Search Results (29)

Prostate cancer is the second leading cause of cancer-related deaths among men in the United States. The early detection of aggressive forms is critical. Current diagnostic methods, including PSA testing and biopsies, are invasive and often yield false results. MicroRNA-141 (miRNA-141) has emerged as a promising non-invasive biomarker due to its elevated levels in the urine of patients with metastatic prostate cancer. Here, a low-cost, paper-based electrochemical biosensor for the sensitive detection of miRNA-141 in synthetic urine is reported. The device employs inkjet-printed gold electrodes on photopaper, functionalized with thiolated single-stranded DNA-141 capture probes for specific target recognition. The biosensor achieves a sensitivity of 78.66 fM µA⁻¹ cm⁻² and a linear detection range of 1 fM to 100 nM, encompassing clinically relevant concentrations of miRNA-141 found in patients with metastatic prostate cancer. A low limit of detection of 2.15 fM, strong selectivity against non-target sequences, and a rapid response time of 15 min further highlight the diagnostic potential of the device. This platform represents a significant advancement in the development of point-of-care diagnostic tools for prostate cancer and is readily adaptable for detecting other disease-specific miRNAs through simple probe modification. As such, it holds broad promise for accessible, early-stage cancer detection and longitudinal disease monitoring in diverse clinical settings. Full article

Drop-on-demand (DoD) printing is an additive manufacturing technique that utilizes functional inks containing nanoparticles (NPs) to fabricate electronic circuits or devices on a variety of substrates. One of the most promising applications for such technology is the aerospace industry, due to the capability of this method to fabricate custom low-weight geometric films. This work evaluates the performance of a gold (Au) nanoparticle (NP)-based film printed on a ceramic substrate for avionics applications, following the environmental temperature guidance of the Radio Technical Commission for Aeronautics (RTCA) DO-160. Experimental results show that the Au films, printed on alumina substrates, successfully survived the environmental temperature procedures for airborne equipment. The thermal coefficient of resistance (TCR) of the films was measured to be $2.7\times {10}^{-3} {°\mathrm{C}}^{-1}.$ Full article

Our research outlines a method for creating chemosensors utilizing hybrid nanostructures derived from TiO₂ ceramic nanotubes alongside conducting polymers, with embedded gold nanoparticles. The method used to create hybrid nanostructures from ceramic nanotubes and conducting polymers was drop-casting. AFM analysis highlighted an increased roughness, particularly for PANI-EB, exhibiting a significantly larger grain size exceeding 3.5 μm, with an increased inclusion of gold and uniform arrangement on the surface. The Rku parameter values being around three suggested that the layers primarily exhibited peaks rather than depressions, showing a Gaussian distribution. A chemiresistor was created by using an ink-jet printer and a multilayer metallization was achieved with commercial silver ink for printed electronics. Based on the experimental calibration curve, which exhibits adequate linearity over a wider range of H₂S concentrations in air up to 1 ppm, the detection limit was established at 0.1 ppm, a threshold appropriate for recognizing oral diseases. The sensor is a simple, affordable, and durable device designed for individual use, offering significant benefits for patients by enabling improved tracking of the syndrome’s advancement or treatment success. Full article

The visualization of the spatial distributions of gases from various sources is essential to understanding the composition, localization, and behavior of these gases. In this study, an inkjet-printed localized surface plasmon resonance (LSPR) subpixel gas sensor array was developed to visualize the spatial distributions of gases and to differentiate between acetic acid, geraniol, pentadecane, and cis-jasmone. The sensor array, which integrates gold nanoparticles (AuNPs), silver nanoparticles (AgNPs), and fluorescent pigments, was positioned 3 cm above the gas source. Hyperspectral imaging was used to capture the LSPR spectra across the sensor array, and these spectra were then used to construct gas information matrices. Principal component analysis (PCA) enabled effective classification of the gases and localization of their sources based on observed spectral differences. Heat maps that visualized the gas concentrations were generated using the mean squared error (MSE) between the sensor responses and reference spectra. The array identified and visualized the four gas sources successfully, thus demonstrating its potential for gas localization and detection applications. The study highlights a straightforward, cost-effective approach to gas sensing and visualization, and in future work, we intend to refine the sensor fabrication process and enhance the detection of complex gas mixtures. Full article

