Search Results (17)

This study reviews the integration of Brayton Cycle (BC) systems in nuclear power generation, emphasizing their potential to enhance thermal efficiency and operational flexibility over traditional Rankine Cycle (RC) systems. Key working fluids, such as helium (He), supercritical carbon dioxide (sCO₂), nitrogen (N₂), and air, are evaluated for their performance, efficiency, and compatibility with nuclear systems. He is recognized for its high thermal conductivity and inertness at elevated temperatures, while sCO₂ demonstrates advantages in compactness and efficiency in midrange temperatures. This article also highlights the importance of compressor designs in optimizing BC performance and reviews, available compressor technologies. Axial and centrifugal compressor designs enable efficient gas compression while managing the thermal and mechanical stresses associated with high-pressure operations in nuclear systems. Combined with variable geometry components and advanced materials, these technologies address the challenges posed by varying load conditions. Despite the promising features of BC systems, several challenges persist, including high leakage rates and material degradation under extreme conditions, which necessitate robust sealing technologies and thorough testing. The insights gained from operational experiences at facilities, such as the Oberhausen II plant and the High-Temperature He Test Facility (HHV), underscore the complexities involved in designing high-temperature gas turbines for nuclear applications. This review concludes that as the nuclear industry evolves, BC systems hold significant promise for contributing to a sustainable energy future, particularly in the context of small modular reactors (SMRs) and microreactors. Further exploration of combined cycle configurations that combine BCs with RCs may enhance overall efficiency and flexibility in power generation. Full article

Nitrogen compression requires centrifugal compressors to operate under relatively high ambient pressure. However, the internal instability characteristics of compressors handling high-density working fluids remain unclear. Therefore, this study employs Dynamic Mode Decomposition (DMD) to investigate unsteady flow fluctuations within an isolated centrifugal impeller under both best efficiency and near-stall conditions at high ambient pressure. Results show that as the throttling process progresses, distinct unsteady phenomena emerge within the impeller. Under near-stall conditions, the frequency of the instability is 0.44 times the blade passage frequency (BPF), manifesting as periodic pressure fluctuations throughout the entire blade passage. This instability originates from periodic passage blockages caused by fluctuations in tip leakage flow. Additionally, the pressure fluctuations at the impeller inlet exhibit a noticeable lag compared to those in the latter half of the passage. Through DMD analysis, it is found that after the tip leakage vortex exits the blade, it interacts with the pressure surface of the adjacent blade, affecting the tip loading of the neighboring blade and forming a dynamic cycle. However, this vortex is not the primary flow structure responsible for the instability. These insights into the nature of unsteady disturbances provide valuable implications for future stall warning and instability prediction technologies. Full article

This study examines how leading-edge inclination angles affect a two-stage centrifugal compressor’s aerodynamic performance using numerical and experimental methods. Five impellers with varied inclination configurations were designed for both stages. The results show that negative inclination improves the pressure ratio and efficiency under near-choke conditions, with greater enhancements in the low-pressure stage. Positive inclination significantly boosts the pressure ratio and efficiency under near-stall conditions, particularly in the low-pressure stage. Negative inclinations optimize blade loading and choke flow capacity, while effectively reducing incidence angle deviations induced by interstage pipeline distortion and decreasing outlet pressure fluctuation amplitude in the high-pressure stage. Positive inclinations delay flow separation, suppress tip leakage vortices, and extend the stall margin. Full article

Recent advancements in computational fluid dynamics (CFD) enable new and more complex analysis methods to be developed for early design stages. One such method is the isolated unsteady diffuser model, which seeks to reduce the computational cost of unsteady CFD when modeling diffusion systems in centrifugal compressors with vaned diffusers by isolating the diffuser from the computational domain and prescribing an unsteady and periodic inlet boundary condition. An initial iteration of this computational methodology was developed and validated for the Centrifugal Stage for Aerodynamic Research (CSTAR) at the High-Speed Compressor Laboratory at Purdue University. However, that work showed discrepancies in flow structure predictions between full-stage and isolated unsteady CFD models, and it also presented a narrow scope of only a single loading condition. Thus, this work addresses the need for improvement in the modeling fidelity. The original methodology was expanded by including a more accurate, non-uniform definition of turbulence at the diffuser inlet and modeling several loading conditions ranging from choke to surge. Results from isolated unsteady diffuser models with non-uniform turbulence modeling were compared with uniform turbulence isolated unsteady diffuser models and full-stage unsteady models at four loading conditions along a speedline. Flow structure predictions by the three methodologies were compared using 1D parameters and outlet total pressure and midspan velocity contours. The comparisons indicate a significant improvement in 1D parameter and flow structure predictions by the isolated unsteady diffuser models at all four loading conditions when including more accurate non-uniform turbulence, without a corresponding increase in computational cost. Additionally, both isolated diffuser methodologies accurately track trends in 3D flow structures along the speedline. Full article

