Search Results (35)

Electric-assist bicycles have recently become very popular. However, riding them generally requires significantly more energy, generated simultaneously by the motor and the rider, compared to much lighter traditional bicycles. Assessing the energy efficiency of electric-assist bicycles in comparison to traditional bikes allows us to determine in which cases using electric bikes is cost-effective and in which it is not. This study proposes a method for evaluating the energy efficiency of bicycles, which stands out by relying on relatively imprecise data recorded at low frequency by a commercial bike computer with accessories. The core of the method is an algorithm developed by the authors to determine the tractive force acting on the bicycle and rider, based on a minimal set of recorded data: road incline, riding speed, and the wind speed component parallel to the direction of movement. Depending on the situation, the tractive force may act as a driving force or as a braking force. Based on the calculated tractive force, the power required to maintain the recorded bicycle speed can be estimated. Full article

Riding comfort and safety are essential requirements for any form of transportation but particularly for electric bicycles (e-bikes), which are highly affected by varying road conditions. These factors largely depend on the effectiveness of the e-bike’s control strategy. While several studies have proposed control approaches that address comfort and safety, vibration—an influential factor in both structural integrity and rider experience—has received limited attention during the design phase. Moreover, many commercially available e-bikes provide manual assistance-level settings, leaving comfort and safety management to the rider’s experience. This study proposes a Road-Adaptive Vibration Reduction System (RAVRS) that can be deployed on an e-bike rider’s smartphone to automatically maintain riding comfort and safety using manual assistance control. A fuzzy-based control algorithm is adopted to dynamically select the appropriate assistance level, aiming to minimize vibration while maintaining velocity and acceleration within thresholds associated with comfort and safety. This study presents a vibration analysis to highlight the significance of vibration control in improving electronic reliability, reducing mechanical fatigue, and enhancing user experience. A functional prototype of the RAVRS was implemented and evaluated using real-world data collected from experimental trips. The simulation results demonstrate that the proposed system achieves effective control of speed and acceleration, with success rates of 83.97% and 99.79%, respectively, outperforming existing control strategies. In addition, the proposed RAVRS significantly enhances the riding experience by improving both comfort and safety. Full article

In smart cities, bicycle-sharing systems have become an essential component of the transportation services available in major urban centers around the globe. Due to environmental sustainability, research on the power-assisted control of electric bikes has attracted much attention. Recently, fuzzy logic controllers (FLCs) have been successfully applied to such systems. However, most existing FLC approaches have a fixed fuzzy rule base and cannot adapt to environmental changes, such as different riders and roads. In this paper, a modified FLC, named self-tuning FLC (STFLC), is proposed for power-assisted bicycles. In addition to a typical FLC, the presented scheme adds a rule-tuning module to dynamically adjust the rule base during fuzzy inference processes. Simulation and experimental results indicate that the presented self-tuning module leads to comfortable and safe riding as compared with other approaches. The technique established in this paper is thought to have the potential for broader application in public bicycle-sharing systems utilized by a diverse range of riders. Full article

This paper presents a novel approach to address noise, vibration, and harshness (NVH) issues in electrically assisted bicycles (e-bikes) caused by the drive unit. By investigating and optimising the structural dynamics during early product development, NVH can decisively be improved and valuable resources can be saved, emphasising its significance for enhancing riding performance. The paper offers a comprehensive analysis of the e-bike drive unit’s mechanical interactions among relevant components, culminating—to the best of our knowledge—in the development of the first high-fidelity model of an entire e-bike drive unit. The proposed model uses the principles of elastic multi body dynamics (eMBD) to elucidate the structural dynamics in dynamic-transient calculations. Comparing power spectra between measured and simulated motion variables validates the chosen model assumptions. The measurements of physical samples utilise accelerometers, contactless laser Doppler vibrometry (LDV) and various test arrangements, which are replicated in simulations and provide accessibility to measure vibrations onto rotating shafts and stationary structures. In summary, this integrated system-level approach can serve as a viable starting point for comprehending and managing the NVH behaviour of e-bikes. Full article

