Search Results (16)

Anaerobic wastewater treatment technology has been intensively and extensively investigated in the industry and scientific research. Inspired by the advantages of multi-stage and multi-phase anaerobic reactor technology (SMPA) in recent years, a three-stage anaerobic reactor (3S-AR) was designed and applied to treat poplar chemical–mechanical pulp wastewater, and various operation parameters, including the volume loading rate (VLR), hydraulic retention time (HRT), ascending velocity, reflux ratio, pH and temperature of the 3S-AR, were optimized to evaluate the reactor’s removal efficiency for poplar wastewater. The properties of anaerobic granular sludge and the composition of wastewater were also characterized to assess microorganism growth and pollutant migration. Results show that the COD removal rate was over 75% with a volume loading rate range of 15–25 gCOD/(L·d) in the 3S-AR; the hydraulic retention time was also found to be an important factor affecting the performance of the 3S-AR reactor. The volume loading rate and degradation efficiency of the 3S-AR reactor are higher than those of the up-flow anaerobic sludge blanket (UASB) reactor. Microorganism separation can be achieved in the 3S-AR, which is conducive to the growth and methanogenesis activity of bacteria, thereby leading to enhanced removal and buffering efficiency. After treatment in the 3S-AR, the main pollutants of poplar wastewater were benzene aromatic acids and long-chain esters, which do no biodegrade easily; in contrast, most of the fatty acid substances with small molecules were completely degraded. Full article

Nowadays, almost all countries in the world are intensifying their search for locally available energy sources to become independent of external supplies. The production of alternative fuels from biomass and waste by thermal treatment or direct use in the combustion process is still the simplest method for fast and cheap heat production. However, the different characteristics of these fuels can cause problems in the operation of the plants, resulting in increased air pollution. Therefore, the analysis of the thermal treatment of solid fuels is still an important issue from a practical point of view. This work aimed to study biomass combustion in a small-scale reactor using the in-house Extended DEM (XDEM) method based on mixed Lagrangian–Eulerian approaches. This was provided by a novel, independently developed coupling computational interface. This interface allows for a seamless integration between CFD and DEM, improving computational efficiency and accuracy. In addition, significant advances have been made in the underlying physical models. Within the DEM framework, each particle undergoes the thermochemical processes, allowing for the prediction of its shape and structural changes during heating. Together, these changes contribute to a more robust and reliable simulation tool capable of providing detailed insights into complex multi-phase flows and granular material behavior. Numerical results were obtained for a non-typical geometry to check the influence of the walls on the distribution of the parameters in the reactor. The results show that XDEM is a very good tool for predicting the phenomena during the thermal treatment of solid fuels. In particular, it provides information about all the moving particles undergoing chemical reactions, which is very difficult to obtain from measurements. Full article

Ultrafast X-ray computed tomography is an advanced imaging technique for multiphase flows. It has been used with great success for studying gas–liquid as well as gas–solid flows. Here, we apply this technique to analyze density-driven particle segregation in a rotating drum as an exemplary use case for analyzing industrial particle mixing systems. As glass particles are used as the denser of two granular species to be mixed, beam hardening artefacts occur and hamper the data analysis. In the general case of a distribution of arbitrary materials, the inverse problem of image reconstruction with energy-dependent attenuation is often ill-posed. Consequently, commonly known beam hardening correction algorithms are often quite complex. In our case, however, the number of materials is limited. We therefore propose a correction algorithm simplified by taking advantage of the known material properties, and demonstrate its ability to improve image quality and subsequent analyses significantly. Full article

