The authors have designed a structure for a gyro system (used for the guidance of self-guided missiles) with two gimbals and a rotor in magnetic suspension (AMBs—active magnetic bearings). The system (double-gimbal magnetic suspension gyro system for guidance—DGMSGG) orients the common axis rotor AMB (the sight line) in the direction of the target line (the guide line) by means of some control system of the gyro rotor’s rotations and translations, as well as by means of some servo systems for the gimbals’ rotation angle control. The DGMSGG provides specific signals for the missile’s autopilot, to guide it toward the target, so that the guidance line translates parallel to itself to the point of interception of the target (according to the self-guidance method by parallel approach). Based on the DGMSGG’s established mathematical model, the authors propose and design adaptive control systems for the decoupled dynamics of the gyro rotor’s translations and rotations and of the gimbals’ rotations; the concept of dynamic inversion is used, as well as linear dynamic compensators (P.D.- and P.I.D.-type), state observers, reference models, and neural networks. The theoretical results are validated through numerical simulations, using Simulink/Matlab models’ stabilization and orientation operating regimes. Full article

This paper deals with identifying the fractional-order noise parameters for MEMS gyroscopes under various temperature conditions. The significant contribution of the paper is to investigate the relation between the fractional noise model of MEMS devices and different ambient temperatures. In our paper, variance, correlation, and introduced estimation analysis methods have been meticulously applied to determine noise parameters with fractional-order dynamics. Experimental data were collected precisely under various ambient temperatures, while the MEMS device was located in a climate chamber. The origin of the paper is motivated by a project entitled “Family of optoelectronic heads for guided missiles—SEEKER”, where the IMU sensor is a crucial electronic device used to measure the angular velocity of the optoelectronic head. It is widely known that the IMU measurements built-in MEMS technology often come with a random walk, as well as biases and noises affecting the final results. Full article

Incorporating silver wires into propellant has emerged as a highly effective strategy for enhancing propellant burning rates, a technique extensively deployed in the construction of numerous fielded sounding rockets and tactical missiles. Our research, employing a multi-faceted approach encompassing thermogravimetric-differential scanning calorimetry measurements (TG-DSC), combustion diagnoses, burning rate tests, and meticulous collection of condensed combustion products, sought to elucidate how variations in silver wire quantity and winding configuration impact the combustion properties of propellants. Our findings underscore the remarkable efficacy of double tightly twisted silver wire in significantly boosting propellant burning rates under ambient conditions. Moreover, at lower temperatures, the reduced gap between the propellant and silver wire further magnifies the influence of silver wire on burning rates. However, it is noteworthy that the relationship between burning speed and combustion efficiency is not deterministic. While a smaller cone angle of the burning surface contributes to heightened burning rates, it concurrently exacerbates the polymerization effect of vapor phase aluminum particles, consequently diminishing propellant combustion efficiency. Conversely, propellants configured with sparsely twinned silver wires exhibit notable enhancements in combustion efficiency, despite a less pronounced impact on the burning rate attributed to the larger cone angle of the burning surface. Remarkably, these trends persist at lower temperatures. Based on the principle of heat transfer balance, a theoretical model for the combustion of propellants with wire inserts is developed. The reliability of this theoretical model is validated through a comparison of calculated values with experimental data. Our research outcomes carry significant implications for guiding the application and advancement of the silver wire method in solid propellants for solid rocket motors, offering valuable insights to inform future research and development endeavors in this domain. Full article

Submerged inlets have been widely used in advanced aircraft due to their excellent stealth characteristics, but they also suffer from poor aerodynamic performance. To improve the aerodynamic efficiency while maintaining stealth capabilities, this paper proposes a design scheme for a front auxiliary inlet with an inlet grille. The front auxiliary inlet is connected to the main inlet to form a composite inlet system. The low-energy upstream airflow that accumulates at the inlet is guided by the front auxiliary inlet to flow into the mainstream, resulting in a stable and high-quality airflow. A certain type of cruise missile was used as the research subject, and intake systems with and without front auxiliary inlets were constructed to compare the inlet performance of the two configurations using the CFD method. Additionally, a sensitivity analysis of the main design parameters of the front auxiliary inlet was carried out. The study reveals that a reasonable design of the front auxiliary inlet can prevent low-energy airflow, which accumulates on the missile body surface, from directly entering the inlet. Moreover, the front auxiliary inlet can inject additional mechanical energy into the low-energy airflow, inhibit airflow separation, and improve the uniformity of the flow field. Under cruise conditions, the total pressure recovery coefficient of the front auxiliary inlet configuration increased by 12.39% compared to the model without a front auxiliary inlet configuration. Furthermore, the total pressure distortion index was reduced by 47.24%. Full article

