Search Results (248)

This work presents a compact broadband in-fiber polarization filter using gold-deposited square-lattice photonic crystal fiber (PCF) numerically. The finite element method (FEM) is utilized to analyze the transmission characteristics of this PCF. The simulation results indicate that when the cladding hole diameter is 1.5 μm, the large hole diameter is 2.1 μm, the long axis of elliptical holes is 1.96 μm, the short axis of elliptical holes is 0.98 μm, the pitch is 2 μm, and the gold layer thickness is 50 nm, the x-polarized mode can interact with two plasmonic modes, and two surface plasmon resonance (SPR) processes at two common communication windows can be achieved. The length of this PCF filter is set as 0.5 mm, exhibiting the maximum extinction ratio (ER) of −51.4 dB at 1.31 μm and −47.3 dB at 1.55 μm, and the operating bandwidth of >860 nm. Additionally, the estimated splice losses are ~2.22 dB at 1.31 μm and ~1.42 dB at 1.55 μm. It is expected that this small-size PCF-SPR filter, characterized by its efficient filtering performance and wide bandwidth, will serve as a promising candidate for building integrated networks that combine optical fiber communication, sensing, and computing capabilities. Full article

Based on mode crosstalk theory, this paper develops a spontaneous Raman scattering (SpRS) model for the quantum-classical coexistence system using few-mode fiber (FMF) integrated with wavelength-division multiplexing (WDM) and spatial-division multiplexing (SDM). Through numerical calculations, the influence degrees of three factors (mode coupling, the number of modes and wavelengths) on SpRS are analyzed. The investigation identifies the dominant contributors to SpRS and reveals their relative impact magnitudes. Based on these results, a ring-assisted FMF is proposed to mitigate noise impacts on quantum signals. The numerical results show that the optimized FMF enhances quantum signal transmission distance by up to 41.5%. Full article

In this work, a D-shaped Photonic Crystal Fiber (PCF) sensor with a detection range of 1.30–1.35 is proposed, including Gold (Au), Titanium Dioxide (TiO₂), graphene, and a functionalized sensing region. Instead of filling or coating inside the PCF’s air holes, the Gold (Au) layer is applied to the polished surface. The effects of the larger air holes’ diameter and the thickness of the Au layer are examined. To achieve effective RI sensing, the proposed design leverages the strong coupling between the core mode and the Surface Plasmon (SP) excitation mode. Modal dispersion, confinement loss, and electric field distributions are analyzed for analyte RI values ranging from 1.30 to 1.35 using the Finite Element Method (FEM). The sensor demonstrates improved plasmonic excitation with a maximum Wavelength Sensitivity (WS) of 3000 nm/RIU (Au = 45 nm), strong confinement loss of more than 788.39 dB/cm (at Au = 40 nm), and a highest Figure of Merit (FoM) of 62.5/RIU (at Au = 40 nm with RI = 1.32). The TiO₂ layer enhances mode coupling and resonance sharpness, while the optimized Au thickness boosts sensitivity and spectral resolution. Additionally, the blood components reach the WS of 5000 nm/RIU for plasma and 3000 nm/RIU for Krypton. Because of its high tunability and repeatable performance, the PCF–SPR biosensor is a promising choice for precise biochemical and biomedical sensing applications. Full article

The rapid and accurate detection of SARS-CoV-2 biomarkers remains a critical requirement for effective outbreak control and decentralized diagnostics. Although RT-PCR is the current gold standard, its reliance on centralized laboratories and long processing times limits its applicability in point-of-care settings. In this context, optical biosensing platforms based on surface plasmon resonance (SPR) offer attractive features, including label-free, real-time, and quantitative detection. This study explores the use of synthetic receptors for the highly sensitive detection of the receptor-binding domain (RBD) of the SARS-CoV-2 spike protein. Specifically, soft molecularly imprinted polymer nanoparticles (nanoMIPs) were employed as synthetic receptors and integrated into a high-sensitivity, portable plasmonic platform based on a D-shaped plastic optical fiber (POF) SPR sensor. The nanoMIPs were selectively imprinted against the RBD, characterized by Dynamic Light Scattering (DLS), Isothermal Titration Calorimetry (ITC), and Scanning Electron Microscopy (SEM) to confirm nanoMIPs size, binding properties, and surface morphology. Next, the nanoMIPs were immobilized onto a gold-coated sensing surface, enabling enhanced specificity, affinity, and signal amplification compared to conventional biological recognition elements. The resulting RBD-SPR-nanoMIPs sensor demonstrated promising analytical performance, exhibiting high selectivity against potentially interfering proteins and an anticipated sensitivity suitable for RBD detection at femtomolar concentrations. The inherent stability of nanoMIPs suggests the potential for reusable SPR sensing platforms, paving the way for next-generation synthetic receptor-based plasmonic biosensors. Full article

