Search Results (16)

Background/Objectives: Granular cell tumors (GCTs) are rare neurogenic tumors with Schwann cell differentiation. Although most are benign, 1–2% exhibit malignant behavior. The imaging features of GCTs remain poorly characterized due to their rarity and anatomic variability. This study aims to elucidate the manifestations of GCTs in multimodal imaging across different anatomic locations. Methods: We retrospectively analyzed 66 histopathologically confirmed GCT cases (2011–2024), assessing their clinical presentations, pathological characteristics, and imaging findings from ultrasound (n = 31), CT (n = 14), MRI (n = 8), and endoscopy (n = 15). Two radiologists independently reviewed the imaging features (location, size, morphology, signal/density, and enhancement). Results: The cohort (mean age: 42 ± 12 years; 72.7% female) showed tendency in location towards soft tissue (48.4%), the digestive tract (30.3%), the respiratory system (7.6%), the breasts (7.6%), and the sellar region (6.1%). Six cases (9.1%) were malignant. The key imaging findings by modality were as follows: Ultrasound: Well-circumscribed hypoechoic masses in soft tissue (96.1%) and irregular margins in the breasts (80%, BI-RADS 4B) were found. MRI: The sellar GCTs exhibited T1-isointensity, variable T2-signals (with 50% showing “star-like crack signs”), and heterogeneous enhancements. The soft tissue GCTs were T1-hypointense (75%) with variable T2-signals. CT: Pulmonary/laryngeal GCTs appeared as well-defined hypodense masses with mild/moderate enhancements. Endoscopy: Submucosal/muscularis hypoechoic nodules with smooth surfaces were found. Malignant GCTs were larger (mean: 93 mm vs. 30 mm) but lacked pathognomonic imaging features. Three malignant cases demonstrated metastases. Conclusions: GCTs exhibit distinct imaging patterns based on their anatomical location. While certain features (e.g., star-like crack signs) are suggestive, imaging cannot reliably differentiate benign from malignant variants. Histopathological confirmation remains essential to diagnosis, particularly given the potential for malignant transformations (at 9.1% in our series). Multimodal imaging guides the localization and biopsy planning, but clinical–radiological–pathological correlation is crucial for the optimal management. Full article

Ball bearings are one of the most critical components of rotating machines. They ensure shaft support and friction reduction, thus their malfunctioning directly affects the machine’s performance. As a consequence, it is necessary to monitor the health conditions of such a component to avoid major degradations which could permanently damage the entire machine. In this context, HMS (Health Monitoring Systems) and PHM (Prognosis and Health Monitoring) methodologies propose a wide range of algorithms for bearing diagnosis and prognosis. The present article proposes an end-to-end PHM approach for ball bearing RUL (Remaining Useful Life) estimation. The proposed methodology is composed of three main steps: HI (Health Indicator) construction, bearing diagnosis and RUL estimation. The HI is obtained by processing non-stationary vibration data with the MODWPT (Maximum Overlap Discrete Wavelet Packet Transform). After that, a degradation profile is defined and coupled with crack initiation and crack propagation fatigue models. Lastly, a MB-HMM (Hidden Markov Model) is trained to capture the bearing degradation dynamics. This latter model is used to estimate the current degradation state as well as the RUL. The obtained results show good RUL prediction capabilities. In particular, the fatigue models allowed a reduction of the ML (Machine Learning) model size, improving the algorithms training phase. Full article

Bearings are critical components of motors. However, they can cause several issues. Proper and timely detection of faults in the bearings can play a decisive role in reducing damage to the entire system, thereby reducing economic losses. In this study, a hybrid fuzzy V-structure fuzzy fault estimator was used for fault diagnosis and crack size identification in the bearing using vibration signals. The estimator was designed based on the combination of a fuzzy algorithm and a V-structure approach to reduce the oscillation and improve the unknown condition’s estimation and prediction in using the V-structure method. The V-structure surface is developed by the proposed fuzzy algorithm, which reduces the vibrations and improves the stability. In addition, the parallel fuzzy method is used to improve the robustness and stability of the V-structure algorithm. For data modeling, the proposed combination of an external autoregression error, a Laguerre filter, and a support vector regression algorithm was employed. Finally, the support vector machine algorithm was used for data classification and crack size detection. The effectiveness of the proposed approach was evaluated by leveraging the vibration signals provided in the Case Western Reserve University bearing dataset. The dataset consists of four conditions: normal, ball failure, inner fault, and outer fault. The results showed that the average accuracy of fault classification and crack size identification using the hybrid fuzzy V-structure fuzzy fault estimation algorithm was 98.75% and 98%, respectively. Full article

