Adobe churches are representative of Andean architectural heritage, yet their structural vulnerability to seismic events remains a significant concern. This study evaluates the seismic performance of the 17th-century Church of Santo Tomás de Aquino in Rondocan, Peru, an adobe building that underwent conservation work in the late 1990s. The assessment combines in situ inspections and experimental testing with advanced nonlinear numerical modeling. A finite-element macro-model was developed and calibrated using sonic and ambient vibration tests to replicate the observed structural behavior. Nonlinear static (pushover) analyses were performed in the four principal directions to identify failure mechanisms and to evaluate seismic capacity using the Peruvian seismic code. Kinematic limit analyses were conducted to assess out-of-plane mechanisms using force- and displacement-based criteria. The results revealed critical vulnerabilities in the rear façade and lateral walls, particularly in terms of out-of-plane collapse, while the main façade exhibited a higher capacity but a brittle failure mode. This study illustrates the value of advanced numerical simulations, calibrated with field data, as effective tools for assessing seismic vulnerability in historic adobe buildings. The outcomes highlight the necessity of strengthening measures to balance life safety requirements with preservation goals. Full article

This paper is focused on the numerical evaluation of the equivalent damping ratio (EDR) given by a dissipative wood-based roof diaphragm in the seismic retrofitting of single-nave historical churches. In the design phase, the EDR could be a key parameter to select the optimal roof structure configuration, thereby obtaining the maximum energy dissipation. In this way, the roof structure works as a damper to facilitate a box behavior of the structure during the seismic response. The EDR measures the energy dissipated by the nonlinear behavior of the roof’s steel connections and masonry walls during seismic events. In a preliminary retrofitting design phase, an initial implementation of the geometries of the walls and the chosen geometry for the roof is carried out by adopting an equivalent frame model (FEM) with inelastic rotational hinges for the nonlinear properties of the masonry walls and inelastic shear hinges for the nonlinear behavior of the roof’s steel connections. Since, for historical churches, the transversal response under seismic events is the worst situation for the single-nave configuration, the earthquake is applied as transversal accelerograms. In this way, the damped rocking of the perimeter walls due to the dissipative roof diaphragm can be described in terms of a hysteretic variable. By varying the value of the hysteretic variable, possible configurations of the roof diaphragm are tested in the design phase, considering the different shear deformation values of the inelastic hinges of the roof. Under these hypotheses, the EDR is evaluated by performing nonlinear Time History analyses based on the cyclic behavior of the inelastic hinges of the roof, the strain energy contribution due to the walls, and the lateral displacements of the structure. The EDR values obtained with the Time History method are compared with those obtained by applying the Capacity Spectrum Method by performing nonlinear static analyses, either for the coefficient method of FEMA 356 or the equivalent linearization technique of ATC-40. The EDR evaluations are performed by considering the following different hysteretic behaviors of the roof’s steel connections: the skeleton curves with stiffness degradation and the trilinear model with strength and stiffness degradation. Finally, the variation in the EDR values as a function of the hysteretic variable is presented as well so to evaluate if the maximum EDR value corresponds to the optimal value of the hysteretic variable able to reduce the lateral displacements and to contain the shear forces acting on the roof and the façade under a safety limit. Full article

In 2015, hazard mitigation became a top priority on the international agenda, according to the United Nations Office for Disaster Risk Reduction. When it comes to architectural heritage, it is crucial to develop tools and site-specific response plans that can help the prompt and effective management of seismic events. The paper presents part of a research study carried out at the University of Parma, aimed at improving emergency strategies for the protection of cultural heritage damaged by earthquakes. Specifically, it analyses first aid and recovery reinforcements, with a specific focus on masonry churches affected by the 2012 quake in the Emilia Romagna region (Italy). The study highlights criticalities and good practices of a site-specific response. It shows that recovery with a sharp separation between emergency and reconstruction activities leads to wasted resources in terms of cost, material, and time. On the other hand, the most effective strategies for the conservation of architectural heritage in earthquake-prone areas have proved to be based on an integrated and shared approach, aimed at balancing safety, conservation, and economic issues. This leads to a broadening of the concept of emergency interventions and, more generally, of structural reinforcement in the field of architectural conservation. Full article

