This study investigates a heavy-duty CNC machine tool crossbeam casting manufactured by a leading heavy machine tool producer. A numerical simulation model for the demolding process was developed using proprietary Computer-Aided Engineering (CAE) software. The experimental validation of the residual stress was performed using the blind-hole method on the guide rail mounting surface. The simulation results were compared with experimental data, revealing that the post-demolding simulations exhibited smaller fluctuations than the pre-demolding predictions. The maximum principal stress prediction resulted in an absolute error of 11.8%, effectively reflecting the residual stress distribution for casting design and production optimization. Full article

In the process of heavy-duty cutting, the reciprocating motion of the sliding guide pair surface is prone to local wear, which seriously affects the overall machining accuracy and service life of the machine tool. This study proposes a biomimetic micro-texture design scheme combining elliptical grooves and shell-shaped grooves on the surface of carp as biomimetic prototypes to enhance the oil film bearing capacity, drag reduction, and wear resistance of guide rail pairs. Based on Fluent fluid simulation research, it has been shown that this texture has a better dynamic pressure lubrication effect. We used response surface methodology to optimize the texture design parameters and further verify the accuracy of the optimal parameters with the NSGA-II genetic algorithm. The results show that under lubricated conditions, the load-bearing pressure of the combined micro-textured guide rail pair increased by 53.79%, the friction coefficient decreased by 39.04%, and the temperature decreased by 15.83%. This texture can still significantly improve drag reduction and wear resistance in a low-oil state. Full article

Cobalt-bonded tungsten carbide (WC-Co) is widely used in heavy-duty machining applications due to its exceptional hardness and wear resistance, and it is increasingly being adopted in industries such as aerospace and the automotive sector, among others. Its superior mechanical properties make it difficult to machine with conventional methods such as turning or milling. Electrical Discharge Machining (EDM) has emerged as an efficient alternative, as it allows for the machining of hard materials to be carried out without direct contact between the tool and the workpiece, provided that the material has sufficient electrical conductivity. In this study, a multilevel Design of Experiments (DOE) was conducted to analyze the influence of EDM parameters—specifically, the current intensity and pulse time—on the surface roughness (SR), electrode wear (EW), and material removal rate (MRR) for 94WC–6Co. The results indicate that the current intensity was the most significant factor across all responses, while the pulse time played a secondary role. Surface finishes as low as Ra = 0.47 μm were achieved at I = 2 A and t_i = 10 μs. For each outcome variable, mathematical models were obtained in order to improve the EDM processes and better understand the machining of WC-Co. Full article

In the heavy-duty vehicle industry, unbalance in the armature is one of the most common problems affecting starters’ performance and durability. This research presents a comprehensive study to improve the balancing process for starting rotors in heavy-duty vehicles. The complete manufacturing process of armatures was analyzed to understand the contribution of assembly processes to unbalancing. The analysis revealed that the primary factor leading to high unbalance in these parts is the misalignment of conductors within the armature winding. During assembly, these conductors experience axial movements, resulting in non-uniform mass distribution and causing unbalanced values ranging from 150 to 350 g·mm. These values surpass the permissible limit, making rectification during the balancing process at the end of the assembly impossible. Consequently, a novel alignment tool was designed to address this issue, significantly reducing the effect and achieving the maximum allowable unbalance of 100 g·mm. This allowed the balancing machine used in the process to correct the initial unbalance of the reinforcements in a single work cycle, improving operation efficiency by about 15%. Full article

For future internal combustion engines, driven by regenerative fuels, efficiency is more important than ever. One approach to reduce the losses inside the piston cylinder unit (PCU) is to improve the alignment of the liner and the piston. Therefore, a cylinder liner with a free form was developed at the Institute of Technical Combustion (ITV) of the Leibniz University Hannover which compensates radial and linear deformations along the stroke. The layout is based on a FEM simulation. The liner was manufactured by the Institute of Production Engineering and Machine Tools (IFW) of Leibniz University of Hannover with a novel turn-milling process. The liner was investigated on the heavy-duty Floating-Liner engine of ITV with a displacement of 1991 ccm and a bore diameter of 130 mm. The experimental results show improvement in the friction losses over the whole engine map in the range of 9% and up to 17.3% compared to a serial liner. Sealing efficiency could be improved up to 28.8%, depending on the operational point. Overall, the investigation aims for lower fuel consumption which would in result fewer emissions. Full article

