Additive manufacturing (AM) has revolutionized the production of complex geometrical parts with metals; however, the usual layer-by-layer deposition results in poor surface quality and unpredictable surface integrity. Abrasive machining and finishing techniques play vital roles in counteracting these challenges and qualifying AM parts for practical applications. This review aims to present recent research developments concerning the machining of additively manufactured metal parts via both conventional and nonconventional abrasive machining methods. Conventional methods such as grinding, milling, polishing, honing, and sandblasting have been widely investigated for their ability to enhance the surface finish, dimensional accuracy, and mechanical properties of AM metal components. However, the characteristic features of various AM processes, such as porosity, microstructural features, and residual stresses, can significantly influence the machinability of the produced parts. Nonconventional methods such as abrasive flow machining, electrochemical machining, magnetic abrasive finishing, and vibratory bowl finishing, on the other hand, have shown potential in addressing the difficulties associated with internal machining geometries and hard-to-machine material combinations that are typical for many AM parts. This review also highlights some challenges and future trends in the machining of AM metal parts and emphasizes that further research is required in the direction of combinations of various postprocessing techniques, machinability regarding new alloy compositions, and the integration of AI for process optimization. As the demand for high-precision AM parts grows across various industries, the advancement of abrasive machining and finishing techniques is crucial for driving the wider adoption of AM technologies. Full article

With the rapid development of high-end manufacturing industries such as aerospace and national defense, the demand for metal additive manufactured parts with complex internal cavities has been steadily increasing. However, the finishing of complex internal surfaces, especially for irregularly shaped parts, remains a significant challenge due to their intricate geometries. Through a comparative analysis of common finishing methods, the distinctive characteristics and applicability of magnetic abrasive finishing (MAF) are highlighted. To meet the finishing needs of complex metal additive manufactured parts, this paper reviews the current research on magnetic abrasive finishing devices, processing mechanisms, the development of magnetic abrasives, and the MAF processes for intricate internal cavities. Future development trends in MAF for complex internal cavities in additive manufactured parts are also explored; these are (1) investigating multi-technology composite magnetic abrasive finishing equipment designed for complex internal surfaces; (2) studying the dynamic behavior of multiple magnetic abrasive particles in complex cavities and their material removal mechanisms; (3) developing high-performance magnetic abrasives suitable for demanding conditions; and (4) exploring the MAF process for intricate internal surfaces. Full article

Surface quality is one of the most important things to think about when using precision equipment. Inadequate surface quality in engineering products can result in a number of issues, such as excessive wear, failures, improper geometry, and more. Traditional finishing techniques are neither flexible nor economical when it comes to finishing complex geometries. When it comes to finishing with low tolerances and no surface topography degradation, magnetic assisted finishing systems rank among the best. This chapter discusses the types of magnetic assisted finishing techniques, including BERMP, UAMAF, and MAF, and how they are used to finish internal surfaces. Full article

To enhance the surface quality of metal 3D-printed components, magnetic abrasive finishing (MAF) technology was employed for post-processing polishing. Experimental investigation employing response surface methodology was conducted to explore the impact of processing gap, rotational speed of the magnetic field, auxiliary vibration, and magnetic abrasive particle (MAP) size on the quality enhancement of internal surfaces. A regression model correlating roughness with crucial process parameters was established, followed by parameter optimization. Ultimately, the internal surface finishing of waveguides with blind cavities was achieved, and the finishing quality was comprehensively evaluated. Results indicate that under optimal process conditions, the roughness of the specimens decreased from Ra 2.5 μm to Ra 0.65 μm, reflecting a reduction rate of 74%. Following sequential rough and fine processing, the roughnesses of the cavity bottom, side wall, and convex surface inside the waveguide reduced to 0.59 μm, 0.61 μm, and 1.9 μm, respectively, from the original Ra above 12 μm. The findings of this study provide valuable technical insights into the surface finishing of metal 3D-printed components. Full article

