Search Results (11)

Search Parameters:
Keywords = inkjet printhead nozzle

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
12 pages, 1835 KiB
Article
Droplet Trajectory Movement Modeling Using a Drop-on-Demand Inkjet Printhead Simulations
by Tim Tofan, Sergejus Borodinas and Raimondas Jasevičius
Mathematics 2025, 13(2), 280; https://doi.org/10.3390/math13020280 - 16 Jan 2025
Cited by 2 | Viewed by 953
Abstract
Previous studies of the authors were focused on the vertical movement of the jet print when the printed head was stationary. In this work, the following study was presented, in which the movement of droplets is achieved using a moving horizontal print head. [...] Read more.
Previous studies of the authors were focused on the vertical movement of the jet print when the printed head was stationary. In this work, the following study was presented, in which the movement of droplets is achieved using a moving horizontal print head. The printed head moves at various velocities, which affects the time of printing and deposition accuracy. This study provides a 3D numerical model with a complete turnover/interchange of the droplet shape at different time steps during the formation and movement process. By considering the dynamics of a droplet surrounded by air, we modeled them using the two-phase flow coupling and level set function from the computational fluid dynamics module by COMSOL Multiphysics. The trajectory shifts of the inkjet droplet are considered from its ejection to its impact on the surface at each time step. The conclusions summarize all the factors responsible for the trajectory shift of the droplet during vertical fall. Full article
Show Figures

Figure 1

17 pages, 5514 KiB
Article
Novel and Efficient Methodology for Drop Placement Accuracy Testing of Robot-Guided Inkjet Printing onto 3D Objects
by Robert Thalheim, Andreas Willert, Dana Mitra and Ralf Zichner
Machines 2023, 11(5), 568; https://doi.org/10.3390/machines11050568 - 19 May 2023
Cited by 3 | Viewed by 2464
Abstract
Robot-guided inkjet printing technology offers a new way for the digital and additive deposition of low-viscous inks to be made directly onto arbitrary surfaces and, thus, enables the production of individualized printed electronics on large-scale objects. When compared to conventional flatbed printing, the [...] Read more.
Robot-guided inkjet printing technology offers a new way for the digital and additive deposition of low-viscous inks to be made directly onto arbitrary surfaces and, thus, enables the production of individualized printed electronics on large-scale objects. When compared to conventional flatbed printing, the distance between the nozzle plate and the object’s surface varies and needs to be considered in order to match the accuracy requirements needed for the positioning of single drops. Knowledge about applicable distance limits and the influence of tunable print parameters is crucial for improving the print process and results. This study discusses the sources of errors in the inkjet printing process onto 3D objects and presents extensive results about position accuracy in relation to jetting distance for different parameter sets of functional inks, drop volumes, and piezo voltages. Additionally, an efficient novel method was applied to determine the drop position accuracy of inkjet droplets in relation to the jetting distance. The method relies on cylinder geometry for the object and an inkjet head that is guided by a six-axis robot manipulator along the cylinder’s axis. For the determination of drop placement accuracy, the position of single dots on the surface was compared to a model which considered the cylinder radii, drop velocity, and the movement speed of the guided inkjet printhead. The method and the extensive research results can be utilized for the prediction of achievable drop placement accuracy and the prior definition of distance limits. Full article
(This article belongs to the Section Advanced Manufacturing)
Show Figures