This paper proposes a novel torque measurement and control technique for cycling-assisted electric bikes (E-bikes) considering various external load conditions. For assisted E-bikes, the electromagnetic torque from the permanent magnet (PM) motor can be controlled to reduce the pedaling torque generated by the human rider. However, the overall cycling torque is affected by external loads, including the cyclist’s weight, wind resistance, rolling resistance, and the road slope. With knowledge of these external loads, the motor torque can be adaptively controlled for these riding conditions. In this paper, key E-bike riding parameters are analyzed to find a suitable assisted motor torque. Four different motor torque control methods are proposed to improve the E-bike’s dynamic response with minimal variation in acceleration. It is concluded that the wheel acceleration is important to determine the E-bike’s synergetic torque performance. A comprehensive E-bike simulation environment is developed with MATLAB/Simulink to evaluate these adaptive torque control methods. In this paper, an integrated E-bike sensor hardware system is built to verify the proposed adaptive torque control. Full article

This paper presents the development of an electronic system that converts an electrically assisted bicycle into an intelligent health monitoring system, allowing people who are not athletic or who have a history of health issues to progressively start the physical activity by following a medical protocol (e.g., max heart rate and power output, training time). The developed system aims to monitor the health state of the rider, analyze data in real-time, and provide electric assistance, thus diminishing muscular exertion. Furthermore, such a system can recover the same physiological data used in medical centers and program it into the e-bike to track the patient’s health. System validation is conducted by replicating a standard medical protocol used in physiotherapy centers and hospitals, typically conducted in indoor conditions. However, the presented work differentiates itself by implementing this protocol in outdoor environments, which is impossible with the equipment used in medical centers. The experimental results show that the developed electronic prototypes and the algorithm effectively monitored the subject’s physiological condition. Moreover, when necessary, the system can change the training load and help the subject remain in their prescribed cardiac zone. This system allows whoever needs to follow a rehabilitation program to do so not only in their physician’s office, but whenever they want, including while commuting. Full article

Electrically-assisted bicycles (e-bikes) are a means through which to increase individual physical activity (PA) and overcome some commonly reported barriers to engaging in conventional cycling. Fatigue is a common side effect to breast cancer treatment, and the rate of PA engagement drops significantly following a breast cancer diagnosis. The aim of this qualitative study was to examine perceptions of e-cycling as a means of increasing PA in this population. Twenty-four participants (mean age = 57.88 (standard deviation 10.8), 100% female) who have had a breast cancer diagnosis, completed two semi-structured interviews via Zoom. One interview was conducted prior to an e-bike taster session and a second, after the session. Taster sessions were conducted by certified cycling instructors in the community. Interviews were conducted between December 2021 and May 2022. Data were transcribed verbatim and analyzed thematically using NVivo 12 software. An inductive and deductive approach to analysis was adopted. Five themes were generated: (1) Perceived role of e-bikes during treatment, (2) The relationship between e-bikes and fatigue, (3) Cancer-specific considerations, (4) Is e-cycling ‘enough’?, and (5) Optimizing the intervention. Negative perceptions of e-bikes noted before the taster session were altered following riding an e-bike. The multiple levels of assistance made cycling manageable and less impacted by fatigue, thereby enabling individuals to re-establish previous cycling habits. E-cycling may be a suitable option to increase PA behavior amongst individuals being treated for breast cancer, with the potential to overcome many of the barriers of conventional cycling. Enabling this population to trial an e-bike elicits positive physical and psychological responses that may help to promote future engagement. Full article

In recent years, the mobility sector is undergoing a revolution, which is resulting also into a worldwide spread of light electric vehicles, such as electric scooters and bicycles. The increasing public concern about environmental problems further feeds this revolution. Electric-bicycles (or e-bikes) are a new trend which fits different riders’ needs. In fact, they offer extended range and ease of use, allowing riders to travel in urban centres, but also to take longer trips. E–bikes are reliable, easy to ride, affordable, and they help people live and travel a little greener, with a great benefit for their health. Many Companies (such as Brose, Bafang, Bosch and Shimano) developed performing e-bike motor drives. However, there is not a detailed general procedure to help the choice and design of electric bikes, in particular concerning the electric machine. This review focuses on the analysis of different motors for e-bike application. First, the e-bike system state of art is presented. The pedal-assist and power-on-demand e-bike system typologies are presented, together with the most popular parallel configuration and the less common series configuration. Further on, the environmental resistances are analysed for a traditional bicycle system and then the force balance is extended to the electric vehicle example. The most common Lithium-ion battery and the battery management system state of art is discussed, presenting design schemes and typical performances. Concerning the electrical machine, some electromagnetic design approaches are described, together with some data on commercial motors. Finite element analysis of a common motor model is carried out and some experimental tests are presented to highlight their capabilities. Different control strategies are compared, including innovative solutions and new trends. Full article

