Search Results (73)

In recent decades, the automotive industry has faced challenges around improving energy efficiency, reducing pollutant emissions, increasing occupant safety, and reducing production costs. To solve these challenges, it is necessary to reduce the weight of vehicle bodies. In this way, the steel industry has developed more efficient metal alloys. To combine vehicle mass reduction with improved performance in deformations in cases of impact, a new family of advanced steels is present, AHSS (Advanced High-Strength Steels). However, this family of steels has lower formability and greater springback compared to conventional steels; if it is not properly controlled, it will directly affect the accuracy of the product and its quality. Different regions of a stamped component, such as the flange, the body wall, and the punch pole, are subjected to different states of stress and deformation, determined by numerous process variables, such as friction/lubrication and tool geometry, in addition to blank holder force and drawbead geometry, which induce the material to different deformation modes. Thus, it is understood that the degree of work hardening in each of these regions can be evaluated by grain morphology and material hardening, defining critical regions of embrittlement that, consequently, will affect the material’s stampability. This work aims to study the formability of the cold-formed DP600 steel sheets in the die radius region using a Modified Nakazima test, varying drawbead geometry, followed by a nanohardness evaluation and material characterization through the electron backscatter diffraction (EBSD). The main objective is to analyze the work hardening in the critical blank regions by applying these techniques. The nanoindentation evaluations were consistent in die radius and demonstrated the hardening influence, proving that the circular drawbead presented the most uniform hardness variation along the profile of the stamped blank and presented lower hardness values in relation to the other geometries, concluding that the drawbead attenuates this variation, contributing to better sheet formability, which corroborates the Forming Limit Curve results. Full article

Reduced Beam Sections (RBS) are used in steel design to promote ductile behavior by shifting inelastic deformation away from critical joints, enhancing seismic performance through controlled energy dissipation. While current design guidelines assist in detailing RBS connections, moment–rotation curves—essential for understanding energy dissipation—require extensive testing and/or modeling. Machine learning (ML) offers a promising alternative for predicting these curves, yet few studies have explored ML-based approaches, and none, to the best of the authors’ knowledge, have applied Explainable Artificial Intelligence (XAI) to interpret model predictions. This study presents an ML framework using Artificial Neural Networks (ANN), Random Forest (RF), Support Vector Machines (SVM), Gradient Boosting (GB), and Ridge Regression (RR) trained on 500 numerical models to predict the moment–rotation backbone curve of RBS connections under cyclic loading. Among all the models applied, the ANN obtained the highest R² value of 99.964%, resulting in superior accuracy. Additionally, Shapley values from XAI are employed to evaluate the influence of input parameters on model predictions. The average SHAP values provide important insights into the performance of RBS connections, revealing that cross-sectional characteristics significantly influence moment capacity. In particular, flange thickness (t_f), flange width (b_f), and the parameter “c” are critical factors, as the flanges contribute the most substantially to resisting bending moments. Full article

Welded joints of tubular flange connections (TFCs) for steel structures are prone to cumulative fatigue breakdown under oscillatory loading regimes. This study investigates the constant-amplitude fatigue performance of these welded connections through combined experimental testing and finite element analysis. Seven tubular flange connection specimens were subjected to constant-amplitude fatigue tests, and the nominal stress range approach was employed to establish S-N curves for the TFC welds, which were then compared with existing design codes. Stress concentration behavior at the weld toe was analyzed using ABAQUS finite element software. Macro- and micro-scale examinations of fatigue fracture surfaces were conducted to elucidate the fatigue crack mechanisms. The results demonstrate an allowable stress range of 82.41 MPa at a 2-million-cycle fatigue strength, exceeding the specifications of current fatigue design codes. The finite element analysis shows that there is a significant stress concentration at the weld toe of the steel tube–flange weld, and the uneven stress distribution in the circumferential direction of the weld makes this position more prone to fatigue failure, which is consistent with the experimental phenomena. The derived fatigue design method for TFCs provides practical guidance for engineering applications. Full article

