Search Results (70)

A new brazing process for thin-walled stainless steel was proposed by combining green and efficient Ni-Cr-P electrodeposition with brazing technology. Novel information was attained by analyzing the electrodeposited Ni-Cr-P interlayers and the brazed joints and characterizing them using a combination of advanced techniques. The incorporation mechanisms of impurities (i.e., oxygen and carbon) in the Ni-Cr-P interlayers electrodeposited from a Cr(III)–glycine solution were revealed. The oxygen mainly came from the Cr(III)–hydroxy complexes formed by the hydrolysis and olation between Cr(III) complexes and OH⁻ ions near the cathode. Glycine did not directly participate in the cathode reactions but decomposed on the anode surface. These byproducts (carbonyl compounds) were directly incorporated into the interlayers in a molecular pattern, forming a weak link to the metallic chromium. Brazing test results showed that a certain amount of Cr₂O₃ powder, formed by the decomposition of chromium hydroxides in the interlayers under high-temperature catalysis, would cause the degradation of the brazed joints. Using the step-wise brazing method, the brazing sheets were first annealed to eliminate the impurities by utilizing the strong reducing effect of hydrogen and the weak link characteristics between carbonyl compounds and metallic chromium atoms. An excellent joint with a shear strength of 63.0 MPa was obtained by subsequent brazing. The microstructural analysis showed that the brazed seam was mainly composed of a Ni-Fe-Cr solid solution, the Ni₃P eutectic phase, and small quantities of the Ni₅P₂ phase scattered in the Ni₃P eutectic phase. Fracture mode observations showed that the cracks extended along the interface between the brittle P-containing phase and the primary phase, resulting in fracture. Full article

K417G superalloy is widely applied in gas turbine components such as blades, vanes, and nozzles. In this work, the oxidation behavior and mechanism of K417G alloy prepared by wide-gap brazing were investigated in air at 800, 900, 1000, and 1100 °C. Microstructures of the bonded joints differ in the wide-gap braze region (WGBR) and base metal (BM). The surface and cross-sectional morphology, composition, and structure of specimens were analyzed by XRD, SEM, and EDS after oxidation tests. The experimental data demonstrate that the WGBR (wide-gap brazed region) exhibits markedly superior oxidation resistance compared to the BM (base material) under elevated-temperature conditions exceeding 1000 °C. This performance disparity is quantitatively validated by oxidation kinetics analysis, where the weight gain curve of the WGBR demonstrates parabolic oxidation kinetics, as evidenced by its significantly lower parabolic rate constant relative to the BM. The oxide layers of the BM and WGBR are similar after oxidation at high temperatures of 800–900 °C, and they consist of an outermost layer of NiO, a middle mixed layer of Cr₂O₃, and an innermost layer of dendritic Al₂O₃. However, when the temperature is between 1000 and 1100 °C, the NiO on the surface of the BM spalls of due to thermal expansion coefficient mismatch in coarse-grained regions, resulting in oxidation mainly divided into outer layer Cr₂O₃ and inner layer Al₂O₃ and TiO₂. Under high-temperature oxidation conditions (1000–1100 °C), a structural transition occurs in the oxide scale of the BM, with the underlying mechanism attributable to grain-coarsening-induced oxide scale destabilization. Specifically, the coarse-grained structure of the BM (characteristic grain size exceeding 50 μm) is exhibited. Therefore, the WGBR demonstrates outstanding oxidation resistance, as evidenced by the formation of a continuous Al₂O₃ scale with parabolic rate constants of about 1.38 × 10⁻³ mg²·cm⁻⁴·min⁻¹ at 1100 °C. Full article

SiC matrix composites are widely used in high-temperature structural components of aircraft engines and nuclear reactor materials because of their excellent properties such as their high modulus, high strength, corrosion resistance, and high-temperature resistance. However, the bonding of SiCf/SiC composites poses significant challenges in practical engineering applications, primarily due to residual stresses, anisotropy in composite properties, and the demanding conditions required for high-performance joints. This work reviews various bonding technologies for SiC ceramics and SiC matrix composites. These include solid-state diffusion bonding, NITE phase bonding, direct bonding without filling materials, MAX phase bonding, glass ceramic bonding, polymer precursor bonding, metal brazing bonding, and Si-C reaction bonding. Key results, such as the highest bending strength of 439 MPa achieved with Si-C reaction bonding, are compared alongside the microstructural characteristics of different joints. Additionally, critical factors for successful bonding, such as physical mismatch and metallurgical incompatibility, are discussed in detail. Future research directions are proposed, emphasizing the optimization of bonding techniques and evaluation of joint performance in harsh environments. This review provides valuable insights into advancing bonding technologies for SiC composites in aerospace and nuclear applications. Full article

