The Visible Infrared Imaging Radiometer Suite (VIIRS) onboard the National Oceanic and Atmospheric Administration-20 (NOAA-20) satellite was launched on 18 November 2017. The on-orbit calibration of the NOAA-20 VIIRS visible and near-infrared (VisNIR) bands has been very stable over time. However, NOAA-20 operational M1 (a dual gain band with a center wavelength of 0.41 µm) sensor data records (SDR) have exhibited persistent scene-dependent striping over clear-sky ocean (high gain, low radiance) since the beginning of the mission, different from other VisNIR bands. This paper studies the root causes of the striping in the operational NOAA-20 M1 SDRs. Two potential factors were analyzed: (1) polarization effect-induced striping over clear-sky ocean and (2) imperfect on-orbit radiometric calibration-induced striping. NOAA-20 M1 is more sensitive to the polarized lights compared to other NOAA-20 short-wavelength bands and the similar bands on the Suomi NPP and NOAA-21 VIIRS, with detector and scan angle-dependent polarization sensitivity up to ~6.4%. The VIIRS M1 top of atmosphere radiance is dominated by Rayleigh scattering over clear-sky ocean and can be up to ~70% polarized. In this study, the impact of the polarization effect on M1 striping was investigated using radiative transfer simulation and a polarization correction method similar to that developed by the NOAA ocean color team. Our results indicate that the prelaunch-measured polarization sensitivity and the polarization correction method work well and can effectively reduce striping over clear-sky ocean scenes by up to ~2% at near nadir zones. Moreover, no significant change in NOAA-20 M1 polarization sensitivity was observed based on the data analyzed in this study. After the correction of the polarization effect, residual M1 striping over clear-sky ocean suggests that there exists half-angle mirror (HAM)-side and detector-dependent striping, which may be caused by on-orbit radiometric calibration errors. HAM-side and detector-dependent striping correction factors were analyzed using deep convective cloud (DCC) observations (low gain, high radiances) and verified over the homogeneous Libya-4 desert site (low gain, mid-level radiance); neither are significantly affected by the polarization effect. The imperfect on-orbit radiometric calibration-induced striping in the NOAA operational M1 SDR has been relatively stable over time. After the correction of the polarization effect, the DCC-based striping correction factors can further reduce striping over clear-sky ocean scenes by ~0.5%. The polarization correction method used in this study is only effective over clear-sky ocean scenes that are dominated by the Rayleigh scattering radiance. The DCC-based striping correction factors work well at all radiance levels; therefore, they can be deployed operationally to improve the quality of NOAA-20 M1 SDRs. Full article

We report a novel dual-band barrier infrared detector (DBIRD) design using InAs/GaSb type-II superlattices (T2SLs). The DBIRD structure consists of back-to-back barrier diodes: a “blue channel” (BC) diode which has an nBp architecture, an n-type layer of a larger bandgap for absorbing the blue band infrared/barrier/p-type layer, and a “red channel” (RC) diode which has a pBn architecture, a p-type layer of a smaller bandgap for absorbing the red band infrared/barrier/n-type layer. Each has a unipolar barrier using a T2SL lattice matched to a GaSb substrate to impede the flow of majority carriers from the absorbing layer. Each channel in the DBIRD can be independently accessed with a low bias voltage as is preferable for high-speed thermal imaging. The device modeling of DBIRDs and simulation results of the current–voltage characteristics under dark and illuminated conditions are also presented. They predict that the dual-band operation of the DBIRD will produce low dark currents and 45–56% quantum efficiencies for the in-band photons in the BC with ${\lambda }_c$ = 5.58 μm, and a nearly constant 32% in the RC with ${\lambda }_c$ = 8.05 μm. The spectral quantum efficiency of the BC for 500 K blackbody radiation is approximately 50% over the range of $\lambda$ = 3–4.7 μm, while that of the RC has a peak of 42% at 5.9 μm. The DBIRD may provide improved high-speed dual-band imaging in comparison with NBn dual-band detectors. Full article

Gas detection based on infrared thermal imaging is applied in many areas, but it is generally applied as a qualitative detection method to observe the target area; on the other hand, quantitative research on gas concentration is less common, the measurement accuracy is poor, and the calculation method of concentration in the commonly adopted transmission model is also complicated. In this paper, based on the radiance transfer model of gas infrared imaging technology, the influence of gas concentration, gas temperature, and background temperature on gas imaging detection is investigated, a gas detection and concentration inversion method based on dual-temperature background points is proposed, and the effects of the choice of reference band on background temperature correction are analyzed in relation to the changing trend of dual-band radiance difference. To verify the effectiveness of this method, a gas detection system with dual-temperature background spots was constructed in this paper utilizing a cooled mid-wave infrared focal plane detector plus a reference filter and a measurement filter, which achieved a promising concentration accuracy of less than 10% for carbon dioxide at a detectable range. Meanwhile, an infrared imaging system with a noise equivalent temperature difference (NETD) of 40 mK was employed to simulate the detection of methane, which enables the detection and concentration inversion of methane gas at a minimum concentration of 500 ppm·m at a distance of 1 km, which proves the capability of long-range detection. Full article