The application of centrifugal compressors is extensive in industries such as aerospace and energy. The blade is the primary factor affecting the aerodynamic performance of compressors. In this paper, the aerodynamic performance of a centrifugal compressor with leaned and bowed 3D blades is investigated. The spanwise section profiles of the blade in the circumferential direction are deflected at different angles, resulting in four compressors with distinct leaned and bowed 3D blades based on the original model. There is a significant change in isentropic efficiency of the modified models under design conditions. Specifically, models 1, 3, and 4 experienced an increase of 0.97%, 1.04%, and 0.79%, respectively, while model 2 experienced a decrease of 0.70%. The profile of the blade tip and 50% spanwise section are shifted towards the suction surface, resulting in a geometric structure where the blade is concave towards the pressure surface. This structure gradually lifts the flow from the blade root to the blade tip downstream to the outlet area of the flow channel, reducing the load on the trailing edge of the blade and making the flow more closely aligned with the blade. At the same time, the larger radial velocity gradient near the blade tip suppresses the backflow on the shroud side, making the flow at the impeller outlet more stable. The outlet velocity of the impeller is more evenly distributed along the spanwise and circumferential directions, which improves the flow at the inlet of the diffuser and enhances the efficiency of the diffuser. Due to the high spanwise height of the leading edge of the blade, this bowed blade structure has little effect on the spanwise curvature upstream of the blade, resulting in negligible influence on the flow of the upstream channel. Full article

High-pressure ratio centrifugal compressors’ diffusers face challenges from high-velocity, non-uniform flow at the impeller outlet, decreasing efficiency and stall margin. To address this, this paper presents a novel vaned diffuser passage design method that successfully improved the compressor’s performance. An optimization method using axisymmetric hub contours and NURBS curves was applied to modify the diffuser’s design. After optimization, centrifugal compressor peak efficiency increased by 0.78%, and stall margin expanded from 12.8% to 20.4%. Analysis at the peak efficiency point showed loss reduction mainly from decreased recirculation and mixing losses in the diffuser’s vaneless and semi-vaneless spaces. Furthermore, correlation analysis and Mach number distribution revealed that flow behavior at the diffuser’s leading edge significantly influences efficiency. Consequently, design principles emphasize satisfying specific Mach number distribution rules at the diffuser’s leading edge under certain inflow conditions for optimal performance. Full article

Understanding the influence of environmental boundary parameters on the through-flow characteristics of two-stage supercharged centrifugal compressors is the key to maximizing the power recovery potential of diesel engines at high altitudes. In this paper, the influence of the compressor through-flow characteristics on the full-load thermal cycle performance of a diesel engine under variable altitude is studied by means of tests and simulation. The results show that with the increase in altitude, the range of stable work flow decreases, and the pressure ratio of the plugging point changes greatly with altitude. The efficiency of the compressor with the same mass flow point decreases, and the highest efficiency point moves in the direction of the small flow range. With the goal of maximizing the torque of the diesel engine under full load and low speed, the key geometric parameters of the variable-altitude through-flow characteristics of the two-stage supercharged compressor were optimized as follows: at the altitudes of 0 m, 2500 m, and 5500 m, the diesel engine torque increased by 5.89%, 3.78%, and 2.18%, respectively. Based on the optimization method of the compressor through-flow design, a new direction is provided to break through the research on the independent limitation of the diesel engine thermal cycle performance optimization and compressor flow control. Full article

The motivation to design a more efficient and compact aircraft engine leads to a continuous increase in overall pressure ratio and decrease in the stage number in compressors. Compared to the traditional multi-stage compressor, a single-stage ultra-high-pressure-ratio centrifugal compressor with a pressure ratio higher than 10.0 can significantly improve the engine’s power-to-weight ratio and fuel economy with a reduced structure complexity. Thus, it has great potential to be adopted in the compression system of advanced aero engines, such as turboshaft engines, in the future. However, the highly narrow Stable Flow Range (SFR) of ultra-high-pressure-ratio centrifugal compressors is a severe restriction for engineering applications. This research focuses on the aerodynamic performance of a ultra-high-pressure-ratio centrifugal compressor, and three-dimensional simulation is employed to investigate the effect of Self-Recirculating Casing Treatment (SRCT) on the performance and stability of the centrifugal compressor. Firstly, the parametric model of SRCT is established to investigate the effect of geometry parameters (rear slot distance and rear slot width) on the aerodynamic performance of the centrifugal compressor. It is concluded that SRCT improves the compressor’s SFR but deteriorates its efficiency. Also, a non-linear and non-monotone relationship exists between the SFR and rear slot distance or width. Then, the flow mechanism behind the effect of SRCT is explored in detail. By introducing the SRCT, an additional flow path is provided across the blade along the circumferential direction, and the behavior of the shock wave and tip leakage flow is significantly changed, resulting in the obviously different loading distribution along the streamwise direction. As a result, the mixing and flow separation loss are enhanced in the impeller flow passage to deteriorate the efficiency. On the other hand, the blockage effect caused by the mixing of slot recirculation and mainstream flow near the impeller inlet increases the axial velocity and reduces the incidence angle below the 90% spanwise section, which is considered to effectively stabilize the impeller flow field and enhance the stability. Full article