Bearings cause the most breakdowns in induction motors, which can result in significant economic losses. If faults in the bearings are not detected in time, they can cause the whole system to fail. System failures can lead to unexpected breakdowns, threats to worker safety, and huge economic losses. In this investigation, a new approach is proposed for fault diagnosis of bearings under variable low-speed conditions using a smooth sliding digital twin analysis of indirect acoustic emission (AE) signals. The proposed smooth sliding digital twin is designed based on the combination of the proposed autoregressive fuzzy Gauss–Laguerre bearing modeling approach and the proposed smooth sliding fuzzy observer. The proposed approach has four steps. The AE signals are resampled and the root mean square (RMS) feature is extracted from the AE signal in the first step. To estimate the resampled RMS bearing signal, a new smooth sliding digital twin is proposed in the second step. After that, the resampled RMS bearing residual signal is generated using the difference between the original and estimated signals. Next, a support vector machine (SVM) is proposed for crack detection and crack size identification. The effectiveness of this new approach is evaluated by AE signals provided by our lab’s bearing dataset, where the benchmark dataset consists of one normal and seven abnormal conditions: ball, outer, inner, outer-ball, inner-ball, inner-outer, and inner-outer-ball. The results demonstrated that the average accuracies of the anomaly diagnosis and crack size identification of AE signals for the bearings used in this new smooth sliding digital twin are 97.75% and 97.78%, respectively. Full article

Gearboxes are frequently used in the mining industry, especially for power transmission between the electric drive and the ball mill; besides the extreme complexity of a ball mill gear transmission system, the fault diagnosis by vibration analysis can be easily distorted by the presence of impulsive noises due to the ball pulses on the mill shell. Although several works in the literature are related to the influence of an impulsive noise on the accuracy of the diagnosis, no dynamic model exists yet in the literature that can explain the influence of these forces on the dynamic behavior of gearboxes. This paper presents a new approach to determine the influence of the grinding forces in crack defects diagnosis. This approach is based on a hybrid numerical model of a 24-degree-of-freedom gearbox, simulating one gear train and two drive shafts. The impact forces of the mill drum are modelled by a discrete element method (DEM). The ball-filling rate ($F_r$), the mill speed ($N_r$), and the ball size ($D_b$) are considered to study this phenomenon. The simulations results show by a time series representation, fast Fourier transform, and short-time Fourier transform (STFT), that the acceleration is significantly affected by the presence of the grinding forces, developing an impulsive noise due to the impact of the balls governed by the studied parameters. Full article

This study experimentally investigates vibration-based approaches for fault diagnosis of automotive gearboxes. The primary objective is to identify methods that can detect gear-tooth cracks, a common fault in gearboxes. Vibrational signals were supervised on a gearbox test rig under different operating conditions of gears with three symmetrical crack depths (1, 2, and 3 mm). The severity of the gear-tooth cracks was predicted from the vibrational signal dataset using an artificial feedforward multilayer neural network with backpropagation (NNBP). The vibration amplitudes were the greatest when the crack size in the high-speed shaft was 3 mm, and the root mean square of its vibration speed was below 3.5 mm/s. The vibration amplitudes of the gearbox increased with increasing depth of the tooth cracks under different operating conditions. The NNBP predicted the states of gear-tooth cracks with an average recognition rate of 80.41% under different conditions. In some cases, the fault degree was difficult to estimate via time-domain analysis as the vibration level increases were small and not easily noticed. Results also showed that when using the same statistical features, the time-domain analysis can better detect crack degree compared to the neural network technique. Full article

