Search Results (31)

This paper proposes a comprehensive Mixed-Integer Linear Programming (MILP) formulation for the simultaneous scheduling of machines and Automated Guided Vehicles (AGVs) within a partitioned Flexible Manufacturing System (FMS). The main objective is to numerically optimize the simultaneous scheduling of machines and AGVs while considering various workshop layouts and operational constraints. Three different workshop layouts are analyzed, with varying numbers of machines in partitioned workshop areas A and B, to evaluate the performance and effectiveness of the proposed model. The model is tested in multiple scenarios that combine different layouts with varying numbers of workpieces, followed by an extension to consider dynamic initial conditions in a more generalized MILP framework. Results demonstrate that the proposed MILP formulation efficiently generates globally optimal solutions and consistently outperforms a greedy algorithm enhanced by A*-inspired heuristics. Although computationally intensive for large scenarios, the MILP’s optimal results serve as an exact benchmark for evaluating faster heuristic methods. In addition, the study provides practical insight into the integration of AGVs in modern manufacturing systems, paving the way for more flexible and efficient production planning. The findings of this research are expected to contribute to the development of advanced scheduling strategies in automated manufacturing systems. Full article

The emergence of Flexible Manufacturing Systems (FMS) presents new challenges in Industrial IoT (IIoT) environments. Unlike traditional real-time systems, FMS must accommodate task set variability driven by human–machine interaction. As such variations can lead to abrupt resource overload or idleness, a dynamic scheduling mechanism is required. Although prior studies have explored dynamic scheduling, they often relax deadlines for lower-criticality tasks, which is not well suited to IIoT systems with strict deadline constraints. In this paper, instead of treating dynamic scheduling as a prediction problem, we model it as deterministic planning in response to explicit, observable user input. To this end, we precompute feasible resource plans for anticipated task set variations through offline optimization and switch to the appropriate plan at runtime. During this process, our approach jointly optimizes processor speeds, memory allocations, and edge/cloud offloading decisions, which are mutually interdependent. Simulation results show that the proposed framework achieves up to 73.1% energy savings compared to a baseline system, 100% deadline compliance for real-time production tasks, and low-latency responsiveness for user-interaction tasks. We anticipate that the proposed framework will contribute to the design of efficient, adaptive, and sustainable manufacturing systems. Full article

In the domain of application of PN theory, the system deadlock problem of a flexible manufacturing system (FMS) is a thorny problem that needs to be solved urgently. All the research has the same objective of designing optimal controllers with maximal permissiveness and liveness. Plenty of the past literature used deadlock prevention as the main control strategy that is implemented by control places. However, these methods usually forbid undesirable system states from being reached, while reducing the system’s liveness. This study employed the resource flow graph (RFG)-based method to achieve a deadlock recovery policy that can maintain maximal permissiveness by adding control transitions (CTs). Also, we improved the current definition of RFG and developed a systematic approach for generating the corresponding RFG, which is based on flow mirroring pair (FMP) functions and the software Graphviz 12.2.1. Furthermore, this study proposed an automatic method that forms DOT script for generating Graphviz images, which is convincingly demonstrated in this study to enhance the execution efficiency and recognition of circular waiting situations. Full article

This paper proposes a fault-tolerant flexible manufacturing system (FMS) that features a dual-level fault tolerance mechanism at both the workcell and system levels to enhance reliability. The workcell controller was implemented on a Field Programmable Gate Array (FPGA). Reconfigurable duplication was used as the first level of fault tolerance at the workcell level. It was shown how to detect and recover from FPGA faults such as Single Event Upsets (SEUs), hard faults, and Single Event Functional Interrupts (SEFIs). The prototype of the workcell controller was successfully implemented using two Zybo Z7-20 AMD boards and an Arduino DUE. Petri Nets were used to prove that controller reliability increased by 346% after 1440 operational hours. The second level of fault tolerance was at the FMS level; the Supervisor (SUP) took over the responsibilities of any malfunctioning workcell controller. Riverbed software was used to prove that the system successfully met the end-to-end delay requirements. Finally, Matlab showed that there is a further increase in performability. Full article