Figure 1

17 pages, 1841 KiB
Article
Conjugate Heat Transfer in Thermal Inkjet Printheads
by S. G. Mallinson, G. D. McBain and B. R. Brown
Fluids 2023, 8(3), 88; https://doi.org/10.3390/fluids8030088 - 1 Mar 2023
Cited by 3 | Viewed by 2412
Abstract
The mass of individual droplets ejected from a thermal inkjet printhead increases with increasing local temperature near the ejector nozzles. The amount of ink deposited on the page and so the printed image density depends on the droplet mass. Thus, printhead temperature nonuniformity [...] Read more.
The mass of individual droplets ejected from a thermal inkjet printhead increases with increasing local temperature near the ejector nozzles. The amount of ink deposited on the page and so the printed image density depends on the droplet mass. Thus, printhead temperature nonuniformity results in printed image density variations that can be unacceptable to the end users of the printed output. Such temperature variations arise from a combination of the ink fluid flow and the heat transfer in both the ink and the solid components in the printhead. Conjugate heat transfer (CHT) in thermal inkjet printheads is investigated here using validated numerical simulations. A typical thermal inkjet printhead is considered here for the first time, with cold ink drawn through the solid structural components by the ejector nozzle refill. The effect of the width of the feedhole above the printhead chip on the temperature field within the chip is analyzed. Validation of the simulation model required the derivation of novel analytical solutions for the relatively simple problems of fully developed forced convection in a differentially heated planar channel and conduction against convection in plug flow. The results from numerical simulations of these two problems are found to compare well with the newly derived analytical solutions. CHT in flow over a backward-facing step with a heated downstream wall was also simulated as part of the validation process, and good agreement was observed with earlier numerical studies. For the main part of the study, it was found that increasing the width of the feedhole reduces the gradients in temperature on the surface of the printhead chip, thus reducing temperature-related printing defects. Full article
Show Figures

Figure 1

18 pages, 4118 KiB
Article
Influence of the Volatility of Solvent on the Reproducibility of Droplet Formation in Pharmaceutical Inkjet Printing
by Robert Mau and Hermann Seitz
Pharmaceutics 2023, 15(2), 367; https://doi.org/10.3390/pharmaceutics15020367 - 21 Jan 2023
Cited by 7 | Viewed by 2738
Abstract
Drop-on-demand (DOD) inkjet printing enables exact dispensing and positioning of single droplets in the picoliter range. In this study, we investigate the long-term reproducibility of droplet formation of piezoelectric inkjet printed drug solutions using solvents with different volatilities. We found inkjet printability of [...] Read more.
Drop-on-demand (DOD) inkjet printing enables exact dispensing and positioning of single droplets in the picoliter range. In this study, we investigate the long-term reproducibility of droplet formation of piezoelectric inkjet printed drug solutions using solvents with different volatilities. We found inkjet printability of EtOH/ASA drug solutions is limited, as there is a rapid forming of drug deposits on the nozzle of the printhead because of fast solvent evaporation. Droplet formation of c = 100 g/L EtOH/ASA solution was affected after only a few seconds by little drug deposits, whereas for c = 10 g/L EtOH/ASA solution, a negative affection was observed only after t = 15 min, while prominent drug deposits form at the printhead tip. Due to the creeping effect, the crystallizing structures of ASA spread around the nozzle but do not clog it necessarily. When there is a negative affection, the droplet trajectory is affected the most, while the droplet volume and droplet velocity are influenced less. In contrast, no formation of drug deposits could be observed for highly concentrated, low volatile DMSO-based drug solution of c = 100 g/L even after a dispensing time of t = 30 min. Therefore, low volatile solvents are preferable to highly volatile solvents to ensure a reproducible droplet formation in long-term inkjet printing of highly concentrated drug solutions. Highly volatile solvents require relatively low drug concentrations and frequent printhead cleaning. The findings of this study are especially relevant when high droplet positioning precision is desired, e.g., drug loading of microreservoirs or drug-coating of microneedle devices. Full article
(This article belongs to the Collection Feature Papers in Pharmaceutical Technology)
Show Figures