The Church of Panaghia Krena is a very important Byzantine monument situated in the island of Chios, well-known due to the high aesthetic value of the ceramic tile decoration on its facades and of its frescoes. The church suffered severe damage especially due to the 1881 devastating Chios earthquake and different interventions were implemented soon after (1884), consisting mainly of the reconstruction of collapsed areas and the addition of ties. Nevertheless, deterioration of old damages and appearance of new ones was observed. Thus, a restoration program was carried out between 2000 and 2007. This paper presents the basic characteristics of all types of historic materials examined, the main results of the in situ and laboratory experimental program carried out for the selection of the raw materials, and the design of optimum compositions of mortars and grouts to be used for the restoration works. The importance of in situ pilot applications is underlined, as well as of the production of site-specific aggregates for the repointing mortars by crushing a local rock, in order to succeed the adequate reddish color to match with the original mortars and bricks still preserved and achieve an aesthetic harmony with the color hue and texture of the original materials. Full article

This study provides insight into the structural assessment, diagnosis, and strengthening of the medieval church of Tazlău Monastery in Piatra Neamț, Romania. The first part of the paper briefly presents the wider context of strengthening and preserving heritage churches and monastic buildings and describes the architectural setting and the structural features of the traditional Romanian Orthodox churches. The second part of the paper is a case study related to the rehabilitation of a medieval heritage church, which is the paramount building of a larger monastic complex. Erected in 1496, the church of the Nativity of the Blessed Virgin Mary closely follows the medieval traditional Orthodox patterns from both architectural and structural points of view. Structural assessment and diagnosis revealed that degradations were induced and developed throughout the life of the structure due to approximately 24 earthquakes (estimated at over 6.0 magnitude) having endangered the structural safety of the building and the mural iconography. After the structural diagnosis, a combined and complex method of strengthening consisting of both grouting and introducing steel rods in vertically drilled galleries along the entire height of the walls was selected. The main advantage of applying this combined strengthening strategy was a remarkable enhancement of the structural seismic performance of the church building. Full article

The complexity of historical urban centres progressively needs a strategic improvement in methods and the scale of knowledge concerning the vulnerability aspect of seismic risk. A geographical multi-scale point of view is increasingly preferred in the scientific literature and in Italian regulation policies, that considers systemic behaviors of damage and vulnerability assessment from an urban perspective according to the scale of the data, rather than single building damage analysis. In this sense, a geospatial data sciences approach can contribute towards generating, integrating, and making virtuous relations between urban databases and emergency-related data, in order to constitute a multi-scale 3D database supporting strategies for conservation and risk assessment scenarios. The proposed approach developed a vulnerability-oriented GIS/HBIM integration in an urban 3D geodatabase, based on multi-scale data derived from urban cartography and emergency mapping 3D data. Integrated geometric and semantic information related to historical masonry buildings (specifically the churches) and structural data about architectural elements and damage were integrated in the approach. This contribution aimed to answer the research question supporting levels of knowledge required by directives and vulnerability assessment studies, both about the generative workflow phase, the role of HBIM models in GIS environments and toward user-oriented webGIS solutions for sharing and public use fruition, exploiting the database for expert operators involved in heritage preservation. Full article

Religious practice in Serbia has taken place using both indoors and outdoors sacred sites ever since the adoption of Christianity in medieval times. However, previous archaeoacoustic research was focused on historic church acoustics, excluding the open-air soundscapes of sacred sites. The goal of this review paper is to shed light on the varieties of sacred soundscapes that have supported the various needs of Orthodox Christian practice in medieval Serbia. First, in relation to the acoustic requirements of the religious service, we compare the acoustic properties of masonry and wooden churches based on the published archaeoacoustic studies of medieval churches and musicological studies of the medieval art of chanting. Second, we provide an overview of the ethnological and historical studies that address the outdoor sacred soundscapes and investigate the religious sound markers of large percussion instruments, such as bells and semantra, the open-air litany procession that has been practiced during the annual celebration of a patron saint’s day in rural areas, and the medieval assemblies that took place on the sacred sites. This paper finally points out that the archaeoacoustic studies of sacred soundscapes should not be limited to church acoustics but also include open-air sacred sites to provide a complete analysis of the aural environment of religious practice and thus contribute to understanding the acoustic intention of medieval builders, as well as the aural experience of both clergy and laity. Full article

