This paper proposes the development of a robust nonlinear soft sensor for online estimation of product compositions in a Heat-Integrated Distillation Column (HIDiC). Traditional composition analyzers, such as gas chromatographs, are costly and suffer from long measurement delays, making them inefficient for real-time monitoring and control. To address this, data-driven soft sensors are developed using tray temperature data obtained from a high-fidelity dynamic HIDiC simulation. The study investigates both linear and nonlinear modeling strategies for composition estimation, including principal component regression (PCR), artificial neural networks (ANNs), and, for the first time in HIDiC modeling, a Bidirectional Long Short-Term Memory (BiLSTM) network. The objective is to evaluate the capability of each method for accurate estimation of product compositions in a HIDiC. The results demonstrate that the BiLSTM-based soft sensor significantly outperforms conventional methods and offers strong potential for enhancing real-time composition estimation and control in HIDiC systems. Full article

In recent decades, the attention of researchers has been directed towards the study of the dehydration of isopropanol (IPA) through different techniques. Besides its multiple uses in the chemical industry, IPA is also a potential bio-component in eco-friendly gasolines. Extractive distillation is a successful technique for separating IPA from a minimum boiling azeotrope with water. However, the major challenge is the production of fuel-grade IPA (minimum 99.92 mol%) with low expenses. As a consequent step in the investigation of IPA dehydration with propylene glycol as extractive solvent, the present study compares its efficiency and economic viability with two other extractive solvents, namely ethylene glycol (EG) and dimethyl sulfoxide (DMSO). A systematic and comprehensive methodology was developed to design a three-column extractive distillation (TCED) for each investigated solvent. A techno-economic assessment of all the investigated processes concluded that ethylene glycol, followed by propylene glycol, seems to be the most promising solvent in the IPA dehydration process. Further, the heat integration of hot streams (SH flowsheets) demonstrated improvements over 17% in the case of ethylene glycol solvent, around 16% in the case of propylene glycol (PG) solvent, and only 10% (in the case of DMSO solvent) reduction in utility consumption, improving the energy efficiency of TCED processes. Furthermore, SH flowsheets yield a 14% cost saving obtained in terms of total annualized cost (TAC) and, respectively, 8.69%, by comparison with TCED processes. In the case of DMSO solvent, the TAC reduction is only 3.54% due to the capital cost, which has an increase of 3% mainly due to the high solvent cost. Full article

Heat-integrated distillation columns (HIDiC) are well known for their high energy efficiency, which has been demonstrated through thorough model-based simulation and practical testing. Despite this advantage, HIDiC systems are fundamentally complicated and provide major hurdles, particularly in terms of dynamic control, complicating their industrial implementation. Ongoing research is critical to improving their stability and scalability, allowing for wider incorporation into industrial processes. This review focuses on the fundamental aspects of HIDiC systems, such as heat transfer models, design improvements, experimental research, modelling, simulation, optimization, and process control techniques. This paper summarizes the present status of research and identifies significant technological obstacles that must be overcome to increase the functionality and industrial applications of HIDiC technology. In response to the increased demand for energy-efficient industrial processes, the analysis also investigates current developments in HIDiC control and optimization methodologies. It evaluates several control approaches, both model-based and data-driven, and their capacity to handle the dynamic complexities seen in HIDiC systems. Furthermore, this paper discusses the most recent optimization efforts targeted at improving product purity, operational flexibility, and overall energy efficiency. Full article

The extractive distillation process using propylene glycol (IUPAC name: 1,2 propanediol) as an extractive agent for the separation of the isopropanol–water system was investigated in this work. A systematic procedure was set out to obtain the optimal design and process conditions for extractive distillation and solvent recovery columns using the PRO/II process simulator. Four thermally integrated flowsheets were proposed, implying the recovery of the sensible heat and latent heat from the hot streams in the process. To establish the economic feasibility of the proposed process, we calculated the total annual cost for all the simulated versions, and the proposed fully thermally integrated flowsheets could save up to 43.13% in terms of the utility costs and up to 15.57% in terms of the TAC compared to the conventional design. Thus, propylene glycol (PG) is found to be suitable as a new solvent for isopropanol dehydration, being comparable with other classical solvents used for the dehydration of alcohols. Full article

The heat-integrated distillation column (HIDiC) has more energy-saving potential than conventional distillation columns. However, its nonlinearity and coupling effects pose significant challenges for the online operation of the HIDiC. To overcome these challenges, it becomes necessary to utilize accurate nonlinear models for design optimization or control schemes. Traditional modeling methods require extensive tray information, implying the impractical use of numerous sensors in real-world applications. This paper proposes a modeling approach for the HIDiC based on a limited number of measurements. It only requires the measurement of a finite amount of tray information to construct a global model of the HIDiC. This method serves as an online observer, providing real-time information about the entire column, and also enables the prediction of tray concentration changes. The proposed model forms the basis for developing model-based online monitoring and control schemes. Experimental simulation results demonstrate that the proposed method achieves high accuracy in global observation and prediction for the HIDiC. Full article