Graphical abstract

14 pages, 7092 KiB
Article
Squeeze-Type Piezoelectric Inkjet Printhead Actuating Waveform Design Method Based on Numerical Simulation and Experiment
by Ning Liu, Xianjun Sheng, Mingcong Zhang, Wei Han and Kexin Wang
Micromachines 2022, 13(10), 1695; https://doi.org/10.3390/mi13101695 - 9 Oct 2022
Cited by 13 | Viewed by 2905
Abstract
The piezoelectric inkjet printing technique has been commonly used to produce conductive graphics. In this paper, a trapezoidal waveform design method for squeeze-type piezoelectric inkjet printhead is presented to provide a modified steady ejection and optimal droplet shape, in which a coupled multi-physics [...] Read more.
The piezoelectric inkjet printing technique has been commonly used to produce conductive graphics. In this paper, a trapezoidal waveform design method for squeeze-type piezoelectric inkjet printhead is presented to provide a modified steady ejection and optimal droplet shape, in which a coupled multi-physics model of a piezoelectric inkjet printhead is developed. This research describes the effects of parameters, including rising time tr, falling time tf, and dwelling time td, of the trapezoidal waveform on the pressure at the nozzle through numerical simulations. These parameters are initially optimized based on numerical simulations and further optimized based on experimental results. When the printhead is actuated by the optimized waveform with the tr = 5 µs, td = 10 µs, and tf = 2 µs, the droplets are in optimal shape, and their size is about half the diameter of the nozzle. The experimental results validate the efficacy of this waveform design method, which combines numerical simulation and experiment, as well as demonstrating that ink droplet formation can be studied from the point of pressure variation at the nozzle. Full article
(This article belongs to the Section D3: 3D Printing and Additive Manufacturing)
Show Figures

Figure 1

12 pages, 3800 KiB
Article
Modeling 3D Droplet Movement Using a Drop-on-Demand Inkjet Printhead Model
by Tim Tofan, Sergejus Borodinas, Rimantas Kačianauskas and Raimondas Jasevičius
Processes 2022, 10(8), 1467; https://doi.org/10.3390/pr10081467 - 27 Jul 2022
Cited by 10 | Viewed by 3260
Abstract
This article presents a numerical simulation of a printhead model for drop-on-demand (DoD) inkjet printers. A three-dimensional droplet model is provided for the numerical study of inks, ejection parameters, droplet movement, and the analysis of droplet impacts on the surface. This work is [...] Read more.
This article presents a numerical simulation of a printhead model for drop-on-demand (DoD) inkjet printers. A three-dimensional droplet model is provided for the numerical study of inks, ejection parameters, droplet movement, and the analysis of droplet impacts on the surface. This work is devoted to the analysis of different droplet ejection settings during the printing process, when the behavior of the droplet directly affects the accuracy of the printing process itself. A numerical model was also developed to investigate the effect of various settings on droplet stability, including printhead size and nozzle orifice, motion parameters (pulse strength and droplet ejection amplitude) and fluid properties. The results reflect the behavior of the ink droplet over time. The behavior of the drop was tested at different waveform ejection parameters and a mass turnover was observed. Full article
(This article belongs to the Special Issue Advanced Research and Applications of Inkjet Printing (IJP) Technique)
Show Figures

Figure 1

13 pages, 2709 KiB
Article
A Simple Method for Fabricating Ink Chamber of Inkjet Printheads
by Zheguan Huang, Yang Tang, Zhibin Liu, Xiaofei Zhang, Yan Zhou and Yonglin Xie
Micromachines 2022, 13(3), 455; https://doi.org/10.3390/mi13030455 - 17 Mar 2022
Viewed by 3136
Abstract
The process of fabricating chambers is becoming more important for inkjet printheads. However, there are some problems with the majority of present fabrication methods, such as nozzle structural deformation, blocked chambers, and collapsed chambers. In this paper, we propose a new process for [...] Read more.
The process of fabricating chambers is becoming more important for inkjet printheads. However, there are some problems with the majority of present fabrication methods, such as nozzle structural deformation, blocked chambers, and collapsed chambers. In this paper, we propose a new process for preparing printhead chips by bonding tantalum nitride thin-film heaters and SU-8 chamber film using UV curing optical adhesive. This process simplifies the preparation process of printhead chips and overcomes the limitations of the traditional adhesive bonding process. Firstly, a chamber film was prepared by the molding lithography process based on a PDMS mold. The chamber film was then bonded with the membrane heater by the adhesive bonding process based on film transfer to form a thermal bubble printhead chip. Finally, the chip was integrated with other components to form a thermal inkjet printhead. The results show that the overflow width of bonding interface of 3.10 μm and bonding strength of 3.3 MPa were achieved. In addition, the printhead could stably eject polyvinyl pyrrolidone binder droplets, which are expected to be used for binder-jetting printing of powder such as ceramics, metals, and sand molds. These results might provide new clues to better understand the adhesive bonding process based on film transfer and the new applications of inkjet printheads. Full article
(This article belongs to the Section D1: Semiconductor Devices)
Show Figures