The development of high-performance optical fiber sensors based on surface plasmon resonance (SPR) represents a significant advancement in precision detection technology, particularly for biomedical and environmental monitoring applications requiring real-time response and minimal sample consumption. This research conducts a systematic numerical investigation of a D-shaped fiber SPR sensor incorporating an optimized silver-hematite (Ag-α-Fe₂O₃) composite grating structure. Through comprehensive finite element simulations and parameter analysis, we demonstrate that controlling the silver layer thickness at 45 nm while maintaining the α-Fe₂O₃ thickness at 12 nm achieves optimal electric field confinement. The grating gap width optimization at 30 nm enables maximum sensitivity through enhanced localized surface plasmon resonance effects, while the residual cladding thickness of 0.5 μm provides the ideal balance between detection accuracy and sensitivity. The research establishes fundamental design principles for high-performance SPR sensors by elucidating the critical relationships between geometric parameters and sensing characteristics, providing valuable insights for developing next-generation sensors with enhanced performance for advanced sensing applications in environmental monitoring and medical diagnostics. Full article

Optical fiber surface plasmon resonance (SPR) sensing, as a label-free, highly sensitive, rapid-response and in situ detection technology, has demonstrated significant utility in various physical, chemical and biological detection applications. This paper focuses on a fiber-integrated microscale spiral-grating tapered gold tip SPR sensor. We first introduce the working principle and sensing capability with high space–time resolution of this SPR microsensor. Then we provide a comprehensive description of its application in the study on the important fundamental scientific issue of liquid–liquid diffusion. Finally, we demonstrate the application of the spiral-grating tapered gold tip to plasmonic enhanced fluorescence and scanning near-field optical microscopy. By systematically summarizing the excellent multifunctional sensing performance of the microscale spiral-grating tapered gold tip, this paper aims to provide new optical schemes and tools for the study on complex physicochemical processes and light-matter interactions at microscale and nanoscale. Full article

Surface plasmon resonance (SPR) sensors based on photonic crystal fibers (PCFs) hold significant promise for high-precision detection in biochemical and chemical sensing. However, achieving high sensitivity in low-refractive-index (RI) aqueous environments remains a formidable challenge due to weak light-matter interactions. To address this limitation, this paper designs and proposes a novel dual-channel D-shaped PCF-SPR sensor tailored for the refractive index range of 1.34–1.40. The sensor incorporates a dual-layer gold/titanium dioxide film, with gold nanoparticles deposited on the surface to synergistically enhance both propagating and localized surface plasmon resonance effects. Furthermore, a D-shaped polished structure integrated with double-sided microfluidic channels is employed to significantly strengthen the interaction between the guided-mode electric field and the analyte. Finite element method simulations demonstrate that the proposed sensor achieves an average wavelength sensitivity of 5733 nm/RIU and a peak sensitivity of 15,500 nm/RIU at a refractive index of 1.40. Notably, the introduction of gold nanoparticles contributes to an approximately 1.47-fold sensitivity enhancement over conventional structures. This work validates the efficacy of hybrid plasmonic nanostructures and optimized waveguide design in advancing RI sensing performance. Full article

In this work, a quasi-D-shaped photonic crystal fiber (PCF)-based surface plasmon resonance (SPR) biosensor is proposed and numerically investigated using the finite element method (FEM) implemented in COMSOL Multiphysics version 6.2 for the detection of cancer cells with different refractive indices. The biosensor has a coating of plasmonic material gold (Au) and a polymer coat of polymethyl methacrylate (PMMA). The effects of plasmonic material thickness and air hole dimensions on key sensing parameters, including confinement loss (CL), wavelength sensitivity (WS), and amplitude sensitivity (AS), are systematically analyzed. The results revealed that increasing plasmonic thickness beyond its optimum value significantly raises CL while reducing sensitivity due to reduced penetration depth of the evanescent field. Similarly, variations in the geometrical dimensions of the air holes (±10%) also affect the sensor response, emphasizing the importance of precise structural optimization. For the optimized design the proposed biosensor exhibits high performance with a maximum WS of 31,000 nm/RIU for MDA-MB-231 cells under x-polarization and 29,500 nm/RIU under y-polarization. The corresponding resolutions achieved are as low as 3.22 × 10⁻⁶ RIU and 3.38 × 10⁻⁶ RIU, respectively, with AS exceeding 9000 RIU⁻¹. The WS, AS, and other sensing parameters obtained from our sensor are relatively higher than some of the PCF–SPR sensors reported recently. These numerical results demonstrate that the optimized quasi-D-shaped PCF–SPR biosensor exhibits enhanced sensitivity to refractive index (RI) variations associated with cancerous cells, suggesting its suitability for early detection. Full article

