As micron-sized objects, mobile microrobots have shown significant potential for future biomedical applications, such as targeted drug delivery and minimally invasive surgery. However, to make these microrobots viable for clinical applications, several crucial aspects should be implemented, including customizability, motion-controllability, imageability, biodegradability, and biocompatibility. Developing materials to meet these requirements is of utmost importance. Here, a gelatin methacryloyl (GelMA) and (2-(4-vinylphenyl)ethene-1,1,2-triyl)tribenzene (TPEMA)-based multifunctional hydrogel with 3D printability, fluorescence imageability, biodegradability, and biocompatibility is demonstrated. By using 3D direct laser writing method, the hydrogel exhibits its versatility in the customization and fabrication of 3D microstructures. Spherical hydrogel microrobots were fabricated and decorated with magnetic nanoparticles on their surface to render them magnetically responsive, and have demonstrated excellent movement performance and motion controllability. The hydrogel microstructures also represented excellent drug loading/release capacity and degradability by using collagenase, along with stable fluorescence properties. Moreover, cytotoxicity assays showed that the hydrogel was non-toxic, as well as able to support cell attachment and growth, indicating excellent biocompatibility of the hydrogel. The developed multifunctional hydrogel exhibits great potential for biomedical microrobots that are integrated with customizability, 3D printability, motion controllability, drug delivery capacity, fluorescence imageability, degradability, and biocompatibility, thus being able to realize the real in vivo biomedical applications of microrobots. Full article

In recent years, the field of microrobots has exploded, yielding many exciting new functions and applications, from object grasping and release to in vivo drug transport. Smart responsive materials have had a profound impact on the field of microrobots and have given them unique functions and structures. We analyze three aspects of microrobots, in which the future development of microrobots requires more efforts to be invested, and in which smart materials play a significant role in the development of microrobots. These three aspects are smart materials for building microrobots, manufacturing methods, and the functions and applications they achieve. In this review, we discuss the deformation mechanism of materials in response to external stimuli, starting from smart materials, and discuss fabrication methods to realize microrobots, laying the theoretical foundation for future smart material-based microrobots to realize their intelligence and programmability. Full article

As one of the most significant research topics in robotics, microrobots hold great promise in biomedicine for applications such as targeted diagnosis, targeted drug delivery, and minimally invasive treatment. This paper proposes an enhanced YOLOv5 (You Only Look Once version 5) microrobot detection and tracking system (MDTS), incorporating a visual tracking algorithm to elevate the precision of small-target detection and tracking. The improved YOLOv5 network structure is used to take magnetic bodies with sizes of 3 mm and 1 mm and a magnetic microrobot with a length of 2 mm as the pretraining targets, and the training weight model is used to obtain the position information and motion information of the microrobot in real time. The experimental results show that the accuracy of the improved network model for magnetic bodies with a size of 3 mm is 95.81%, representing an increase of 2.1%; for magnetic bodies with a size of 1 mm, the accuracy is 91.03%, representing an increase of 1.33%; and for microrobots with a length of 2 mm, the accuracy is 91.7%, representing an increase of 1.5%. The combination of the improved YOLOv5 network model and the vision algorithm can effectively realize the real-time detection and tracking of magnetically controlled microrobots. Finally, 2D and 3D detection and tracking experiments relating to microrobots are designed to verify the robustness and effectiveness of the system, which provides strong support for the operation and control of microrobots in an in vivo environment. Full article

Magnetic microrobots, with their small size and agile maneuverability, are well-suited for navigating the intricate and confined spaces within the human body. In vivo cargo delivery within the context of microrobotics involves the use of microrobots to transport and administer drugs and cells directly to the targeted regions within a living organism. The principal aim is to enhance the precision, efficiency, and safety of therapeutic interventions. Despite their potential, there is a shortage of comprehensive reviews on the use of magnetic microrobots for in vivo cargo delivery from both research and engineering perspectives, particularly those published after 2019. This review addresses this gap by disentangling recent advancements in magnetic microrobots for in vivo cargo delivery. It summarizes their actuation platforms, structural designs, cargo loading and release methods, tracking methods, navigation algorithms, and degradation and retrieval methods. Finally, it highlights potential research directions. This review aims to provide a comprehensive summary of the current landscape of magnetic microrobot technologies for in vivo cargo delivery. It highlights their present implementation methods, capabilities, and prospective research directions. The review also examines significant innovations and inherent challenges in biomedical applications. Full article

Due to their enormous potential to be navigated through complex biological media or narrow capillaries, microrobots have demonstrated their potential in a variety of biomedical applications, such as assisted fertilization, targeted drug delivery, tissue repair, and regeneration. Numerous initial studies have been conducted to demonstrate the biomedical applications in test tubes and in vitro environments. Microrobots can reach human areas that are difficult to reach by existing medical devices through precise navigation. Medical imaging technology is essential for locating and tracking this small treatment machine for evaluation. This article discusses the progress of imaging in tracking the imaging of micro and nano robots in vivo and analyzes the current status of imaging technology for microrobots. The working principle and imaging parameters (temporal resolution, spatial resolution, and penetration depth) of each imaging technology are discussed in depth. Full article