The dynamic servo error of heavy-duty vertical machining centres is one of the decisive factors affecting the machining accuracy of large and complex parts. Due to the characteristics of large mass, large load, and the large travel distance of the machine tool, non-linear factors such as friction, backlash, and lateral shift are more likely to cause unstable behaviours such as stick-slip and oscillation of the servo feed system of the machine tool, and reduce the performance and servo accuracy of the motion axis. In this paper, to consider the influence of non-linear factors such as friction, backlash, and lateral shift, an appropriately simplified representation of the mechanical transmission system of the ball screw has been used. According to the control structure of the Siemens 840D numerical control system, a theoretical model of the servo feed system for the heavy-duty vertical machining centre was established based on three-loop control. Then, the single-axis and double-axis closed-loop simulation models of the servo feed system were built in Simulink, and the influence pattern of control parameters and nonlinear factors on the dynamic servo error was obtained through simulation analysis. Finally, the validity of the theoretical model for the servo feed system was verified through a comprehensive comparison of simulation and experimental outcomes. This encompasses an analysis of the control system Bode plots, critical stick-slip velocity, and tracking errors in the X-axis with linear motion. The validation provides theoretical guidance for parameter design and mechanical adjustments of the servo feed system in heavy-duty vertical machining centres. Full article

In the European Union (EU), road transport contributes a major proportion of the total greenhouse gas (GHG) emissions, of which a significant amount is caused by heavy-duty commercial vehicles (CV). The increasing number of emission regulations and penalties by the EU have forced commercial vehicle manufacturers to investigate powertrain technologies other than conventional internal combustion engines (ICE). Since vehicle economics plays an important role in purchase decisions and the powertrain of a battery electric vehicle (BEV) contributes to about 8–20% of the total vehicle cost and the electric machine (EM) alone contributes to 33–43% of the drivetrain cost, it is necessary to analyze suitable EM topologies for the powertrain. In this paper, the authors aim to analyze the technical and cost aspects of an EM for electric commercial vehicles (ECV). Based on prior research and literature on this subject, an appropriate methodology for selecting suitable geometrical parameters of an e-machine for the use case of a heavy-duty vehicle is developed using MATLAB and Simulink tools. Then, for the economic analysis of the e-machine, reference ones are used, and their design parameters and cost structures are utilized to develop a cost function. Different use cases are evaluated according to the vehicle’s application. The results for a use case are compared by varying the design parameters to find the most cost-effective EM. Later, an analysis is performed on other decisive factors for EM selection. This highlights the importance of collaborative consideration of technological as well as the economic aspects of EMs for different use cases in ECVs. The method developed in this work contributes to understand the economic aspect of EMs as well as considering their performance factors. State-of-the-art methods and research are used to develop a novel methodology that helps with the selection of the initial geometry of the electric motor during the design process, which can serve to aid future designers and converters of electric heavy-duty vehicles. Full article

The static and dynamic performances of a machine tool structure are considered to constitute the primary factors affecting the load-carrying capacity, geometric accuracy and surface precision of the workpiece. The machining performance of a large machine tool under stable conditions is effectively determined by its dynamic response to the cutting force at low-frequency excitation. This study, therefore, investigated the static and dynamic characteristics of a large heavy-duty lathe machine tool in which the headstock and tailstock comprised critical component modules supporting a large workpiece during low-speed machining. Using a finite element model, the influences of the structural modules on the static and dynamic characteristics of the lathe were analyzed, considering the effects of the workpiece load. The results indicated that the fundamental vibration modes of the lathe were primarily dominated by headstock, tailstock, and workpiece behaviors. The maximum compliances of the lathe under the rated load were found to occur at relatively low frequencies (22, 40.7, and 82.7 Hz) and increase with the reduction in workpiece weight. Notably, these modal frequencies were significantly higher than the maximum rotational speed of the spindle (450 rpm). In addition, the dynamic rigidity corresponding to the rated speed was higher than that induced at the natural frequency. These results indicate that the subject lathe possesses sufficient capacity to sustain the cutting load during stable turning machining. This study can, therefore, help designers improve the performance of machine tools for future fabrication. Full article