This study attempts to use fly ash as the brazing filler additive to increase the sustainable use of coal-fired power plant by-product materials. The experimental results show that adding 5 wt% fly ash into the Ag paste filler contributes to the interfacial reactions in heterogeneous reactive air brazing (RAB) of the ZrO₂ and Crofer alloy. The Ag-rich phase dominates the brazed zone. The interfacial reaction layers contain oxidation of the Cu-Ti coating layer, Crofer alloy, and the Si/Al-rich oxides from the fly ash particles. The 5% fly ash RAB joint maintained airtightness for 280 h under 2 psig helium at room temperature. When the test temperature was raised to 600 °C for 24 h, the pressure of the joint assembly still did not drop. When the fly ash addition was increased to 10 wt%, the joint assembly was no longer leak-free at room temperature. Many visible voids and cracks exist in the brazed zone and at the ZrO₂/braze and braze/Crofer interfaces. A high volume fraction of the fly ash particles results in many brittle Si/Al-rich oxides in the joint after RAB, and the fracture of these oxides significantly deteriorates the airtightness of the joint. This study shows the feasibility and potential of introducing 5 wt% fly ash particles to the Ag-rich paste filler during the RAB of ZrO₂ and Crofer for airtight applications. Full article

This article presents research on advanced surface preparation methods for sintered carbides (WC-Co, grade B2) commonly used in the tool industry, particularly in the context of bonding these materials with C45 steel using adhesives. Sintered carbides are widely used due to their high hardness, wear resistance, and good ductility, making them ideal for manufacturing tools operating in harsh conditions. Traditional bonding methods, such as brazing and welding, often result in stresses and cracks. Adhesive bonding has therefore emerged as an effective alternative to mitigate these challenges. The research focuses on comparing the results obtained through modern surface treatment techniques, such as laser micro-texturing and plasma treatment, with traditional methods like grinding, abrasive blasting, and electrolytic etching. The influence of these methods on adhesion properties and the strength of adhesive bonds was evaluated through mechanical tests, including static shear and pull-off tests. An approximately 50% increase in the mechanical strength of adhesive joints was observed for surfaces treated with low-temperature plasma (operating voltage: 18 kV, flow of gasses: 20 l/min., treatment time: 60 s) and laser micro-texturing (infrared fiber laser, wavelength: 1064 nm (±5 nm), power: 20 W), as compared to mechanical grinding. The shear strength of the adhesive joints was equal to 32 MPa and 30 MPa on average in the case of treatment with low-temperature plasma made of helium and argon, respectively. The highest strength of an adhesive joint was equal to 34.5 MPa on average in the case of laser micro-texturing. Full article

The wettability and high-temperature mechanical properties of porous BN/Si₃N₄ ceramics brazed with SiTi22 (wt. %) filler were studied. It is manifested that SiTi22 filler presents remarkable wetting and spreading capabilities on the porous BN/Si₃N₄ ceramic surface. An interfacial reaction layer is generated at the interface, and the thickness of the reaction layer initially grows and subsequently remains constant with the escalation of temperature. Carbon coating modification is beneficial to the wettability and high-temperature mechanical properties of porous BN/Si₃N₄ ceramics. The wetting driving force is mainly controlled by the interfacial reaction at the three-phase line of the wetting front. The mechanical properties of the carbon-coated joints are significantly enhanced in comparison with uncoated joints. The joint strength attains a maximum value of roughly 73 MPa in the shear test implemented at 800 °C. The strength of the joint is significantly enhanced mainly due to the TiN_0.7C_0.3 particles that consume energy by changing the crack propagation direction, and the SiC nanowires strengthen the connection by bridging. Full article