The electrification of process industries is one of the main challenges when building a low-carbon society since they consume huge amounts of fossil fuels, generating different emissions. Heat pumps are some of the key players in the industrial sector of the carbon-neutral market. This study proposes an approach to improve the economic feasibility of heat pumps within process plants. Initial energy targeting with grand composite curves was used and supplemented with the detailed design of an evaporator and a compressor for different condensation and evaporation pressures. The trade-off between the capital cost of the heat pump and the electricity cost was investigated, and optimal configurations were selected. This case study investigates the gas fractioning unit of a polymer plant, where three heat pumps are integrated into distillation columns. The results demonstrate that the heat recovery is 174 MW and requires an additional 37.9 MW of electricity to reduce the hot utility by 212 MW. The selection of the evaporation and condensation pressures of heat pumps allows 21.5 M EUR/y to be saved for 7 years of plant operation. The emission-saving potential is estimated at 1.89 ktCO₂/y. Full article

Distillation is significantly influenced by energy costs, prompting a need to explore effective strategies for reducing energy consumption. Among these, heat integration is a key approach, but evaluating its efficiency is paramount. Therefore, this study presents exergy as an energy quality indicator, analyzing irreversibility and efficiencies in tetrahydrofuran/water and acetone/chloroform distillations. Both systems have equimolar feed streams, yielding products with 99.99 mol% purity. The simulations are performed using Aspen Plus™, enabling evaluation at the column level, as a standalone process, or from a lean perspective that considers integration opportunities with other plants. The results show that, despite anticipated energy savings from heat integration, economic viability depends on pressure sensitivity. The results demonstrate that heat-integrated extractive distillation for acetone/chloroform raises utility energy consumption. Exergy calculations comparing standalone and total site integration reveal the variation in distillation efficiency with operation mode. Global exergy efficiency in both extractive and pressure-swing distillation depends on the fate of condenser duty. In heat-integrated extractive distillation, global exergy efficiency drops from 8.7% to 5.7% for tetrahydrofuran/water and 11.5% to 8.3% for acetone/chloroform. Similarly, heat-integrated pressure-swing distillation sees global exergy efficiency decrease from 34.2% to 23.7% for tetrahydrofuran/water and 9.5% to 3.6% for acetone/chloroform, underscoring the nuanced impact of heat integration, urging careful process design consideration. Full article

Reactive distillation (RD) combines chemical reactions and separation in a single unit essential to equilibrium-limited reactions. This new technique encompasses multiple advantages over traditional processes, including lower operating costs, increased thermal energy efficiency, high product selectivity, high purity percentage, and lower environmental impact. This paper provided an overview of the features, industrial applications, and industrial perspective of advanced reactive distillation technologies (ARDTs). This study focused on five under-development ARDTs: reactive dividing wall column (R-DWC), reactive high-gravity distillation (R-HiGee), reactive heat-integrated distillation column (R-HIDiC), catalytic cyclic distillation (CCD), and membrane-assisted reactive distillation (MA-RD). The primary drivers for new RD applications are reduced number of vessels, reduced residence time and holdup volume, increased mass and heat transfer, overcoming azeotropes, and prefractionation or impurity removal. ARDT’s potential has yet to be studied, and research remains active to improve it further by investigating other RD technologies, simulation, and optimization techniques. Full article

The process of low-temperature air separation consumes a significant amount of energy. Internal heat-integrated distillation technology has considerable energy-saving potential. Therefore, the combination of low-temperature air separation and heat-integrated distillation technology has led to the development of a heat-integrated air separation column (HIASC). Due to the heat integration and the inherent complexity of air separation, the modeling and control of this process poses significant challenges. This paper first introduces the nonlinear wave theory into the HIASC, derives the expression for the velocity of the concentration distribution curve movement and the curve describing function, and then establishes a nonlinear wave model. Compared to the traditional mechanical models, this approach greatly reduces the number of differential equations and variables while ensuring an accurate description of the system characteristics. Subsequently, based on the wave model, a model predictive control scheme is designed for the HIASC. This scheme is compared with two conventional control schemes: PID and a general model control. The simulation results demonstrate that MPC outperforms the other control schemes from the response curves and performance metrics. Full article

The electrification of industrial processes offers sustainable opportunities for reducing carbon footprints and enhancing energy efficiency in the chemical industry. This paper presents an overview of recent research developments in incorporating electrical energy as a replacement for conventional thermal sources like gas and coal in industrial sectors. A literature review was conducted, identifying 70 relevant articles published until September 2020. The topics cover applications for industrial hydrogen generation processes and others, heat pumps, heat pumps, vapor re-compression systems, electric and magnetic fields as heat sources, nanoparticles for improved heat exchange, and ionized gases (plasma) in heating systems. While the application of industrial electrification shows promise globally, its sustainability depends on the efficiency and cost of electrical energy production and transportation at the regional and national levels. Among the various technologies, heat pumps integrated with vapor re-compression systems (VCR) for chemical processes, particularly in industrial distillation product separation columns, appear to be the most viable and widely applicable for waste heat recovery in the near future. Other technologies like electrochemical, plasma, microwave, magnetic, and electric field heating are still in the early stages of development or are limited to specific pilot or laboratory-scale processes. Full article

