The intentional yaw offset of wind turbines has shown potential to redirect wakes, enhancing overall plant power production, but it may increase fatigue loading on turbine components. This study analyzed fatigue loads on the NREL 5 MW reference wind turbine under varying yaw offsets using blade element momentum theory, dynamic blade element momentum, and the converging Lagrange filaments vortex method, all implemented in OpenFAST. Simulations employed yaw angles from −40° to 40°, with turbulent inflow generated by TurbSim, an OpenFAST tool for realistic wind conditions. Fatigue loads were calculated according to IEC 61400-1 design load case 1.2 standards, using thirty simulations per yaw angle across five wind speed bins. Damage equivalent load was evaluated via rainflow counting, Miner’s rule, and Goodman correction. Results showed that the free vortex method, by modeling unsteady aerodynamic forces, yielded distinct differences in damage equivalent load compared to the blade element method in yawed conditions. The free vortex method predicted lower damage equivalent load for the low-speed shaft bending moment at negative yaw offsets, attributed to its improved handling of unsteady effects that reduce load variations. Conversely, for yaw offsets above 20°, the free vortex method indicated higher damage equivalent for low-speed shaft torque, reflecting its accurate capture of dynamic inflow and unsteady loading. These findings highlight the critical role of unsteady aerodynamics in fatigue load predictions and demonstrate the free vortex method’s value within OpenFAST for realistic damage equivalent load estimates in yawed turbines. The results emphasize the need to incorporate unsteady aerodynamic models like the free vortex method to accurately assess yaw offset impacts on wind turbine component fatigue. Full article

Robust dynamic equivalents of large power networks are essential for fast and reliable stability analysis of bulk power systems. This is because the dimensionality of modern power systems raises convergence issues in modern stability-analysis programs. However, even with modern computational power, it is challenging to find reduced-order models for power systems due to the following factors: the tedious mathematical analysis involved in the classical reduction techniques requires large amounts of computational power; inadequate information sharing between geographical areas prohibits the execution of model-dependent reduction techniques; and frequent fluctuations in the operating conditions (OPs) of power systems necessitate updates to reduced models. This paper focuses on a measurement-based approach that uses a deep artificial neural network (DNN) to estimate the dynamics of an external system (ES) of a power system, enabling stability analysis of a study system (SS). This DNN technique requires boundary measurements only between the SS and the ES. However, machine learning-based techniques like this DNN are known for their extensive training requirements. In particular, for power systems that undergo continuous fluctuations in operating conditions due to the use of renewable energy sources, the applications of this DNN technique are limited. To address this issue, a Deep Transfer Learning (DTL)-based technique is proposed in this paper. This approach accounts for variations in the OPs such as time-to-time variations in loads and intermittent power generation from wind and solar energy sources. The proposed technique adjusts the parameters of a pretrained DNN model to a new OP, leveraging symmetry in the balanced adaptation of model layers to maintain consistent dynamics across operating conditions. The experimental results were obtained by representing the Queensland (QLD) system in the simplified Australian 14 generator (AU14G) model as the SS and the rest of AU14G as the ES in five scenarios that represent changes to the OP caused by variations in loads and power generation. Full article

This study investigates the low-signal behavior of electric motors in automotive applications, emphasizing impedance measurement, evaluation, and the definition of a simplified dummy load. A comprehensive experimental analysis was conducted on two induction motors with different power ratings (300 W and 45 kW), exploring the influence of winding topology, rotor position, and excitation amplitude on the impedance response. A simplified equivalent circuit model (ECM), derived solely from terminal impedance measurements, was developed and validated to construct a practical dummy load. This model facilitates realistic simulations without requiring detailed internal motor specifications. Experimental results confirm that the dummy load accurately replicates the measured impedance characteristics in the low-to-mid frequency range, demonstrating its effectiveness for electromagnetic interference (EMI) prediction and system-level simulations in automotive electric drive system. Full article

Tall buildings are vulnerable to wind loads, which can cause significant displacements that can affect their stability, strength, and serviceability. Their structural configuration can significantly influence their behavior to wind loads. There are not enough comparative studies in the literature examining the effects of wind loads on different structural configurations. This study examines the response of tall buildings to wind loads by varying their structural forms. Twelve models of tall buildings of different heights and structural configurations were analyzed using the finite element method. Wind loads were applied to the models as equivalent static forces, according to existing codes. The maximum displacements were calculated for each model, and the results were compared. It was found that a considerable reduction in the response was achieved by including shear walls at specific locations in the building’s layout, thereby identifying the optimal location. However, the effectiveness of the different configurations converges at building heights greater than 120 m. In addition, the maximum displacement on the same floor in buildings with the same structural form may vary depending on the building’s total height. An increase in wind velocity results in an almost linear increase in the maximum displacements of the buildings. The findings of this study can assist designers in optimizing shear wall placement in tall building designs. Full article