The circular economy is attracting the attention of governments and companies who recognize the importance of promoting a sustainable approach toward social and industrial development. The European Union requires EU State members to support a sustainable approach to improving the production and consumption of Waste Electrical and Electronic Equipment (WEEE). This paper supports the conceptualization of a sustainable circular economy model, proposing the reuse of lithium-ion batteries from WEEE. The aim is to define a circular economy-based production model for the reuse of waste lithium-ion batteries and support the inclusion of disadvantaged people in the recovery process, breaking the barriers of social discrimination. The activities introduced in this paper are part of a circular economy project for the social integration of disadvantaged people. In this paper, the preliminary results of the project are introduced, proposing a methodology for the disassembly of waste lithium-ion batteries. The disassembly line balancing proposed in this paper focuses on the need to include workers with physical, psychological, sensory, or intellectual limitations, as well as people experiencing communication difficulties. Future steps of the project will focus on the design of the assembly line to produce battery packs for pedal-assisted bicycles from the recovered lithium-ion cells. Full article

Negative effects of a massive use of cars, such as congestion, air pollution, noise, and traffic injuries, are affecting the cities everywhere. Recently introduced shared vehicles, such as e-scooters and electric bicycles, could potentially accelerate the transition towards sustainable mobility. Although these vehicles are becoming increasingly common and accepted within regulatory frameworks, some local governments are not yet ready to integrate e-scooters into their transport systems. Indeed, the legislation is unclear as it is not easy to determine whether the e-scooter is more like a bicycle or a vehicle. Moreover, it is difficult to predict the impact of e-scooters on road traffic, as well as the type of road infrastructure chosen by e-scooter drivers or the possible interaction of such vehicles with weak road users, such as pedestrians or cyclists. This study showed an analysis of speed and behaviour of e-scooter drivers in the city of Trondheim (Norway) to investigate how to manage this mode of transport. A total of 204 e-scooters were observed on six different roads in the city centre. The speed of e-scooter drivers was measured by a speed tracker (average value 15.4 km/h) and their behaviour recorded by a hidden observer in the field. Gender, age, distance from pedestrians, speed adaptation to the environment, and type of vehicle used were registered for each e-scooter. Through a Binomial Logit analysis, the data obtained were used to analyse the type of road infrastructure preferred by e-scooter drivers. Results showed that the cycle path is more widely used with percentage value from 60% to 90% of users. In addition, the probability of choice depended mainly on the road environment. The aim of this analysis was to assist local authorities in regulating the safe use of e-scooters and developing appropriate policies for their integration into cities. Full article

A modal shift to electric pedal-assisted cycles (EPACs) can help with reaching the transport emission goals of the European Green Deal. With the rising sales of EPACs in Europe, a lack of appropriate (electric) cycling infrastructure remains a major barrier for many potential users. This paper discusses the results of a survey about the requirements of (potential) cyclists to design a better cycling infrastructure. The differences in requirements for non-cyclists vs. cyclists and electric cyclists vs. conventional cyclists are discussed using statistical analysis. The key findings are that cyclists and non-cyclists both require wide quality cycling infrastructure with safe crossing points, secure bicycle parking and smart traffic lights. Non-cyclists’ requirements significantly differ from cyclists’ on 12 items, of which rain cover while cycling and parking spots for the car are the most noteworthy. There is (but) one significant difference between the requirements of EPAC users and conventional cyclists: the need for charging points for EPACs along the cycle route. Full article

