This paper investigates a back-electromotive force (EMF) harmonic compensation strategy for six-phase permanent-magnet synchronous motors (PMSMs) to reduce current harmonics and improve system performance. Ideally, the back-EMF waveform should be perfectly sinusoidal. However, manufacturing imperfections such as suboptimal magnetic circuit design, uneven winding distribution, and mechanical eccentricity introduce low-order spatial harmonics, particularly the 5th, 7th, 11th, and 13th orders, which distort the back-EMF, increase current harmonics, complicate control, and reduce efficiency. To address these issues, this study proposes a compensation strategy utilizing common-mode and differential-mode current control. By injecting the 6th and 12th harmonics into the decoupled voltage commands along the d-axis and q-axis, the strategy significantly reduces current harmonic distortion. Experimental validation was conducted using a TMS320F28386D microcontroller, which controlled dual inverters via PWM signals and processed real-time current feedback. Rotor position feedback was provided by a resolver to ensure precise and responsive motor control. At a rotational speed of 900 rpm, with a peak phase current $I_m$ of 200 A and an IGBT switching frequency of 10 kHz, the phase-a current total harmonic distortion (THD) was reduced from 11.86% (without compensation) to 6.83% (with compensation). This study focused on mitigating harmonics below the 14th order. The experimental results demonstrate that the proposed back-EMF harmonic compensation strategy effectively minimizes current THD, highlighting its potential for improving the performance and efficiency of multi-phase motor systems. Full article

This paper presents a highly efficient, low-power, compact mixed-signal sinusoidal current generator (CG) integrated circuit (IC) designed for bioelectrical impedance spectroscopy (BIS) with low total harmonic distortion (THD). The proposed system employs a 9-bit sine wave lookup table (LUT) which is simplified to a 4-bit data stream through a third-order digital delta–sigma modulator (ΔΣM). Unlike conventional analog low-pass filters (LPF), which statically limit bandwidth, the finite impulse response (FIR) filter attenuates high-frequency noise according to the operating frequency, allowing the frequency range of the sinusoidal signal to vary. Additionally, the output of the FIR filter is applied to a 6-bit capacitive digital-to-analog converter (CDAC) with data-weighted averaging (DWA), enabling dynamic capacitor matching and seamless interfacing. The sinusoidal CG IC, fabricated using a 65 nm CMOS process, produces a 5 μA amplitude and operates over a wide frequency range of 0.6 to 20 kHz. This highly synthesizable CG achieves a THD of 0.04%, consumes 19.2 μW of power, and occupies an area of 0.0798 mm². These attributes make the CG IC highly suitable for compact, low-power bio-impedance applications. Full article

The availability of synthetic indicators of the degree and type of nonlinearity in systems is used in various fields to assess system quality or to highlight possible malfunctions. Different distortion or damage indexes are synthetic measures designed (and standardized) to evaluate the frequency trend of specific aspects resulting from the nonlinear behavior of the system under consideration. The different measures of deviation from linear behavior quantitatively consider the system and its nonlinearity characteristics; they were defined according to practically feasible measurement methodologies and the various aspects of the system’s nonlinearity that needed to be highlighted. In parallel, techniques for representing and modeling nonlinear systems have been defined, capable of describing the system in a more general way, attempting to capture its input–output characteristics by varying the level of stress to which the system is subjected. Numerous modeling techniques have been proposed, aimed at representing the nonlinear behavior of physical devices. In this paper, after an extensive description of the Hammerstein model identification technique based on swept sinusoidal signals, we show how the nonlinear model of the system can be used to obtain accurate estimates of the parameter aimed at describing the nonlinearity characteristics of the system. This extensive description makes it possible to point out that the same Hammerstein model can be obtained not only from a single type of excitation, but it is shown that the identification technique can be extended to input signals of different types. The description of the method also makes clear the motivation behind the introduction of the proposed original technique for estimating, from a single measurement, the model parameters of the nonlinear system—and from these the synthetic estimators—relative to multiple values of the input signal amplitude, thus enabling a considerable increase in the estimation efficiency of these parameters. The proposed technique is verified with both synthetic and laboratory experiments, demonstrating the effectiveness of the method in evaluating nonlinear system parameters, distortion estimates, and parameters defined for an early detection of defects of the structure. Full article