Electrochemical paper-based analytical devices (ePADs) offer an innovative, low-cost, and environmentally friendly approach for real-time diagnostics. In this study, we developed a functional all-inkjet paper-based electrochemical immunosensor using gold (Au) printed ink to detect salivary cortisol. Covalent binding of the cortisol monoclonal antibody onto the printed Au surface was achieved through electrodeposition of 4-carboxymethylaniline (CMA), with ethanolamine passivation to prevent non-specific binding. The ePAD exhibited a linear response within the physiological cortisol range (5–20 ng/mL), with sensitivities of 25, 23, and 19 Ω·ng/mL and R² values of 0.995, 0.979, and 0.99, respectively. Additionally, interference studies against tumor necrosis factor-α (TNF-α) and N-terminal pro-B-type natriuretic peptide (NT-proBNP) yielded excellent results. This novel ePAD, fabricated using inkjet printing technology on paper, simplifies the process, reduces environmental impact, and lowers fabrication costs. Full article

Cancer is the second leading cause of death globally, with 9.7 million fatalities in 2022. While routine screenings are vital for early detection, healthcare disparities persist, highlighting the need for equitable solutions. Recent advancements in cancer biomarker identification, particularly microRNAs (miRs), have improved early detection. MiR-21 is notably overexpressed in various cancers and can be a valuable diagnostic tool. Traditional detection methods, though accurate, are costly and complex, limiting their use in resource-limited settings. Paper-based electrochemical biosensors offer a promising alternative, providing cost-effective, sensitive, and rapid diagnostics suitable for point-of-care use. This study introduces an innovative electrochemical paper-based biosensor that leverages gold inkjet printing for the quantitative detection of miR-21. The biosensor, aimed at developing cost-effective point-of-care devices for low-resource settings, uses thiolated self-assembled monolayers to immobilize single-stranded DNA-21 (ssDNA-21) on electrodeposited gold nanoparticles (AuNPs) on the printed gold surface, facilitating specific miR-21 capture. The hybridization of ssDNA-21 with miR-21 increases the anionic barrier density, impeding electron transfer from the redox probe and resulting in a current suppression that correlates with miR-21 concentration. The biosensor exhibited a linear detection range from 1 fM to 1 nM miR-21 with a sensitivity of 7.69 fM µA⁻¹ cm² and a rapid response time (15 min). With a low detection limit of 0.35 fM miR-21 in serum, the biosensor also demonstrates excellent selectivity against interferent species. This study introduces an electrochemical paper-based biosensor that uses gold inkjet printing to precisely detect miR-21, a key biomarker overexpressed in various cancers. This innovative device highlights the potential for cost-effective, accessible cancer diagnostics in underserved areas. Full article

The selection of an appropriate transducer is a key element in biosensor development. Currently, a wide variety of substrates and working electrode materials utilizing different fabrication techniques are used in the field of biosensors. In the frame of this study, the following three specific material configurations with gold-finish layers were investigated regarding their efficacy to be used as electrochemical (EC) biosensors: (I) a silicone-based sensor substrate with a layer configuration of 50 nm SiO/50 nm SiN/100 nm Au/30–50 nm WTi/140 nm SiO/bulk Si); (II) polyethylene naphthalate (PEN) with a gold inkjet-printed layer; and (III) polyethylene terephthalate (PET) with a screen-printed gold layer. Electrodes were characterized using electrochemical impedance spectroscopy (EIS) and cyclic voltammetry (CV) to evaluate their performance as electrochemical transducers in an aptamer-based biosensor for the detection of cardiac troponin I using the redox molecule hexacyanoferrade/hexacyaniferrade (K3[Fe (CN)6]/K4[Fe (CN)6]. Baseline signals were obtained from clean electrodes after a specific cleaning procedure and after functionalization with the thiolate cardiac troponin I aptamers “Tro4” and “Tro6”. With the goal of improving the PEN-based and PET-based performance, sintered PEN-based samples and PET-based samples with a carbon or silver layer under the gold were studied. The effect of a high number of immobilized aptamers will be tested in further work using the PEN-based sample. In this study, the charge-transfer resistance (Rct), anodic peak height (I_pa), cathodic peak height (I_pc) and peak separation (∆E) were determined. The PEN-based electrodes demonstrated better biosensor properties such as lower initial Rct values, a greater change in Rct after the immobilization of the Tro4 aptamer on its surface, higher I_pc and I_pa values and lower ∆E, which correlated with a higher number of immobilized aptamers compared with the other two types of samples functionalized using the same procedure. Full article