This study proposed a new magnetic abrasive finishing (MAF) method, in which a 6-axis robot with a magnetic machining tool was used to polish the inner surfaces of curved tubes. We have also developed a magnetic machining tool jig, which can be fixed at the front of the 6-axis robot, rotating freely and suitable for polishing the inner surfaces of curved tubes. In this study, we focused on investigating the machining parameters in the initial machining stage and precision finishing stage. Based on the characteristics of machining parameters, a multi-stage MAF process was conducted to obtain an inner surface with high quality and high efficiency. The experimental results showed that both the roughness Ra and Rz of inner surface in the initial machining stage significantly decreased with the increase in the mixed magnetic abrasives, to as low as less than 20 nm Ra in the precision finishing stage when the machining parameters were appropriately adjusted. In addition, the roughness Ra of inner surface could be further reduced to less than 10 nm Ra in the multi-stage MAF process. Finally, the magnetic flux density cloud map and the magnetic field line distribution map were analyzed in Ansys Maxwell. Full article

Fast progress in near-net-shape production of parts has attracted vast interest in internal surface finishing. Interest in designing a modern finishing machine to cover the different shapes of workpieces with different materials has risen recently, and the current state of technology cannot satisfy the high requirements for finishing internal channels in metal-additive-manufactured parts. Therefore, in this work, an effort has been made to close the current gaps. This literature review aims to trace the development of different non-traditional internal surface finishing methods. For this reason, attention is focused on the working principles, capabilities, and limitations of the most applicable processes, such as internal magnetic abrasive finishing, abrasive flow machining, fluidized bed machining, cavitation abrasive finishing, and electrochemical machining. Thereafter, a comparison is presented based on which models were surveyed in detail, with particular attention to their specifications and methods. The assessment is measured by seven key features, with two selected methods deciding their value for a proper hybrid machine. Full article

The internal wall of cardiovascular stent tubing produced by a drawing process has defects such as pits and bumps, making the surface rough and unusable. In this research, the challenge of finishing the inner wall of a super-slim cardiovascular stent tube was solved by magnetic abrasive finishing. Firstly, a spherical CBN magnetic abrasive was prepared by a new method, plasma molten metal powders bonding with hard abrasives; then, a magnetic abrasive finishing device was developed to remove the defect layer from the inner wall of ultrafine long cardiovascular stent tubing; finally, response surface tests were performed and parameters were optimized. The results show that the prepared spherical CBN magnetic abrasive has a perfect spherical appearance; the sharp cutting edges cover the surface layer of the iron matrix; the developed magnetic abrasive finishing device for a ultrafine long cardiovascular stent tube meets the processing requirements; the process parameters are optimized by the established regression model; and the inner wall roughness (Ra) of the nickel–titanium alloy cardiovascular stents tube is reduced from 0.356 μm to 0.083 μm, with an error of 4.3% from the predicted value. Magnetic abrasive finishing effectively removed the inner wall defect layer and reduced the roughness, and this solution provides a reference for polishing the inner wall of ultrafine long tubes. Full article

The magnetic abrasive finishing process using the magnetic machining tool was proposed to finish the internal surface of the thick tube (the thickness of the tube is 5~30 mm). It has been proved that this process can improve the roundness while improving the roughness. In this paper, we mainly study the machining mechanism of roundness improvement. Firstly, the influence of finishing characteristics on the roundness improvement was discussed, including the rotational speed of the magnetic machining tool and the rotational speed of the tube. It was concluded that the roundness improvement increases with the increase in the rotational speed through the analysis of finishing force and finishing times. Furthermore, the influence on roundness improvement of different distributions of magnetic particles were experimentally compared. After finishing, due to the magnetic force generated by the magnetic machining tool and the magnetic pole unit exerting pressure on the magnetic particles, a fixed magnetic brush is formed. The experimental results show that the circumferential length of the fixed magnetic brush is different due to the different distribution areas of magnetic particles. It was concluded that the roundness improvement increases with the circumferential length of the fixed magnetic brush increases by discussing the relationship between the circumferential length of the fixed magnetic brush and the wavelength of the roundness curve. When the circumferential length of the fixed magnetic brush is 76 mm, the roundness was improved from 379 μm to 236 μm after 60 min of finishing. Full article