Herein, we fabricated a low-melting-point Zr-16Ti-6Cu-8Ni-6Co eutectic filler based on a Zr-Ti-Cu-Ni filler to achieve effective joining of a Ti6Al4V (TC4) titanium alloy. The temperature at which the brittle intermetallic compound (IMC) layer in the seam completely disappeared was reduced from 920 °C to 900 °C, which broadened the temperature range of the Zr-based filler, brazing the TC4 without a brittle IMC layer. The shear strength of the Zr-16Ti-6Cu-8Ni-6Co brazed joint increased by 113% more than that of the Zr-16Ti-9Cu-11Ni brazed joint at 900 °C. The proportion of β-Ti in the seam of the Zr-16Ti-6Cu-8Ni-6Co brazed joint increased by 21.31% compared with that of the Zr-16Ti-9Cu-11Ni brazed joint. The nano-indentation results show that the elastic modulus of the β-Ti (143 GPa) in the interface is lower than that of the α-Ti (169 GPa) and (Ti,Zr)₂(Ni,Cu,Co) (203 GPa). As a result, the β-Ti is subjected to a greater strain under the same stress state compared with the α-Ti and (Ti,Zr)₂(Ni,Cu,Co), and the Zr-16Ti-6Cu-8Ni-6Co brazed joint can maintain a higher strength than the Zr-16Ti-9Cu-11Ni brazed joint under a middle–low erosion area of the TC4 base metal. This provides valuable insights into the use of high-strength, fatigue-resistant TC4 brazed joints in engineering applications. Full article

To meet the demands for high-temperature performance and lightweight materials in aerospace engineering, the Au-Ni solder is often utilized for joining dissimilar materials, such as Ti₃Al-based alloys and Ni-based high-temperature alloys. However, the interaction between Ti and Ni can lead to the formation of brittle phases, like Ti₂Ni, TiNi, and TiNi₃, which diminish the mechanical properties of the joint and increase the risk of crack formation during the welding process. Cu doping has been shown to enhance the mechanical properties and high-temperature stability of the Au-Ni brazed joint’s central area. Due to the difficulty in accurately controlling the solid solution content of Cu in the Au-Ni alloy, along with the high cost of Au, traditional experimental trial-and-error methods are insufficient for the development of Au-based solders. In this study, first principles calculations based on density functional theory were employed to analyze the effect of Cu content on the stability of the Au-2.0Ni-xCu (x = 0, 0.25, 0.5, 0.75, 1.0, 1.25 wt%) alloy phase structure. The thermal properties of the alloy were determined using Gibbs software fitting. The results indicate that the Au-2.0Ni-0.25Cu alloy exhibits the highest plastic toughness (B/G = 5.601, ν = 0.416, Cauchy pressure = 73.676 GPa) and a hardness of 1.17 GPa, which is 80% higher than that of Au-2.0Ni. This alloy balances excellent strength and plastic toughness, meeting the mechanical performance requirements of brazed joints. The constant pressure specific heat capacity (C_p) of the Au-2.0Ni-xCu alloy is higher than that of Au-2.0Ni and increases with Cu content. At 1000 K, the C_p of the Au-2.0Ni-0.25Cu alloy is 35.606 J·mol⁻¹·K⁻¹, which is 5.88% higher than that of Au-2.0Ni. The higher C_p contributes to enhanced high-temperature stability. Moreover, the linear expansion coefficient (CTE) of the Au-2.0Ni-0.25Cu alloy at 1000 K is 8.76 × 10⁻⁵·K⁻¹, only 0.68% higher than Au-2.0Ni. The lower CTE helps to reduce the risk of solder damage caused by thermal stress. Therefore, the Au-2.0Ni-0.25Cu alloy is more suitable for brazing applications in high-temperature environments due to its excellent mechanical properties and thermal stability. This study provides a theoretical basis for the performance optimization and engineering application of the Au-2.0Ni-xCu alloy as a gold-based solder. Full article