Bearings are nonlinear systems that can be used in several industrial applications. In this study, the combination of a strict-feedback backstepping digital twin and machine learning algorithm was developed for bearing crack type/size diagnosis. Acoustic emission sensors were used to collect normal and abnormal data for various crack sizes and motor speeds. The proposed method has three main steps. In the first step, the strict-feedback backstepping digital twin is designed for acoustic emission signal modeling and estimation. After that, the acoustic emission residual signal is generated. Finally, a support vector machine is recommended for crack type/size classification. The proposed digital twin is presented in two steps, (a) AE signal modeling and (b) AE signal estimation. The AE signal in normal conditions is modeled using an autoregressive technique, the Laguerre algorithm, a support vector regression technique and a Gaussian process regression procedure. To design the proposed digital twin, a strict-feedback backstepping observer, an integral term, a support vector regression and a fuzzy logic algorithm are suggested for AE signal estimation. The Ulsan Industrial Artificial Intelligence (UIAI) Lab’s bearing dataset was used to test the efficiency of the combined strict-feedback backstepping digital twin and machine learning technique for bearing crack type/size diagnosis. The average accuracies of the crack type diagnosis and crack size diagnosis of acoustic emission signals for the bearings used in the proposed algorithm were 97.13% and 96.9%, respectively. Full article

In recent years, artificial intelligence technology has been widely used in fault prediction and health management (PHM). The machine learning algorithm is widely used in the condition monitoring of rotating machines, and normal and fault data can be obtained through the data acquisition and monitoring system. After analyzing the data and establishing a model, the system can automatically learn the features from the input data to predict the failure of the maintenance and diagnosis equipment, which is important for motor maintenance. This research proposes a medium Gaussian support vector machine (SVM) method for the application of machine learning and constructs a feature space by extracting the characteristics of the vibration signal collected on the spot based on experience. Different methods were used to cluster and classify features to classify motor health. The influence of different Gaussian kernel functions, such as fine, medium, and coarse, on the performance of the SVM algorithm was analyzed. The experimental data verify the performance of various models through the data set released by the Case Western Reserve University Motor Bearing Data Center. As the motor often has noise interference in the actual application environment, a simulated Gaussian white noise was added to the original vibration data in order to verify the performance of the research method in a noisy environment. The results summarize the classification results of related motor data sets derived recently from the use of motor fault detection and diagnosis using different machine learning algorithms. The results show that the medium Gaussian SVM method improves the reliability and accuracy of motor bearing fault estimation, detection, and identification under variable crack-size and load conditions. This paper also provides a detailed discussion of the predictive analytical capabilities of machine learning algorithms, which can be used as a reference for the future motor predictive maintenance analysis of electric vehicles. Full article

Bearings prevent damage caused by frictional forces between parts supporting the rotation and they keep rotating shafts in their correct position. However, the continuity of work under harsh conditions leads to inevitable bearing failure. Thus, methods for bearing fault diagnosis (FD) that can predict and categorize fault type, as well as the level of degradation, are increasingly necessary for factories. Owing to the advent of deep neural networks, especially convolutional neural networks (CNNs), intelligent FD methods have achieved significantly higher performance in terms of accuracy. However, in addition to accuracy, the efficiency issue still needs to be weathered in complicated diagnosis scenarios to adapt to real industrial environments. Here, we introduce a method based on multi-output classification, which utilizes the correlated features extracted for bearing compound fault type classification and crack-size classification to serve both aims. Additionally, the synergy of a time–frequency signal processing method and the proposed two-dimensional CNN helped the method perform well under the condition of variable rotational speeds. Monitoring signals of acoustic emission also had advantages for incipient FD. The experimental results indicated that utilizing correlated features in multi-output classification improved both the accuracy and efficiency of multi-task diagnosis compared to conventional CNN-based multiclass classification. Full article