The finite-element model was developed using ABAQUS to investigate the hysteretic properties of space joints. This study examined the effects of axial compression ratio, T-plate stiffness, column wall thickness, and bolt-preload on the joint’s hysteretic behavior. The model was verified by comparing the failure modes, hysteresis curves, and skeleton curves of the specimens with the test results of the relevant literature, ensuring the reliability of the research. The results reveal three primary failure modes: beam flange buckling, T-plate buckling, and column-wall buckling; increasing the thickness of the T-plate web or column wall significantly enhances joint stiffness and mitigates brittle failure. Specifically, the stiffness of T-plate 1 has a substantial impact on joint performance, and it is recommended that its web thickness be no less than 18 mm. In contrast, variations in the thickness of T-plate 2 have negligible effects on seismic performance. Increasing the column wall thickness improves the bearing capacity and stiffness of the joint, with a recommended minimum thickness of 12 mm, which should not be less than the flange thickness of the steel beam. While an increase in the axial compression ratio reduces the bearing capacity and stiffness, it enhances the energy dissipation capacity and ductility of the joint. Notably, variations in bolt-preload were found to have minimal influence on joint performance. These findings provide valuable insights for optimizing the design of unilateral bolted joints in steel structures to improve seismic resilience. Full article

To solve the problems of numerous influencing factors, such as the high uncertainty and leakage risk of gas production pipelines in high-sulfur gas fields, a dynamic analysis of a gas production pipeline’s leakage risk using a dynamic Bayesian network is proposed. By means of Bow-tie model analysis, the primary risk sources of gas pipeline leakage and different accidents are summarized. A temporal dimension was introduced to construct a dynamic Bayesian network model, utilizing the Leaky noisy-OR gate model to rectify and compute conditional probability, thereby facilitating dynamic risk prediction of gas pipeline leakage. Taking the first section of the pipeline of a municipal gas collection station as an example, with the help of GeNIe 4.0 Academic software, the influence degree of each basic event on pipeline gas leakage was revealed. The change curve of gas leakage probability over time was drawn, and the occurrence probability of potential consequences of accidents was computed. The results indicate that the status of flanges, valves, and pipelines are key factors in determining the occurrence of gas leakage accidents, and six risk sources, including medium corrosion in gas leakage accidents, were determined, with these having practical conspicuousness for strengthening the leakage protection of gas pipelines and providing proper support for the formulation of relevant safety measures. Full article

Steel traditional Chinese buildings (STCBs) are constructed using modern materials, replicating the esthetics of ancient Chinese buildings, but their irregular joints differ significantly from those in conventional steel structures. To investigate the influence of beam section shape and axial compression ratio on the failure mode and shear resistance of all-welded irregular joints (WIJs) in STCBs, the size proportion relationships in the traditional Chinese modular construction system for such joints in existing practical projects are analyzed. Four exterior joint specimens were designed and fabricated for pseudo-static loading tests. The failure mode, hysteresis curve, and skeleton curve of the specimens were obtained. The test results indicate that the failure mode of the specimens involves shear deformation in the lower core area, with final failure due to crack formation in the weld at the junction between the column wall and the beam flange. As the axial compression ratio increases, the bearing capacity of the joint decreases. Based on the test results, the numerical model was established by using finite element software Abaqus2016, and parameter analysis was performed by varying the axial compression ratio of the column. After analyzing the force transfer mechanism of the core area in the WIJs of STCBs, a simplified calculation formula for the shear bearing capacity of the core area was derived based on the proportional relationship outlined in the construction manual from the Song Dynasty. The calculated results show good agreement with the experimental results, providing a basis for the structural design of WIJs in STCBs. Full article

In its duration of service, Bailey truss is commonly exposed to corrosion threats due to the failure of anti-corrosion coatings, resulting in corrosion damage to its steel members and degradation of its structural performance. There is a lack of research on the degradation of the material properties of Bailey truss due to natural corrosion. This paper investigated the degradation of a Bailey truss that had been in service for eight years, in northeast China. Tensile tests were carried out on corroded specimens from three truss members (the chords, diagonals, and verticals), to establish regression equations for the minimum residual cross-sectional rate and several material properties of four parts (chord flange, chord web, diagonal web, and vertical web). The equations were compared with the degradation of steel properties with different yield strengths, cross-sectional shapes, and corrosion types. Fitting formulas for the true constitutive models of the four parts of non-corroded and corroded specimens were developed. It was found that the diagonal truss member was the most severely affected by corrosion, while the chord web was the least impacted. The degradation trend of 80% in regard to natural corrosion specimens is lower than that of the Bailey truss diagonal web and the degradation trend in terms of the yield strength and ultimate strength in the same part is less than 5%. According to the Ramberg–Osgood model, the multi-curve constitutive model fitting formulas are suitable for four parts of naturally corroded Bailey truss. Full article