In the ever-changing world of modern manufacturing, maintaining product quality is of great importance, yet extremely difficult due to complexities and the dynamic production paradigm. Currently, quality is rather reactively measured through periodic inspections and manual assessments. Traditional quality management systems (QMS), through these reactive measures, are often inefficient because of their higher operational cost and delayed defect detection and mitigation. The paper introduces a novel cognitive twin (CT) framework, which is the next evolved version of digital twin (DT). It is designed to advance the current quality management in flexible manufacturing systems (FMSs) through real-time, data-driven, and predictive optimization. This proposed framework uses four data types, namely feedstock quality (Q_f), machine degradation (Q_m), product processing quality (Q_p), and quality inspection (Q_i). By utilizing the power of machine learning algorithms, the cognitive twin constantly monitors and then analyzes real-time data. The cognitive twin optimizes the above quality components. This enables a very proactive decision making through an augmented reality (AR) interface by providing real-time visual insights and alerts to the operators. Thorough experimentation was conducted on the aforementioned FMS. Through the experiments, it was revealed that the proposed cognitive twin outperforms conventional QMSs by a great margin. The cognitive twin achieved a 2% improvement in the total quality scores. A 60% decrease in defects per unit (DPU) is observed as well as a sharp 40% decrease in scrap rate. Furthermore, the overall equipment efficiency (OEE) increased to 93–96%. The overall equipment efficiency increased by 11.8%, on average, from 82% to 93%, and the scrap rate decreased by 33.3% from 60% to 40%. The excellent results showcase the effectiveness of cognitive twin quality management via minimum wastage, continuous quality improvement, and enhancement in operational efficiency in the paradigm of smart manufacturing. This research study contributes to the field of industry 4.0 by providing a comprehensive, scalable, and adaptive quality management solution, thus leading the way for further advancements in intelligent manufacturing systems. Full article

The deadlock control problem in flexible manufacturing systems (FMSs) has received much attention in recent years. The formalism of the Petri net is employed to effectively model, analyze, and control deadlocks in an FMS case study. There are many kinds of deadlock prevention strategies based on the Petri net approach, where computational complexity is a major problem that needs to be considered. Based on the Petri net theory, this paper focuses on the two special subclasses in the ${\mathrm{S}}^3$PR net, namely the dual-process ${\mathrm{S}}^3$PR and the dual-process ${\mathrm{US}}^3$PR, in a bid to prevent deadlocks in an FMS. The relationship between the net structural characteristics and the deadlocks reached was analyzed, and then a regular method of adding controllers for these two models was proposed to reduce computational complexity. Full article

This research article proposes a new method for an enhanced Flexible Manufacturing System (FMS) using a combination of smart methods. These methods use a set of three technologies of Industry 4.0, namely Artificial Intelligence (AI), Digital Twin (DT), and Wi-Fi-based indoor localization. The combination tackles the problem of asset tracking through Wi-Fi localization using machine-learning algorithms. The methodology utilizes the extensive “UJIIndoorLoc” dataset which consists of data from multiple floors and over 520 Wi-Fi access points. To achieve ultimate efficiency, the current study experimented with a range of machine-learning algorithms. The algorithms include Support Vector Machines (SVM), Random Forests (RF), Decision Trees, K-Nearest Neighbors (KNN) and Convolutional Neural Networks (CNN). To further optimize, we also used three optimizers: ADAM, SDG, and RMSPROP. Among the lot, the KNN model showed superior performance in localization accuracy. It achieved a mean coordinate error (MCE) between 1.2 and 2.8 m and a 100% building rate. Furthermore, the CNN combined with the ADAM optimizer produced the best results, with a mean squared error of 0.83. The framework also utilized a deep reinforcement learning algorithm. This enables an Automated Guided Vehicle (AGV) to successfully navigate and avoid both static and mobile obstacles in a controlled laboratory setting. A cost-efficient, adaptive, and resilient solution for real-time tracking of assets is achieved through the proposed framework. The combination of Wi-Fi fingerprinting, deep learning for localization, and Digital Twin technology allows for remote monitoring, management, and optimization of manufacturing operations. Full article