Attacking a naval vessel with multiple missiles is an important way to improve the hit rate of missiles. Missile-borne radars need to complete detection and antijamming tasks to guide missiles, but communication between these radars is often difficult. In this paper, an optimization method based on multi-agent reinforcement learning is proposed for the collaborative detection and antijamming tasks of multiple radars against one naval vessel. We consider the collaborative radars as one player to make their confrontation with the naval vessel a two-person zero-sum game. With temporal constraints of the radar’s and jammer’s recognition and preparation interval, the game focuses on taking a favorable position at the end of the confrontation. It is assumed the total jamming capability of a shipborne jammer is constant and limited, and the shipborne jammer allocates the jamming capability in the radar’s direction according to the radar threat assessment result and its probability of successful detection. The radars work collaboratively through prior centralized training and obtain a good performance by decentralized execution. The proposed method can make radars collaborate to detect the naval vessel, rather than only considering the detection result of each radar itself. Experimental results show that the proposed method in this paper is effective, improving the winning probability to 10% and 25% in the two-radar and four-radar scenarios, respectively. Full article

Given the increasing tensions between world powers, missile defense is a topic that is more relevant than ever. However, information on the subject is often fragmented, confusing and untrustworthy. On the other hand, we believe that an informed overview of the current status is important for decision makers and citizens alike. A missile is essentially a guided rocket and therefore the term can be used to describe a very wide range of weapon systems. In this paper, we focus on long-range and intercontinental threats, which we believe are more important and problematic to defend against. We provide an overview of the two most common types of sensors, space-based infrared sensors and radars, and highlight their peculiarities and, most importantly, their drawbacks that severely limit their effectiveness. Full article

In this paper, an optimal-damage-effectiveness cooperative-control strategy based on a damage-efficiency model and a virtual-force method is proposed to solve the pursuit–evasion problem with multiple guided missiles. Firstly, different from the overly ideal assumption in the traditional pursuit–evasion problem, an optimization problem that maximizes the damage efficiency is established and solved, making the optimal-damage-effectiveness strategy more meaningful for practical applications. Secondly, a modified virtual-force method is proposed to obtain this optimal-damage-effectiveness control strategy, which solves the numerical solution challenges brought by the high-complexity damage function. Thirdly, adaptive gain is designed in this strategy based on guidance-integrated fuze technology to achieve robust maximum damage efficiency in unpredictable interception conditions. Finally, the effectiveness and robustness of the proposed strategy are verified by numerical simulations. Full article

A war game between two matched fleets of equal size and capability is designed and simulated in this work. Each fleet is composed of a carrier vessel (CV), a guided missile cruiser (CG), and two guided-missile destroyers (DDGs). Each vessel is equipped with specific weapons, including fighters, missiles, and close-in weapon system (CIWS), to carry out tactical operations. The maneuverability, maximum flying distance, and kill probability of different weapons are specified. Three goal options, a defense option and two more aggressive ones, are available to each fleet. A particle-pair swarm optimization (P${}^2$SO) algorithm is proposed to optimize the tactical parameters of both fleets concurrently according to their chosen options. The parameters to be optimized include take-off time delay of fighters, launch time delay of anti-ship missiles (ASHMs), and initial flying directions of fighters and ASHMs, respectively. All six possible contests between options are simulated and analyzed in terms of payoff, impact scores on CV, CG, DDG, and the number of lost fighters. Some interesting outlier cases are inspected to gain some insights on this game. Full article