The aim of this publication was to investigate the effects the blade count of a high-pressure centrifugal compressor’s impeller has on the performance of the DGEN 380 turbine engine at take-off. The study began with the development of a zero-dimensional thermo-fluid model of the engine. The model was matched with experimental data from the WESTT CS/BV virtual test bench for the baseline count and then implemented to analyse the engine behaviour at alternative counts. The corresponding changes in the compressor pressure ratio and efficiency were modelled in a commercial 3D CFD software and transferred to the zero-dimensional model with proper scaling. The results proved that the baseline design lied in the optimal range of thrust-specific fuel consumption. The increase in the blade count led to a crisis of the aerodynamic loading at the splitters, so that no further rise in the pressure ratio could be achieved. The results of the study could be implemented by mechanical engineers while solving the tasks of the maintenance and modernisation of gas turbines with radial compressors. Full article

At present, two-stage centrifugal compressors based on air bearing and high-speed motor technology are widely used in automotive hydrogen fuel cells. The low-pressure stage and high-pressure stage of the compressor are directly connected through an interstage pipeline, thus the structure of the interstage pipeline has an important influence on the aerodynamic performance of the compressor. In this work, a two-stage compressor with three different interstage pipelines were investigated experimentally and numerically. Results show that affected by the interstage pipeline bend section, the flow distortion will be induced at the impeller inlet of the high-pressure stage, and the distortion intensity changes with the pipeline structure. Among the three models, the EPC (elbow pipe change) model induces the most intense total pressure distortion at the condition of 80 kr/min and 130% mass flow rate, resulting in an efficiency reduction of 2 and 1.5 percentage points compared with the SPC (straight pipe change) and the TPC (total pipe change) model, respectively. Further research indicates that the upstream distortion has obvious influence on the downstream rotor blades. As the blade height decreases, the load becomes more uniform on the main blades, while the load extremum migrates to the trailing edge on the splitter blades. Finally, three models are tested, and their performance is compared at three typical rotational speeds., It is recommended that interstage pipelines similar to SPC models should be chosen to improve the two-stage compressor efficiency in the design. Full article

Chillers are widely used in commercial buildings for air conditioning, and their energy consumption is the main contribution to the building’s carbon emissions. Currently, the COPs of small- and medium-capacity screw chillers are still generally lower than 6.5, whereas large-capacity commercial centrifugal chillers have achieved an ultra-high energy-efficiency level of COP ≥ 7.0. To achieve an ultra-high energy efficiency of COP ≥ 6.5 in medium-capacity chillers, the authors developed a 200 RT screw chiller by adopting the technologies of two-stage compression and interstage vapor injection. The whole development process, including the design, simulation, analysis, and experiment, is presented in this paper. It was found that the two-stage compression technology could effectively boost the performance of the chiller’s compressor to a maximum volumetric and adiabatic efficiency of 99% and 80%, respectively. With the interstage vapor injection technology, the chiller’s cooling capacity and COP were increased by more than 11% and 8%, respectively. When the use of these two technologies was combined, the maximum COP of the chiller reached 7.17. Additionally, under these working conditions, the COP and integrated part-load value (IPLV) were 6.74 and 10.04, respectively. In all, the combination use of vapor injection and two-stage compression technologies shows great potential to improve the performance of chillers. The work and conclusions described here might provide an effective reference for the future development of high-efficiency small- and medium-capacity screw chillers. Full article

