In this paper, we implement a compact switchable bandpass filter on a 50 Ω microstrip line. The proposed structure consists of an input/output stage with one end terminated at 50 Ω, a C-shaped-open loop resonator, and two L-shaped-open loop resonators. The proposed filter operates in four different modes depending on the on/off combination of the five PIN diodes. Each mode includes a dual-band pass filter (DB-BPF) designed for the 1.4 GHz and 5.1 GHz bands, another DB-BPF covering the 2.4 GHz and 4.2 GHz bands, a wideband BPF with a bandwidth ranging from 2 to 4.5 GHz, and an all-pass filter (APF) that allows all frequencies to pass through. The proposed structure is extremely compact because it is implemented on a 50 Ω line without any additional space. Full article

The proliferation of the Internet of Things (IoT) propels the continuous demand for compact, low-cost, and high-performance multiband filters. This paper introduces a novel low-profile dual-band bandpass filter (BPF) constructed with a back-to-back coupled pair of shielded folded quarter-mode substrate integrated waveguide (SF-QMSIW) multimode cavities. A hybrid structure is obtained by etching a coplanar waveguide (CPW) coupling line in the folded cavity’s septum layer. It serves multiple functions: generating an additional resonance, providing a separate coupling mechanism for the upper passband, and offering the flexibility to control the passbands’ center frequency ratio. Additionally, the unused second higher-order mode is suppressed by integrating embedded split-ring resonators (ESRRs) with an inter-digital capacitor (IDC) structure into the feed lines. A filter prototype has been fabricated and experimentally tested. The measurements confirmed reliable operation in two passbands having center frequencies 3.6 GHz and 5.8 GHz, and exhibiting 3 dB fractional bandwidths (FBWs) of 6.4% and 5.3%, respectively. Furthermore, the group delay variation within both passbands equals only 0.62 ns and 1.00 ns, respectively. Owing to the second higher-order mode suppression, the filter demonstrated an inter-band rejection exceeding 38 dB, within a compact footprint of 0.71${\lambda }_g^2$ (with ${\lambda }_g$ being the guided wavelength at the lower passband’s center frequency). Full article

In this paper, a dual-band integrated bandpass filter (DI-BPF) based on a mode composite substrate integrated coaxial line (MCSICL) is proposed for a large frequency ratio. The low-frequency bandpass filter is formed by incorporating an SICL line and a gap into the MCSICL, operating in the fundamental mode of the MCSICL. The high-frequency bandpass filter is formed by introducing grounded vias into the MCSICL, operating in the first high-order mode of the MCSICL. To guide the design, the equivalent circuit models of the low- and high-frequency bandpass filters are built. Based on the equivalent circuit models, the DI-BPF is synthesized for a large frequency ratio. The transitions from the DI-BPF to ground coplanar waveguides (GCPWs) are designed for the low- and high-frequency bandpass filters. The DI-BPF with the transitions is fabricated by the printed circuit board (PCB) process. Measurement results indicate a large frequency ratio of 23.16, with the isolation between the low- and high-frequency bandpass filters exceeding 30 dB from dc to 50 GHz. Full article

This article presents two novel architectures of dual-band substrate-integrated waveguide (SIW) bandpass filters (BPFs). Initially, two identical open-loop ring resonators (OLRRs) were coupled face-to-face on the top of the SIW cavity to realize a dual-band single-pole BPF. To obtain two-pole dual-band characteristics, two OLRRs resonant units were assembled horizontally within the top metal layer of the SIW, which is a technique used for the first time in the literature. For demonstration purposes, two types of SIW filters loaded with OLRRs were designed and fabricated. The proposed filters feature an extremely compact size, a low insertion loss, and good selectivity. The single- and two-pole filters have an overall size of 0.012${\lambda }_g$${}^2$ and 0.041${\lambda }_g$${}^2$, respectively. The simulated and measured circuit responses are in good agreement. Full article

In this paper, two novel dual-band bandpass filters (BPFs) and a compact quad-channel diplexer working at 1.7/3.3 GHz and 1.9/3.6 GHz are proposed. In the proposed diplexer design, triangular loop resonators and rectangular loop resonators are used together to reduce the circuit size and improve diplexer performances. Insertion loss (IL) and return loss (RL) of the proposed diplexer are better than 0.8 dB and 21 dB, respectively, at these four operating frequencies. Output ports isolation parameter is better than 30 dB. With the achieved specifications, the proposed diplexer can be used in L and S band applications. Full article

The paper introduces a novel structure of a dual-band filtering Wilkinson power divider (WPD). Its essential component is a dual-band bandpass filter (BPF), implemented using coupling lines and two T-shaped resonators. The BPF is incorporated into the divider structure to suppress the unwanted harmonics within the circuit. The latter is achieved owing to a wide stopband of the filter. The designed dual-band WPD can suppress third unwanted harmonics in both channels with high levels of attenuation. The designed dual-band WPD operates at 2.6 GHz and 3.3 GHz with a return loss of 22.1 dB and 22.3 dB at the operating frequencies. Furthermore, the insertion loss and isolation are 0.3 dB and 20.2 dB at 2.6 GHz and 0.9 dB and 24.5 dB at 3.3 GHz. The analysis and simulation results are corroborated by the measurements of the fabricated divider prototype. The competitive performance of the proposed circuit is also demonstrated through comparisons with state-of-the-art divider circuits from the literature. Full article