When analyzing vibration or acoustic signals in machinery, noise interference within the characteristic signals can significantly distort the results. This issue is particularly pronounced in complex environments, where mechanical signals are often overwhelmed by noise, making it extremely difficult or even impossible to determine the operational status of mechanical equipment by the analysis of characteristic signals. Existing methods for analyzing weak signals in the presence of strong Gaussian noise have limitations in their effectiveness. This paper proposes an innovative approach that utilizes a Variable-Step Gaussian-Sinusoidal Filter (VSGF) combined with rotational coordinate transformation to extract weak signals from strong noise backgrounds. The proposed method improves noise reduction capabilities and frequency selectivity, showing significant improvements over traditional Gaussian filters. Experimental validation demonstrates that the signal detection accuracy of the proposed method is 10–15% higher than that of conventional Gaussian filters. This paper presents a detailed mathematical analysis, experimental validation, and comparisons with other methods to demonstrate the effectiveness of the proposed approach. Full article

In the inverter circuit, the speed at which the MOSFET is impacted by the presence of a parasitic inductor within the printed circuit board (PCB) leads to a delay in the switching process. Furthermore, the parasitic inductor within the circuit can easily form an LC oscillation with the parasitic capacitor of the MOSFET. These two issues result in an inconsistency between the actual output of the MOSFET and the driving signal waveform, leading to distortion in the sinusoidal pulse width modulation (SPWM) waveform and an increase in total harmonic distortion (THD). It is a common practice to mitigate gate oscillation by introducing a resistor at the gate of the MOSFET. However, elevating the resistance leads to deceleration in the charging process of the MOSFET’s parasitic capacitor, consequently causing an increase in the switching delay, and thereby increasing THD. Therefore, an effective strategy to reduce THD is proposed in this paper, while augmenting the gate resistance, computing the MOSFET switching delay, and applying corrective compensation. In this way, the inherent issues of the switch are addressed, resulting in inverter output waveforms that closely resemble sine waves and reduced THD. Through a combination of simulation and empirical experimentation, the efficacy of the proposed approach in significantly reducing THD in the inverter’s output waveform has been empirically substantiated. Full article

The paper proposes an innovative model able to predict the output signals of resistance and capacitance (RC) low-pass filters for machine-controlled systems. Specifically, the work is focused on the analysis of the parametric responses in the time- and frequency-domain of the filter output signals, by considering a white generic noise superimposed onto an input sinusoidal signal. The goal is to predict the filter output using a black-box model to support the denoising process by means of a double-stage RC filter. Artificial neural networks (ANNs) and random forest (RF) algorithms are compared to predict the output of noisy signals. The work is concluded by defining guidelines to correct the voltage output by knowing the predictions and by adding further RC elements correcting the distorted signals. The model is suitable for the implementation of Industry 5.0 Digital Twin (DT) networks applied to manufacturing processes. Full article

The main contribution of this paper is to present a simple algorithm that theoretically and numerically assesses the switching angles of an inverter operated with the SPWM technique. This technique is the most widely used for eliminating harmonics in DC-AC converters for powering motors, renewable energy applications, household appliances, etc. Unlike conventional implementations of the SPWM technique based on the analog or digital comparison of a sinusoidal signal with a triangular signal, this paper mathematically performs this comparison. It proposes a simple solution to solve the transcendental equations arising from the mathematical analysis numerically. The technique is validated by calculating the total harmonic distortion (THD) of the generated signal theoretically and numerically, and the results indicate that the calculated angles produce the same distribution of harmonics calculated analytically and numerically. The algorithm is limited to single-phase inverters with unipolar SPWM. Full article

The growth of renewables in public energy networks requires suitable strategies to assess the stable operation of the respective power electronic devices, e.g., inverters. Different assessment methods can be performed with regard to the available knowledge and the assessment objective, e.g., a specific frequency range or the input signal characteristics that are typically classified into small-signal and large-signal disturbances. This paper addresses the limits of the measurement-based small-signal stability analysis in the harmonic frequency range of commercially available single-phase inverters for photovoltaic applications. The harmonic stability is analyzed, and the results for a sinusoidal background voltage and distorted background voltages are assessed based on measurements. The measurements prove that even in the harmonic frequency range, the harmonic stability analysis can only provide a sufficient but not a necessary condition in terms of the statement towards an instable operation. Full article