The structural reliability of bottom-fixed offshore wind turbines is generally influenced by the dispersion of and variability in soil properties, which affect their ultimate capacity, serviceability, and both the short- and long-term fatigue. During an earthquake, the soil–pile system is subjected to intense cyclic loads that can lead to stiffness and strength degradation, typically captured through cyclic soil models. Calibration of soil parameter variability is fundamental for reliable structural assessments of wind turbine integrity. In this study, a method to generate randomness of the parameters affecting cyclic soil degradation models is proposed. Fatigue parameters are quantified through random cyclic undrained triaxial tests conducted using the Discrete Element Method. Deterministic simulations are first performed based on experimental results from the Liquefaction Experiments and Analysis Project for validation. Subsequently, variability in the initial particle size distribution functions is introduced to generate random soil samples, and triaxial simulations are repeated to quantify the dispersion of soil fatigue parameters. The proposed procedure is then applied through Monte Carlo simulations on the IEA 15-MW reference wind turbine, which is subjected to both short- and long-duration earthquakes. The results demonstrate the significant impact of soil degradation on the bending moment envelope, as well as the effect of soil uncertainty on tower fatigue, assessed using the damage equivalent load approach. Full article

This paper proposes an analysis of voltage stability under small disturbances following the integration of an offshore wind farm into a real power system, considering various load and generation scenarios under both normal and post-disturbance conditions. This study utilizes the southern region equivalent system, simulated with Anarede software version 11.7.2, an offshore wind farm with a maximum capacity of 2010 MW. This wind farm is modeled as a PQ bus, operating at partial (50%) and full (100%) generation levels. Three power factor scenarios are examined: resistive, capacitive, and inductive. Submodule 2.3 of the Brazilian National System Operator guidelines states that the base case operating conditions are considered voltage insecurity. Resistive and capacitive power factor operation improved voltage stability margins but resulted in overvoltage on several buses. Conversely, inductive power factor operation led to reduced stability margins and undervoltages at buses near the wind farm. Contingency analysis further revealed stability margins below security limits. Static Var Compensators were installed at critical buses to mitigate these effects, successfully eliminating the initial overvoltage and undervoltage. Modeling as PQ buses does not guarantee stability, making compensators essential for the safe integration of offshore wind generation in Brazilian test systems. Full article

This study presents a detailed investigation of the torque-speed characteristics of a WEG single-phase squirrel-cage induction motor (SPSCIM) of (1/2 hp), 110/220 V at 60 Hz. The primary objective was to derive the motor’s equivalent circuit and validate its performance curves through finite element analysis (FEA), simulation using MATLAB^®/Simulink^®, and experimental testing. Finite element simulations were conducted using the software FEMM (Finite Element Method Magnetics) to model the magnetic flux distribution within the motor’s stator and rotor. These simulations, based on the motor’s dimensions and nameplate data, provided essential insights into the electromagnetic behavior, including flux density and saturation effects, which are crucial for accurate torque-speed curve predictions. For experimental validation, tests were performed under open-circuit and locked-rotor conditions through a universal machine as a load emulator. The torque-speed characteristics were determined using the Suhr method and the classical approach, with the resulting curves compared to experimental measurements. Voltage and current were measured using AC PZEM-004T and DC PZEM-017 meters, while rotor speed was monitored with a Hall effect sensor (A3144). The results revealed strong agreement between the FEM simulations, Surh method, and experimental data, demonstrating the reliability and accuracy of the combined simulation and analytical methods for modeling the motor’s performance. The estimations using classical and Suhr methods, Simulink simulations, and FEMM yielded low error percentages, mostly below 2%. However, in the FEMM simulation, rotor resistance showed a higher error of around 20% due to unavailable data on the exact number of windings turns, a modifiable parameter that can be corrected through further adjustments in the simulation. The torque-speed curves obtained at different voltage levels showed an excellent correlation, confirming the effectiveness of the proposed approach in characterizing the motor’s operational behavior. Full article

