Under the new normal of China’s development, urban construction has shifted from incremental expansion to the optimization of existing stock. As the focal point of urban stock, old communities have garnered increasingly in-depth research. Recent studies have extended their perspectives from physical spaces to the interactive relationship between “space and behavior”, while also emphasizing the integration of qualitative and quantitative analyses. However, existing research primarily focuses on the static characteristics of material spatial environments, neglecting the dynamic interplay between spatial attributes and social network relationships. This study takes the Cangxia Community in Fuzhou as a case study, employing social network analysis (SNA) to construct a dual-network model of resident behavior and public space. Through a three-level analysis of “overall–subgroup–single point”, the intrinsic relationship between “space and behavior” in old communities is revealed. The model demonstrates that resident behavior characteristics are positively correlated with public space attributes, namely, the better the spatial accessibility and visibility, the higher the frequency of resident behaviors. However, mismatched spatial nodes also exist, limiting the synergistic optimization of the dual-network model. This research aims to provide scientifically effective methods and paradigms for the renewal of old communities and the sustainable development of cities. Full article

In this study, novel focusing performances of high-numerical-aperture (NA) micro-Fresnel zone plates (FZPs) with selective occlusion are identified and investigated through numerical calculations based on vectorial angular spectrum (VAS) theory, and further rigorously validated using the finite-difference time-domain (FDTD) method. The central occlusion of a standard micro-FZP can significantly extend the depth of focus while keeping the lateral size of the focusing spot essentially unchanged. When a standard micro-FZP only retains two separated transparent rings and all other rings are obstructed, it will result in multi-focus phenomena; at the same time, the number of focal points is equal to the difference in number between the two separated transparent rings. Furthermore, a focusing light needle can be generated by combining the central occlusion and wavelength shift of a standard micro-FZP. This study not only provides new ideas for the design and optimization of micro-FZPs but also provides reference for the expansion of practical applications of FZPs. Full article

The steep northern slopes of Giona Mt in central continental Greece are the result of an E-W normal fault dipping 35–45° to the north, extending from the Mornos River in the west to the village of Gravia in the east. This fault creates a significant elevation difference of approximately 1500 m between the northern Giona footwall and the southern Iti hanging wall. The footwall comprises imbricated Mesozoic carbonates of the Parnassos unit, which exhibit large-scale drag folding near and parallel to the fault. The hanging wall comprises deformed sedimentary rocks of the Beotian unit and tectonic klippen of the Eastern Greece unit, forming a southward-tilted neotectonic block with subsidence near the Northern Giona Fault and uplift near the Ypati fault to the north. These two E-W faults represent younger structures disrupting the older NNW-trending tectonic framework. Fault scarps are observed all along the 14 km length of the Northern Giona fault accompanied by cataclastic zones, separating the carbonate formations of the Parnassos Unit from thick scree, slide blocks, boulders and olistholites. Inversion of fault-slip data has shown a mean slip vector of 45°, N004°E, which aligns with the current regional extensional deformation of the area, as confirmed by focal mechanism solutions. Based on the general asymmetry of the alpine units in the hanging wall, we interpret a listric fault geometry at depth using slip-line analysis and we forward modelled a disrupted fault-propagation fold using kinematic trishear algorithms, estimating a total displacement of 6500 m and a throw of approximately 2000 m. Seismic activity in the area of the Northern Giona Fault includes a magnitude 6.1 earthquake in 1852, which caused casualties, rockfalls and extensive damage, as well as a magnitude 5.1 event in 1983. The expected seismic magnitude is deterministically estimated between 6.2 and 6.7, depending on the potential westward continuation of the Northern Giona Fault beyond the Mornos River to the Northern Vardoussia saddle. The seismic hazard zone includes several villages located near the fault, particularly on the hanging wall, where intense landslide activity during seismic events could result in severe damage to regional infrastructure. The neotectonic development of the Northern Giona Fault highlights the importance of extending seismotectonic research into the mountainous regions of central Greece within the alpine formations, beyond the post-orogenic sedimentary basins. Full article