A stepped impedance resonator (SIR) is suitable for designing a dual-band bandpass filter (BPF) that can be adjusted to reject spurious bands. A BPF is proposed using an SIR T-shaped meander line and folded structure. The BPF mainly comprises a meander line, a folded structure, and a T-shaped line. A novel BPF is used for the T-shaped line, which operates as a band-stop filter connecting to the center of the BPF. As a result, the complete BPF enables dual-band operation. The insertion and return losses of the first frequency passband (f₀₁) are 0.024 and 17.3 dB, respectively, with a bandwidth of 46% at a center frequency of 2.801 GHz (2.2–3.48 GHz). The insertion and return losses of the second frequency passband (f₀₂) are 0.026 and 17.2 dB, respectively, with a bandwidth of 10% at a center frequency of 4.351 GHz (4.13–4.55 GHz). The proposed BPF provides low loss, a simple structure, and a small size of only 4.29 × 4.08 mm, and it can be integrated into mobile communications systems. Full article

We present an experimental method for evaluating interfacial force per width and predicting internal stress in mid-infrared band-pass filters (MIR-BPF). The interfacial force per width between the two kinds of thin-film materials was obtained by experimental measurement values, and the residual stress of the multilayer thin films was predicted by the modified Ennos formula. A dual electron beam evaporation system combined with ion-assisted deposition was used to fabricate mid-infrared band-pass filters. The interfacial forces per width for Ge/SiO₂ and SiO₂/Ge were 124.9 N/m and 127.6 N/m, respectively. The difference between the measured stress and predicted stress in the 23-layer MIR-BPF was below 0.059 GPa. The residual stresses of the four-layer film, as well as the 20-layer and 23-layer mid-infrared band-pass filter, were predicted by adding the interface stress to the modified Ennos formula. In the four-layer film, the difference between the predicted value and the measured stress of the HL (high–low refractive index) and LH (low–high refractive index) stacks were −0.384 GPa for (HL)² and −0.436 GPa for (LH)², respectively. The predicted stress and the measured stress of the 20-layer mid-infrared filter were −0.316 GPa and −0.250 GPa. The predicted stress and the measured stress of the 23-layer mid-infrared filter were −0.257 GPa and −0.198 GPa, respectively. Full article

In this paper, we present a dual-band microstrip bandpass filter (BPF) with an improved stopband, which was constructed by a quad-mode stub-loaded resonator (SLR). Since the SLR is able to produce multiresonance within a single unit, the area saving is significant. The proposed quad-mode SLR was implemented by two stubs allocated at symmetry places, thus the even-/odd-mode can be applied to analysis the resonance. Moreover, to shift the spurious passband, the step impedance structure was applied to shift the harmonic resonance to the higher frequency. Design procedure for high performance dual-band BPF is proposed, and filter examples were designed for wireless local area network (WLAN) of 2.4/5.2 GHz. The measured insertion losses, return losses and fractional bandwidths (FBW) are 1.43 dB, 10 dB, and 14.8% at 2.4 GHz and 1.34 dB, 10 dB, and 12.9% at 5.2 GHz. Moreover, by applying two quarter-wavelength stubs on the input/output ports, the passband selectivity with an isolation of 40 dB can be achieved. The simulation and measurement have a close match, verifying the design concept. Full article

A dual-band bandpass filter (BPF) composed of a coupling structure and a bent T-shaped resonator loaded by small L-shaped stubs is presented in this paper. The first band of the proposed BPF covers 4.6 to 10.6 GHz, showing 78.9% fractional bandwidth (FBW) at 7.6 GHz, and the second passband is cantered at 11.5 GHz with a FBW of 2.34%. The bent T-shaped resonator generates two transmission zeros (TZs) near the wide passband edges, which are used to tune the bandwidth of the first band, and the L-shaped stubs are used to create and control the narrow passband. The selectivity performance of the BPF is analyzed using the transfer function extracted from the lumped circuit model verified by a detailed even/odd mode analysis. The BPF presents a flat group delay (GD) of 0.45 ns and an insertion loss (IL) less than 0.6 dB in the wide passband and a 0.92 IL in the narrow passband. A prototype of the proposed BPF is fabricated and tested, showing very good agreement between the numerically predicted and measured results. Full article