Pneumatic conveying is a vital technology for delivering bulk solids, powders, and granular materials in various industries. Significant advances in pneumatic conveying technology have occurred in recent years, spurred by the demand for sustainable and energy-efficient industrial processes. This paper explores the current advances in pneumatic conveying technology and their implications for the industry. First, the principles of pneumatic conveying are discussed. Then, two significant advances in pneumatic conveying technology are highlighted. Schenck Process, for example, has created the Enhanced Dilute Phase Pneumatic Conveying (EDIP) system, the E-Finity continuous dense phase system, and high-pressure systems utilizing Lontra’s LP2 Compressor Blower. Second, Palamatic Process provides dense-phase vacuum conveying cyclones as well as powder pumps for nonabrasive dense-phase vacuum conveying. Several research gaps in pneumatic conveying technology are identified in the paper, including the integration of artificial intelligence and machine learning, the optimization of multiphase flow behavior, energy efficiency and sustainability, material degradation, and particle damage, handling of cohesive and difficult-to-convey materials, scale-up and design optimization, and real-time monitoring and control systems. The future outlook highlights the potential of sustainable practices to advance pneumatic conveying technology further. The integration of these technologies can lead to improved performance, energy efficiency, and sustainability in pneumatic conveying systems. Full article

The Eulerian Wall Film (EWF) model is a mathematical model employed to analyze the behavior of fluid films on a surface. The model has been widely adopted in various engineering applications due to its accuracy and efficiency. However, it is rarely applied in the aerospace field. The solution of the water-drop impact constitutes an indispensable prerequisite for the computation of ice accretion on the exterior of aircraft wings. In this study, we propose a novel approach for the estimation of water-drop impact on wing surfaces by integrating the Euler–Euler approach and EWF model. This approach is capable of furnishing a point of reference and a theoretical foundation for prospective water-drop impact experiments. Through comparison with pertinent experimental findings, the precision of the numerical simulation approach utilized in this paper is substantiated. Specifically, the research object is the NACA653-218 airfoil of the C-919 transport aircraft, for which the aerodynamic properties, water-drop collision, and liquid film flow characteristics during steady flight were simulated. Full article

A numerical simulation procedure is proposed for analyzing the partial replacement of pulverized coal injection by hydrogen, oxygen, and blast furnace gas (BFG) injections mixed with pulverized coal (PCI) within the tuyeres of large blast furnaces. The massive use of hydrogen-rich gas is extremely interesting for ironmaking blast furnaces in the context of net-zero carbon hot metal production. Likewise, this new approach allows for increasing productivity and for reducing the specific emissions of carbon dioxide toward a net-zero carbon ironmaking technology. Nevertheless, the mixture of pulverized coal injection and gas injection is a complex technology. In addition to the impact on chemical reactions and energy exchange, the internal temperature and gas flow patterns can also change drastically. With a view to assessing the state of the furnace in this complex operation, a comprehensive mathematical model utilizing multiphase theory was developed. The model simultaneously handles bulk solids (sinter, pellets, small coke, granular coke, and also iron ore), gas, liquid metal and slag, and coal powder phases. The associated conservation equations take into account momentum, mass, chemical species, and energy while being discretized and solved using finite volume techniques. The numerical model was validated against the reference operating conditions using 220 kg per ton of pig iron (kg/t_HM) of pulverized coal. Therefore, the combined injection of different concentrations of fuel hydrogen, blast furnace gas, and oxygen was simulated for replacing 40, 60, and 80 kg/t_HM of coal injection. Theoretical analysis showed that the best scenario with stable operation conditions could be achieved with a productivity increase of 20% corresponding to a CO₂ reduction of 15% and 60 kg/t_HM of PCI replacement. Full article

Complex multiphase flow problems in ocean engineering have long been challenging topics. Problems such as large deformations at interfaces, multi-media interfaces, and multiple physical processes are difficult to simulate. Mesh-based algorithms could have limitations in dealing with multiphase interface capture and large interface deformations. On the contrary, the Smoothed Particle Hydrodynamics (SPH) method, as a Lagrangian meshless particle method, has some merit and flexibility in capturing multiphase interfaces and dealing with large boundary deformations. In recent years, with the improvement of SPH theory and numerical models, the SPH method has made significant advances and breakthroughs in terms of theoretical completeness and computational stability, which starts to be widely used in ocean engineering problems, including multiphase flows under atmospheric pressure, high-pressure multiphase flows, phase-change multiphase flows, granular multiphase flows and so on. In this paper, we review the progress of SPH theory and models in multiphase flow simulations, discussing the problems and challenges faced by the method, prospecting to future research works, and aiming to provide a reference for subsequent research. Full article