The research presented in this paper aligns with the advancement of Industry 4.0 by integrating intelligent machine tools and industrial robots within Flexible Manufacturing Systems (FMS). Primarily, a development approach for Digital Twin (DT) is presented, beginning from the design, sizing, and configuration stages of the system and extending through its implementation, commissioning, operation, and simulation-based optimization. The digitization of current industrial processes entails the development of applications based on modern technologies, utilizing state-of-the-art tools and software. The general objective was to create a digital replica of a process to propose optimization solutions through simulation and subsequently achieve virtual commissioning. The practical nature of the research is reflected in the design and implementation of a Digital Twin for a real physical system processing a family of cylindrical parts within an existing experimental FMS. A digital model of the system was created by defining each individual device and piece of equipment from the physical system, so the virtual model operates just like the real one. By implementing the Digital Twin, both time-based and event-based simulations were performed. Through the execution of multiple scenarios, it was possible to identify system errors and collisions, and propose optimization solutions by implementing complex, collaborative-robot equipment where multiple interactions occur simultaneously. Full article

Because disruption happens unpredictably and generates serious impact in supply chain and production environments in the real world, it is important to develop approaches to handle disruption. This paper investigates disruption handling in part input sequencing of flexible manufacturing systems (FMSs). An algorithm is proposed for FMS part input sequencing to handle machine breakage. Evaluation is performed for the proposed algorithm by simulation experiments and result analyses. Finally, conclusions are summarized with managerial implications discussed and further research works suggested. Full article

Flexible manufacturing systems (FMS) are highly adaptable production systems capable of producing a wide range of products in varying quantities. While this flexibility caters to evolving market demands, it also introduces complex scheduling and control challenges, making it difficult to optimize productivity, quality, and energy efficiency. This paper explores the application of digital twin technology to tackle these challenges and enhance FMS optimization and control. A digital twin, constructed by integrating simulation models, data acquisition, and machine learning algorithms, was employed to replicate the behavior of a real-world FMS. This digital twin enabled real-time dynamic optimization and adaptive control of manufacturing operations, facilitating informed decision making and proactive adjustments to optimize resource utilization and process efficiency. Computational experiments were conducted to evaluate the digital twin implementation on an FMS equipped with robotic material handling, CNC machines, and automated inspection. Results demonstrated that the digital twin significantly improved FMS performance. Productivity was enhanced by 14.53% compared to conventional methods, energy consumption was reduced by 13.9%, and quality was increased by 15.8% through intelligent machine coordination. The dynamic optimization and closed-loop control capabilities of the digital twin significantly improved overall equipment effectiveness. This research highlights the transformative potential of digital twins in smart manufacturing systems, paving the way for enhanced productivity, energy efficiency, and defect reduction. The digital twin paradigm offers valuable capabilities in modeling, prediction, optimization, and control, laying the foundation for next-generation FMS. Full article

Flexible Manufacturing Systems (FMSs) provide a competitive edge in the ever-evolving manufacturing landscape, offering the agility to swiftly adapt to changing customer demands and product lifecycles. Nevertheless, the complex and interconnected nature of FMSs presents a distinct challenge: the evaluation and prioritization of performance variables. This study clarifies a conspicuous research gap by introducing a pioneering approach to evaluating and ranking FMS performance variables. The Best-Worst Method (BWM), a multicriteria decision-making (MCDM) approach, is employed to tackle this challenge. Notably, the BWM excels at resolving intricate issues with limited pairwise comparisons, making it an innovative tool in this context. To implement the BWM, a comprehensive survey of FMS experts from the German manufacturing industry was conducted. The survey, which contained 34 key performance variables identified through an exhaustive literature review and bibliometric analysis, invited experts to assess the variables by comparing the best and worst in terms of their significance to overall FMS performance. The outcomes of the BWM analysis not only offer insights into the factors affecting FMS performance but, more importantly, convey a nuanced ranking of these factors. The findings reveal a distinct hierarchy: the “Quality (Q)” factor emerges as the most critical, followed by “Productivity (P)” and “Flexibility (F)”. In terms of contributions, this study pioneers a novel and comprehensive approach to evaluating and ranking FMS performance variables. It bridges an evident research gap and contributes to the existing literature by offering practical insights that can guide manufacturing companies in identifying and prioritizing the most crucial performance variables for enhancing their FMS competitiveness. Our research acknowledges the potential introduction of biases through expert opinion, delineating the need for further exploration and comparative analyses in diverse industrial contexts. The outcomes of this study bear the potential for cross-industry applicability, laying the groundwork for future investigations in the domain of performance evaluation in manufacturing systems. Full article