Guideway hydrostatic bearings with the function of supporting and moving loads are a key component of ultra-precision heavy-duty machine tools. Because the dimension difference between the oil gap and the overall structure is great, it is difficult to generate the three-dimensional mesh, which has limited the improvement of bearing performance through structural innovation. To solve these problems, we propose an approach using the global fluid domain for performance analysis. The grid skewness of the film region and other regions are less than 0.4 and 0.8, respectively, which can satisfy the demands of static and dynamic high-accuracy simulation. Then, we used supporting load capacity, stiffness and damping to analyze the performance of hydrostatic bearings. The average error between the simulation result and the actual value was 10.76%, which is better than the result calculated by the traditional empirical formulae. The stiffness and damping of the bearings are easy to obtain by application of dynamic mesh technology. Furthermore, many obvious vortices were shown by visualization analysis in the bearing internal flow pattern in the bearing moving state of 400 mm/s. Finally, a specially designed double-slit septum successfully suppressed the formation of visible vortices. This structural improvement, combining the advantages of deep and shallow recesses, is expected to make hydrostatic bearings at high-speed conditions more stable for ultra-precision machine tools. Full article

Due to the large size and large span of heavy-duty machine tools, the structural deformation errors caused by gravity account for a large proportion of the static errors, and the influence of gravity deformation must thus be considered in the machine tool precision design. This paper proposes a precision design method for heavy-duty vertical machining centers based on gravity deformation error modelling. By abstracting the machine tool into a multibody system topology, the static error model of the machine tool is established based on the multibody system theory and a homogeneous coordinate transformation. Assuming that the static error of each motion axis is composed of two parts, i.e., the manufacturing-induced geometric error and the gravity deformation error, the machine tool stiffness model of the relationship between gravity and deformation error is developed using the spatial beam elements. In the modelling process, the stiffness coefficients and volume coefficients of the components are introduced to fully consider the influences of structural parameters on machine tool precision. Taking the machine tool static precision, the component stiffness coefficients and the volume coefficients as the design variables, based on the use of the worst condition method, error sensitivity analysis and global optimization algorithm, the optimal allocation of the static error budget of the machine tool and the structural design requirements of each component are determined, providing a valuable guide for the detailed structure design and manufacture processing of the machine tool components. Full article

Condition monitoring of components in internal combustion engines is an essential tool for increasing engine durability and avoiding critical engine operation. If lubrication at the crankshaft main bearings is insufficient, metal-to-metal contacts become likely and thus wear can occur. Bearing temperature measurements with thermocouples serve as a reliable, fast responding, individual bearing-oriented method that is comparatively simple to apply. In combination with a corresponding reference model, such measurements could serve to monitor the bearing condition. Based on experimental data from an MAN D2676 LF51 heavy-duty diesel engine, the derivation of a data-driven model for the crankshaft main bearing temperatures under steady-state engine operation is discussed. A total of 313 temperature measurements per bearing are available for this task. Readily accessible engine operating data that represent the corresponding engine operating points serve as model inputs. Different machine learning methods are thoroughly tested in terms of their prediction error with the help of a repeated nested cross-validation. The methods include different linear regression approaches (i.e., with and without lasso regularization), gradient boosting regression and support vector regression. As the results show, support vector regression is best suited for the problem. In the final evaluation on unseen test data, this method yields a prediction error of less than 0.4 °C (root mean squared error). Considering the temperature range from approximately 76 °C to 112 °C, the results demonstrate that it is possible to reliably predict the bearing temperatures with the chosen approach. Therefore, the combination of a data-driven bearing temperature model and thermocouple-based temperature measurements forms a powerful tool for monitoring the condition of sliding bearings in internal combustion engines. Full article