The seismic sequence occurring in Central Italy in 2016 represents a new test benchmark for historical masonry churches and a chance for a better comprehension of their structural behavior under earthquake actions. The many earthquakes that took place in the past have led to stratifications of repair and retrofitting interventions that sometimes worsened the structural behavior, especially when resulting in the introduction of elements not compatible with the churches’ original layout. Within this framework, the present paper intends to provide a critical review of the main interventions carried out in the churches of Central Italy for mitigating their seismic vulnerability and to evaluate their effectiveness in light of the damage surveyed on a representative sample of masonry churches after the 2016–2017 seismic sequence. The work is organized into three parts: (1) historical analysis of the territory; (2) review of the featured interventions; (3) critical appraisal of the interventions in relation to the surveyed data and assessment of their effectiveness. The goal of the work is to shed light on the correct design of retrofitting interventions in ancient masonry structures in order to enhance the structural safety of such artefacts without compromising their historical and cultural value. Full article

This paper presents the results of the application of a holistic procedure for a seismic vulnerability analysis of complex masonry aggregates which are ascribable as cultural heritage buildings. The methodological framework allowed us to properly identify the structural units comprising a historical palace through a hierarchical approach combining integrated geometrical and structural surveys with non-destructive (ND) and minor destructive (MD) techniques. The investigations were conducted on a significant palace located in the historical center of Florence, the Palagio di Parte Guelfa. The building covers an entire urban block, as it is constituted by many structural units developed over the centuries since the Roman period. The palace incorporates pre-existing structures, such as the Church of Santa Maria Sopra Porta and medieval terraced houses. Over the decades, different restorations and renovations have been carried out, including by Filippo Brunelleschi in the XV century and by Vasari in the XVI. Nowadays, the building constitutes an urban cluster. Our seismic vulnerability analysis took advantage of a specific knowledge path which was suitable for the identification of the different structural units of the palace. To this end, the historical evolution of the construction was traced through bibliographic research and ND surveys. We finally assessed the seismic performance of the different units according to different approaches, i.e., a rapid assessment based on simplified computations at the global scale, and a kinematic analysis for local phenomena. Full article

The concepts of structural assessment and retrofit of historical constructions are of particular complexity and require advanced knowledge in material science, conservation techniques and structural analysis. In particular, adobe constructions, given their low mechanical properties and brittle failure modes, are in immense need of comprehensive assessment and retrofitting plans. The current work focuses on the adobe Church of Kuñotambo in Peru, having experienced long periods of deterioration and earthquake-related damage. Under the ongoing Seismic Retrofitting Project (SRP) of the Getty Conservation Institute (GCI), the structural assessment of the church initiated in 2015 confirmed the low lateral capacity of the building and the poor connectivity between the structural parts. Based on the existing cracks and damage, a strengthening scheme was optimized and validated. After the implementation of the retrofitting plan, the quality of its execution and efficiency were assessed in 2019 with a new in situ campaign, which included ambient vibration testing (AVT) and sonic testing. From the acquired field data, the FE model of the retrofitted church was optimized, by updating the stiffness properties of masonry and discontinuities. Moreover, nonlinear static analyses were performed on the updated model in all in-plan directions. Finally, a displacement-based performance assessment was undertaken, under different earthquake limit states, demonstrating the adequacy of the retrofitting. Full article

The structural analysis of historic masonry churches subject to earthquakes is commonly based on two distinct approaches: that of the global response to seismic actions and that of the local analysis of a priori pre-determined collapse mechanisms. This is a conventional decoupling of the structural problem due to the difficulty of addressing the seismic vulnerability of individual parts from the modelling of the whole. The aim of this work is to establish a link between the global behavior of the church and the assessment of the local mechanisms, re-evaluating the value of modal analysis to be associated with non-linear seismic assessment. With this aim, a two steps procedure is proposed, where: the first step is based on the detection of the main vibration modes of the whole building with identification of the structural bi-dimensional macro-elements that are responsible for the overall seismic vulnerability, while the second step, is based on the non-linear finite element analysis of the previously identified macro-elements, to evaluate the failure pattern caused by the earthquakes. The procedure will applied to the case study of the Casamari Gothic church in Veroli (Italy). Full article