Single-cell microrobots are new microartificial devices that use a combination of single cells and artificial devices, with the advantages of small size, easy degradation and ease of manufacture. With externally driven strategies such as light fields, sound fields and magnetic fields, microrobots are able to carry out precise micromanipulations and movements in complex microenvironments. Therefore, single-cell microrobots have received more and more attention and have been greatly developed in recent years. In this paper, we review the main classifications, control methods and recent advances in the field of single-cell microrobot applications. First, different types of robots, such as cell-based microrobots, bacteria-based microrobots, algae-based microrobots, etc., and their design strategies and fabrication processes are discussed separately. Next, three types of external field-driven technologies, optical, acoustic and magnetic, are presented and operations realized in vivo and in vitro by applying these three technologies are described. Subsequently, the results achieved by these robots in the fields of precise delivery, minimally invasive therapy are analyzed. Finally, a short summary is given and current challenges and future work on microbial-based robotics are discussed. Full article

During recent years, microrobots have drawn extensive attention owing to their good controllability and great potential in biomedicine. Powered by external physical fields or chemical reactions, these untethered microdevices are promising candidates for in vivo complex tasks, such as targeted delivery, imaging and sensing, tissue engineering, hyperthermia, and assisted fertilization, among others. However, in clinical use, the biodegradability of microrobots is significant for avoiding toxic residue in the human body. The selection of biodegradable materials and the corresponding in vivo environment needed for degradation are increasingly receiving attention in this regard. This review aims at analyzing different types of biodegradable microrobots by critically discussing their advantages and limitations. The chemical degradation mechanisms behind biodegradable microrobots and their typical applications are also thoroughly investigated. Furthermore, we examine their feasibility and deal with the in vivo suitability of different biodegradable microrobots in terms of their degradation mechanisms; pathological environments; and corresponding biomedical applications, especially targeted delivery. Ultimately, we highlight the prevailing obstacles and perspective solutions, ranging from their manufacturing methods, control of movement, and degradation rate to insufficient and limited in vivo tests, that could be of benefit to forthcoming clinical applications. Full article

Targeted drug delivery using microrobots manipulated by an external actuator has significant potential to be a practical approach for wireless delivery of therapeutic agents to the targeted tumor. This work aimed to develop a novel acoustic manipulation system and macrophage-based microrobots (Macbots) for a study in targeted tumor therapy. The Macbots containing superparamagnetic iron oxide nanoparticles (SPIONs) can serve as drug carriers. Under an acoustic field, a microrobot cluster of the Macbots is manipulated by following a predefined trajectory and can reach the target with a different contact angle. As a fundamental validation, we investigated an in vitro experiment for targeted tumor therapy. The microrobot cluster could be manipulated to any point in the 4 × 4 × 4 mm region of interest with a position error of less than 300 μm. Furthermore, the microrobot could rotate in the O-XY plane with an angle step of 45 degrees without limitation of total angle. Finally, we verified that the Macbots could penetrate a 3D tumor spheroid that mimics an in vivo solid tumor. The outcome of this study suggests that the Macbots manipulated by acoustic actuators have potential applications for targeted tumor therapy. Full article

Approaches to studying electromagnetic induction in weak coupling have recently received attention in robotics since they could be used to supply energy to robots, allowing robots to diagnose and treat diseases in the human body. A three-dimensional orthogonal receiving coil connected in parallel, with a size of 13 mm × 13 mm × 13 mm, for an intestinal examination microrobot is designed in this article. Based on the defined attitude functions, we build and verify the stability and effectiveness of the proposed coil model through both analytical calculation and simulation analysis. In addition, to supply enough power to the microrobot, the number of turns of the receiving coil is optimized, considering both the electrical coil parameters and the limited space inside the robot. Then, an evaluation of the proposed 3D orthogonal receiving coil is presented in the bench tests. The results show that the power transmission efficiency can reach as high as 9.6%, with 1271 mW. This paper also uses a curved pipe to simulate the robot’s movement with the designed coil in the tortuous intestine. The average speed is 0.97 mm/s, with the path covering 180°. The experiments illustrate the excellent performance of the wireless power transmission, even when the positions of the two induction coils are constantly changing. Full article

Microscopic swarms consisting of, e.g., active colloidal particles or microorganisms, display emergent behaviors not seen in equilibrium systems. They represent an emerging field of research that generates both fundamental scientific interest and practical technological value. This review seeks to unite the perspective of fundamental active matter physics and the perspective of practical applications of microscopic swarms. We first summarize experimental and theoretical results related to a few key aspects unique to active matter systems: the existence of long-range order, the prediction and observation of giant number fluctuations and motility-induced phase separation, and the exploration of the relations between information and order in the self-organizing patterns. Then we discuss microscopic swarms, particularly microrobotic swarms, from the perspective of applications. We introduce common methods to control and manipulate microrobotic swarms and summarize their potential applications in fields such as targeted delivery, in vivo imaging, biofilm removal, and wastewater treatment. We aim at bridging the gap between the community of active matter physics and the community of micromachines or microrobotics, and in doing so, we seek to inspire fruitful collaborations between the two communities. Full article

