Crosstalk is an undesirable factor that degrades the quality of data transmission in printed circuit boards (PCBs). The signal integrity (SI) in multiconductor transmission lines is controlled by using a large number of multiport tests and measurements, which require a lot of time and expensive laboratory equipment. Proposed signal processing methods based on blind identification allow a reduction in the measurement burden. Contrary to the traditional approach requiring knowledge of sampling time offset, input pseudorandom bit sequence (PRBS), and time delay between received data and transmitted PRBS, the proposed alternative method performs blind separation of measured data for the linear fit pulse response (LFPR) procedure. The waveform identification of the partial pulse responses is evaluated for additively mixed cyclostationary sources of the data, intersymbol interference, and crosstalk. A mixed matrix model of composed random vectors is considered. The proposed estimation procedure is based on preprocessing of measured data using principal component analysis (PCA) and following independent component analysis (ICA). It is shown that the proposed component analysis allows diagnostics of signal integrity using eye-diagram patterns and the channel operating margin (COM). Full article

In this paper, a comparison of signal analysis techniques for the diagnostics of rolling element bearings is carried out. Specifically, the comparison is performed in terms of fault detection, diagnosis and prognosis techniques with regards to the first rolling element bearing dataset released by NASA IMS Center in 2014. As for fault detection, it is obtained that RMS value, Kurtosis and Detectivity, as statistical parameters, are able to properly detect the arising of the fault on the defective bearings. Then, several signal processing techniques, such as deterministic/random signal separation, time-frequency and cyclostationary analyses are applied to perform fault diagnosis. Among these techniques, it is found that the combination of Cepstrum Pre-Whitening and Squared Envelope Spectrum, and Improved Envelope Spectrum, allow the faults to be correctly identified on specific bearing components. Finally, the Correlation, Monotonicity and Robustness of the previous statistical parameters are computed to identify the most accurate tools for bearing fault prognosis. Full article

This article addresses the problem of estimating the spectral correlation function (SCF), which provides quantitative characterization in the frequency domain of wide-sense cyclostationary properties of random processes which are considered to be the theoretical models of observed time series or discrete-time signals. The theoretical framework behind the SCF estimation is briefly reviewed so that an important difference between the width of the resolution cell in bifrequency plane and the step between the centers of neighboring cells is highlighted. The outline of the proposed double-number fast Fourier transform algorithm (2N-FFT) is described in the paper as a sequence of steps directly leading to a digital signal processing technique. The 2N-FFT algorithm is derived from the time-smoothing approach to cyclic periodogram estimation where the spectral interpolation based on doubling the FFT base is employed. This guarantees that no cyclic frequency is left out of the coverage grid so that at least one resolution element intersects it. A numerical simulation involving two processes, a harmonic amplitude modulated by stationary noise and a binary-pulse amplitude-modulated train, demonstrated that their cyclic frequencies are estimated with a high accuracy, reaching the size of step between resolution cells. In addition, the SCF components estimated by the proposed algorithm are shown to be similar to the curves provided by the theoretical models of the observed processes. The comparison between the proposed algorithm and the well-known FFT accumulation method in terms of computational complexity and required memory size reveals the cases where the 2N-FFT algorithm offers a reasonable trade-off. Full article

This work is devoted to the procedure for constructing of a cyclically correlated random process of a continuous argument as a mathematical model of cyclic signals in dynamic systems, which makes it possible to consistently describe cyclic stochastic signals, both with regular and irregular rhythms, not separating them, but complementing them within the framework of a single integrated model. The class of cyclically correlated random processes includes the subclass of cyclostationary (periodically) correlated random processes, which enable the use of a set of powerful methods of analysis and the forecasting of cyclic signals with a stable rhythm. Mathematical structures that model the cyclic, phase and rhythmic structures of a cyclically correlated random process are presented. The sufficient and necessary conditions that the structural function and the rhythm function of the cyclically correlated random process must satisfy have been established. The advantages of the cyclically correlated random process in comparison with other mathematical models of cyclic signals with a variable rhythm are given. The obtained results contribute to the emergence of a more complete and rigorous theory of this class of random processes and increase the validity of the methods of their analysis and computer simulation. Full article

It is shown that the models of gear pair vibration, proposed in literature, are particular cases of the bi-periodically correlated random processes (BPCRPs), which describe its stochastic recurrence with two periods. The possibility of vibration and analysis within the framework of BPCRP approximation, in the form of periodically correlated random processes (PCRPs), is grounded and the implementation of vibration processing procedures using PCRP techniques, which are worked out by the authors, is given. Searching for hidden periodicities of the first and the second orders was considered as the main issue of this approach. The estimation of the non-stationary period (basic frequency) allowed us to carry out a detailed analysis of the deterministic part, the covariance structure of the stochastic part, and to form, using their parameters, the sensitive indicators for fault detection. The results of the processing of the wind turbine gearbox vibration signals are presented. The amplitude spectra of the deterministic oscillations and the time changes of the stochastic part power for different fault stages are analyzed. The most efficient indicators, which are formed using the amplitude spectra for practical applications, are proposed. The presented approach was compared with known in literature cyclostationary analysis and envelope techniques, and its advantages are shown. Full article

The theoretical and experimental evaluation of the cyclostationary random data transferring process corrupted by the individually and jointly cyclostationary crosstalk interference is presented. The interference and the message signals were measured by the real time digital oscilloscope. Autocorrelation functions were evaluated by synchronous cyclic averaging procedure. The analyzed periodic two-dimensional impulse response of the time-varying filter allows to obtain the output random process with the same cyclic frequency at the output of the filter by separation of orthogonal stationary waveforms constituting the input cyclostationary random process (CSRP). The filtering of the measured random process was implemented by the cyclic Wiener filter. The evaluation of the two-dimensional autocorrelation function and eye diagrams at the output of the cyclic Wiener filter showed significant reduction of the independent interference components in the estimated message signal. Full article

Non-contact detection and estimation of vital signs such as respiratory and cardiac frequencies is a powerful tool for surveillance applications. In particular, the continuous wave bio-radar has been widely investigated to determine the physiological parameters in a non-contact manner. Since the RF-reflected signal from the human body is corrupted by noise and random body movements, traditional Fourier analysis fails to detect the heart and breathing frequencies. In this effort, cyclostationary analysis has been used to improve the radar performance for non-invasive measurement of respiratory rate and heart rate. However, the preliminary works focus only on one frequency and do not include the impact of attenuation and random movement of the body in the analysis. Hence in this paper, we evaluate the impact of distance and noise on the cyclic features of the reflected signal. Furthermore, we explore the assessment of second order cyclostationary signal processing performance by developing the cyclic mean, the conjugate cyclic autocorrelation and the cyclic cumulant. In addition, the analysis is carried out using a reduced number of samples to reduce the response time. Implementation of the cyclostationary technique using a bi-static radar configuration at 2.5 GHz is shown as an example to demonstrate the proposed approach. Full article