High-resolution multi-channel digitizers are used extensively for precision low voltage measurements in numerous applications and allow the simultaneous measurement of voltage magnitude ratio and phase difference between two different waveforms in power system applications. Delta–sigma-based analog-to-digital conversion enables the use of sampling frequencies in the range of megahertz, which provides accurate measurement bandwidths for transformed high-frequency, high-voltage signals. With the increased use of power electronic converters contributing to high-frequency harmonic emissions in power systems, there is a growing interest in developing calibration systems to measure voltage ratio and phase difference of distorted fundamental frequency waveforms consisting of superimposed, high-frequency harmonics. However, information regarding the accuracy of the high-resolution digitizers in the measurement of distorted voltage waveforms is limited as characterization is typically performed under sinusoidal voltage waveform conditions. This paper presents the details of the accuracy characterization of a 24-bit resolution digitizer under both sinusoidal and distorted waveform conditions for measuring complex voltage ratio and phase error for frequencies up to 10 kHz. The detailed experimental results and the measurement uncertainty evaluations show that increased voltage ratio and phase difference errors should be allocated when these high-resolution digitizers are used to measure distorted voltage waveforms. The estimated expanded uncertainties of complex voltage ratio measurement and phase error measurement for harmonic frequencies up to 10 kHz are ±260 ppm and ±100 µrad, respectively. Full article

In various applications, multiscale entropy (MSE) is often used as a feature to characterize the complexity of the signals in order to classify them. It consists of estimating the sample entropies (SEs) of the signal under study and its coarse-grained (CG) versions, where the CG process amounts to (1) filtering the signal with an average filter whose order is the scale and (2) decimating the filter output by a factor equal to the scale. In this paper, we propose to derive a new variant of the MSE. Its novelty stands in the way to get the sequences at different scales by avoiding distortions during the decimation step. To this end, a linear-phase or null-phase low-pass filter whose cutoff frequency is well suited to the scale is used. Interpretations on how the MSE behaves and illustrations with a sum of sinusoids, as well as white and pink noises, are given. Then, an application to detect attentional tunneling is presented. It shows the benefit of the new approach in terms of p value when one aims at differentiating the set of MSEs obtained in the attentional tunneling state from the set of MSEs obtained in the nominal state. It should be noted that CG versions can be replaced not only for the MSE but also for other variants. Full article

This paper presents a multiple-input fully differential operational transconductance amplifier (MI-FD OTA) with very low power consumption. To obtain a differential MOS pair with minimum supply voltage and minimum power consumption, the multiple-input bulk-driven MOS transistor operating in the subthreshold region is used. To show the advantage of the MI-FD OTA, a fifth-order Chebyshev filter was used to realize a low-pass filter capable of operating with a supply voltage of 0.5 V and consuming 60 nW at a nominal setup current of 3 nA. The proposed filter uses five MI-FD OTAs and five capacitors. The total harmonic distortion (THD) was 0.97% for a rail-to-rail sinusoidal input signal. The MI-FD OTA and the filter application were designed and simulated in the Cadence environment using a 0.18 µm CMOS process from TSMC. The robustness of the design was confirmed by Monte Carlo analysis and process, voltage, and temperature corner analysis. Full article

A sinusoidal phase modulation laser interferometer is proposed to detect water surface acoustic waves excited by underwater acoustic radiation, and an improved PGC-Arctan demodulation algorithm that combines prenormalization and Lissajous ellipse fitting is proposed to demodulate detection signals. In this paper, the effects of phase modulation depth, carrier phase delay, and interference signal visibility on the Lissajous figure formed by quadrature interference components are analyzed. The demodulation algorithm first uses the amplitudes of multiple Fourier spectral components of an interference signal to calculate the phase modulation depth C, and calculation of the carrier phase delay V_c is achieved through the introduction of a quadrature carrier signal. Then, certain coefficients regarding C and V_c are constructed for prenormalization of the two quadrature interference signal components to eliminate the local nonuniform widening phenomenon of Lissajous ellipse. Next, the outer and the inner contours are extracted from a uniformly widened Lissajous ellipse resulting from light intensity disturbance, and the axial ratio of the ellipse is obtained, which is used to correct the ratio of the quadrature interference signal to eliminate the effect of filter gain coefficients. At last, through the combination of an Arctan algorithm and a phase-unwrapping algorithm, high-precision demodulation of the interference signal is realized. A sinusoidal phase modulation interferometer was set up to detect water surface acoustic waves, and a series of detection experiments were carried out. The experiment results show that the detection method and demodulation algorithm described in this paper can accurately realize the measurement of weak water surface acoustic waves. The proposed algorithm shows less distortion in demodulation results, and its signal-to-noise distortion ratio is less than 20 dB at 500 Hz, which is significantly better than traditional algorithms. The experimental results demonstrate the effectiveness and accuracy of water surface acoustic wave detection using sinusoidal phase modulation interferometer. Full article