A radar guidance system is a core component of a radar-guided air-to-air missile, and its tracking accuracy of airborne targets determines the operational effectiveness of said missile. To verify the tracking accuracy of the radar guidance system against an airborne target under the real flight conditions of the missile, an experimental verification system was implemented in this study. The mechanical, electrical, and bus interfaces of the verification system were examined. A tracking accuracy evaluation model of the seeker was designed based on the data obtained from the experiments using the proposed test method, and the tracking accuracy of the seeker in the typical state was analyzed. Full article

Single-axis rotation modulation (SRM) still accumulates errors in the roll axis direction, which leads to the navigation accuracy not meeting the requirements of guided missiles. Compound rotation modulation (CRM) superimposes one-dimensional rotation on the basis of SRM, so that the error of the projectile in the direction of the roll axis is also modulated. However, the error suppression effect of CRM is not only affected by the error of the IMU itself, but also related to the modulation angular velocity. In order to improve the accuracy of rotary semi-strapdown inertial navigation system (RSSINS), this paper proposes an optimal rotation angular velocity determination method. Firstly, the residual error in CRM scheme is analyzed; then, the relationship between the incomplete modulation error and the modulation angular velocity in CRM is discussed; finally, a method for determining the optimal modulation angular velocity is proposed (K-value method). The analysis of the results shows that the navigation accuracy of the guided projectile is effectively improved with the rotation scheme set at the modulation angular velocity determined by the K-value method. Full article

This correspondence proposes an optimal cooperative guidance law for protecting a target from a guided missile. The linearized three-body kinematics using the line-of-sight (LOS) triangle concept is formulated, and a new concept called error distance is introduced. A generalized linear quadratic optimization problem is formulated in minimizing weighted energy consumption while regulating the error distance. The analytic guidance command is derived by solving the optimization problem formulated. The main feature of the proposed guidance law lies in that it helps reduce the maneuver capability demand of the defender. Extensive numerical simulations are carried out to demonstrate the effectiveness of the proposed solution. Full article

This article approaches the issue of the optimal control of a hypothetical anti-tank guided missile (ATGM) with an innovative rocket engine thrust vectorization system. This is a highly non-linear dynamic system; therefore, the linearization of such a mathematical model requires numerous simplifications. For this reason, the application of a classic linear-quadratic regulator (LQR) for controlling such a flying object introduces significant errors, and such a model would diverge significantly from the actual object. This research paper proposes a modified linear-quadratic regulator, which analyzes state and control matrices in flight. The state matrix is replaced by a Jacobian determinant. The ATGM autopilot, through the LQR method, determines the signals that control the control surface deflection angles and the thrust vector via calculated Jacobians. This article supplements and develops the topics addressed in the authors’ previous work. Its added value includes the introduction of control in the flight direction channel and the decimation of the integration step, aimed at speeding up the computational processes of the second control loop, which is the LQR based on a linearized model. Full article

In order to carry out various detections of system indicators during the research and development phase of infrared guided missiles, the article first analyzes several main design schemes of the infrared guided missile detection simulator and finds that it has the disadvantages of difficult processing technology and low detection accuracy. The overall structure of the detection device was designed, including the design of the rotation and swing mechanism, lens mechanism, optical system and control system. The optical system error analysis is performed on the infrared guided missile detection simulator. The position of the receiving light source is obtained by analyzing the mechanism characteristics of the detection simulator and the kinematics model of the device. The phase difference analysis of the eccentricity and tilt system is obtained. The image quality was evaluated by the optical transfer function (MTF), and the system error was found to meet the requirements of imaging quality. The experiments show that the simulation of 1.7~4.9 um medium wave infrared dynamic target signals provides an accurate and reasonable experimental environment for the missile and the verification of the light source target and meets the experimental requirements. Full article

The paper presents the concept of controlling the designed optoelectronic scanning and tracking seeker. The above device is intended for the so-called passive guidance of short-range anti-aircraft missiles to various types of air maneuvering targets. In the presented control method, the modified linear-quadratic regulator (LQR) and the estimation of input signals using the extended Kalman filter (EKF) were used. The LQR regulation utilizes linearization of the mathematical model of the above-mentioned seeker by means of the so-called Jacobians. What is more, in order to improve the stability of the seeker control, vector selection of signals received by the optoelectronic system was used, which also utilized EKF. The results of the research are presented in a graphical form. Numerical simulations were carried out on the basis of the author’s own program developed in the programming language C++. Full article