In this work, the Ag-SiO₂-Ag metamaterial with elliptical nano-slits was proposed to investigate the multi-band polarization-dependent perfect absorber. It was found that multi-band perfect absorptions can be induced under TE and TM-polarized illuminations. Simulation results showed that the absorption peaks for TE-polarized wave appeared at 337.6 THz and 360.0 THz with 98.5% and 97.6% absorbance, respectively. Conversely, the absorption peaks for TM-polarized wave appeared at 325.7 THz and 366.1 THz with 96.3% and 97.9% absorbance, respectively. As a result, the elliptical metamaterial presented polarization-selectivity property for perfect absorption, and so, the metamaterial can filter out different frequencies of TE- and TM-reflected waves, i.e., the elliptical metamaterial can be used as a reflecting filter. In addition, this work studied the sensing performance of the elliptical metamaterial and showed that the dual-band sensing performances were different at low and high frequencies. The sensitivities (S) to the refractive index reached up to 151.1 THz/RIU and 120.8 THz/RIU for the TE and TM-polarized waves around 337.6 THz and 325.7 THz, which provide promising potential in near-infrared photoelectric sensor and detector. However, both the absorption frequency and intensity of TM-polarized wave were insensitive to the refractive index of the medium around 366.1 THz, and so, the study provides a theoretical basis for infrared stealth of different media. Full article

Non-uniformity in the response of spectral image elements is an inevitable phenomenon in hyperspectral imaging, which mainly manifests itself as the presence of band noise in the acquired hyperspectral data. This problem is prominent in the infrared band owing to the detector material, operating environment, and other factors. Non-uniformity is an important factor that can affect the quality of the hyperspectral data, which has a serious impact on both data analysis and applications and requires corrections via technical means wherever possible. This paper proposes a novel target-based non-uniformity self-correction method for infrared push-broom hyperspectral images. The Mars Mineralogical Spectrometer (MMS) onboard the Tianwen-1 orbiter was used as the research and application object. The model is constructed and applied to the target scene characteristics and detection patterns of Mars remote sensing exploration, which are combined with the causes of noise generation in the infrared spectral image bands. The design of the MMS dual-channel Visible-Near-Infrared (V-NIR) and Near-Mid-Infrared (N-MIR) co-field of view co-target detection and laboratory calibration data for the V-NIR spectral band can achieve non-uniformity corrections (NUCs). Therefore, for the MMS in-orbit Mars exploration mission, the method selected spectral data (920–1055 nm) characterized by a reduced atmospheric influence to iteratively obtain the homogeneous region, which was used to calculate the non-uniformity correction factor for the N-MIR spectral band. This method was compared, validated, and evaluated with other conventional methods using both laboratory and in-orbit hyperspectral data. The results showed that the experimental data corrections were comparable to laboratory calibrations, with a maximum relative deviation of <2.6%. These results prove that our method not only provides an excellent non-uniformity correction, but also ensures spectral fidelity. It can thus be used as a non-uniformity correction process for the MMS and similar hyperspectral imagers. Full article

The uncertainty of emissivity has a major effect on the accuracy of a pyrometer in billet temperature measurement. In order to eliminate the influence of emissivity, we place a reflector with two apertures at the front of a pyrometer. The two apertures on the reflector are used to measure intrinsic radiation and approximate blackbody radiation of the billet. The radiation is collected by two infrared dual-band detectors in the pyrometer. Then, the real-time emissivity of the billet can be measured with no assumptions, so the influence of emissivity is eliminated. In addition, the measurement uncertainty is analyzed based on the ray-tracing method. The pyrometer is developed and the accuracy verification of emissivity is implemented. Compared with the reference material at the same temperature, the measurement errors of the emissivity are 0.021 and 0.005 at two wavelengths. Then, we install the pyrometer in the medium plate rolling process for measurement. Compared with a thermal imager used in the rolling process, the measurement fluctuation is reduced obviously. It indicates that the method of emissivity measurement is very effective for billet temperature measurement. Full article

