UV-C LEDs, which offer short-wavelength characteristics and serve as an alternative to traditional UV mercury lamps, represent a new light source for applications in space decontamination and surface disinfection. This paper presents the design and development of a UV-C LED lamp driver circuit configured to operate with a DC-input voltage source for sterilization and germicidal purposes. The primary circuit integrates a modified buck converter with a flyback converter, resulting in an innovative single-stage, single-switch DC-DC power converter. Additionally, the proposed electronic driver recovers energy stored in the transformer’s leakage inductors, enhancing overall circuit efficiency. A prototype driver circuit with a 3.3 W power rating (10 V/330 mA) is developed for a UV-C LED lamp intended for sterilization and germicidal applications with a DC-input voltage source. The experimental results from the prototype circuit, tested at an 18 V DC input, confirm the functionality of the proposed electronic driver for UV-C LED sterilization and germicidal lighting. Additionally, the circuit achieves efficiency exceeding 91%. Full article

Recently, a new type of lighting source, deep ultraviolet light-emitting diode (LED), has appeared in the markets of space purification and surface sterilization. In this paper, a new type of electronic lighting driver for supplying a deep-ultraviolet LED sterilization lamp is proposed and developed. The main circuit combines a buck converter and a flyback converter into a single-stage single-switch buck-flyback AC-DC power converter with power factor correction. In addition, the proposed electronic lighting driver leverages a wide bandgap SiC Schottky diode as the output diode to lower the power diode losses and recycles the energy stored in the leakage inductance of the transformer in order to improve the circuit efficiency. The magnetizing inductor inside the presented AC-DC power converter is designed to operate in discontinuous conduction mode (DCM), which naturally enables power factor correction (PFC). A single-stage prototype driver with a power rating of 3.6 W (90 V/40 mA) was developed and implemented for providing a deep ultraviolet LED disinfection and sterilization lamp. Experimental results show that the measured power factor (PF) is greater than 0.9 and the measured total harmonic distortion (THD) of the input current is less than 18% at an input utility voltage of 110 V. Furthermore, the measured output voltage ripple factor is less than 1% and the output current ripple factor is less than 4%. In addition, the proposed single-stage electronic lighting driver for supplying a deep ultraviolet LED disinfection and sterilization lamp achieves high circuit efficiency (greater than 90%), low circuit component count, and low circuit cost. Full article

Vibration measurements pose specific experimental challenges to be faced. In particular, optical methods can be used to obtain full-field vibration information. In this scenario, stereo-camera systems can be developed to obtain 3D displacement measurements. As vibration frequency increases, the common approach is to reduce camera exposure time to avoid blurred images, which can lead to under-exposed images and data loss, as well as issues with the synchronization of the stereo pair. Both of these problems can be solved by using high-intensity light pulses, which can produce high-quality images and guarantee camera synchronization since data is saved by both cameras only during the short-time light pulse. To this extent, high-power Light-Emitting Diodes (LEDs) can be used, but even if the LED itself can have a fast response time, specific electronic drivers are needed to ensure the desired timing of the light pulse. In this paper, a circuit is specifically designed to achieve high-intensity short-time light pulses in the range of 1 µs. A prototype of the designed board was assembled and tested to check its capability to respect the specification. Three different measurement methods are proposed and validated to achieve short-time light pulse measurements: shunt voltage measurement, direct photodiode measurement with a low-cost sensor, and indirect pulse measurement through a low-frame-rate digital camera. Full article

Flat panel displays are electronic displays that are thin and lightweight, making them ideal for use in a wide range of applications, from televisions and computer monitors to mobile devices and digital signage. The Thin-Film Transistor (TFT) layer is responsible for controlling the amount of light that passes through each pixel and is located behind the liquid crystal layer, enabling precise image control and high-quality display. As one of the important parameters to evaluate the display performance, the faster response time provides more frames in a second, which benefits many high-end applications, such as applications for playing games and watching movies. To further improve the response time, the single-pixel charging efficiency is investigated in this paper by optimizing the TFT dimensions in gate driver circuits in active-matrix liquid crystal displays. The accurate circuit simulation model is developed to minimize the signal’s fall time ($T_f$) by optimizing the TFT width-to-length ratio. Our results show that using a driving TFT width of 6790 $\mathsf{\mu }\mathrm{m}$ and a reset TFT width of 640 $\mathsf{\mu }\mathrm{m}$ resulted in a minimum $T_f$ of 2.6572 $\mathsf{\mu }\mathrm{s}$, corresponding to a maximum pixel charging ratio of 90.61275%. These findings demonstrate the effectiveness of our optimization strategy in enhancing pixel charging efficiency and improving display performance. Full article