On 23 January 2024, an M_w 7.01 earthquake struck the Wushi County, Xinjiang Uygur Autonomous Region, China. The occurrence of this earthquake provides an opportunity to gain a deeper understanding of the rupture behavior and tectonic activity of the fault system in the Tianshan seismic belt. The coseismic deformation field of the Wushi earthquake was derived from Sentinel-1A ascending and descending track data using Differential Interferometric Synthetic Aperture Radar (D-InSAR) technology. The findings reveal a maximum line-of-sight (LOS) displacement of 81.1 cm in the uplift direction and 16 cm in subsidence. Source parameters were determined using an elastic half-space dislocation model. The slip distribution on the fault plane for the M_w 7.01 Wushi earthquake was further refined through a coseismic slip model, and Coulomb stress changes on nearby faults were calculated to evaluate seismic hazards in surrounding areas. Results indicate that the coseismic rupture in the M_w 7.01 Wushi earthquake sequence was mainly characterized by left-lateral strike-slip motion. The peak fault slip was 3.2 m, with a strike of 228.34° and a dip of 61.80°, concentrated primarily at depths between 5 and 25 km. The focal depth is 13 km. This is consistent with findings reported by organizations like the United States Geological Survey (USGS). The fault rupture extended to the surface, consistent with field investigations by the Xinjiang Uygur Autonomous Region Earthquake Bureau. Coulomb stress results suggest that several fault zones, including the Kuokesale, Dashixia, Piqiang North, Karaitike, southeastern sections of the Wensu, northwestern sections of the Tuoergan, and the Maidan-Sayram Fault Zone, are within regions of stress loading. These areas show an increased risk of future seismic activity and warrant close monitoring. Full article

Camera arrays can enhance the signal-to-noise ratio (SNR) between dim targets and backgrounds through multi-view synthesis. This is crucial for the detection of dim targets. To this end, we design and develop an infrared camera array system with a large baseline. The multi-view synthesis of camera arrays relies heavily on the calibration accuracy of relative poses in the sub-cameras. However, the sub-cameras within a camera array lack strict geometric constraints. Therefore, most current calibration methods still consider the camera array as multiple pinhole cameras for calibration. Moreover, when detecting distant targets, the camera array usually needs to adjust the focal length to maintain a larger depth of field (DoF), so that the distant targets are located on the camera’s focal plane. This means that the calibration scene should be selected within this DoF range to obtain clear images. Nevertheless, the small parallax between the distant sub-aperture views limits the calibration. To address these issues, we propose a calibration model for camera arrays in distant scenes. In this model, we first extend the parallax by employing dual-array frames (i.e., recording a scene at two spatial locations). Secondly, we investigate the linear constraints between the dual-array frames, to maintain the minimum degrees of freedom of the model. We develop a real-world light field dataset called NUDT-Dual-Array using an infrared camera array to evaluate our method. Experimental results on our self-developed datasets demonstrate the effectiveness of our method. Using the calibrated model, we improve the SNR of distant dim targets, which ultimately enhances the detection and perception of dim targets. Full article

The Baihetan Reservoir is built for hydropower in China. The rise of the reservoir water leads to a series of earthquakes in the surrounding area. This study proposes fully coupled equations of pore-viscoelasticity and a parallel partition mesh model to study the short- and long-term effects of the Baihetan Reservoir and further calculate the changes in stress, pore pressure, and Coulomb failure stress with time on the major faults. Based on the calculation results, impoundment increases regional seismicity, which is consistent with the seismic catalog. The reservoir impoundment causes an increase in pore pressure in the crust, primarily enhancing Coulomb failure stress beneath the reservoir center. This effect extends to approximately 60 km in length and 20 km in width at a depth layer of 5–10 km. Seismicity varies greatly among different faults. Coulomb failure stress increases on the northern part of the Xiaojiang Fault and Zhaotong-Ludian Fault, and decreases on the southern part of the Xiaojiang Fault and Zemuhe Fault. The Coulomb failure stress is highly correlated with the number of earthquakes along the Xiaojiang Fault. The influence of the reservoir on the local seismicity is mainly limited to several months, and it has a slight effect later on. The focal depth of the induced earthquakes increases while the magnitude decreases. The earthquakes caused by the impoundment all have a small magnitude, and the $M_{s}4.3$ Qiaojia earthquake on 30 March 2022, was more likely a natural event. Full article