In this paper, a type of co-excitation axial reluctance resolver (CARR) in different winding modes is taken as the simulation model. Detailed explanations have been provided on its stator, rotor, and windings. Simultaneously, an introduction was made to the distribution of two types of signal winding modes. The influence of three kinds of eccentricity on the output characteristics of this CARR during installation and fabrication is also studied. According to two kinds of signal winding modes, the variation law of waveform and amplitude of output potential is analyzed under the conditions of stator radial eccentric distance in different eccentric directions, rotor radial eccentric distance in different eccentric directions and rotor axial offset, and the influence of three factors on total harmonic distortion (THD) is analyzed further. Under the conditions of different eccentricities and offset, a prototype of 15 pair pole CARRs in the mode of sinusoidal windings is tested. The function errors of the signal windings under conditions of radial eccentricity of the stator, radial eccentricity of the rotor and axial offset of the rotor were measured separately. The variation rule of error was compared between measurement and simulation. The correctness of the finite element simulation results under three different eccentricity conditions was verified. The verification results provide theoretical support for further optimization of structural parameters and the installation of the stator and rotor, which can improve measurement accuracy. Full article

A single-phase five-level T-type topology has been investigated in this article. This topology has emerged as a viable option for renewable energy systems (RES) due to its inherent benefits. The finite control set model predictive control (FCS-MPC) strategy has been implemented to this topology in order to improve the performance and overall reliability of the system. This control strategy empowers the inverter to predict future behavior based on a discrete set of control signals, enabling precise modulation and high-speed response to system dynamics. In the realm of RES, integration of FCS-MPC with multilevel inverters (MLIs) holds great potential to enhance energy conversion efficiency, grid integration, and overall system reliability. The article is structured to present an overview of the evolving landscape of power electronic systems, and the advantages of FCS-MPC. This paper provides a comprehensive analysis of the FCS-MPC control strategy applied to the single-phase five-level T-type topology. The study covers various aspects including the theoretical framework, hardware development, and experimental evaluation. It is obvious from the analysis that this inverter topology is reliable. Several redundant states make it fault-tolerant which helps in maintaining the output voltage at the same level even in the fault conditions. Additionally, the results show that the output load voltage is maintained at the same level irrespective of load change. Also, output load voltage has maintained the high-quality sinusoidal characteristics as the total harmonic distortion (THD) is very low. With all these features, this system is suitable within the framework of RES. Full article

The key goal of this effort is to develop an efficient control system for a three-phase cascaded H-bridge multilevel inverter powered by the photovoltaic (PV) system. The power for the system is generated through the use of PV modules, which serve as DC inputs for the cascaded H-bridge multilevel inverter. The authors aim to achieve a nearly sinusoidal signal at the voltage level and are specifically focused on minimizing the total harmonic distortion (THD) to the smallest possible value. Hence, an advanced N-level space vector modulation (SVM) is developed to ensure an appropriate control for the cascaded inverter. The aim is to design an effective control strategy to increase inverter efficacy and, thus, supply the best output quality. In addition, a robust approach to the maximum power point (MPP) tracking (MPPT) technique is developed based on an adaptive perturb and observe (P&O) algorithm to ensure superior tracking of the MPP. The developed algorithm eliminates 90% of the power curve area in the search space process and only maintains 10% of the area that includes the MPP. Each PV system employs its own improved MPPT control. The numerical results confirm that the enhanced P&O algorithm attains a precise response with superior efficiency and a fast response under the fast alteration of environmental conditions. Hence, the energy loss is reduced. The simulation results validate the effectiveness of this study, highlighting the high efficiency of the control strategy and the enhanced performance of the proposed scheme with lesser THD values. Full article