Steel structure flange connections are extensively employed in structural nodes due to their superior mechanical properties. This study combines fatigue testing and theoretical methods to investigate the fatigue performance of high-strength bolts in flange connections under actual gradient descent loads and provide fatigue design methods. Initially, fatigue tests were conducted on two sets of high-strength bolts under a gradient descent loading mode, yielding a total of 11 sets of fatigue data. Subsequently, the stress–life (S-N) curve was plotted using a cumulative damage model combined with an equivalent constant amplitude stress method, and the results were compared with existing fatigue design specifications. Additionally, digital cameras and electron microscopes were utilized to capture fatigue fracture images of the high-strength bolts, allowing a detailed investigation into the mechanisms underlying bolt fatigue fractures. The results indicate that the allowable stress amplitudes for the two sets of high-strength bolts, corresponding to a fatigue life threshold of 2 million cycles, were 144.211 MPa and 130.316 MPa, respectively—both of which exceed the values specified in current fatigue design codes. Moreover, finite element simulations revealed that the most pronounced stress concentration occurs at the first thread where the bolt and nut interface, which is identified as the critical location for fatigue fracture in bolts. The allowable stress and fatigue calculation method of bolts obtained in this study will provide a reference for flange node design Full article

To facilitate the disassembly and recycling of structural components, this study proposes a novel demountable reinforced-concrete column–steel beam (RCS) joint. Numerical simulations were conducted to analyze the performance of this new RCS joint using finite element software ABAQUS 2021. Simultaneously, to expand the parametric analysis of the finite element model, further validating aspects such as concrete strength, the flange strength of the steel beam, the strength of the gusset plates, and the longitudinal reinforcement ratio were studied. The finite element analysis results demonstrate that the proposed demountable RCS joint exhibits superior bearing capacity and ductility compared to conventional cast-in-place joints. To further investigate the seismic behavior and influencing rules of this joint, analyses were carried out focusing on aspects such as hysteresis curves, skeleton curves, ductility, energy dissipation, residual deformations, and strength degradation. The findings reveal that gusset plate strengths, steel beam strength, beam-end connecting plate strength, longitudinal reinforcement ratio, and concrete strength have significant impacts on the strength and failure modes of the RCS joints. In addition, the life cycle analysis of four different material structures shows that the demountable RCS joints have the smallest carbon emission during the life cycle, which is conducive to the reuse of resources. Finally, the development of demountable RCS joints is proposed for China’s construction industry. Full article

For wide flange box sections, conventional Euler–Bernoulli beam theory with maintaining the cross-section planarity may lead to underestimation of axial stresses. Axial stresses in cross-section flanges may have a non-uniform distribution due to shear pliability, decreasing in value from the flange–web junction to the middle area of the flange. This phenomenon leads to the introduction of an effective flange width with a uniform distribution of original maximum stress. Furthermore, the introduction of flange curvature makes it even more complex due to the varying lever arm of each flange part with respect to the neutral bending axis. Because of this, in some cases, it is hard to predict where the flange’s highest normal stress value will appear. In this paper, the shear lag effect on wide curved box sections is analyzed through parametric numerical analysis using the FEA software Dlubal RFEM 5, together with visual programming performed in Rhino Grasshopper. This study investigates the interaction of the shear lag effect and plane section hypothesis, which can be simplistically represented as a reduction in the impact of shear lag and the activation of a larger part of the flange of a wide-flange beam in the structural system of a continuous beam. The results suggest that for higher flange curvature and higher width to length ratio, this effect is more prominent. Full article

Sealing rings are the core components of flange sealing structures and play a crucial role in the storage and operation of gas generators. The aging and deformation of seals affect the safe operation of the device. This paper aims to investigate the effect of rubber aging on the sealing performance of the components, which is realized by nonlinear finite element analysis. Firstly, an accelerated degradation test method was used to obtain the compression permanent deformation and stress–strain curve of rubber during the aging process. A two-dimensional finite element model of the sealing structure was constructed and the Yeoh model was utilized to describe the mechanical response of rubber. During the simulation, the contact area was modified based on the compression permanent deformation, and the Yeoh model was updated based on the stress–strain curve changes obtained by the test. The impact of key parameters such as material property changes, rubber physical section deformation, and fluid pressure on sealing performance during the seal ring aging process was systematically studied. The numerical results indicate that due to the aging deformation of rubber seals, there is a significant decrease in contact stress and contact width, as well as a shift in maximum equivalent stress area. Taking into account these findings, this study proposes a new design concept for sealing structures. This provides a relatively simple research method for studying flange sealing structure performance. Full article