This paper proposes a novel magnetic abrasive finishing (MAF) process that uses an auxiliary magnetic machining tool for the internal surface finishing of a thick-walled tube. The auxiliary magnetic machining tool and external poles form a closed magnetic field circuit. Thus, a stronger magnetic force can be generated during the process. In the current study, we focus on analyzing the distribution of the magnetic field and magnetic flux density and investigating the finishing characteristics of a mixed magnetic abrasive finishing process and speed of relative revolutions. Based on the finishing characteristics, we also conduct a stage-by-stage finishing process by changing the combinations of the mixed magnetic abrasive finishing process. The finishing quality of the internal surface was mainly evaluated by the measured roundness and surface roughness. The experimental results show that the roundness and surface roughness Ra are affected when the total amount of WA abrasive and iron powder is too much; a better surface roughness could be obtained when the difference in the speed of relative revolutions is considerable, but the roundness is the worst. Furthermore, the original roundness measurement of 270 µm can reach 10 µm, and the surface roughness Ra can increase from an original surface roughness of 4.1 µm to reach 10 nm after 105 min of the stage-by-stage finishing process. Full article

An internal magnetic abrasive finishing process using a magnetic machining tool was proposed for finishing the internal surface of the thick tubes. It has been proved that this process is effective for finishing thick tubes, and it can improve the roundness while improving the roughness. However, the mechanism of improving the roundness is not clear, so it is necessary to study it theoretically. In this research, firstly, the roundness curve expression was derived using the principle of roundness measurement by the assumed center method, and the expression of roundness curve expanded by Fourier series was obtained. The influencing factors of roundness improvement were then analyzed. Secondly, the experiments were carried out on SUS304 stainless steel tubes. By confirming the mechanism analysis results and the experimental results, it was concluded that the internal magnetic abrasive finishing process using the magnetic machining tool was effective for improving the roundness of the thick tubes whose thickness is from 10 mm to 30 mm. As the thickness of the tube increased, the improvement in roundness decreased. Full article

This paper describes the development of a movable manual electromagnet with an adjustable flux density to improve the inner surface smoothness of a cone pipe using a magnetic abrasive finishing process. This method is fabricated to reduce further the roughness of the internal surface of the conic shape, which was modeled as an electromagnet oscillating in the work zone with a ball roller. Statistically significant improvement in the process was achieved using unbounded magnetic abrasive, light oil, flux density, controlled feed rate, and constant rotational speed in the experiment. The ball transfer equipped on the top of the electromagnet pole plays an essential role in spinning over the outer cone pipe during the experiment and helps reduce friction while the workpiece fluctuates. Furthermore, the flux density can be changed to control the magnetic force and select the most acceptable option. In addition, a procedure for finishing has been designed for finishing a cone pipe, and we sought to understand how the flux density affects the material in removal exterior roughness. As a result, the flux density is clarified, and a higher flux density achieves excellent removal of surface roughness of the inner deformed pipe from 1.68 μm to 0.39 μm within 24 min. Full article

In this study, a novel magnetorheological (MR) polishing device under a compound magnetic field is designed to achieve microlevel polishing of the titanium tubes. The polishing process is realized by combining the rotation motion of the tube and the reciprocating linear motion of the polishing head. Two types of excitation equipment for generating an appropriate compound magnetic field are outlined. A series of experiments are conducted to systematically investigate the effect of compound magnetic field strength, rotation speed, and type and concentration of abrasive particles on the polishing performance delivered by the designed device. The experiments were carried out through controlling variables. Before and after the experiment, the surface roughness in the polished area of the workpiece is measured, and the influence of the independent variable on the polishing effect is judged by a changing rule of surface roughness so as to obtain a better parameter about compound magnetic field strength, concentration of abrasive particles, etc. It is shown from experimental results that diamond abrasive particles are appropriate for fine finishing the internal surface of the titanium-alloy tube. It is also identified that the polishing performance is excellent at high magnetic field strength, fast rotation speed, and high abrasive-particle concentration. Full article
