Search Results (9)

Old Cairo, also known as Islamic Cairo, is a UNESCO World Heritage Site representing a rich tapestry of history and culture. Today, among various significant aspects, its cultural heritage necessitates the elaboration of a proactive conservation strategy, which should take advantage of the intrinsic support provided by the efforts documented in the literature that have been made in several scientific fields, disciplines, and directions over the years. Most historic religious monumental buildings in Old Cairo, in particular, not only face the effects of local seismic hazards, which are emphasized by damage by past earthquakes, but also suffer the consequences of several influencing parameters that are unique to the Cairo city context. In this sense, it is known that the structural retrofitting of these monumental buildings requires sound knowledge of technical details and criticalities, based on inspections, numerical simulations, the in-field integration of technologies, and laboratory tests. Many other gaps should also be addressed, and a sound conservation strategy should be elaborated on the basis of a multi-target approach, which could account for the structural engineering perspective but also contextualize the retrofit within the state of the art and the evolution of past events. This is the target of the contemporary “Particular Relevance” bilateral Italy–Egypt “CoReng” project, seeking to define a multidisciplinary strategy for conserving Old Cairo’s cultural heritage and focusing primarily on the case study of the Religions Complex. To this end, a review analysis of major oversights and challenges relating to historic monuments in Old Cairo is presented in this paper. Learning from past accidents and experiences is, in fact, the primary supporting basis for elaborating new operational steps and efficient approaches to mitigating challenges and minimizing the consequences of emergency events. As such, this review contribution specifically focuses on the structural vulnerability of historic monumental buildings in Old Cairo, reporting on past efforts, past strategy proposals, research experiences, and trends. Full article

Traditional methods for assessing the stability of rubble mound breakwaters (RMBs) often rely on 2.5D data, which may fall short in capturing intricate changes in the armor units, such as tilting and lateral shifts. Achieving a detailed analysis of RMB geometry typically requires fully 3D methods, but these often hinge on expensive acquisition technologies like terrestrial laser scanning (TLS) or airborne light detection and ranging (LiDAR). This article introduces an innovative approach to evaluate the structural stability of RMBs by integrating UAV-based photogrammetry and the random sample consensus (RANSAC) algorithm. The RANSAC algorithm proves to be an efficient and scalable tool for extracting primitives from point clouds (PCs), effectively addressing challenges presented by outliers and data noise in photogrammetric PCs. Photogrammetric PCs of the RMB, generated using Structure-from-Motion and MultiView Stereo (SfM-MVS) from both pre- and post-storm flights, were subjected to the RANSAC algorithm for plane extraction and segmentation. Subsequently, a spatial proximity criterion was employed to match cuboids between the two time periods. The methodology was validated on the detached breakwater of Cabedelo do Douro in Porto, Portugal, with a specific focus on potential rotations or tilting of Antifer cubes within the protective layer. The results, assessing the effects of the Leslie storm in 2018, demonstrate the potential of our approach in identifying and quantifying structural changes in RMBs. Full article

An investigation into the inspection capabilities of in-field advanced ultrasound detection for use on ultra-thick (20 to 100 mm) glass fibre-reinforced polyester composites is presented. Plates were manufactured using custom moulding techniques, such that delamination flaws were created at calibrated depths. The full matrix capture technique with an on-board total focussing method was used to detect flaws scanned by a 0.5 MHz linear array probe. Flaw through-thickness dimensions were altered to assess the threshold for crack face separation at which delaminations could be identified. Furthermore, part thickness and in-plane flaw dimensions were varied to identify the inspection capability limitations of advanced ultrasonics for thick composites. The results presented in this study demonstrate an inverse relationship between the ability to find delaminations and plate thicknesses, with inspections successful at depths up to 74 mm. When the delamination thickness exhibited surface-to-surface contact, the inspection capability was reduced to 35 mm. There was an exponential decay relationship between the accuracy of the flaw depth measurement and plate thickness, likely due to the necessity of low probe frequencies. The effective inspection depth was determined to be in the range of 1 to 20 times the wavelength. It is speculated that the accuracy of measurements could be improved using probes with novel coupling solutions, and detectors with optimised signal processing/filtration algorithms. Full article