To investigate the seismic behavior of composite columns with high-strength concrete-filled steel tube flanges and honeycomb steel webs (STHHC) after being subjected to freeze-thaw cycles, 36 full-scale STHHCs were designed with the following main parameters: the shear span ratio (λ_s), the axial compression ratio (n₀), the number of freeze-thaw cycles (N_c), the concrete cubic compression strength (f_cu), and the steel ratio of the section (α_s). Compared with existing experimental data, the validity of the finite element modeling method was verified. Parameter analysis was conducted on 36 full-scale STHHCs to obtain the hysteresis curve of the composite columns and to clarify the impact of the different parameters on the skeleton curve, the energy dissipation capacity, the stiffness degradation, and the ductility of the composite columns. The results showed that the hysteresis curves of all specimens after freeze-thaw cycles exhibited an ideal shuttle shape, reflecting that this kind of composite column has good energy dissipation ability and freeze-thaw resistance. The specimens’ maximum bulging deformation and maximum stress both occurred at the column base. Finally, the restoring force model of this kind of composite column is therefore established, and design recommendations based on these results are proposed. Full article

This paper introduces a modular, assembled steel beam-column flange connection joint that efficiently connects prefabricated beams and columns using high-strength bolts. It enables the rapid repair of damaged joints after earthquakes by replacing flange connectors and high-strength bolt groups. Four joint specimens with varying thicknesses and lengths of the inner flange sleeve, scaled at a 1:2 ratio, were fabricated to evaluate performance. These specimens were subjected to low circumferential reciprocal loads to investigate damage modes, hysteresis curves, skeleton curves, ductility performance, energy dissipation capacity, and seismic performance, including stiffness degradation. The test and analysis results reveal that the primary failure mode is characterized by bulging of the flange jacket cover, with damage concentrated in the plastic hinge zone at the beam end. The flange connection joint exhibits excellent load-bearing, rotational, and energy dissipation capacities. The ‘secondary strengthening’ feature significantly enhances joint load-bearing capacity, ductility performance, and energy dissipation, increasing overall safety redundancy. Increasing the thickness and length of the flange connector substantially improves seismic performance and enlarges the plastic development area. Full article

The assembled corrugated steel initial support structure is a new prefabricated structure in highway tunnel engineering, achieving a balance between economy and safety. This study proposes a simplified calculation method and elucidates the mechanical mechanisms of assembled corrugated steel initial support structures. Firstly, the stiffness characteristics of corrugated steel plates were studied based on full-scale tests. A general equivalent stiffness coefficient table was established. Numerical simulations of corrugated steel flange joints were conducted to explore their bending mechanical properties. A two-stage rotational stiffness model for corrugated steel flange joints was proposed. Finally, a plane strain-spring simplified calculation method for the assembled corrugated steel initial support structure was developed, and the monitoring data from the Qipanshan Tunnel validated the correctness and reliability of the proposed method. The results demonstrate that (1) the plane strain-spring simplified model consists of the planar strain equivalent calculation method for corrugated steel plates and the two-line stiffness equivalent spring of the corrugated steel flange joint. The simplified model was validated as effective by monitoring data. (2) Corrugated steel plates exhibit two stages under loading, namely gap elimination and elastic stages. The elastic stage stiffness of corrugated steel plates decreases with increasing ratio of depth to pitch (RDP), positively correlating with plate thickness when the RDP exceeds 0.333 and otherwise negatively correlated. (3) Corrugated steel lining flange joints exhibit distinct elastic and plastic stages in their linear moment–rotation curves under loading. Full article

The amplitude of a bolt load in dynamically loaded bolted flange joints depends on several factors: the resilience of the bolt and the clamping parts, the magnitude of the working load, the point of action of the working load, the way the working load is transferred from the structure to the bolt, the preload, and the geometrical imperfections of the contact surfaces of the joint. These factors are analysed in many papers, and they are covered in the VDI 2230 guideline and in standards. Fatigue curves (S-N curves) of bolts are determined by tests in which an ideal axial load is usually applied to the bolts. The effects of the bolt strength class, the thread manufacturing process, the surface protection, and the cross-section size on the fatigue strength of bolts are precisely defined. The main problem in the evaluation of bolted joints is the calculation of the actual stress, which is compared with the fatigue curves. Despite extensive research, fatigue-related bolt failures still occur in practise. This article provides a systematic overview of the influences that affect the fatigue of bolts. The conclusions are based on the research results of many authors and on our own analytical, numerical, and experimental investigations. The effects are illustrated using two practical examples of flange bolting. The assessment of fatigue according to Eurocode 3 and the VDI 2230 guideline is discussed in more detail. Full article