In this research, the aim is to investigate an adaptive digital twin algorithm for fault diagnosis and crack size identification in bearings. The main contribution of this research is to design an adaptive digital twin (ADT). The design of the ADT technique is based on two principles: normal signal modeling and estimation of signals. A combination of mathematical and data-driven techniques will be used to model the normal vibration signal. Therefore, in the first step, the normal vibration signal is modeled to increase the reliability of the modeling algorithm in the ADT. Then, to help challenge the complexity and uncertainty, the data-driven method will solve the problems of the mathematically based algorithm. Thus, first, Gaussian process regression is selected, and then, in two steps, we improve its resistance and accuracy by a Laguerre filter and fuzzy logic algorithm. After modeling the vibration signal, the second step is to design the data estimation for ADT. These signals are estimated by an adaptive observer. Therefore, a proportional-integral observer is then combined with the proposed technique for signal modeling. Then, in two stages, its robustness and reliability are strengthened using the Lyapunov-based algorithm and adaptive technique, respectively. After designing the ADT, the residual signals that are the difference between original and estimated signals are obtained. After that, the residual signals are resampled, and the root means square (RMS) signals are extracted from the residual signals. A support vector machine (SVM) is recommended for fault classification and crack size identification. The strength of the proposed technique is tested using the Case Western Reserve University Bearing Dataset (CWRUBD) under diverse torque loads, various motor speeds, and different crack sizes. In terms of fault diagnosis, the average detection accuracy in the proposed scheme is 95.75%. In terms of crack size identification for the roller, inner, and outer faults, the proposed scheme has average detection accuracies of 97.33%, 98.33%, and 98.33%, respectively. Full article

Bearings are complex components with onlinear behavior that are used to mitigate the effects of inertia. These components are used in various systems, including motors. Data analysis and condition monitoring of the systems are important methods for bearing fault diagnosis. Therefore, a deep learning-based adaptive neural-fuzzy structure technique via a support vector autoregressive-Laguerre model is presented in this study. The proposed scheme has three main steps. First, the support vector autoregressive-Laguerre is introduced to approximate the vibration signal under normal conditions and extract the state-space equation. After signal modeling, an adaptive neural-fuzzy structure observer is designed using a combination of high-order variable structure techniques, the support vector autoregressive-Laguerre model, and adaptive neural-fuzzy inference mechanism for normal and abnormal signal estimation. The adaptive neural-fuzzy structure observer is the main part of this work because, based on the difference between signal estimation accuracy, it can be used to identify faults in the bearings. Next, the residual signals are generated, and the signal conditions are detected and identified using a convolution neural network (CNN) algorithm. The effectiveness of the proposed deep learning-based adaptive neural-fuzzy structure technique by support vector autoregressive-Laguerre model was analyzed using the Case Western Reverse University (CWRU) bearing vibration dataset. The proposed scheme is compared to five state-of-the-art techniques. The proposed algorithm improved the average pattern recognition and crack size identification accuracy by 1.99%, 3.84%, 15.75%, 5.87%, 30.14%, and 35.29% compared to the combination of the high-order variable structure technique with the support vector autoregressive-Laguerre model and CNN, the combination of the variable structure technique with the support vector autoregressive-Laguerre model and CNN, the combination of RAW signal and CNN, the combination of the adaptive neural-fuzzy structure technique with the support vector autoregressive-Laguerre model and support vector machine (SVM), the combination of the high-order variable structure technique with the support vector autoregressive-Laguerre model and SVM, and the combination of the variable structure technique with the support vector autoregressive-Laguerre model and SVM, respectively. Full article