A barrier to the adoption of floating offshore wind turbines is their high cost relative to conventional fixed-bottom wind turbines. The largest contributor to this cost disparity is generally the floating substructure, due to its large size and complexity. Typically, a primary driver of the geometry and size of a floating substructure is the extreme environmental load case of Region 4, where platform loads are the greatest due to the impact of extreme wind and waves. To address this cost issue, a new concept for a floating offshore wind turbine’s substructure, its moorings, and anchors was optimized for a reference 10-MW turbine under extreme load conditions using OpenFAST. The levelized cost of energy was minimized by fixing the above-water turbine design and minimizing the equivalent substructure mass, which is based on the mass of all substructure components (stem, legs, buoyancy cans, mooring, and anchoring system) and associated costs of their materials, manufacturing, and installation. A stepped optimization scheme was used to allow an understanding of their influence on both the system cost and system dynamic responses for the extreme parked load case. The design variables investigated include the length and tautness ratio of the mooring lines, length and draft of the cans, and lengths of the legs and the stem. The dynamic responses investigated include the platform pitch, platform roll, nacelle horizontal acceleration, and can submergence. Some constraints were imposed on the dynamic responses of interest, and the metacentric height of the floating system was used to ensure static stability. The results offer insight into the parametric influence on turbine motion and on the potential savings that can be achieved through optimization of individual substructure components. A 36% reduction in substructure costs was achieved while slightly improving the hydrodynamic stability in pitch and yielding a somewhat large surge motion and slight roll increase. Full article

As is well known, due to carbon dioxide emissions, the combustion of lignite in power plants creates environmental pollution. In contrast, nuclear fuels do not produce carbon dioxide emissions. This paper investigates the effects of replacing lignite thermal power plants with small modular nuclear reactors (SMRs) of equivalent rated power and related characteristics. In terms of the emissions criterion, nuclear fuels belong to the same category of clean sources as the sun and wind. A second criterion is the economic one and concerns the operating cost of the nuclear–thermal power plant. Based on the economic criterion, although nuclear reactors require a higher initial invested capital, they have lower fuel costs and lower operating costs than lignite plants, which is important due to their long service life. A third criterion is the effect of the operation mode of an SMR, constant or variable, on the cost of energy production. In terms of the operation mode criterion, two cycles were investigated: the production of a constant amount of energy and the production of a variable amount of energy related to fluctuations in the electric load demand or the operation load-following. Using multi-criteria managerial scenarios, the results of the research demonstrate that the final mean minimal cost of energy generated by hybrid thermal units with small nuclear reactors in constant power output operation is lower than the mean minimal cost of the energy generated in the load-following mode by 2.45%. At the same time, the carbon dioxide emissions in the constant power output operation are lower than those produced in the load-following mode by 2.14%. In conclusion, the constant power output operation of an SMR is more sustainable compared to the load-following operation and also is more sustainable compared to generation by lignite thermal power plants. Full article

In this paper, an advanced model of a switched reluctance generator (SRG) with mutual coupling, iron losses, and remanent magnetism is presented. The proposed equivalent circuit for each SRG phase is represented by the winding resistance, phase inductance and electromotive forces (EMFs) induced by mutual flux-linkage and remanent magnetism. In the advanced SRG model, the phase inductance and equivalent iron-loss resistance need not be known, as the components of the phase current flowing through them are determined directly from appropriate look-up tables, making the advanced SRG model simpler. Both the magnitude of the mutual flux-linkage and its time derivative are considered in the advanced model. The proposed model only requires knowledge of data that can be obtained using the DC excitation method and does not require knowledge of the SRG material properties. For the first time, the remanent magnetic flux of the SRG is modeled and the induced EMS caused by it is included in the advanced SRG model. Stray losses within the SRG are considered negligible. Connection to an asymmetric bridge converter is assumed. Magnetization angles of individual SRG phases are provided by the terminal voltage controller. The results obtained with the advanced SRG model are compared with experiments carried out in the steady-state of the 8/6 SRG with a rated power of 1.1 kW SRG over a wide range of load, terminal voltage, turn-on angle, and rotor speed in single-pulse mode suitable for high-speed applications. Full article

The large-scale integration of renewable energy and the serious safety issues faced by coal-fired units during peak regulation pose significant challenges to the reliable operation of power systems. Traditional probabilistic production simulation (PPS) methods fail to account for the fluctuations in load demand and the time-series variability of renewable energy, and they do not sufficiently consider the lifespan degradation of coal-fired units during actual peak regulation operations, which results in an inaccurate reflection of system reliability. This paper proposes an improved PPS method. First, this method rigorously considers the time-series fluctuations of load demand and renewable energy. Secondly, a multi-state model is established for coal-fired units, incorporating lifespan degradation and failure rates under different output conditions, which are dynamically updated based on load demand and operational status. An equivalent multi-state model for wind power output is also developed for different time periods. Finally, the Universal Generating Function (UGF) algorithm is used for PPS, enabling the calculation of system reliability indices, as well as dynamic costs such as unit start-up and shutdown, to assess the system’s capability to accommodate wind power. The impact of different peak regulation capabilities of units on system reliability is also studied. This paper presents the theoretical foundation, algorithm implementation, and related case studies, verifying the rationality and effectiveness of the proposed method in addressing the above-mentioned issues. Full article