Nano/microrobots (NMRs) are tiny devices that can convert energy into motion and operate at nano/microscales.54 Especially in biomedical research, NMRs have received much attention over the past twenty years because of their excellent capabilities and great potential in various applications, including on-demand drug delivery, gene and cell transport, and precise microsurgery. Reports published in recent years show that synthetic nano/microrobots have promising potential to function in the gastrointestinal (GI) region, particularly in terms of drug delivery. These tiny robots were able to be designed in such a way that they propel in their surroundings (biological media) with high speed, load cargo (drug) efficiently, transport it safely, and release upon request successfully. Their propulsion, retention, distribution, and toxicity in the GI tract of mice has been evaluated. The results envisage that such nano/microrobots can be further modified and developed as a new-generation treatment of GI tract diseases. In this minireview, we focus on the functionality of micro/nanorobots as a biomedical treatment system for stomach/intestinal diseases. We review the research progress from the first in vivo report in December 2014 to the latest in August 2021. Then, we discuss the treatment difficulties and challenges in vivo application (in general) and possible future development routes. Full article

Magnetic micro- and nanoparticles (MPs)-based composite materials are widely used in various applications in electronics, biotechnology, and medicine. This group of silicone composites have advantageous magnetic and mechanical properties as well as sufficient flexibility and biocompatibility. These composites can be applied in medicine for biological sensing, drug delivery, tissue engineering, and as remote-controlled microrobots operating in vivo. In this work, the properties of polydimethylsiloxane (PDMS)-based composites with different percentages (30 wt.%, 50 wt.%, 70 wt.%) of NdFeB microparticles as a filler were characterized. The novelty of the work was to determine the influence of the percentage of MP content and physiological conditioning on the properties of the PDMS-MP composites after in vitro incubation. An important essence of the work was a comprehensive study of the properties of materials important from the point of view of medical applications. Materials were tested before and after conditioning in 0.9 wt.% NaCl solution at a temperature of 37 °C. Several studies were carried out, including thermal, physicochemical, and rheological tests. The results show that with an increase of the incubation time, most of the measured thermal and physicochemical parameters decreased. The presence of the magnetic filler, especially at a concentration of 70 wt.%, has a positive effect on thermal stability and physicochemical and rheological properties. The performed tests provided important results, which can lead to further research for a broader application of magnetic composites in the biomedical field. Full article

Microrobots have received great attention due to their great potential in the biomedical field, and there has been extraordinary progress on them in many respects, making it possible to use them in vivo clinically. However, the most important question is how to get microrobots to a given position accurately. Therefore, autonomous actuation technology based on medical imaging has become the solution receiving the most attention considering its low precision and efficiency of manual control. This paper investigates key components of microrobot’s autonomous actuation systems, including actuation systems, medical imaging systems, and control systems, hoping to help realize system integration of them. The hardware integration has two situations according to sharing the transmitting equipment or not, with the consideration of interference, efficiency, microrobot’s material and structure. Furthermore, system integration of hybrid actuation and multimodal imaging can improve the navigation effect of the microrobot. The software integration needs to consider the characteristics and deficiencies of the existing actuation algorithms, imaging algorithms, and the complex 3D working environment in vivo. Additionally, considering the moving distance in the human body, the autonomous actuation system combined with rapid delivery methods can deliver microrobots to specify position rapidly and precisely. Full article

In the last few decades, the introduction of microrobotics has drastically changed the way medicine will be approached in the future. The development of untethered steerable microdevices able to operate in vivo inside the human body allows a high localization of the therapeutical action, thus limiting invasiveness and possible medical complications. This approach results are particularly useful in drug delivery, where it is highly beneficial to administer the drug of choice exclusively to the target organ to avoid overdosage and side effects. In this context, drug releasing layers can be loaded on magnetically moveable platforms that can be guided toward the target organ to perform highly targeted release. In the present paper, we evaluate the possible application of alginate hydrogel layers on moveable platforms manufactured by coupling additive manufacturing with wet metallization. Such alginate layers are reticulated using three different physical crosslinkers: Ca, Zn or Mn. Their effect on drug release kinetics and on device functionality is evaluated. In the case of alginate reticulated using Mn, the strongly pH dependent behavior of the resulting hydrogel is evaluated as a possible way to introduce a triggered release functionality on the devices. Full article

Magnetic microrobots with versatile mechanical motion will enable many ex- and in vivo applications. Unfortunately, monolithic integration of multiple functions in a streamlined microrobotic body is still challenging due to the compromise between fabrication throughput, device footprints, and material choices. In this talk, I will present a unified framework architecture for microrobotic functionalization to enable magnetically steered locomotion, chemical sensing and in vivo tracking. This has been achieved through stratifying stimuli-responsive nanoparticles in a hydrogelmicro-disk. We uncovered the key mechanism of leveraging spatially alternating magnetic energy potential to control a Euler’s disk-like microrobot to locomote swiftly on its sidewall. The results suggest great potential for microrobots to locomote while cooperating a wide range of functions, tailorable for universal application scenarios. Full article