Rotating machines represent a class of nonlinear, uncertain, and multiple-degrees-of-freedom systems that are used in various applications. The complexity of the system’s dynamic behavior and uncertainty result in substantial challenges for fault estimation, detection, and identification in rotating machines. To address the aforementioned challenges, this paper proposes a novel technique for fault diagnosis of a rolling-element bearing (REB), founded on a machine-learning-based advanced fuzzy sliding mode observer. First, an ARX-Laguerre algorithm is presented to model the bearing in the presence of noise and uncertainty. In addition, a fuzzy algorithm is applied to the ARX-Laguerre technique to increase the system’s modeling accuracy. Next, the conventional sliding mode observer is applied to resolve the problems of fault estimation in a complex system with a high degree of uncertainty, such as rotating machinery. To address the problem of chattering that is inherent in the conventional sliding mode observer, the higher-order super-twisting (advanced) technique is introduced in this study. In addition, the fuzzy method is applied to the advanced sliding mode observer to improve the accuracy of fault estimation in uncertain conditions. As a result, the advanced fuzzy sliding mode observer adaptively improves the reliability, robustness, and estimation accuracy of rolling-element bearing fault estimation. Then, the residual signal delivered by the proposed methodology is split in the windows and each window is characterized by a numerical parameter. Finally, a machine learning technique, called a decision tree, adaptively derives the threshold values that are used for problems of fault detection and fault identification in this study. The effectiveness of the proposed algorithm is validated using a publicly available vibration dataset of Case Western Reverse University. The experimental results show that the machine learning-based advanced fuzzy sliding mode observation methodology significantly improves the reliability and accuracy of the fault estimation, detection, and identification of rolling element bearing faults under variable crack sizes and load conditions. Full article

Rail inspections are required and used to ensure safety and preserve the availability of railway infrastructure. According to the statistics published by railroad administrations worldwide, the transverse fissure appearing in railhead is the principal cause of rail accidents. These particular defects are initiated inside the railhead. Detection of these cracks has always been challenging because a defect signature remains mostly small until the defect size reaches a significant value. The present work deals with the theoretical analysis of an integrated contact-less system for rail diagnosis, which is based on ultrasounds. The generation of these waves was performed through non-ablative laser sources. Rotational laser vibrometry was used to achieve the reception of the echoes. Detection of flaws in the rail was monitored by considering special ultrasound wave signal based indicators. Finite element modeling of the rail system was performed, and transverse defect detection of the rail was analyzed. Full article

For full ceramic ball bearings, cracks occur frequently in the spalling on the rings, which leads to impacts on the bearing dynamic characteristics. In this paper, the spalling is set on the outer ring, and the dynamic model considering the effect of crack is proposed. The crack is considered to be related to the strain energy, and the effect on the stiffness of the outer ring is also analyzed. Results show that the appearance of cracks leads to the reduction of the full ceramic bearing stiffness, and the vibration amplitude of bearing increases. The effect of a crack depends on its size, and the vibration of the bearing with cracks of different widths and depths vary greatly. This study provides theoretical basis for the calculation of full ceramic bearing and is of great significance for the state monitoring and fault diagnosis. Full article

This paper proposes an extended-state ARX-Laguerre proportional integral observer (PIO) for fault detection and diagnosis (FDD) in bearings. The proposed FDD technique improves fault estimation using a nonlinear function while generating a robust residual signal using the sliding mode technique, which can indirectly improve the performance of FDD. Experimental results indicate that the system modeling error in a healthy condition is less than 2.5 × 10⁻¹⁰ N.m. In the next step, the ARX-Laguerre PIO is designed to define the state and output of the system observer. The high gain extended-state observer is designed in the third step to estimate the mechanical (bearing) faults based on the nonlinear function. In the last step, robust residual signals are generated based on the sliding mode algorithm for accurate fault identification. This approach improves the performance of an ARX-Laguerre linear PIO method. Employing the proposed method, we demonstrate that in the presence of uncertainties and disturbances, the ball, inner, outer, inner-ball, outer-ball, inner-outer, and inner-outer-ball failures with various motor torque speeds (300 RPM, 400 RPM, 450 RPM, and 500 RPM) and crack sizes (3 mm and 6 mm) are detected, identified, and estimated efficiently. The effectiveness of the proposed technique is compared with an ARX-Laguerre proportional integral observation (ALPIO). Experimental results indicate that the proposed technique outperforms the ALPIO technique, yielding 17.82% and 16.625% performance improvements for crack sizes of 3 mm and 6 mm, respectively. Full article