The traditional light source of projection lamps adopts a halogen lamp, which has the advantages of high brightness, but its luminous efficiency is not good and consumes energy. A light-emitting diode (LED) has the characteristics of high luminous efficiency and energy savings and can be used as a new light source for projection lamps. The conventional two-stage electronic lighting driver circuit for supplying an LED projection lamp is composed of an AC-DC converter with power factor correction (PFC) as the first stage and a DC-DC converter for providing rated lamp voltage and current as the second stage. The conventional LED projection lamp driver circuit has more circuit components, a higher cost and limited efficiency. Therefore, this paper proposes a novel electronic lighting driver circuit for supplying an LED projection lamp with PFC function, which integrates a modified stacked dual boost converter and a half-bridge LLC resonant converter into a single-stage power-conversion circuit. The inductor inside the modified stacked boost converter is designed to operate at discontinuous conduction mode (DCM) for the driver circuit achieving PFC. Wide bandgap semiconductor devices silicon carbide (SiC)-based Schottky diodes are utilized to reduce power diode losses, and soft switching is implemented in the proposed LED projector lamp driver circuit to reduce the switching losses of the power switches and thus improve circuit efficiency. This paper has completed a single-stage prototype driver circuit for an LED projection lamp with PFC function, and the prototype circuit has a high power factor (PF > 0.98), low input current total-harmonic-distortion (THD < 6%) and high efficiency (>89%) in the case of an AC input power supply with an RMS value of 110 volts, and both power switches have the characteristics of soft switching. Full article

This paper attempts to describe a laser diode driver circuit using the depletion mode gallium nitride high electron mobility transistor (D-mode GaN HEMT) to generate nanosecond pulses at a repetition rate up to 10 MHz from the vertical-cavity surface-emitting laser (VCSEL). The feature of this driver circuit is a large instantaneous laser power output designed in the most efficient way. The design specifications include a pulse duration between 10 ns and 100 ns and a peak power up to above 100 W. The pulsed laser diode driver uses the D-mode GaN HEMT, which has very small C_oss difference between turn-on and turn-off states. The analysis is according to a laser diode model that is adjusted to match the VCSEL, made in National Yang Ming Chiao Tung University (NYCU). A design guide is summarized from the derivations and analysis of the proposed laser diode driver. According to the design guide, we selected the capacitor, resistor, and diode components to achieve 10 ns to 100 ns pulse duration for laser lighting. The experiment demonstrated that the maximum power-to-light efficiency can be as high as 86% and the maximum peak power can be 150 W, which matches the specifications of certain applications such as light detection and ranging (LiDAR). Full article

Bidirectional current-regulating ability is needed for AC light emitting diode (LED) drivers. In previous studies, various rectifier circuits have been used to provide constant bidirectional current. However, the usage of multiple electronic components can lead to additional costs and power consumption. In this work, a novel AlGaN/GaN lateral bidirectional current-regulating diode (B-CRD) featuring two symmetrical hybrid-trench electrodes is proposed and demonstrated by TCAD Sentaurus (California USA) from Synopsys corporation. Through shortly connecting the Ohmic contact and trench Schottky contact, the unidirectional invariant current can be obtained even with the applied voltage spanning a large range of 0–200 V. Furthermore, with the combination of two symmetrical hybrid-trench electrodes at each side of the device, the proposed B-CRD can deliver an excellent steady current in different directions. Through the TCAD simulation results, it was found that the device’s critical characteristics (namely knee voltage and current density) can be flexibly modulated by tailoring the depth and length of the trench Schottky contact. Meanwhile, it was also demonstrated through the device/circuit mixed-mode simulation that the proposed B-CRD can respond to the change in voltage in a few nanoseconds. Such a new functionality combined with excellent performance may make the proposed B-CRD attractive in some special fields where the bidirectional current-limiting function is needed. Full article

The theoretical temporal resolution limit $t_T$ of a silicon photodiode (Si PD) is 11.1 ps. We call “super temporal resolution” the temporal resolution that is shorter than that limit. To achieve this resolution, Germanium is selected as a candidate material for the photodiode (Ge PD) for visible light since the absorption coefficient of Ge for the wavelength is several tens of times higher than that of Si, allowing a very thin PD. On the other hand, the saturation drift velocity of electrons in Ge is about 2/3 of that in Si. The ratio suggests an ultra-short propagation time of electrons in the Ge PD. However, the diffusion coefficient of electrons in Ge is four times higher than that of Si. Therefore, Monte Carlo simulations were applied to analyze the temporal resolution of the Ge PD. The estimated theoretical temporal resolution limit is 0.26 ps, while the practical limit is 1.41 ps. To achieve a super temporal resolution better than 11.1 ps, the driver circuit must operate at least 100 GHz. It is thus proposed to develop, at first, a short-wavelength infrared (SWIR) ultra-high-speed image sensor with a thicker and wider Ge PD, and then gradually decrease the size along with the progress of the driver circuits. Full article