The dehydration of isopropanol (IPA) is a crucial process in numerous industries, and the optimization of its efficiency and economic viability is essential. This review provides a comprehensive analysis and comparison of various distillation processes, heat integration (HI) strategies, and process intensification (PI) techniques employed for IPA dehydration. The advantages, limitations, and applicability of distillation processes, such as extractive distillation, heterogeneous azeotropic distillation, and pressure swing distillation, are discussed. In addition, this review explores the potential of HI techniques to optimize energy consumption and reduce operating costs of IPA dehydration processes. PI techniques, including thermally coupled arrangements and dividing wall columns, are examined for their ability to improve the process efficiency and sustainability. It is crucial to conduct thorough evaluations, as well as energy and economic analyses, when choosing the appropriate distillation process, HI approach, and PI technique for specific IPA dehydration applications. This review emphasizes the potential for improving the energy efficiency, product purity, and cost-effectiveness of IPA dehydration through the integration of advanced distillation processes and PI techniques. Full article

A heat integration optimization method that considers the changes in process parameters is proposed to find the global optimal process scheme for a coal chemical company’s phenols and ammonia recovery process. The phenols and ammonia recovery process is simulated by Aspen Plus, and a programming method for heat exchanger networks synthesis that can simultaneously optimize process parameters and heat integration is constructed by Matlab. Taking the total annual cost as the objective function, the following process parameters are optimized: the hot feed temperature and cold/hot feed ratio of sour water stripper, the temperature of three-step partial condensation system, the feed temperature and column pressure of both solvent distillation column and solvent stripper. The result shows that, compared with the heat integration process under original process parameters, the new heat integration process saves 14.3% energy consumption and reduces the total annual cost by about 15.1%. The new heat integration process provides guidance for the optimization of the phenols and ammonia recovery process. The proposed heat integration optimization method based on changing process parameters is an effective and practical tool that offers good application prospects. Full article

Distillation is important to chemical processes but it is energy intensive, and its optimization is of great significance to energy savings and emissions reduction. Varying the operating pressures of distillation columns could assist heat integration of distillation columns into the overall process, thereby reducing energy consumption. However, influences of varying column pressures on the energy profiles of the overall process have not been systematically analyzed in previous studies. This paper presents an insightful analysis of heat integration of distillation into the overall process considering the change of operating pressure. Firstly, effects of changing the operating pressure of a distillation column on its own utility requirements and the related process streams are studied. Next, such effects are graphically represented and incorporated into the grand composite curve (GCC). The change tendencies of the GCC, pinch temperature, and total utility consumption are analyzed and presented. On this basis, rules to identify the best operating pressure that minimize the overall energy consumption are proposed. A continuous reforming unit in a petrochemical enterprise is quantitatively analyzed to verify the obtained rules. The result indicates that the hot utility of the overall process can be reduced by 758 kW when the column pressure is lowered by 260 kPa. Full article

Distillation has relatively low thermodynamic efficiency, so it is a prime target for process intensification studies. The current research aims to study exergy losses in various heat-integrated distillation columns. A conventional industrial-scale i-butane/n-butane fractionator has been selected as a case study for the comparison of the performances of various heat-integrated designs. The Aspen Plus^® process simulator is used to perform steady-state simulations and exergy analyses of the conventional distillation column (CDC), internally heat-integrated distillation column (iHIDiC), externally heat-integrated double distillation columns (EHIDDiC), and vapor recompression (VRC) systems. The results of these exergy analyses show that a modified VRC system (η_E = 10.69%) is the most efficient design for this separation. The exergy efficiency of the conventional VRC system is the same as that of the CDC (η_E = 9.27%). The EHIDDiC system (η_E = 9.77%) is somewhat better than the CDC, whereas iHIDiC shows poor exergy efficiency (η_E = 8.09%), even lower than the CDC. Full article

This perspective describes different schemes of power systems integration for various process technology in oil refining and petrochemistry with a focus on distillation. An overview is given of different methods of gas turbines and turboexpanders. Application of the organic Rankine cycle is considered for distillation processes, especially for unconventional schemes, which are integrated into the main process as stand-alone ones, as well when the working fluid of an energy system is a process stream per se. Despite a more complex structure and potential interference with the main process, such schemes are advantageous in terms of more efficient equipment utilization. Integration of turboexpanders in separation processes and in reactor units can improve energy generation efficiency 2–3 fold compared with traditional schemes of energy generation from fossil feedstock. From the economic viewpoint for distillation columns, total annual costs can be decreased by ca. 5–15% with the specific costs of additional generated electricity being very close to the costs of a heating utility. Full article