As increasingly extensive applications of flexible manufacturing systems (FMSs) arise, their reliability allocation has been a research hot spot. But, since FMSs are always composed of transfer and buffer devices, production machines, and complex control systems, the large number of basic elements makes the number of variables and constraints of reliability-allocation optimization increase greatly, which leads to the difficulty and inefficiency of optimization. To solve the above problem, two dimension-reduction strategies are proposed for the FMS reliability optimization with low cost and a high level of reliability as the objectives, and they are the reliability-weight double-threshold qualification strategy (RWTS) and the bi-level optimization strategy (BLOS), respectively. Based on these two strategies, an overall reliability-allocation optimization model and a bi-level reliability-allocation optimization model are established based on the FMS reliability evaluation presented in our previous work, and their algorithms based on particle swarm optimization (PSO) are presented. In terms of their contributions, for the RWTS, thresholds of reliability and the weight index of each basic element are set to dynamically reduce the number of variables in each iteration of the optimization; for the BLOS, the overall reliability-allocation optimization problem for transitioning from the FMS to basic elements can be transformed into simpler allocation optimizations from the FMS to subsystems and from subsystems to basic elements, which have fewer variables, and this can largely improve the optimization convergence performance. Through applying this to a box-parts finishing FMS, compared with the traditional optimization method, the high efficiency and the good allocation effect of the optimization based on these two strategies for improving convergence speed are verified by the simulation results. The proposed method has great significance for FMS design due to its limited cost but high-reliability requirement. Full article

The maintenance strategies commonly employed in industrial settings primarily rely on theoretical models that often overlook the actual operating conditions. To address this limitation, the present paper introduces a novel selective predictive maintenance approach based on a machine learning model for a multi-parallel series system, which involves executing multiple missions with breaks between them. For this purpose, the proposed selective maintenance approach consists of finding, at each breakdown, the optimal structure of maintenance activities that provide the desired reliability level of the system for each mission. This decision is based on a component’s actual age, as determined by the prediction model. In addition, an optimization model with the Extended Great Deluge (EGD) algorithm uses these predictions as input data to identify the best maintenance level for each component considering the constrained maintenance resources. Finally, the numerical results of the proposed idea applied to the Flexible Manufacturing System (FMS) data are presented to show the robustness of the model. Full article

After the fourth industrial evolution, precision and automatic manufacturing have become increasingly widely accepted in production. With highly variable productivity and flexibility, flexible manufacturing systems (FMS) lower production costs and increase efficiency. Due to its resource shareability, unexpected system deadlock may occur in some specific situations. Many existing works use deadlock prevention as the primary control methodology in research on system deadlock control, while this type of control policy would constrain the transportation resources and reduce the system’s liveness. This paper adopts a new transition-based deadlock recovery policy as the direct control strategy, which uses generating and comparing aiding matrix (GCAM) to determine the optimal control transition. We also improve the existing GCAM-based method by reducing the computational redundancy. This kind of control strategy and its benefit could be demonstrated through two typical systems of simple sequential processes with resource (S³PR) nets and their Petri nets model. Full article

In order to minimize makespan (C_max) without causing tool delay with the fewest copies of each tool type, this study investigates the concurrent scheduling of automated guided vehicles (AGVs), machines (MCs), tool transporter (TT), and tools in a multi-machine flexible manufacturing system (FMS). The tools are housed in a central tool magazine (CTM), accessible to and utilized by several machines. AGVs and the tool transporter (TT) move jobs and tools between machines. Since it involves allocating tool copies and AGVs to job operations, sequencing job operations on machines, and related trip operations, such as AGVs’ and TT’s empty trip and loaded trip times, this simultaneous scheduling problem is highly complicated. This issue is resolved using the symbiotic organisms search algorithm (SOSA), based on the symbiotic interaction strategies that organisms adapt to survive in the ecosystem. This study proposes a mixed nonlinear integer programming formulation to address this problem. Verification is performed using an industrial problem from a manufacturing organization. The results show that employing two copies for two tool types out of 22 tool kinds and one copy for the remaining tool types results in no tool delay, which causes a reduction in the C_max as well as cost. The industries that can benefit directly from this study are consumer electronics manufacturers, original equipment manufacturers, automobile manufacturers, and textile machine producers. The results demonstrate that the SOSA provides promising results compared to the flower pollination algorithm (FPA). Full article