In capturing high-quality photoplethysmographic signals, it is crucial to ensure that appropriate illumination intensities are used. The purpose of the study was to deliver controlled illumination intensities for a multi-wavelength opto-electronic patch sensor that has four separate arrays each consisting of four light-emitting diodes (LEDs), the wavelength of the light generated by each array being different. The study achieved the following: (1) a linear constant current source LED driver incorporating series negative feedback using an integrated operational amplifier circuit; (2) the fitting of a linear regression equation to provide rapid determination of the LEDs driver voltage; and (3) an algorithm for the automatic adjustment of the output voltage to ensure suitable LED illumination. The data from a single centrally-located photo detector, which is capable of capturing all four channels of back-light in a time-multiplexed manner, were used to monitor heart rate and blood oxygen saturation. This paper provides circuitry for driving the LEDs and describes an adaptive algorithm implemented on a microcontroller unit that monitors the quality of the photo detector signals received in order to control each of the individual currents being supplied to the LED arrays. The study demonstrated that the operation of the new circuitry in its ability to adapt LED illumination to the strength of the signal received and the performance of the adaptive system was compared with that of a non-adaptive approach. Full article

Due to the short path length of alpha particles in air, a detector that can be used at a distance from any potential radiological contamination reduces the time and hazard that traditional alpha detection methods incur. This would reduce costs and protect personnel in nuclear power generation and decommissioning activities, where alpha detection is crucial to full characterisation and contamination detection. Stand-off alpha detection could potentially be achieved by the detection of alpha-induced radioluminescence, especially in the ultraviolet C (UVC) wavelength range (180–280 nm) where natural and artificial background lighting is less likely to interfere with detection. However, such a detector would also have to be effective in the field, potentially in the presence of other radiation sources that could mask the UVC signal. This work exposed a UVC sensor, the UVTRON (Hamamatsu, Japan) and associated electronics (driver circuit, microprocessor) to sources of beta and gamma radiation in order to assess its response to both of these types of radiation, as may be found in the field where a mixed radiation environment is likely. It has been found that the UVTRON is affected by both gamma and beta radiation of a magnitude that would mask any UVC signal being detected. ¹⁵²Eu generated 0.01 pulses per second per Bq through beta and gamma interactions, compared to ²¹⁰Po, which generates 4.72 × 10⁻⁸ cps per Bq from UVC radioluminescence, at 20 mm separation. This work showed that UVTRON itself is more susceptible to this radiation than the associated electronics. The results of this work have implications for the use of the UVTRON as a sensor in a stand-off detection system, highlighting the necessity for shielding from both potential gamma and beta radiation in any detector design. Full article

Visible light communication systems can be used in a wide variety of applications, from driving to home automation. The use of wearables can increase the potential applications in indoor systems to send and receive specific and customized information. We have designed and developed a fully organic and flexible Visible Light Communication system using a flexible OLED, a flexible P3HT:PCBM-based organic photodiode (OPD) and flexible PCBs for the emitter and receiver conditioning circuits. We have fabricated and characterized the I-V curve, modulation response and impedance of the flexible OPD. As emitter we have used a commercial flexible organic luminaire with dimensions 99 × 99 × 0.88 mm, and we have characterized its modulation response. All the devices show frequency responses that allow operation over 40 kHz, thus enabling the transmission of high quality audio. Finally, we integrated the emitter and receiver components and its electronic drivers, to build an all-organic flexible VLC system capable of transmitting an audio file in real-time, as a proof of concept of the indoor capabilities of such a system. Full article

In this work, a practical methodology is proposed to analyze, before undertaking a large investment, an outdoor lighting installation renewal with light-emitting diode (LED) luminaires. The main problems found in many of the luminaires tested are associated with inrush peak currents in cold start (which may cause ignition problems with random shutdowns), the harmonic distortions caused by their AC/DC associated electronic nature driver, and their working and efficiency dependency on the ambient temperature. All these issues have been tested in the context of a large metal halide (MH) to LED luminaires lighting point renewal where six commercial LED projectors have been analyzed with the above considerations. This research has isolated a single-phase circuit powered with constant stabilized 230 V_AC voltage source in a real public lighting installation. All of them have been sequentially installed and their main electrical and power-quality parameters measured and recorded. The results indicate that each luminaire option will influence the expected long-term reliability (>50.000 h or more as expressed by the U.S. Department of Energy) of the lighting installation (in the case poor power quality is generated on the grid). The economic analysis made to estimate the profitability of the investment may be severely affected by the difference between the declared and the real consumption values in which they perform in our specific installation. Full article