Among the conventional inks used for inkjet printing, metals, oxides, or polymers have been deposited in order to form functional coatings. Gold is one of the most used metals for electrode fabrication in the gas sensor field due to its inert behavior when exposed to reactive gases and conductive properties. However, only a few commercial gold inks are commercially available, and the combination of excessive price, a high minimum purchase quantity, and an unknown composition renders the actual products unappealing. To meet these shortcomings, gold inks were formulated with different solvents in order to reach sufficient properties for the inkjet printing process, such as surface tension and viscosity. On the one hand, gold ink was developed using a gold nanoparticle (AuNP) solution as the metal. This ink was optimized from nanoparticle synthesis, with the ink formulation obtaining a 32 mN·m⁻¹ surface tension and 11.2 mPa·s viscosity in order to be inkjet-printed onto polyimide foil. On the other hand, a particle-free ink, called a precursor based of ink, was also developed. In this case, ink was made by solubilizing gold salt in aqueous medium in order to reach jettable properties. Surface tension was measured at 32 mN·m⁻¹ while viscosity was 14.0 mPa·s. Then, printing and deposition parameters were optimized in order to obtain a highly conductive gold coating. The measured resistivity was 2 × 10⁻⁷ Ω·m which is close to the bulk gold conductive value. These coatings could be used for the fabrication of various devices in different working fields. Full article

The coating process involves applying a thin material layer to a surface to engender it with specific desirable properties or enhance its performance. In the production of print media (labels, packaging, printed textiles, and promotional materials), the standard functions of the coating process include visual decoration, which involves the addition of appealing colors, textures, and patterns. A pertinent issue in the printing industry is that at present, the predominant coating process uses printing and coating technologies (gravure, flexo, letterset, letterpress, screen printing, inkjet, and electrophotography) and lamination (i.e., attaching decorative layers of materials, such as films or fabrics). In this paper, we present a new method for testing the efficiency with which different-sized metalized printing elements (using gold foil) may be applied to paper substrates; to do so, we gradually vary the amount UV-cured inkjet varnish (or adhesive) that is applied. To test the effectiveness of this method in producing metallic visual effects, we utilize seven different thicknesses of UV-cured varnish with the aid of modular piezo inkjet heads (KM1024 iLHE-30) and three different printing speeds. Our research shows that to achieve optimal production of cold metalized foil, a 21 µm layer should be deposited, and the substrate should move at a speed of 0.30 m/s. Full article

This work focuses on demonstrating the working principle of inkjet-printed Au nanoparticle (NP) split-ring resonators (SRRs) as a novel platform for the detection of analytes on flexible substrates. Potential applications of this technology include rapid and reusable near-patient diagnostics. In the method, a microwave electromagnetic wave is coupled into the Au SRR via a printed Cu-NP stripline sintered photonically on a solid FR1 substrate. This coupling mechanism facilitates the detection of analytes by inducing resonance shifts in the SRR. To demonstrate the sensing principle of the platform, biomolecules are attached to the SRR and the resulting resonance shift is measured. All experiments show resonance frequency shifts in the range of approximately 20–30 MHz. Full article

This work focuses on demonstrating the working principle of inkjet-printed Au nanoparticle (NP) two-layer Gigahertz (2.6 GHz) microwave split-ring resonators (SRRs) as a novel platform for the detection of analytes on flexible substrates. In contrast to the standard fabrication of split-ring resonator biosensors using printed circuit board technology, which results in a seven-layer system, the resonators in this work were fabricated using a two-layer system. A ground plane is embedded in the SRR measurement setup. In this method, a microwave electromagnetic wave is coupled into the Au SRR via an inkjet-printed Cu-NP stripline that is photonically sintered. This coupling mechanism facilitates the detection of analytes by inducing resonance shifts in the SRR. In this study, the functionality of the printed sensors was demonstrated using two different Au functionalization processes, firstly, with HS-PEG7500-COOH, and, secondly, with protein G with an N-terminal cysteine residue. The sensing capabilities of the printed structures are shown by the attachment of biomolecules to the SRR and the measurement of the resulting resonance shift. The experiments show a clear shift of the resonance frequency in the range of 20–30 MHz for both approaches. These results demonstrate the functionality of the simplified printed two-layer microwave split-ring resonator for use as a biosensor. Full article

Dielectric Elastomer Actuators (DEAs) enable the realization of energy-efficient and compact actuator systems. DEAs operate at the kilovolt range with typically microampere-level currents and hence minimize thermal losses in comparison to low voltage/high current actuators such as shape memory alloys or solenoids. The main limiting factor for reaching high energy density in high voltage applications is dielectric breakdown. In previous investigations on silicone-based thin films, we reported that not only do environmental conditions and film parameters such as pre-stretch play an important role but that electrode composition also has a significant impact on the breakdown behavior. In this paper, we present a comprehensive study of electrical breakdown on thin silicone films coated with electrodes manufactured by five different methods: screen printing, inkjet printing, pad printing, gold sputtering, and nickel sputtering. For each method, breakdown was studied under environmental conditions ranging from 1 °C to 80 °C and 10% to 90% relative humidity. The effect of different manufacturing methods was analyzed as was the influence of parameters such as solvents, silicone content, and the particle processing method. The breakdown field increases with increasing temperature and decreases with increasing humidity for all electrode types. The stiffer metal electrodes have a higher breakdown field than the carbon-based electrodes, for which particle size also plays a large role. Full article