The cooling coefficient of performance (COP_R) and energy efficiency ratio (EER) of refrigerant R-134a compressors (single- and double-compressors) with different refrigerant tonnage (200, 250, 300, 380, 500, and 700 RT) for centrifugal and Maglev centrifugal compressors change with different operating performance load percentages (10–100%), and constant-frequency and variable-frequency operation, resulting in performance differences. In particular, a water chiller can have a fixed cooling water inlet temperature of 32 °C and a variable cooling water inlet temperature between 18.33 °C and 32 °C. According to the actual test results, the commercial performance code program and parameter table of the water chiller were established. Based on the performance matching of different load chillers, the on-site load capacity was analyzed and the effective water chiller performance and model matching were determined as the best choice for the ton_R number of the deicing machine and unit matching, providing a reference for a future large water chiller that cannot be used on site for a single unit ton_R. To achieve energy-saving benefits, different types of compressors, different refrigeration ton_R operation, constant-frequency unit and variable-frequency unit alternate operation, and different operating performance load percentage operation can be allocated. Finally, the results show that, when the cooling water inlet temperature is fixed, the Maglev variable-frequency centrifugal compressor water chiller is better than the constant-frequency centrifugal water chiller, and also better than the variable-frequency centrifugal water chiller. The larger the freezing ton_R of the variable-frequency centrifugal water chiller, the smaller the difference between COP_R and EER. When the cooling water inlet temperature changes, the Maglev variable-frequency centrifugal water chiller is better than the constant-frequency centrifugal water chiller, and it is also better than the variable-frequency centrifugal water chiller. The larger the freezing ton_R of the variable-frequency centrifugal water chiller, the smaller the difference between COP_R and EER. Moreover, the operating performance of the constant-frequency centrifugal water chiller is between 60% and 90%, which can maintain relatively high COP_R and EER values. The operating performance of the variable-frequency centrifugal water chiller is between 40% and 70%, which can maintain relatively high COP_R and EER values. Compared with the constant-frequency and variable-frequency, the Maglev variable-frequency centrifugal water chiller can maintain higher COP_R and EER values when the operating performance is between 10% and 100%. When the operating performance is between 10% and 70%, it can maintain very high COP_R and EER values. When the water chiller is selected in the field, the energy-saving of COP_R and EER will be given priority. Therefore, the load capacity can be used to effectively manage the water chiller performance and model selection, so that the operation performance can reach the best percentage and energy saving can be achieved. Full article

Calculations performed with modern CFD programs aid in optimizing flow paths of centrifugal compressors. Characteristics of stator elements of flow paths, calculated via CFD methods, are considered quite accurate. We present optimized return channels (RCh) of three model industrial compressor stages with vaneless diffusers. A parameterized model was created for optimization. The MOGA (Multi-Objective Genetic Algorithm) optimization method was applied in the Direct Optimization program of the ANSYS (Analysis System) software package. Optimization objects were return channels of the stages with high flow rate 0.15. The stages have three different loading factors 0.45, 0.60, 0.70. The optimization goal was to achieve the minimum loss coefficient at the design point. During the optimization process, we varied the following: the number of vanes, the inlet angle of the vanes, the height of the vanes at the inlet, the outer and inner radii of curvature of the U-bend. The outlet angle of the vanes was selected to minimize outlet circumferential velocity. In comparison with preliminary design, the optimized RCh are more efficient across the entire range of flow rates. The optimization reduced the loss coefficient by 20% at the design flow rate. Full article

The performance of a low/high-pressure-stage centrifugal compressor in a land-use MW-level gas turbine with a pressure ratio of approximately 11 is analyzed and optimized with a 1D aerodynamic design and modeling optimization system. 1D optimization results indicate that the diameter ratio of the low-pressure-stage centrifugal compressor with a vane-less diffuser, and the divergent angle of the high-pressure-stage centrifugal compressor with a vaned diffuser, are extremely large and result in low efficiency. Through modeling design and optimization system analysis, a tandem vaned diffuser is used in the low-pressure stage, and a tandem vaned diffuser with splitter vanes is adopted in the high-pressure stage. Computational fluid dynamics (CFD) results show that the pressure ratio and efficiency of the optimized low/high-pressure-stage centrifugal compressor are significantly improved. Coupling calculations of the low/high-pressure stage of the original and optimized designs are conducted based on the results of MW-level gas turbine cycles. CFD results show that the pressure ratio and efficiency of the optimized two-stage centrifugal compressor increase by approximately 8% and 4%, respectively, under three typical load conditions of 100%, 90%, and 60%. Full article

The decrease in the performance of centrifugal compressors operating at low Reynolds numbers (e.g., unmanned aerial vehicles at high altitudes or small turbomachines) can reach 10% due to increased friction. The purposes of this review are to represent the state-of-the-art of the active and passive flow control methods used to improve performance and/or widen the operating range in numerous engineering applications, and to investigate their applicability in low-Reynolds-number centrifugal compressors. The applicable method should increase performance by reducing drag, increasing blade loading, or reducing tip leakage. Based on the aerodynamic and structural demands, passive methods like riblets, squealers, winglets and grooves could be beneficial; however, the drawbacks of these approaches are that their performance depends on the operating conditions and the effect might be negative at higher Reynolds numbers. The flow control method, which would reduce the boundary layer thickness and reduce wake, could have a beneficial impact on the performance of a low-Reynolds-number compressor in the entire operating range, but none of the methods represented in this review fully fulfil this objective. Full article