Spectrometers measure diffuse reflectance and create a “molecular fingerprint” of the material under investigation. Ruggedized, small scale devices for “in-field” use cases exist. Such devices might for example be used by companies in the food supply chain for inward inspection of goods. However, their application for the industrial Internet of Things workflows or scientific research is limited due to their proprietary nature. We propose an open platform for visible and near-infrared technology (OpenVNT), an open platform for capturing, transmitting, and analysing spectral measurements. It is built for use in the field, as it is battery-powered and transmits data wireless. To achieve high accuracy, the OpenVNT instrument contains two spectrometers covering a wavelength range of 400–1700 nm. We conducted a study on white grapes to compare the performance of the OpenVNT instrument against the Felix Instruments F750, an established commercial instrument. Using a refractometer as ground truth, we built and validated models to estimate the Brix value. As a quality measure, we used coefficient of determination of the cross-validation ($R^{2}CV$) between the instrument estimation and ground truth. With 0.94 for the OpenVNT and 0.97 for the F750, a comparable $R^{2}CV$ was achieved for both instruments. OpenVNT matches the performance of commercially available instruments at one tenth of the price. We provide an open bill of materials, building instructions, firmware, and analysis software to enable research and industrial IOT solutions without the limitations of walled garden platforms. Full article

Surface quality measures such as roughness, and especially its uncertain character, affect most magnetic non-destructive testing methods and limits their performance in terms of an achievable signal-to-noise ratio and reliability. This paper is primarily focused on an experimental study targeting nuclear reactor materials manufactured from the milling process with various machining parameters to produce varying surface quality conditions to mimic the varying material surface qualities of in-field conditions. From energising a local area electromagnetically, a receiver coil is used to obtain the emitted Barkhausen noise, from which the condition of the material surface can be inspected. Investigations were carried out with the support of machine-learning algorithms, such as Neural Networks (NN) and Classification and Regression Trees (CART), to identify the differences in surface quality. Another challenge often faced is undertaking an analysis with limited experimental data. Other non-destructive methods such as Magnetic Adaptive Testing (MAT) were used to provide data imputation for missing data using other intelligent algorithms. For data reinforcement, data augmentation was used. With more data the problem of ‘the curse of data dimensionality’ is addressed. It demonstrated how both data imputation and augmentation can improve measurement datasets. Full article

Loblolly pine is an economically important timber species in the United States, with almost 1 billion seedlings produced annually. The most significant disease affecting this species is fusiform rust, caused by Cronartium quercuum f. sp. fusiforme. Testing for disease resistance in the greenhouse involves artificial inoculation of seedlings followed by visual inspection for disease incidence. An automated, high-throughput phenotyping method could improve both the efficiency and accuracy of the disease screening process. This study investigates the use of hyperspectral imaging for the detection of diseased seedlings. A nursery trial comprising families with known in-field rust resistance data was conducted, and the seedlings were artificially inoculated with fungal spores. Hyperspectral images in the visible and near-infrared region (400–1000 nm) were collected six months after inoculation. The disease incidence was scored with traditional methods based on the presence or absence of visible stem galls. The seedlings were segmented from the background by thresholding normalized difference vegetation index (NDVI) images, and the delineation of individual seedlings was achieved through object detection using the Faster RCNN model. Plant parts were subsequently segmented using the DeepLabv3+ model. The trained DeepLabv3+ model for semantic segmentation achieved a pixel accuracy of 0.76 and a mean Intersection over Union (mIoU) of 0.62. Crown pixels were segmented using geometric features. Support vector machine discrimination models were built for classifying the plants into diseased and non-diseased classes based on spectral data, and balanced accuracy values were calculated for the comparison of model performance. Averaged spectra from the whole plant (balanced accuracy = 61%), the crown (61%), the top half of the stem (77%), and the bottom half of the stem (62%) were used. A classification model built using the spectral data from the top half of the stem was found to be the most accurate, and resulted in an area under the receiver operating characteristic curve (AUC) of 0.83. Full article