Figure 1

15 pages, 3855 KiB
Article
Numerical Modeling of the Motion and Interaction of a Droplet of an Inkjet Printing Process with a Flat Surface
by Tim Tofan, Harald Kruggel-Emden, Vytautas Turla and Raimondas Jasevičius
Appl. Sci. 2021, 11(2), 527; https://doi.org/10.3390/app11020527 - 7 Jan 2021
Cited by 13 | Viewed by 4801
Abstract
The numerical simulation and analysis of the ejection of an ink droplet through a nozzle as well its motion through air until its contact with a surface and taking up of a stable form is performed. The fluid flow is modeled by the [...] Read more.
The numerical simulation and analysis of the ejection of an ink droplet through a nozzle as well its motion through air until its contact with a surface and taking up of a stable form is performed. The fluid flow is modeled by the incompressible Navier–Stokes equations with added surface tension. The presented model can be solved using either a level set or a phase field method to track the fluid interface. Here, the level set method is used to determinate the interface between ink and air. The presented work concentrates on the demonstration how to check the suitability of ink for inkjet printhead nozzles, for instance, for the use in printers. The results such as velocity, change of size, and volume dependence on time of an ink droplet are presented. Recommendations for the use of specific inks are also given. Full article
Show Figures

Figure 1

15 pages, 27611 KiB
Article
Precision EDM of Micron-Scale Diameter Hole Array Using in-Process Wire Electro-Discharge Grinding High-Aspect-Ratio Microelectrodes
by Zhixiang Zou, Zhongning Guo, Qinming Huang, Taiman Yue, Jiangwen Liu and Xiaolei Chen
Micromachines 2021, 12(1), 17; https://doi.org/10.3390/mi12010017 - 26 Dec 2020
Cited by 15 | Viewed by 3828
Abstract
Micro-electrical discharge machining (micro-EDM) is a good candidate for processing micro-hole arrays, which are critical features of micro-electro-mechanical systems (MEMS), diesel injector nozzles, inkjet printheads and turbine blades, etc. In this study, the wire vibration of the wire electro-discharge grinding (WEDG) system has [...] Read more.
Micro-electrical discharge machining (micro-EDM) is a good candidate for processing micro-hole arrays, which are critical features of micro-electro-mechanical systems (MEMS), diesel injector nozzles, inkjet printheads and turbine blades, etc. In this study, the wire vibration of the wire electro-discharge grinding (WEDG) system has been analyzed theoretically, and, accordingly, an improved WEDG method was developed to fabricate micron-scale diameter and high-aspect-ratio microelectrodes for the in-process micro-EDM of hole array with hole diameter smaller than 20 μm. The improved method has a new feature of a positioning device to address the wire vibration problem, and thus to enhance microelectrodes fabrication precision. Using this method, 14 μm diameter microelectrodes with less than 0.4 μm deviation and an aspect ratio of 142, which is the largest aspect ratio ever reported in the literature, were successfully fabricated. These microelectrodes were then used to in-process micro-EDM of hole array in stainless steel. The effects of applied voltage, current and pulse frequency on hole dimensional accuracy and microelectrode wear were investigated. The optimal processing parameters were selected using response–surface experiments. To improve machining accuracy, an in-process touch-measurement compensation strategy was applied to reduce the cumulative compensation error of the micro-EDM process. Using such a system, micro-hole array (2 × 80) with average entrance diameter 18.91 μm and average exit diameter 17.65 μm were produced in 50 μm thickness stainless steel sheets, and standard deviations of hole entrance and exit sides of 0.44 and 0.38 μm, respectively, were achieved. Full article
Show Figures

