the maximum jump height while reducing the peak joint torque by 14% at the same height. This significantly eases execution and enhances the robot’s trajectory-tracking ability. Subsequently, a leg statics model is introduced alongside the kinematics model to map the relationship between the virtual model and joint space. This approach improves trajectory tracking performance while circumventing the intricate calculation of the dynamics model, thereby enhancing jump consistency and stability. Finally, the proposed trajectory planning and jump control method is validated through both simulations and real-world experiments, demonstrating its feasibility and effectiveness in practical robotic applications. Full article

The third-generation instrument era is approaching, and the Einstein Telescope (ET) giant interferometer is becoming a reality, with the potential to be installed at an underground site where seismic noise is about 100 times lower than at the surface. Moreover, new available technologies and the experience acquired from operating advanced detectors are key to further extending the detection bandwidth down to 2–3 Hz, with the possibility of suspending a cryogenic payload. The New Generation of Super-Attenuator (NGSA) is an R&D project aimed at the improvement of vibration isolation performance for thirrd-generation detectors of gravitational waves, assuming that the present mechanical system adopted for the advanced VIRGO interferometer (second generation) is compliant with a third-generation detector. In this paper, we report the preliminary results obtained from a simulation activity devoted to the characterization of a mechanical system based on a multi-stage pendulum and a double-inverted pendulum in a nested configuration (NIP). The final outcomes provide guidelines for the construction of a reduced-scale prototype to be assembled and tested in the “PLANET” laboratory at INFN Naples, where the multi-stage pendulum—equipped with a new magnetic anti-spring (nMAS)—will be hung from the NIP structure. Full article

This study presents a sim2real reinforcement learning-based controller for transition control in a double-inverted pendulum system, addressing the limitations of traditional control methods that rely on precomputed trajectories and lack adaptability to strong external disturbances. By introducing the novel concept of ‘transition control’, this research expands the scope of inverted pendulum studies to tackle the challenging task of navigating between multiple equilibrium points. To overcome the reality gap—a persistent challenge in sim2real transfer—a hardware-centered approach was employed, aligning the physical system’s mechanical design with high-fidelity dynamic equations derived from the Euler–Lagrange equation. This design eliminates the need for software-based corrections, ensuring consistent and robust system performance across simulated and real-world environments. Experimental validation demonstrates the controller’s ability to reliably execute all 12 transition scenarios within the double-inverted pendulum system. Additionally, it exhibits recovery characteristics, enabling the system to stabilize and return to equilibrium point even under severe disturbances. Full article

This paper addresses the robust control problem for under-actuated mechanical systems subject to uncertainties. The key challenge lies in achieving precise control with insufficient degrees of freedom while maintaining robustness against system uncertainties. We propose a novel control framework that characterizes bounded, time-varying uncertainties through fuzzy set theory, leading to a fuzzy dynamical system formulation. The main contributions are threefold: (1) the development of a deterministic robust controller that eschews traditional IF-THEN rules while guaranteeing system stability through a Lyapunov–Minimax analysis; (2) the formulation of a performance optimization scheme that minimizes both fuzzy system average performance and control costs, with proven existence and uniqueness of the analytical solution; and (3) the establishment of stability conditions using the Lyapunov theory for time-varying systems with bounded uncertainties. The theoretical framework is validated through both numerical simulations and experimental implementation on a linear motor-driven inverted pendulum system. The experimental results demonstrate significant performance improvements over conventional approaches: the optimal robust controller achieves 34.89% and 29.20% reductions in cart position and pendulum angle errors, respectively, from the initial conditions. A comparative analysis with traditional PD control shows a reduction in steady-state errors from 0.00318 m to 0.00057 m for the cart position and from 0.01117 rad to 0.00055 rad for the pendulum angle, validating the effectiveness of the proposed methodology. Full article

In this paper, we address the modeling, simulation, and control of a rotary inverted pendulum (RIP). The RIP model assembled via the MATLAB (Matlab 2021a)^®/Simulink (Simulink 10.3) Simscape (Simscape 7.3)™ environment demonstrates a high degree of fidelity in its capacity to capture the dynamic characteristics of an actual system, including nonlinear friction. The mathematical model of the RIP is obtained via the Euler–Lagrange approach, and a parameter identification procedure is carried out over the Simscape model for the purpose of validating the mathematical model. The usefulness of the proposed Simscape model is demonstrated by the implementation of a variety of control strategies, including linear controllers as the linear quadratic regulator (LQR), proportional–integral–derivative (PID) and model predictive control (MPC), nonlinear controllers such as feedback linearization (FL) and sliding mode control (SMC), and artificial intelligence (AI)-based controllers such as FL with adaptive neural network compensation (FL-ANC) and reinforcement learning (RL). A design methodology that integrates RL with other control techniques is proposed. Following the proposed methodology, a FL-RL and a proportional–derivative control with RL (PD-RL) are implemented as strategies to achieve stabilization of the RIP. The swing-up control is incorporated into all controllers. The visual environment provided by Simscape facilitates a better comprehension and understanding of the RIP behavior. A comprehensive analysis of the performance of each control strategy is conducted, revealing that AI-based controllers demonstrate superior performance compared to linear and nonlinear controllers. In addition, the FL-RL and PD-RL controllers exhibit improved performance with respect to the FL-ANC and RL controllers when subjected to external disturbance. Full article

In electromechanical systems, backlash in gear trains can lead to a degradation in control performance. We propose a drive–anti-drive mechanism to address this issue. It consists of two DC motors that operate in opposite directions. One motor acts as the drive, while the other serves as the anti-drive to compensate for the backlash. This work focuses on switching between the drive and anti-drive motors, controlled by a switched-mode PID controller. Simulation results on an inverted pendulum demonstrate that the proposed scheme effectively compensates for backlash, improving position accuracy and control. This switched controller approach enhances the performance of electromechanical systems, particularly where gear backlash poses challenges to closed-loop performance. Full article