The recent improvement of infrared image quality has increased the use of thermography as a non-destructive diagnostic technique. Amongst other applications, thermography can be used to monitor historic buildings. The present work was carried out within the framework of the Horizon 2020 European project SHELTER, which aims to create a management plan for cultural heritage subject to environmental and anthropogenic risk. Among the chosen case studies is the Santa Croce Complex in Ravenna (Italy), which is exposed to different hazards, including flooding. The church has a peculiar architecture that develops below the street level, so the internal walls are affected by the deterioration caused by rising humidity. In such a case of advanced degradation, passive thermography cannot be used to its full potential. For this reason, an innovative methodology involving active thermography was first developed and validated with laboratory tests. Secondly, we conducted its first application to a real case study. With this purpose, an active thermography survey with forced ventilation was carried out to enhance different stages of material degradation by means of automatic classification of multitemporal data. These experiments have resulted in a method using an active thermal survey in a high moisture content environment to detect masonry degradation. Full article

Analysis and diagnosis of historical masonry buildings are frequently affected by uncertainties due to unexpected behaviors caused by cumulative damage, material decay or transformations. This research work follows a methodology in the structural analysis of the historical masonry church of San Filippo Neri in Macerata, severely damaged after the Central Italy Earthquake occurred in October 2016. The PRiSMa laboratory (Proof testing and Research in Structures and Materials) of Roma Tre University carried out an extensive onsite testing campaign, including NDT tests as sonic tomography and endoscopy, and minor destructive technique as double flat jack test, together with dynamic monitoring under ambient vibrations, to investigate the state of conservation of the building. The onsite testing results were then implemented in an accurate finite element model, which was tuned up by means of global dynamic response provided by OMA (operational modal analysis) and updated, after the sensitivity analysis, through the Douglas-Reid method. Finally, nonlinear static and dynamic analyses were performed to investigate the state of damage of the church and reduce its uncertainties. This methodology will support the design of strengthening measures to achieve a higher level of safety concerning both needs of protection and conservation, thereby avoiding ineffectual or amiss interventions. Full article

The present manuscript deals with the seismic vulnerability assessment of existing masonry churches, which is a fundamental process for risk and consequent prioritization analyses, as well as application of effective retrofitting strategies. In the past, different approaches with various levels of accuracy and application ranges have been developed to assess the vulnerability to damage of such structures in case of seismic events. Based on the classification provided in the Italian Guidelines for the Cultural Heritage, in this paper a review of seismic vulnerability assessment methodologies for existing masonry churches is presented. The main goal of the current study is to provide a critical comparative overview about these procedures, highlighting the main issues related to the application of each detail level. Moreover, particular attention is focused on the applications present in literature, allowing for the definition of a potential systematic procedure for smart management policy aimed at preserving cultural, architectural and historical heritage. Full article

Historic masonry buildings are characterised by uniqueness, which is intrinsically present in their building techniques, morphological features, architectural decorations, artworks, etc. From the modelling point of view, the degree of detail reached on transforming discrete digital representations of historic buildings, e.g., point clouds, into 3D objects and elements strongly depends on the final purpose of the project. For instance, structural engineers involved in the conservation process of built heritage aim to represent the structural system rigorously, neglecting architectural decorations and other details. Following this principle, the software industry is focusing on the definition of a parametric modelling approach, which allows performing the transition from half-raw survey data (point clouds) to geometrical entities in nearly no time. In this paper, a novel parametric Scan-to-FEM approach suitable for architectural heritage is presented. The proposed strategy uses the Generative Programming paradigm implementing a modelling framework into a visual programming environment. Such an approach starts from the 3D survey of the case-study structure and culminates with the definition of a detailed finite element model that can be exploited to predict future scenarios. This approach is appropriate for architectural heritage characterised by symmetries, repetition of modules and architectural orders, making the Scan-to-FEM transition fast and efficient. A Portuguese monument is adopted as a pilot case to validate the proposed procedure. In order to obtain a proper digital twin of this structure, the generated parametric model is imported into an FE environment and then calibrated via an inverse dynamic problem, using as reference metrics the modal properties identified from field acceleration data recorded before and after a retrofitting intervention. After assessing the effectiveness of the strengthening measures, the digital twin ability of reproducing past and future damage scenarios of the church is validated through nonlinear static analyses. Full article