Figure 1

13 pages, 2678 KiB
Article
The Research on Multi-Material 3D Vascularized Network Integrated Printing Technology
by Shuai Yang, Hao Tang, Chunmei Feng, Jianping Shi and Jiquan Yang
Micromachines 2020, 11(3), 237; https://doi.org/10.3390/mi11030237 - 25 Feb 2020
Cited by 12 | Viewed by 3749
Abstract
Three-dimensional bioprinting has emerged as one of the manufacturing approaches that could potentially fabricate vascularized channels, which is helpful to culture tissues in vitro. In this paper, we report a novel approach to fabricate 3D perfusable channels by using the combination of extrusion [...] Read more.
Three-dimensional bioprinting has emerged as one of the manufacturing approaches that could potentially fabricate vascularized channels, which is helpful to culture tissues in vitro. In this paper, we report a novel approach to fabricate 3D perfusable channels by using the combination of extrusion and inkjet techniques in an integrated manufacture process. To achieve this, firstly we investigate the theoretical model to analyze influencing factors of structural dimensions of the printed parts like the printing speed, pressure, dispensing time, and voltage. In the experiment, photocurable hydrogel was printed to form a self-supporting structure with internal channel grooves. When the desired height of hydrogel was reached, the dual print-head was switched to the piezoelectric nozzle immediately, and the sacrificial material was printed by the changed nozzle on the printed hydrogel layer. Then, the extrusion nozzle was switched to print the next hydrogel layer. Once the printing of the internal construct was finished, hydrogel was extruded to wrap the entire structure, and the construct was immersed in a CaCl2 solution to crosslink. After that, the channel was formed by removing the sacrificial material. This approach can potentially provide a strategy for fabricating 3D vascularized channels and advance the development of culturing thick tissues in vitro. Full article
(This article belongs to the Special Issue 10th Anniversary of Micromachines)
Show Figures

Figure 1

19 pages, 5099 KiB
Article
Design and Characteristic Analysis of a MEMS Piezo-Driven Recirculating Inkjet Printhead Using Lumped Element Modeling
by Muhammad Ali Shah, Duck-Gyu Lee and Shin Hur
Micromachines 2019, 10(11), 757; https://doi.org/10.3390/mi10110757 - 6 Nov 2019
Cited by 17 | Viewed by 5351
Abstract
The recirculation of ink in an inkjet printhead system keeps the ink temperature and viscosity constant, and leads to the development of a high-performance device. Herein, we propose a recirculating piezo-driven micro-electro-mechanical system (MEMS)-based inkjet printhead that has a pressure chamber, a nozzle, [...] Read more.
The recirculation of ink in an inkjet printhead system keeps the ink temperature and viscosity constant, and leads to the development of a high-performance device. Herein, we propose a recirculating piezo-driven micro-electro-mechanical system (MEMS)-based inkjet printhead that has a pressure chamber, a nozzle, and double restrictors. The design and characteristic analysis are performed using a two-port lumped element model (LEM) to investigate the effect of design parameters on the system responses. Using LEM, the jetting pressure at the pressure chamber, velocity at the nozzle inlet, meniscus pressure, and Helmholtz resonance frequency are predicted and the comparative analysis of the jetting pressure and velocity between LEM and the finite element method (FEM) simulation is conducted to validate our proposed LEM method. Furthermore, the effect of a change in major design parameters on the jetting pressure, velocity, and Helmholtz resonance frequency is analyzed. On the basis of this analysis, the optimized device dimensions are finalized. From our analysis, it is also concluded that the restrictor is more sensitive than the pressure chamber in terms of their variations in depth. As the cross-talk effect can occur due to an array of hundreds or thousands of nozzles, we investigated the effect of a single activated nozzle on the non-activated neighboring nozzles, as well as the effect of multi-activated nozzles on a single central nozzle using our proposed LEM. Full article
(This article belongs to the Section A:Physics)
Show Figures

Figure 1