The exceptional property of plasmonic materials to localize light into sub-wavelength regimes has significant importance in various applications, especially in photovoltaics. In this study, we report the localized surface plasmon-enhanced perovskite solar cell (PSC) performance of plasmonic gold nanoparticles (AuNPs) embedded into a titanium oxide (TiO₂) microdot array (MDA), which was deposited using the inkjet printing technique. The X-ray (XRD) analysis of MAPI (methyl ammonium lead iodide) perovskite films deposited on glass substrates with and without MDA revealed no destructive effect of MDA on the perovskite structure. Moreover, a 12% increase in the crystallite size of perovskite with MDA was registered. Scanning electron microscopy (SEM) and high-resolution transmission electron microscopy (HR-TEM) techniques revealed the morphology of the TiO₂_MDA and TiO₂-AuNPs_MDA. The finite-difference time-domain (FDTD) simulation was employed to evaluate the absorption cross-sections and local field enhancement of AuNPs in the TiO₂ and TiO₂/MAPI surrounding media. Reflectance UV-Vis spectra of the samples comprising glass/TiO₂ ETL/TiO₂_MDA (ETL—an electron transport layer) with and without AuNPs in TiO₂_MDA were studied, and the band gap (E_g) values of MAPI have been calculated using the Kubelka–Munk equation. The MDA introduction did not influence the band gap value, which remained at ~1.6 eV for all the samples. The photovoltaic performance of the fabricated PSC with and without MDA and the corresponding key parameters of the solar cells have also been studied and discussed in detail. The findings indicated a significant power conversion efficiency improvement of over 47% in the PSCs with the introduction of the TiO₂-AuNPs_MDA on the ETL/MAPI interface compared to the reference device. Our study demonstrates the significant enhancement achieved in halide PSC by utilizing AuNPs within a TiO₂_MDA. This approach holds great promise for advancing the efficiency and performance of photovoltaic devices. Full article

In this study, we report the development of a technique to fabricate a screen-printed electrode (SPE) and apply it in uric acid sensing. The SPE was fabricated by printing it on a photo paper substrate using a printing technique on an office printer. In particular, the conductive ink used to print the working electrode (WE) and counter electrode (CE) consisted of graphene oxide (GO) and a gold nanorod (AuNR) material. While the reference electrode (RE) was made by applying a conductive silver paste to the fabricated SPE, the electrochemical measurement of uric acid solution using fabricated SPE GO/AuNR provided a higher signal than commercially available SPE. The electroanalytical performance of the fabricated SPE based on GO/AuNR, which was used to measure the uric acid solution, exhibited a linear range of 0.8−200 μM, a detection limit of 0.5 μM, a quantitation limit of 1.0 μM, an outstanding repeatability (% relative standard deviation) of 4.885%, and good selectivity with ascorbic acid, dopamine, glucose, urea, and sodium as interference. Furthermore, an SPE, fabricated based on GO/AuNR, was successfully employed for the determination of uric acid concentration in human urine samples using the standard addition approach. Full article

Early detection and timely intervention play a vital role in the effective management of Alzheimer’s disease. Currently, the diagnostic accuracy for Alzheimer’s disease based on a single blood biomarker is relatively low, and the combined use of multiple blood biomarkers can greatly improve diagnostic accuracy. Herein, we report a printed electrochemical biosensor based on vertical graphene (VG) modified with gold nanoparticles (VG@nanoAu) for the simultaneous detection of four Alzheimer’s disease blood biomarkers. The printed electrochemical electrode array was constructed by laser etching and inkjet printing. Then gold nanoparticles were modified onto the working electrode surface via electrodeposition to further improve the sensitivity of the sensor. In addition, the entire printed electrochemical sensing system incorporates an electrochemical micro-workstation and a smartphone. The customized electrochemical micro-workstation incorporates four electro-chemical control chips, enabling the sensor to simultaneously analyze four biomarkers. Consequently, the printed electrochemical sensing system exhibits excellent analytical performance due to the large surface area, biocompatibility, and good conductivity of VG@nanoAu. The detection limit of the sensing system for Aβ40, Aβ42, T-tau, and P-tau181 was 0.072, 0.089, 0.071, and 0.051 pg/mL, respectively, which meets the detection requirements of Alzheimer’s disease blood biomarkers. The printed electrochemical sensing system also exhibits good specificity and stability. This work has great value and promising prospects for early Alzheimer’s disease diagnosis using blood biomarkers. Full article