This paper presents a monocular biological microscope with colorful 3D reconstruction and an extended depth of field using an electrically tunable lens. It is based on a 4f optical system with an electrically tunable lens at the confocal plane. Rapid and extensive depth scanning while maintaining consistent magnification without mechanical movement is achieved. We propose an improved Laplacian operator that considers pixels in diagonal directions to provide enhanced fusion effects and obtain more details of the object. Accurate 3D reconstruction is achieved using the shape-from-focus method by tuning the focal power of the electrically tunable lens. We validate the proposed method by performing experiments on biological samples. The 3D reconstructed images obtained from the biological samples match the actual shrimp larvae and bee antenna samples. Two standard gauge blocks are used to evaluate the 3D reconstruction performance of the proposed method. The experimental results show that the extended depth of fields are 120 µm, 240 µm, and 1440 µm for shrimp larvae, bee tentacle samples, and gauge blocks, respectively. The maximum absolute errors are −39.9 μm and −30.6 μm for the first and second gauge blocks, which indicates 3D reconstruction deviations are 0.78% and 1.52%, respectively. Since the procedure does not require any custom hardware, it can be used to transform a biological microscope into one that effectively extends the depth of field and achieves highly accurate 3D reconstruction results, as long as the requirements are met. Such a microscope presents a broad range of applications, such as biological detection and microbiological diagnosis, where colorful 3D reconstruction and an extended depth of field are critical. Full article

Longitudinal optical field modulation is very important for applications such as optical imaging, spectroscopy, and optical manipulation. It can achieve high-resolution imaging or manipulation of the target object, but it is also limited by its depth of focus. The depth of focus determines whether the target object can be clearly imaged or manipulated at different distances, so extending the depth of focus can improve the adaptability and flexibility of the system. However, how to extend the depth of focus is still a significant challenge. In this paper, we use a super-oscillation phase modulation optimization method to design a polarization-independent metalens with extended focal depth, taking the axial focal depth length as the optimization objective. The optimized metalens has a focal depth of 13.07 μm (about 22.3 λ), and in the whole focal depth range, the transverse full width at half maximum values are close to the Rayleigh diffraction limit, and the focusing efficiency is above 10%. The results of this paper provide a new idea for the design of a metalens with a long focal depth and may have application value in imaging, lithography, and detection. Full article

Lenses/mirrors with fast data acquisition speeds and extended focal depths have practical importance in terahertz (THz) imaging systems. Thus, a high-speed 600 GHz-band THz imaging scanner system with enhanced focal depth is presented in this work. A polygon mirror with a 250 Hz scanning frequency and an integrated off-axis parabolic (OAP) mirror with an ~170 mm focal depth were employed for 2D imaging. The simulation and experimental results show that a spatial resolution of ~2 mm can be achieved as the imaging distance varies from ~85 to 255 mm. The proposed system was applied to image a hidden metal object as a potential security application, demonstrating that this system can image targets with an enhanced focal depth. Full article

Needle beams have received widespread attention due to their unique characteristics of high intensity, small focal size, and extended depth of focus (DOF). Here, a single–layer all–dielectric metalens based on Pancharatnam–Berry (PB) was used to efficiently generate and focus an azimuthally polarized vortex beam at the same time. Then, additional phase or amplitude modulation was respectively adopted to work with the metalens to produce optical needles. By decorating the PB metalens with the binary optical element (BOE), an optical needle with full–width–at–half–maximum (FWHM) of 0.47 λ and DOF of 3.42 λ could be obtained. By decorating the PB metalens with an annular aperture, an optical needle with long DOF (16.4 λ) and subdiffraction size (0.46 λ) could be obtained. It is expected that our work has potential applications in super–resolution imaging, photolithography, and particle trapping. Full article