In recent years, a variety of novel actuator concepts for the implements of heavy-duty mobile machines (HDMMs) has been proposed by industry and academia. Mostly, novel concepts aim at improving the typically low energy efficiency of state-of-the-art hydraulic valve-controlled actuators. However, besides energy-efficiency, many aspects that are crucial for a successful concept integration are often neglected in studies. Furthermore, most of the time, a specific HDMM is focused as an application while other HDMM types can show very different properties that might make a novel concept less suitable. In order to take more aspects and HDMM types into account when evaluating actuator concepts, this paper proposes a novel evaluation algorithm, which calculates so-called mismatch values for each potential actuator-application match, based on different problem aspects that can indicate a potential mismatch between a certain actuator concept and an HDMM. The lower the mismatch value, which depends on actuator characteristics as well as HDMM attributes, the more potential is the match. At the same time, the modular nature of the algorithm allows to evaluate a large number of possible matches at once, with low effort. For the performance demonstration of the algorithm, 36 potential matches formed out of six actuator concepts and six HDMM types are exemplarily evaluated. The resulting actuator concept ratings for the six different HDMMs are in line with general reasoning and confirm that the evaluation algorithm is a powerful tool to get a first, quick overview of a large solution space of actuator-HDMM matches. However, analyzing the limitations of the algorithm also shows that it cannot replace conventional requirements engineering and simulation studies if detailed and reliable results are required. Full article

A hydraulic system is a key subsystem of heavy-duty machine tools with a high failure intensity, the failure of which often causes shutdown of production and economic loss in machining. Therefore, it is necessary to implement failure analysis to identify the weak links of system and improve the reliability. For hydraulic system, there is often an amount of failure data collected in field, which help to calculate the occurrence probability of basic events through fault tree analysis method. However, the data are incomplete and uncertain. To address this issue, this study presents a fault tree analysis methodology. Experts’ opinions are utilized, combined with field data based on the Dempster–Shafer theory and rough set theory to fill the incompleteness and eliminate the uncertainty. For application in a case study, a fault tree of the hydraulic system of heavy-duty machine tools is firstly constructed. Then, the importance analysis is performed to help identify the weak links of hydraulic system. The results show the critical basic events affecting the safety and reliability of a hydraulic system. Full article

The drive at the center of gravity (DCG) principle has been adopted in computer numerical control (CNC) machines and industrial robots that require heavy-duty and quick feeds. Using this principle requires accurate corrections of positioning errors. Conventional error compensation methods may cause vibrations and unstable control performances due to the delay between compensation and motor motion. This paper proposes a new method to reduce the positioning errors of the dual-driving gantry-type machine tool (DDGTMT), namely, a typical DCG-principle-based machine tool. An error prediction method is proposed to characterize errors online. An algorithm is proposed to quickly and accurately compensate the errors of the DDGTMT. Experiment results verify that the non-delay error compensation method proposed in this paper can effectively improve the accuracy of the DDGTMT. Full article

The effective way to improve the position accuracy of rotary table of ultra-heavy vertical milling lathe is to reduce or even eliminate the clearance of mechanical transmission structure. In this paper, a useful method for eliminating the gear clearance of C axis of heavy duty machine tool is proposed based on dual servo motor driving system. The principle of double gear anti-backlash is explained and the process of clearance elimination is determined by adjusting the driving torques of the two motors. The dynamic model of the driving system of the dual servo motor is established, so as to find the non-linearity of the clearance, wear and tooth clearance in the drive system. According to the dynamic model and simulation results, the master-slave control parameters of the dual servo motor system are optimized in order to eliminate the clearance and improve the accuracy of the dual drive C-axis. Experiments are carried out to verify the validity of the proposed anti-backlash method. The experimental result also shows that the indexing accuracy of the table has been improved by more than 50% under different working conditions. Full article