The aim of this study was to check whether the data recorded by a bicycle computer paired with typical measurement sensors can be useful for a scientific evaluation of the cyclist–bicycle anthropotechnical system, including electric bicycles. The problem arose when the authors searched for methods to assess the energy efficiency of electric bicycles and intelligent power management systems provided by the assistance system, in accordance with the current needs of the bicycle user. This can be of great importance in the efficient use of electric bicycles and their batteries, in the event that they are rented in public access systems. This article focuses primarily on data on bicycle speed, calculated by the GPS module or obtained from speed sensors, as well as data from the cadence sensor, power measurement, pedaling technique and heart rate. An attempt was made to evaluate the correctness and consistency of the data recorded by the computer through various types of comparatives analyses. The conducted research used data recorded when traveling the same route with various bikes, including electric ones, with and without assistance. This is the second part of the research. The first part focusing on data obtained by a computer from a GPS system and a barometric altimeter was published in an earlier article. In both parts, the authors presented some advantages and disadvantages of using bicycle computers as tools for measuring and acquiring data. In general, it seems that the existing technology used by bicycle computers and the measurement sensors that cooperate with it can be used in the development of a system that optimizes energy consumption. Full article

This work presents an analysis of data recorded by a bicycle computer paired with typical measurement sensors in order to determine whether the data can be useful for a scientific evaluation of the cyclist–electric bicycle anthropotechnical system. There are no studies on this subject in the available literature. An attempt was made to estimate the quality of data and define the most effective methods of processing and filtering. The imperfections of the measurement system and the potential directions of the development of bicycle computers are indicated. Particular attention has been given to the data needed to compare the energy efficiency of assisted electric bicycles. However, the results of the analyses can also be used in cyclist endurance tests and to simulate routes in various types of bicycle trainers. The article focuses on the data obtained from the GPS module and the barometric altimeter, which make it possible to estimate the trajectory of movement, the distance traveled, and the height of the route above sea level as well as its slope. In order to assess the accuracy, the data from the bicycle computer was compared with the geodetic data. Methods for averaging GPS routes were also proposed. In this way, it was possible to identify the parameters of the selected path for testing bicycles quite accurately. The research presented in this paper is an introduction to the development of methods for assessing the energy efficiency of electric bicycles. Analyses of other data measured by the cycling computer, such as speed, cadence, and power, will be carried out in the second planned part of the article. Full article

This paper aims to provide a review of the electrically assisted bicycles (also known as e-bikes) used for recovery of the rider’s physical and physiological information, monitoring of their health state, and adjusting the “medical” assistance accordingly. E-bikes have proven to be an excellent way to do physical activity while commuting, thus improving the user’s health and reducing air pollutant emissions. Such devices can also be seen as the first step to help unhealthy sedentary people to start exercising with reduced strain. Based on this analysis, the need to have e-bikes with artificial intelligence (AI) systems that recover and processe a large amount of data is discussed in depth. The Preferred Reporting Items for Systematic Reviews and Meta-Analyses guidelines were used to complete the relevant papers’ search and selection in this systematic review. Full article

This paper presents an analysis of the opportunity to increase the price availability of small electric vehicles, such as electric scooters, such as bicycles and wheelchairs, by applying expandability and modularity principles to their motors. Assuming that, in many cases, small electric vehicles are brought to the market in several power/price versions, the authors of this report evaluate the possibility of combining different numbers of electromechanical modules while, at the same time, maintaining the unity of the entire drive/motor scheme, thus making the mentioned expandability possible. Power-assist wheelchairs are taken as an example of the application, where such expandability is reasonable. The application provides a price reduction for the less powerful wheelchairs in the case of less severe disabilities. To start, the authors briefly compare multidrive schemes that ground the principle of modularity at the electromechanical level. Then, they outline a radially segmented motor concept and discuss this concept using the example of a permanent magnet synchronous motor. In particular, they propose a methodology for the calculation of its parameters and calculate the particular design details of such a motor. The motor is then analyzed with the help of its mathematical model, as well as experimentally. This tentative evaluation of two 50 W segments (of a 300 W 6-segment motor) proves that the proposed segmented modularity concept is feasible, and that it requires a more detailed consideration of the parameters and the other implementation aspects (power driver, control, cooling) of the given synchronous motor. Moreover, the concept might be successfully utilized in the designs of other motor types. Full article