This study presents a comprehensive investigation into multi-directional fatigue damage characteristics of fixed offshore wind turbine tower roots through comparative analysis using FAST (3.5.0) and Bladed (4.3) software platforms. The research methodology encompasses three principal phases: First, a stochastic wind field model was developed through statistical analysis of historical wind speed measurements, achieving superior correlation (R² = 0.983) in goodness-of-fit tests. Subsequently, the rain flow counting technique was employed to characterize equivalent cyclic load spectra. Building upon these foundations, an integrated predictive fatigue life evaluation framework was formulated by synergistically combining S–N curve principles with Palmgren–Miner’s linear cumulative damage theory. The methodology was further validated through cross-platform verification with Bladed software, revealing only a 7.4% deviation in predicted fatigue lives between the two computational models, confirming the technical feasibility of the proposed simplified model. Full article

In CNC machines, the temperature field analysis of spindle servo permanent magnet motors (SSPMMs) under rated load, overload, and weak magnetic conditions is critical for ensuring stable operation and machining accuracy. This paper proposes a temperature calculation method for SSPMMs based on the thermal network method, which is used to quickly evaluate the temperature performance of SSPMMs under different operating conditions during design. This method can calculate the steady-state or transient temperature rise under different operating conditions. First, the electromagnetic performance and heat sources of the SSPMMs were analyzed. Then, based on the thermal network method, the equivalent thermal resistances and equivalent heat dissipation coefficients of the motor components were calculated. By iterating the heat balance equation or solving the heat conduction equation for different operating conditions, the temperature distribution of SSPMMs under different operating conditions was obtained. The accuracy of the thermal network model was validated through temperature analysis using fluid–structure interaction simulations and prototype testing. The results show that the relative error between the winding temperature calculated by the proposed equivalent thermal network model and the measured temperature under different operating conditions is less than 5%. This paper provides a theoretical basis for the thermal management of SSPMM, which can quickly and accurately evaluate the temperature rise in the motor during design. Full article

An assembled elliptical joint was designed for a lattice wind turbine tower, and four samples were analyzed under static loads. Additionally, finite element analysis software was employed to create 40 models, with the wall thickness of the ball seat and the web being the variable parameters. This enabled the identification of the variation pattern in the ultimate bearing capacity. It was found that the failure parts of the four test pieces were located in the connection area between the tensioned web member and the ball table. Increasing the wall thickness of the ball table and the web member significantly increased the joint’s load-bearing capacity. However, increasing the table wall thickness somewhat reduced the joint’s deformation capacity. Increasing the web member thickness significantly improved the deformation capacity and the energy absorption capacity of the joint. Increasing the table wall and the member web thickness reduced the peak equivalent stress in the ball table area and the press plate, as well as the overall stress level. Finite element simulations showed that the joint’s load-bearing ability was adversely impacted when the table wall thickness exceeded 10 mm. When the web member wall thickness exceeded 5 mm, the joint bearing capacity was less sensitive to the increase in the wall thickness. Full article

This paper tests the capability of a simplified model to predict major trends in the dynamic structural response of monopile offshore wind turbines. For this purpose, the results of two numerical models of different levels of complexity are compared: the advanced time-domain multi-physics tool OpenFAST and a simplified static-equivalent model based on beam elements and concentrated masses. The IEA-15-240-RWT reference wind turbine is considered as a benchmarking problem. The comparison between the two structural models is presented in terms of their fundamental frequencies and through the analysis of shear forces and bending moments under wind-only and combined wave and wind load scenarios. The results show that the simplified model can adequately represent the system’s mass and stiffness characteristics, as well as the impact of soil–structure interaction effects on its fundamental frequency. Turbulence and wind velocity have a significant impact on internal forces and on the ability of the simplified model to reproduce their values. Despite the large differences obtained for highly turbulent scenarios, the acceptable accuracy obtained for relevant load scenarios and the conservative nature of the simplified model make it a viable option for preliminary large-scale studies that prioritize efficiency and efficacy over high-precision. Full article