Space target feature extraction and space infrared target recognition are important components of space situational awareness (SSA). However, owing to far imaging distance between the space target and infrared detector, the infrared signal of the target received by the detector is dim and easily contaminated by noise. To effectively improve the accuracy of feature extraction and recognition, it is essential to suppress the noise of the infrared signal. Hence, a novel denoising and extracting feature method combinating optimal variational mode decomposition (VMD) and dual-band thermometry (DBT) is proposed. It takes the mean weighted fuzzy-distribution entropy (FuzzDistEn) of the band-limited intrinsic mode functions (BLIMFs) as the optimization index of dragonfly algorithm (DA) to obtain the optimal parameters (K, α) of VMD. Then the VMD is utilized to decompose the noisy signal to obtain a series of BLIMFs and the Pearson correlation coefficient (PCC) is proposed to determine the effective modes to reconstructe the denoising signal. Finally, based on the denoising signal, the feature of temperature and emissivity-area product are calculated using the DBT. The simulation and experiment results show that the proposed method has better noise reduction performance compared with the other denoising methods, and the accuracy of feature extraction is improved at different noise equivalent irradiance. This provides more accurate feature of temerpature and emissivity-area product for space infrared dim target recognition. Full article

This paper presents a design of a dual-band integrated space telescope system for visible light and long-wave infrared. The system can simultaneously image the visible light band of 450–900 nm and the long-wave infrared band of 7700–10,500 nm. The dual-band integrated imaging system can freely switch the observation band to adapt to different scenes and environmental changes. The camera can also further expand its capabilities in the fields of multi-spectral observation and low-light observation by collocation with different detectors. This design is based on a coaxial reflection system, the two bands share the camera’s primary and secondary mirrors, and the separation of the two bands is achieved through a separate field of view design. After simulation, the average Modulation Transfer Function (MTF) value of the visible light band of the system at 50 lp/mm (line pairs per millimeter) reaches 0.45, and the average MTF value of the long-wave infrared band at 50 lp/mm reaches 0.36. In addition, tolerance analysis, ambient temperature analysis and transmittance analysis of the integrated system are carried out in this paper to further improve the integrated system scheme, and the feasibility of the system is further verified. Full article

An aluminum nitride (AlN) piezoelectric resonant infrared (IR) detector based on a Lame-wave resonator (LWR) and plasmon apertures was designed for dual-band sensing, and was investigated by using the finite element method (FEM) and finite difference time domain (FDTD) simulations. A plasmon structure with the apertures was designed on the surface of the detector in order to maintain electrical performance and to obtain ultrahigh dual-band IR absorption. The electrical performance of the LWR with the plasmon apertures was comparable to that of the LWR with floating electrodes, which was found to be superior to that of the LWRs with plasmon particles or open electrodes. Both of the rectangle aperture and cross-shaped aperture absorbers can achieve ultrahigh dual-band absorptions of up to 97%, and the cross-shaped aperture absorber is insensitive to the polarization angle. Moreover, a detailed optimization analysis for the thermal properties of the detector was conducted to obtain favorable responsivity and response speed. The calculated results demonstrate that the proposed resonant detector has great potential applications in IR detection. Full article

The combination of critical coupling and coupled mode theory in this study elevated the absorption performance of a graphene-based absorber in the near-infrared band, achieving perfect absorption in the double bands (98.96% and 98.22%), owing to the guided mode resonance (the coupling of the leak mode and guided mode under the condition of phase matching, which revealed 100% transmission or reflection efficiency in the wavelet band), and a third high-efficiency absorption (91.34%) emerged. During the evaluation of the single-structure, cross-circle-shaped absorber via simulation and theoretical analysis, the cross-circle shaped absorber assumed a conspicuous preponderance through exploring the correlation between absorption and tunable parameters (period, geometric measure, and incident angle of the cross-circle absorber), and by briefly analyzing the quality factors and universal applicability. Hence, the cross-circle resonance structure provides novel potential for the design of a dual-band unpatterned graphene perfect absorber in the near-infrared band, and possesses practical application significance in photoelectric detectors, modulators, optical switching, and numerous other photoelectric devices. Full article

In this work, we fabricated dual-band 800 × 2 short-wave infrared (SWIR) indium gallium arsenide (InGaAs) focal-plane arrays (FPAs) using N-InP/i-In_0.53Ga_0.47As/N-InP double-heterostructure materials, which are often applied in ocean-color remote sensing. Using narrow-band interference-filter integration, our detector-adopted planner structure produced two detection channels with center wavelengths of 1.24 and 1.64 μm, and a full-width half-maximum (FWHM) of 0.02 μm for both channels. The photoelectric characteristics of the spectral response, modulation transfer function (MTF), and detectability of the detector were further analyzed. Our FPAs showed good MTF uniformity with pixel operability as high as 100% for each 800 × 1 linear array. Peak detectivity reached 4.39 × 1012 and 5.82 × 1012 cm·Hz1/2/W at 278 K, respectively, and response nonuniformity was ideal at 2.48% and 2.61%, respectively. As a final step, dual-band infrared detection imaging was successfully carried out in push-broom mode. Full article