In ultrasonic non-destructive testing, array and matrix transducers are being employed for applications that require in-field steerability or which benefit from a higher number of insonification angles. Having many transmit channels, on the other hand, increases the measurement time and renders the use of array transducers unfeasible for many applications. In the literature, methods for reducing the number of required channels compared to the full matrix capture scheme have been proposed. Conventionally, these are based on choosing the aperture that is as wide as possible. In this publication, we investigate a scenario from the field of pipe inspection, where cracks have to be detected in specific areas near the weld. Consequently, the width of the aperture has to be chosen according to the region of interest at hand. On the basis of ray-tracing simulations which incorporate a model of the transducer directivity and beam spread at the interface, we derive application specific measures of the energy distribution over the array configuration for given regions of interest. These are used to determine feasible subsampling schemes. For the given scenario, the validity/quality of the derived subsampling schemes are compared on the basis of reconstructions using the conventional total focusing method as well as sparsity driven-reconstructions using the Fast Iterative Shrinkage-Thresholding Algorithm. The results can be used to effectively improve the measurement time for the given application without notable loss in defect detectability. Full article

Non-contact optical detection of ultrasound critically depends on the amount of light collected from the detection surface. Although it can be optimized in multiple ways for an ideal flat polished surface, industrial non-destructive testing and evaluation (NDT&E) usually requires optical detectors to be robust for unpolished material surfaces that are usually rough and curved. Confocal detectors provide the best light collection but must trade off sensitivity with depth of field. Specifically, detection efficiency increases with the numerical aperture (NA) of the detector, but the depth of field drops. Therefore, fast realignment of the detector focal point is critical for in-field applications. Here, we propose an optical distance and angle correction system (DACS) and demonstrate it in a kHz-rate laser-ultrasound inspection system. It incorporates a Sagnac interferometer on receive for the fast scanning of aircraft composites, which minimizes the required initial alignment. We show that DACS performs stably for different composite surfaces while providing ±2° angular and ±2 mm axial automatic correction with a maximum 100 ms realignment time. Full article

Surface damage on honeycomb aircraft panels is often measured manually, and is therefore subject to variation based on inspection personnel. Eddy current testing (ECT) is sensitive to variations in probe-to-specimen spacing, or lift-off, and is thus promising for high-resolution profiling of surface damage on aluminum panels. Lower frequency testing also allows inspection through the face sheet, an advantage over optical 3D scanning methods. This paper presents results from the ECT inspection of surface damage on an approximately flat aluminum honeycomb aircraft panel, and compares the measurements to those taken using optical 3D scanning technology. An ECT C-Scan of the dented panel surface was obtained by attaching the probe to a robotic scanning apparatus. Data was taken simultaneously at four frequencies of 25, 100, 400 and 1600 kHz. A reference surface was then defined that approximated the original, undamaged panel surface, which also compensated for the effects of specimen tilt and thermal drift within the ECT instrument. Data was converted to lift-off using height calibration curves developed for each probe frequency. A damage region of 22,550 mm² area with dents ranging in depth from 0.13–1.01 mm was analyzed. The method was accurate at 1600 kHz to within 0.05 mm (2σ) when compared with 231 measurements taken via optical 3D scanning. Testing at 25 kHz revealed a 3.2 mm cell size within the honeycomb core, which was confirmed via destructive evaluation. As a result, ECT demonstrates potential for implementation as a method for rapid in-field aircraft panel surface damage assessment. Full article