This article describes a module and method for measuring the surface tension of liquid solders implemented on a measuring device as part of an integrated platform for automatic measurement of brazebility parameters at high temperatures. A concept for constructing a test stand is presented, with a description of the individual functional blocks. The developed stand allows for testing of the solder’s surface tension. The surface tension is one of the parameters that describe the thermodynamics of interfacial reactions and the structure of newly created joints. Determining the physicochemical interactions between liquid and solid substances is crucial for various industrial processes in fields such as metallurgy, electronics, and aviation, mainly where soldering and brazing technologies are employed. A series of bubble experiments in solder for a ceramic capillary is carried out to verify the proposed method using the developed system. One of these experiments is described in this article. Full article

This study proposes a method to enhance the airtightness of the joint between the ZrO₂ and Crofer alloy using coating technology. With the aid of vacuum sputtering technology, a titanium–copper alloy layer with a thickness between 1.5 μm and 6 μm was first deposited on the surface of ZrO₂ and Crofer, respectively. The chemical composition of the deposited reaction layer was 70.2 Cu and 29.8 Ti in at%. Then, using silver as the base material in the reactive air brazing (RAB) process, we explore the use of this material design to improve the microstructure and reaction mechanism of the joint surface between ceramics and metal, compare the effects of different pretreatment thicknesses on the microstructure, and evaluate its effectiveness through air tightness tests. The results show that a coating of Cu-Ti alloy on the ZrO₂ substrate can significantly improve bonding between the Ag filler and ZrO₂. The Cu-Ti metallization layer on the ZrO₂ substrate is beneficial to the RAB. After the brazing process, the coated Cu-Ti layers form suitable reaction interfaces between the filler, the metal, the filler, and the ceramic. In terms of coating layer thickness, the optimized 3 μm coated Cu-Ti alloy layer is achieved from the experiment. Melting and dissolving the Cu-Ti coated layer into the ZrO₂ substrate results in a defect-free interface between the Ag-rich braze and the ZrO₂. The air tightness test result shows no leakage under 2 psig at room temperature for 28 h. The pressure condition can still be maintained even under high-temperature conditions of 600 °C for 24 h. Full article

In order to address the issues of excessive brittle intermetallic compounds (IMC) formation in the TC4 brazed joints, two types of novel Ti-Zr-Cu-Ni-Sn amorphous braze fillers were designed. The microstructure and shear strength of the TC4/Ti-Zr-Ni-Cu-Sn/TC4 brazed joints were studied by scanning electron microscopy (SEM), transmission electron microscopy (TEM), X-ray diffractometer (XRD) and electronic universal materials testing machine. The results show that the optimized Ti₃₅Zr₂₅Ni₁₅Cu₂₀Sn₅ braze filler whose chemical composition is closer to the eutectic point possesses a lower melting point compared with the equiatomic Ti_23.75Zr_23.75Ni_23.75Cu_23.75Sn₅. This was beneficial to the sufficient diffusion of Cu and Ni elements with the base metal during brazing and reduces the residual (Ti,Zr)₂(Ni,Cu) content in the joint, which helps to improve the joint performance. The room-temperature and high-temperature shear strength of the TC4 brazed joints using the near eutectic component Ti₃₅Zr₂₅Ni₁₅Cu₂₀Sn₅ filler reached a maximum of 472 MPa and 389 MPa at 970 °C/10 min, which was 66% and 48% higher than that of the TC4 joints brazed with the equiatomic Ti_23.75Zr_23.75Ni_23.75Cu_23.75Sn₅ braze filler. Microstructural evolution and the corresponding mechanical response were in-depth discussed. Full article

Laser–MIG hybrid welding–brazing was used to weld 304 stainless steel and 6061-T6 aluminum alloy with a thickness of 2 mm. The microstructure, morphology, chemical composition and corrosion behavior of the samples after high-temperature oxidation were investigated. The results reveal that the 304/6061 dissimilar joint had a thicker intermetallic compound layer (7–8 μm) during high-temperature oxidation (HTO) treatment than the sample without HTO treatment (2–3 μm). The oxide film thickness of the 6061 side of the weld joint treated by HTO (2401 nm) increased compared to the samples (181.1 nm) without HTO treatment. Unlike other metals treated by high-temperature oxidation, the high-temperature treatment process in this paper can reduce the corrosion resistance of the base metal and dissimilar joints, and the sequence of the corrosion current density was weld (HTO) >weld>6061 (HTO) >6061>304 (HTO) >304. Full article