By combining a spiral zone plate (SZP) and a grating, we propose a single optical element, termed a composited spiral zone plate grating (CSZPG), to generate flower mode vortices with the equicohesive petals and has long focal depths. Theoretical analysis reveals that the CSZPG can generate flower mode vortices with approximately equicohesive petals, and that it has longer focal depths compared with the conventional SZP. Moreover, the performance of the CSZPG on the period, focal length and radius is investigated. The experimental results are also presented, agreeing well with the theoretical predictions. The unique characteristics of the proposed CSZPG make it attractive for many applications such as particle trapping and optical imaging. Full article

The light field camera provides a robust way to capture both spatial and angular information within a single shot. One of its important applications is in 3D depth sensing, which can extract depth information from the acquired scene. However, conventional light field cameras suffer from shallow depth of field (DoF). Here, a vari-focal light field camera (VF-LFC) with an extended DoF is newly proposed for mid-range 3D depth sensing applications. As a main lens of the system, a vari-focal lens with four different focal lengths is adopted to extend the DoF up to ~15 m. The focal length of the micro-lens array (MLA) is optimized by considering the DoF both in the image plane and in the object plane for each focal length. By dividing measurement regions with each focal length, depth estimation with high reliability is available within the entire DoF. The proposed VF-LFC is evaluated by the disparity data extracted from images with different distances. Moreover, the depth measurement in an outdoor environment demonstrates that our VF-LFC could be applied in various fields such as delivery robots, autonomous vehicles, and remote sensing drones. Full article

Imaging applications based on microlens arrays (MLAs) have a great potential for the depth sensor, wide field-of-view camera and the reconstructed hologram. However, the narrow depth-of-field remains the challenge for accurate, reliable depth estimation. Multifocal microlens array (Mf-MLAs) is perceived as a major breakthrough, but existing fabrication methods are still hindered by the expensive, low-throughput, and dissimilar numerical aperture (NA) of individual lenses due to the multiple steps in the photolithography process. This paper reports the fabrication method of high NA, Mf-MLAs for the extended depth-of-field using single-step photolithography assisted by chemical wet etching. The various lens parameters of Mf-MLAs are manipulated by the multi-sized hole photomask and the wet etch time. Theoretical and experimental results show that the Mf-MLAs have three types of lens with different focal lengths, while maintaining the uniform and high NA irrespective of the lens type. Additionally, we demonstrate the multi-focal plane image acquisition via Mf-MLAs integrated into a microscope. Full article

Plenoptic cameras have received a wide range of research interest because it can record the 4D plenoptic function or radiance including the radiation power and ray direction. One of its important applications is digital refocusing, which can obtain 2D images focused at different depths. To achieve digital refocusing in a wide range, a large depth of field (DOF) is needed, but there are fundamental optical limitations to this. In this paper, we proposed a plenoptic camera with an extended DOF by integrating a main lens, a tunable multi-focus liquid-crystal microlens array (TMF-LCMLA), and a complementary metal oxide semiconductor (CMOS) sensor together. The TMF-LCMLA was fabricated by traditional photolithography and standard microelectronic techniques, and its optical characteristics including interference patterns, focal lengths, and point spread functions (PSFs) were experimentally analyzed. Experiments demonstrated that the proposed plenoptic camera has a wider range of digital refocusing compared to the plenoptic camera based on a conventional liquid-crystal microlens array (LCMLA) with only one corresponding focal length at a certain voltage, which is equivalent to the extension of DOF. In addition, it also has a 2D/3D switchable function, which is not available with conventional plenoptic cameras. Full article

Endoscopic imaging is an indispensable tool for visual inspection of surfaces in hard-to-access places. The conventional optical endoscope only enables imaging the regions that lie close to the focal plane, and therefore improving the depth of field (DOF) of an endoscopic system has recently attracted much attention. Here, we propose and demonstrate a simple, cost-effective, and easily available industrial endoscopic system, which is composed of a rigid tube and group of optical lenses. The outer diameter of the designed endoscopic modality presented in this article is 3 mm. By employing the wavefront coding technique, the DOF of newly-designed endoscope was extended to 2.7 mm in the proof-of-concept experiment, which is an increase of almost 10 times compared to the initial counterpart. Full article