A narrowband dual-band bandpass filter (BPF) with independently tunable passbands is presented through a systematic design approach. A size-efficient coupling system is proposed with the capability of being integrated with additional resonators without increasing the size of the circuit. Two flag-shaped resonators along with two stepped-impedance resonators are integrated with the coupling system to firstly enhance the quality response of the filter, and secondly to add an independent adjustability feature to the filter. The dual passband of the filter is centered at 4.42 GHz and 7.2 GHz, respectively, with narrow passbands of 2.12% and 1.15%. The lower and upper passbands can be swept independently over 600 MHz and 1000 MHz by changing only one parameter of the filter without any destructive effects on the frequency response. According to United States frequency allocations, the first passband is convenient for mobile communications and the second passband can be used for satellite communications. The filter has very good in- and out-of-band performance with very small passband insertion losses of 0.5 dB and 0.86 dB as well as a relatively strong stopband attenuation of 30 dB and 25 dB, respectively, for the case of lower and upper bands. To verify the proposed approach, a prototype of the filter is fabricated and measured showing a good agreement between numerically calculated and measured results. Full article

Differentially driven devices represent a highly promising research field for radio frequency (RF), microwave (MW), and millimeter-wave (mmWave) designers and engineers. Designs employing differential signals are essential elements in low-noise fourth-generation (4G) and fifth-generation (5G) communications. Apart from the conventional planar MW components, differential–fed balanced microstrip filters, as promising alternatives, have several advantages, including high common-mode rejection, low unwanted radiation levels, high noise immunity, and wideband harmonic suppression. In this paper, a comprehensive and in-depth review of the existing research on differential-fed microstrip filter designs are presented and discussed with a focus on recent advances in this research and the challenges facing the researchers. A comparison between different design techniques is presented and discussed in detail to provide the researchers with the advantages and disadvantages of each technique that could be of interest to a specific application. Challenges and future developments of balanced microstrip bandpass filters (BPFs) are also presented in this paper. Balanced filters surveyed include recent single-, dual-, tri-, and wide-band BPFs, which employ different design techniques and accomplish different performances for current and future wireless applications. Full article

In this paper, we develop a bandpass filter using a stub-loaded stepped impedance resonator (SLSIR) and calculate the even and odd resonant modes of this type of resonator using the input impedance/admittance analysis. In this study, two impedance ratios and two length ratios are operated as the design parameters for controlling the resonant modes of the SLSIR. Several resonant mode variation curves operating three resonant modes with different impedance ratios and two length ratios are developed. By tuning the desired impedance ratios and length ratios of the SLSIRs, compact ultra-wideband (UWB) bandpass filters (BPFs) can be achieved. Two examples of the UWB BPFs are designed in this study. The first example is UWB filter with a wide stopband and the second one is dual UWB BPF, namely, with UWB performance and a notch band. The first filter is designed for a UWB response from 3.1 to 5.26 GHz having a stopband from 5.3 to 11 GHz, with an attenuation level better than 18 dB. The second filter example is a dual UWB BPF with the frequency range from 3.1 to 5 GHz and 6 to 10.1 GHz using two sets of the proposed SLSIR. The measured results have insertion loss of less than 1 dB, and return loss greater than 10 dB. Furthermore, the coupling structures and open stub of the SLSIR also provide several transmission zeros at the skirt of the passbands for improving the passband selectivity. Full article

The design and implementation of the filters for the fifth-generation (5G) mobile communication systems are challengeable due to the demands of high integration, low-cost, and high-speed data transmission. In this paper, a dual-wideband bandpass filter (BPF) and a tri-wideband BPF for 5G mobile communications are proposed. The dual-wideband BPF consists of two folded open-loop stepped-impedance resonators (FOLSIRs), and the tri-wideband BPF is designed by placing a pair of folded uniform impedance resonator inside the dual-wideband BPF with little increase in the physical size of the filter. By employing a novel structural deformation of a stepped-impedance resonator, the FOLSIR is achieved with a more compact structure, a controllable transmission zero, and an adjustable resonant frequency. The measurement results show that the working bands of the two filters are 1.98–2.28/3.27–3.66 GHz and 2.035–2.305/3.31–3.71/4.54–5.18 GHz, respectively, which are consistent with the full-wave EM simulation results. The implemented filters have a compact size and the results show low loss, good out-of-band rejection, and wide passbands covering sub-6 GHz bands of 5G mobile communications and a commonly used spectrum. Full article

In this paper, an ultra-wideband (UWB) bandpass filter (BPF) with dual notched bands using a T-shaped resonator and L-shaped defected microstrip structure (DMS) is proposed and fabricated. First, the principle of generating notched bands by using a T-shaped resonator and L-shaped defected microstrip structure to determine the size parameters of the structure is analyzed. High frequency structure simulator (HFSS) software is used to analyze the performance of the filter, and advanced design system (ADS) is used to extract the equivalent circuit model parameters. The two simulation results are consistent, which further verifies the correctness of the circuit model. Finally, the filter is fabricated and measured. The measured results are in good agreement with simulated results, demonstrating good insertion loss and return loss. The proposed filter has dual independently controllable notched bands which are implemented by coupling the T-shaped resonator to the transmission line and by etching the L-shaped defected microstrip structure respectively. The proposed filter can suppress dispensable bands at 3.5 GHz and 7.5 GHz in WiMAX band and X-band to improve the performance of the ultra-wideband communication system. By adjusting the parameters of the T-shaped resonator and L-shaped defected microstrip structure, the UWB bandpass filter with dual notched bands working at WiMAX band and X-band can be designed and applied to the wireless communication system. Full article