Many actuating and electro-mechanical devices are driven by DC motors. Gear trains are used to amplify the torque in these motors. They are used in a wide variety of automotives, robotics, and automation applications. However, gears are prone to backlash during their operation of amplifying torques of electromehanical drives. This results in the disengagement of gear teeth when the rotation is reversed. These effects give rise to positional inaccuracies and poor control of the system. This proposed Drive-Anti Drive mechanism is used to track the system’s desired response in the presence of backlash in such cases. The Drive-Anti Drive mechanism consists of two motors rotating in opposite directions. Both the drive and the anti-drive are the DC Machines. The simulation results of the proposed scheme on the tracking control of Inverted Pendulum have been presented. Simulation results depict that the utilization of Drive-Anti Drive system has achieved the target outcome in less than 20 s. However, the target tracking of a system with the utilization of single drives takes 40 s. Setting response of an inverted pendulum is approximately twice as efficient with the utilization of the Drive-Anti Drive mechanism. This approach has been able to effectively track the target in the presence of backlash with the utilization of the Drive-Anti Drive mechanism. Full article

The robotics field of engineering has been witnessing rapid advancements and becoming widely engaged in our lives recently. Its application has pervaded various areas that range from household services to agriculture, industry, military, and health care. The humanoid robots are electro–mechanical devices that are constructed in the semblance of humans and have the ability to sense their environment and take actions accordingly. The control of humanoids is broken down to the following: sensing and perception, path planning, decision making, joint driving, stability and balance. In order to establish and develop control strategies for joint driving, stability and balance, the triple inverted pendulum is used as a benchmark. As the presence of uncertainty is inevitable in this system, the need to develop a robust controller arises. The robustness is often achieved at the expense of performance. Hence, the controller design has to be optimized based on the resultant control system’s performance and the required torque. Particle Swarm Optimization (PSO) is an excellent algorithm in finding global optima, and it can be of great help in automatic tuning of the controller design. This paper presents a hybrid H_∞/sliding mode controller optimized by the PSO algorithm to control the triple inverted pendulum system. The developed control system is tested by applying it to the nominal, perturbed by parameter variation, perturbed by external disturbance, and perturbed by measurement noise system. The average error in all cases is 0.053 deg and the steady controller effort range is from 0.13 to 0.621 N.m with respect to amplitude. The system’s robustness is provided by the hybrid H_∞/sliding mode controller and the system’s performance and efficiency enhancement are provided by optimization. Full article

This paper presents the development, control, and experimental validation of a novel bipedal robot with a passive tendon. The robot, featuring foldable legs, coaxial actuation, and compact folded size, is endowed with a leg configuration with a five-bar mechanism. Based on biological observations of human walking, a passive artificial tendon made of emulsion is fabricated to work in conjunction with a tensioning device, providing adaptive heel touchdown and toe push-off in sync with single-leg movement. The tailored control framework for the bipedal robot is further established with the double-layer architecture. The regulation layer employs the linear inverted pendulum (LIP) model to generate reference trajectory of the center of mass (CoM) with a dead-beat style of parameter adjustment. An inverse-dynamics-based whole-body controller (WBC) is applied to enforce the full-order dynamics of the bipedal robot to reproduce the LIP model’s behavior. We carry out the experiments on the physical prototype to evaluate the walking performance of the developed bipedal robot. The results show that the robot achieves stable walking at the speed of 0.8 m/s (almost twice the leg length/s) and exhibits robustness to external push disturbance. Full article

Through the pendulum mechanism inside the spherical shell, the centroid can be varied circumferentially, enabling the spherical robot to achieve omnidirectional flexible movement. Additionally, the radial variation ability of the centroid enables spherical robots to adopt two distinct driving modes: the traditional lower pendulum driving mode and the inverted pendulum driving mode. There are two manifestations of radial variation in the centroid: having different radial positions of the centroid and achieving radial movement of the centroid. Focusing on these two manifestations, experimental data are obtained through different motion velocities and different motion slopes to conduct research on the influence of radial variation in the centroid on the motion of spherical robots. Based on the experimental data, multiple indicators are analyzed, including response speed, convergence speed, stability, and overshoot, as well as steering ability, climbing ability, and output power. The impact of the radial variation ability of the centroid on the control performance, locomotion capability, and energy consumption of spherical robots is summarized, and the correlation model relating the motion requirements to the radial position of the centroid is established, providing a theoretical basis for the selection of driving modes and centroid positions for spherical robots facing complex task requirements. Full article

The cart–inverted pendulum system (CIPS) is a typical example of underactuated mechanical systems. For the CIPS with friction and disturbances, a gain-scheduled model predictive control method is proposed to achieve the upright stabilization objective of the single inverted pendulum (SIP) while controlling the cart to reach a desired new position. To this end, first, a dynamic equation of the CIPS with friction and disturbances is formulated based on the Newton–Euler equation. On the basis of the dynamic equation of the CIPS, its motion characteristics and control process are analyzed. Next, the given dynamic equation of the CIPS is linearized to obtain a series of linearized models at seven different pendulum angles. Then, seven model predictive controllers (MPCs) are designed based on the above-linearized models, respectively. Introducing the idea of the gain-schedule, a gain-scheduled MPC (GSMPC) is designed to switch one of these seven MPCs to realize the control objective of the CIPS, according to the actual pendulum angle of the SIP during the control process. Finally, multi-group simulations that consider the friction and disturbances of the CIPS are implemented to demonstrate the effectiveness of the proposed gain-scheduled model predictive control method. Full article