In this work, we report the development of a highly sensitive optical sensor for the detection of cardiac troponin I (cTnI), a key biomarker for early-stage myocardial infarction diagnosis. The sensor combines castor oil-derived biomimetic receptors, called GreenNanoMIPs and prepared via the molecular imprinting technology using as a template an epitope of cTnI (i.e., the NR10 peptide), with a portable multimode plastic optical fiber surface plasmon resonance (POF-SPR) transducer. For sensing, gold SPR chips were functionalized with GreenNanoMIPs as proven by refractive index changes and confirmed by means of XPS. Binding experiments demonstrated the cTnI_nanoMIP-SPR sensor’s ability to detect both the NR10 peptide epitope and the full-length cTnI protein within minutes (t = 10 min), with high sensitivity and selectivity in buffer and serum matrices. The cTnI_nanoMIP-SPR showed an LOD of 3.53 × 10⁻¹⁵ M, with a linearity range of 1 pM–100 pM, outperforming previously reported sensor platforms and making it a promising tool for early-stage myocardial infarction detection. Full article

This study presents an ultra-sensitive dual-core photonic crystal fiber-based surface plasmon resonance (PCF-SPR) sensor for the detection of waterborne pathogens through refractive index (RI) variation. The proposed sensor integrates a bimetallic coating of silver and titanium dioxide (Ag–TiO₂). Silver ensures sharp plasmonic resonance, and TiO₂ enhances chemical stability and coupling efficiency. This dual-core configuration allows for increased interaction between the core-guided modes and the plasmonic interface. As a result, the sensor’s sensitivity improves significantly. The sensor can accurately detect analytes with an RI value of 1.28 to 1.43. It demonstrates a maximum wavelength sensitivity (WS) of 107,000 nm/RIU, an amplitude sensitivity (AS) of 2209.21 RIU⁻¹, a wavelength resolution of 9.35 × 10⁻⁷ RIU, and a figure of merit (FOM) of about 520. These results support the sensor’s ability to identify the presence of different pathogenic contaminants, such as E. coli, Vibrio cholerae, and Bacillus anthracis, based on their unique RI properties. This optimized design, high resolution, and potential for real-time detection enable this sensor to be a promising solution for environmental monitoring applications. Full article

Optical fiber biosensors have evolved into powerful tools for non-invasive biomedical analysis. While foundational principles are well-established, recent years have marked a paradigm shift, driven by advancements in nanomaterials, fabrication techniques, and data processing. This review provides a focused overview of these emerging trends, critically analyzing the innovations that distinguish the current generation of optical fiber biosensors from their predecessors. We begin with a concise summary of fundamental sensing principles, including Surface Plasmon Resonance (SPR) and Fiber Bragg Gratings (FBGs), before delving into the latest breakthroughs. Key areas of focus include integrating novel 2D materials and nanostructures to dramatically enhance sensitivity and advancing synergy with Lab-on-a-Chip (LOC) platforms. A significant portion of this review is dedicated to the rapid expansion of clinical applications, particularly in early cancer detection, infectious disease diagnostics, and continuous glucose monitoring. We highlight the pivotal trend towards wearable and in vivo sensors and explore the transformative role of artificial intelligence (AI) and machine learning (ML) in processing complex sensor data to improve diagnostic accuracy. Finally, we address the persistent challenges—biocompatibility, long-term stability, and scalable manufacturing—that must be overcome for widespread clinical adoption and commercialization, offering a forward-looking perspective on the future of this dynamic field. Full article