Computational fluid dynamics (CFD) have been extensively used to simulate the hydrodynamics of multiphase flows (MPFs) in rotating machinery. In the presence of a granular dense phase, the Kinetic Theory of Granular Flow (KTGF) is usually coupled to Eulerian multi-fluid models to obtain tractable computational fluid models. In the present work, the hydrodynamic behavior of a three dimensional, industrial scale, and rotating drum granulator with gas–solid flows is assessed using the Eulerian–Eulerian approach coupled with the k-$\epsilon$ standard turbulence model. A Eulerian–Eulerian Two-Fluid Model (TFM) is used with the KTGF model for the granular phase. The sensitivities to different operating parameters, including the rotational speed (8, 16, and 24 rpm), inclination degree ($3.{57}^{\circ }$, $5.{57}^{\circ }$, and $7.{57}^{\circ }$), and degree of filling ($20\%$, $30\%$, and $40\%$) are studied. Moreover, the impact of the drag model on the simulation accuracy is investigated. The flow behavior, regime transitions, and particle distribution are numerically evaluated, while varying the operating conditions and the drag models. The rotational speed and filling degree appear to have greater influences on the granulation effectiveness than on the inclination degree. Three drag models are retained in our analysis. Both the Gidaspow and Wen and Yu models successfully predict the two-phase flow in comparison to the Syamlal and O’Brien model, which seems to underestimate the hydrodynamics of the flow in both its axial and radial distributions (a fill level less than $35\%$). The methodology followed in the current work lays the first stone for the optimization of the phosphates fertilizer wet-granulation process within an industrial installation. Full article

The present study provides and examines an experimental and CFD simulation to predict and accurately quantify the individual phase holdup. The experimental findings demonstrated that the increase of solid beads has a significant influence on the (U_mf), as comparatively small glass beads particles require a low (U_mf) value, which tends to increase as the diameter of the beads increases. Besides that, the expansion ratio is proportional to the velocity of the liquid. Even though, the relationship becomes inversely proportional to the diameter of the beads. The liquid holdup was found to increase with increasing liquid velocity, however, the solid holdup decreased. The Eulerian–Eulerian granular multiphase flow technique was used to predict the overall performance of the liquid–solid fluidized beds (LSFBs). There was a good agreement between the experimental results and the dynamic properties of liquid–solid flows obtained from the CFD simulation, which will facilitate future simulation studies of liquid–solid fluidized beds. This work has further improved the understanding and knowledge of CFD simulation of such a system at different parameters. Furthermore, understanding the hydrodynamics features within the two-phase fluidization bed, as well as knowing the specific features, is essential for good system design, enabling the systems to perform more effectively. Full article

Various simulations have been conducted to understand the macroscopic behavior of particles in the solid-gas flow in rotating drums in the past. In these studies, the no-slip wall boundary condition and fixed restitution coefficient between particles were usually adopted. The paper presents a numerical study of the gas-solid flow in a rotating drum to understand the effect of the specularity coefficient and restitution coefficient on the hydrodynamic behavior of particles in the segregation process. The volume fraction, granular pressure, granular temperature and their relationships are examined in detail. The boundary conditions of the no-slip and specularity coefficient of 1 are compared. In the simulations, two different sizes of particles with the same density are considered and the Eulerian–Eulerian multiphase model and the kinetic theory of granular flow (KTGF) are used. The results reveal that the hydrodynamical behavior of the particles in the rotating drum is affected by the boundary condition and restitution coefficient. In particular, the increase of specularity coefficient can increase the active region depth, angle repose, granular pressure for both small and large particles and granular temperature for large particles. With increasing restitution coefficient, the angle of repose decreases and granular pressure and temperature increase at the same volume fraction for both small and large particles. Full article