The Al–Mn alloy heat exchanger fin production process includes a brazing treatment at s high temperature of 600 °C, in which coarse grains are preferred for their high resistance to deformation at elevated temperatures by decreasing the grain boundary sliding. In this study, Al-1.57Mn-1.57Zn-0.58Si-0.17Fe alloy foils cold rolled by 81.7% (1.1 mm in thickness) and 96.5% (0.21 mm in thickness) were annealed at 100–550 °C for 1 h to investigate their recrystallization behavior, grain sizes, and precipitates by increasing the annealing temperature, using micro-hardness measurement, electron back-scattered diffraction (EBSD), scanning electron microscopy (SEM), and transmission electron microscopy (TEM) techniques. The micro-hardness results showed that the recrystallization finishing temperatures for the two samples were almost the same, 323 ± 2 °C. The EBSD results showed that when the annealing temperature decreased from 550 to 400 °C, the recrystallized grain sizes of the two samples were nearly identical—both increased slightly. Further decreasing the annealing temperature from 400 to 330 °C caused the grain sizes to increase more, with the thinner foil sample having a more significant increase. The SEM and TEM observations showed that the micron-sized primary-phase remained unchanged during the annealing process. The nano-sized secondary phase precipitates formed during the hot-rolling process experienced a coarsening and dissolving process upon annealing. The particle size of the secondary phase increased from 32 nm to 44 nm and the area fraction decreased from 4.2% to 3.8%. The nucleation analysis confirmed that the large primary-phase could act as a nucleation site through particle stimulated nucleation (PSN) mode. The relatively dense secondary phase precipitates with small sizes at lower temperatures could provide higher Zener drag to the grain boundaries, leading to fewer nuclei and thereafter coarser grains. The coarsening of the recrystallized grains in the foils could be implemented through thickness reduction and/or precipitation processes to form densely distributed nano-sized precipitates. Full article

Ti-45Al-8Nb alloy is widely utilized in the lightweight design of the aerospace field because of its excellent properties. In order to make full use of this alloy, it is important to carry out relevant research, such as into the joining process of Ti-45Al-8Nb alloy. In this work, Ti-45Al-8Nb alloys were successfully connected by a TiZrCuNi amorphous interlayer, which was fabricated using the rapid solidification method. Ti-45Al-8Nb joints were composed of two zones. The typical microstructure of a Ti-45Al-8Nb joint was Ti-45Al-8Nb/AlCuTi + Ti₃Al/(Ti, Zr)(Cu, Ni) + (Ti, Zr)₂(Cu, Ni)/Ti₃Al + AlCuTi/Ti-45Al-8Nb. The diffusion of elements between the interlayer and the substrate was enhanced by increasing the brazing temperature, which resulted in an increase in the thickness of the interfacial reaction layer. The maximum shear strength was 171.2 MPa, which was obtained at 930 °C. The typical cleavage fracture was found in all of the Ti-45Al-8Nb joints. The mechanical properties of the joint were compromised at high brazing temperature due to the presence of excessive (Ti, Zr)₂(Cu, Ni) phase and coarse Ti₃Al phase, both of which are inherently brittle and harmful to the shear strength of the obtained joint. Full article

In heat pumps and refrigeration systems, copper parts play a crucial role. Since heat pumps for space and water heating work under high pressure and are susceptible to vibrations, it is crucial to perfectly weld the copper pipes and heat exchangers to avoid system failures and prevent the leakage of the circulating refrigerants, which are harmful to the environment. The welding of the copper pipes is usually performed by the brazing process in a furnace. The components are subjected to a period of approximately 50 min inside a continuously open oven, varying the temperature from 710 °C to 830 °C. The oven inlets and outlets are protected by nitrogen curtains to guarantee a suitable internal environment and prevent the contamination of the gas inside the oven. This work analyses which welding methods are most suitable for welding copper, the best joint shape, process time, brazing specimens of a copper alloy, tightness tests, and mechanical properties and composition of the welding samples. From the tests carried out, the appearance of small and large defects is reduced by using a 1 mm thick external ring of filler material and a brazing temperature of 820 °C. Full article