Two low-cost optical–chemical sensors based on plastic optical fibers (POFs) and molecularly imprinted polymers (MIPs) are developed and tested for the detection of 4-chloro-2-methylphenoxyacetic acid (MCPA), a herbicide of great interest in environmental monitoring. The first sensor is based on an optical splitter composed of two modified POFs coupled with an MIP for measuring MCPA. The second type of sensor is based on a surface plasmon resonance (SPR) D-shaped POF platform combined with the same MIP receptor for MCPA. The two proposed polymer-based sensors, exploiting different optical phenomena, were tested using similar equipment, consisting of white light sources and spectrometers. The experimental results show that both MCPA sensors present high selectivity for the target analyte and similar performances in terms of detection limits (LODs) of 3 nM and detection ranges (between 3 nM and 500 nM) by exploiting the MIP’s sites with a similar affinity constant. The polymer-based sensors exhibited better performances than those achieved by the electrochemical technique combined with the same MIP presented in the literature. Then, tests performed on real samples demonstrated good recovery values (between 82% and 116%), assessing the applicability of both sensors in real-world scenarios. Moreover, the POF-MIP splitter sensor configuration can be fabricated without expensive fabrication steps, such as spinning and sputtering processes. Full article

This research investigates a dual-polished surface plasmon resonance sensor based on dual-core photonic crystal fiber, featuring an innovative design aimed at enhancing hemoglobin concentration detection in blood, providing a valuable tool for diagnosing numerous health issues, such as chronic obstructive pulmonary disease. The sensor makes use of an external sensing mechanism and utilizes gold (Au) coating as the plasmonic material, chosen for its strong plasmonic response and excellent chemical stability, ensuring robust performance across the 1.31–1.42 refractive index range. The electromagnetic characteristics and efficacy of the designed sensor were thoroughly investigated using the finite element method. Our proposed sensor demonstrates outstanding performance metrics, attaining peak amplitude sensitivity of about 734 RIU⁻¹, and wavelength sensitivity of 74,000 nm/RIU along with 1.35 × 10⁻⁶ RIU wavelength resolution. It also exhibits a notable Figure of Merit value of 667 for a corresponding Full width at Half Maximum value of 111 nm. Finally, a machine learning model based on linear regression was employed that enables the prediction of any hemoglobin concentration levels corresponding to analyte RI values. These exceptional performance metrics highlight the potential of our sensor as a reliable, cost-effective and highly sensitive solution for real-time biosensing applications. Full article

ZnO nanostructures have attracted attention as transducer materials in optical biosensing platforms due to their wide bandgap, defect-mediated photoluminescence, high surface-to-volume ratio, and tunable morphology. This review examines how the dimensionality of ZnO nanostructures affects biosensor performance, particularly in terms of charge transport, signal transduction, and biomolecule immobilization. The synthesis approaches are discussed, highlighting how they influence crystallinity, defect density, and surface functionalization potential. The impact of immobilization strategies on sensor stability and sensitivity is also assessed. The role of ZnO in various optical detection schemes, including photoluminescence, surface plasmon resonance (SPR), localized (LSPR), fluorescence, and surface-enhanced Raman scattering (SERS), is reviewed, with emphasis on label-free and real-time detection. Representative case studies demonstrate the detection of clinically and environmentally relevant targets, such as glucose, dopamine, cancer biomarkers, and SARS-CoV-2 antigens, with limits of detection in the pico- to femtomolar range. Recent developments in ZnO-based hybrid systems and their integration into fiber-optic and microfluidic platforms are explored as scalable solutions for portable, multiplexed diagnostics. The review concludes by outlining current challenges related to reproducibility, long-term operational stability, and surface modification standardization. This work provides a framework for understanding structure–function relationships in ZnO-based biosensors and highlights future directions for their development in biomedical and environmental monitoring applications. Full article

We propose a dual-groove few-mode fiber surface plasmon resonance sensor that exploits the LP₁₁ mode for enhanced plasmonic sensing. The device incorporates two physically separated grooves with distinct metallic coatings, enabling dual-channel operation via wavelength-division multiplexing. Finite element method simulations show that the optimized design achieves a maximum sensitivity of 14,800 nm/RIU within the RI range of 1.33–1.40. The introduction of a TiO₂–Au bilayer enhances mode coupling and ensures complete spectral separation, thereby improving stability and reducing environmental interference. Biosensing simulations at 37 °C further confirm the practicality of the proposed architecture. Channel 1, filled with ethanol as a temperature-sensitive medium, provides temperature monitoring, while Channel 2 successfully distinguishes between normal and tumor cells, reaching a sensitivity of up to 9428.57 nm/RIU for Jurkat cells. Overall, the TiO₂-enhanced dual-channel FMF-SPR sensor combines ultra-high sensitivity, spectral independence, and biosensing capability, demonstrating strong potential for next-generation fiber-optic sensing and biomedical applications. Full article