Submarine debris flows and their generated waves are common disasters in Nature that may destroy offshore infrastructure and cause fatalities. As the propagation of submarine debris flows is complex, involving granular material sliding and wave generation, it is difficult to simulate the process using conventional numerical models. In this study, a numerical model based on the smoothed particle hydrodynamics (SPH) algorithm is proposed to simulate the propagation of submarine debris flow and predict its generated waves. This model contains the Bingham fluid model for granular material, the Newtonian fluid model for the ambient water, and a multiphase granular flow algorithm. Moreover, a boundary treatment technique is applied to consider the repulsive force from the solid boundary. Underwater rigid block slide and underwater sand flow were simulated as numerical examples to verify the proposed SPH model. The computed wave profiles were compared with the observed results recorded in references. The good agreement between the numerical results and experimental data indicates the stability and accuracy of the proposed SPH model. Full article

A critical challenge underpinning the adoption of Additive Manufacture (AM) as a technology is the postprocessing of manufactured components. For Powder Bed Fusion (PBF), this can involve the removal of powder from the interior of the component, often by vibrating the component to fluidise the powder to encourage drainage. In this paper, we develop and validate a computational model of the flow of metal powder suitable for predicting powder removal from such AM components. The model is a continuum Eulerian multiphase model of the powder including models for the granular temperature; the effect of vibration can be included through appropriate wall boundaries for this granular temperature. We validate the individual sub-models appropriate for AM metal powders by comparison with in-house and literature experimental results, and then apply the full model to a more complex geometry typical of an AM Heat Exchanger. The model is shown to provide valuable and accurate results at a fraction of the computational cost of a particle-based model. Full article

In this study, the multi-phase Eulerian–Eulerian two-fluid method (TFM) coupled with the kinetic theory of granular flow (KTGF) was used to investigate the hydrodynamics of particle flows (Geldart Group B) in a lab-scale bubbling fluidized bed. The goal was to improve the bubble flow behavior inside the fluidized bed to improve the distribution of an injected liquid, by increasing the flow of bubbles entering the spray jet cavity and, thus, reduce the formation of wet agglomerates. The effects of a baffle on both the injection level and the whole fluidized bed were studied. Different baffle geometries were also investigated. Adding a fluxtube to a baffle can improve the bubble flows and a long fluxtube works best at redirecting gas bubbles. Baffles tend to smooth out variations in the gas distribution caused by the non-uniform inlet gas distribution. A gas pocket appears under all the baffles. Full article

Particle mixing process is critical for the design and quality control of concrete and composite production. This paper develops an algorithm to simulate the high-shear mixing process of a granular flow containing a high proportion of solid particles mixed in a liquid. DEM is employed to simulate solid particle interactions; whereas SPH is implemented to simulate the liquid particles. The two-way coupling force between SPH and DEM particles is used to evaluate the solid-liquid interaction of a multi-phase flow. Using Darcy’s Law, this paper evaluates the coupling force as a function of local mixture porosity. After the model is verified by two benchmark case studies, i.e., a solid particle moving in a liquid and fluid flowing through a porous medium, this method is applied to a high shear mixing problem of two types of solid particles mixed in a viscous liquid by a four-bladed mixer. A homogeneity metric is introduced to characterize the mixing quality of the particulate mixture. The virtual experiments with the present algorithm show that adding more liquid or increasing liquid viscosity slows down the mixing process for a high solid load mix. Although the solid particles can be mixed well eventually, the liquid distribution is not homogeneous, especially when the viscosity of liquid is low. The present SPH-DEM model is versatile and suitable for virtual experiments of particle mixing process with different blades, solid particle densities and sizes, and liquid binders, and thus can expedite the design and development of concrete materials and particulate composites. Full article

The compressible and turbulent gas–solid multiphase flow inside a fluidized bed opposed jet mill was systematically investigated through numerical simulations using the Euler–Euler approach along with the kinetic theory of granular flow and frictional models. The solid holdup and nozzle inlet air velocity effects on the gas–solid dynamics were assessed through a detailed analysis of the time-averaged volume fraction, the time-averaged velocity, the time-averaged streamlines, and the time-averaged vector field distributions of both phases. The simulated results were compared with the experimental observations available in the literature. The numerical simulations contributed to a better understanding of the particle–flow dynamics in a fluidized bed opposed gas jet mill which are of fundamental importance for the milling process performance. Full article
