Coreless filament winding (CFW) enables the material-efficient digital fabrication of lattice fiber composite lightweight structures with high geometric freedom. However, the unconstrained formation of fiber bundle leads to variable cross-sectional shapes, rugged surfaces, and limited predictability of bundle-level geometry. This study evaluates an industrial epoxy spray coating and a custom epoxy immersion coating as post-processing technologies for improving the cross-sectional geometry of CFW fiber bundles at different compaction levels. Three groups of samples were compared: manually squeezed high-compaction elongated samples with immersion coating, wrapped medium-compaction circularized samples with spray coating, and low-compaction elongated samples with spray coating. Loop specimens were fabricated, modified after winding where applicable, cured, coated, sectioned into samples, and analyzed using digital light microscopy. Image-based analysis quantified layer thickness, coverage interruptions, roundness, ruggedness, roughness, second moments of area distribution, volumetric phase fractions, surface gain, mass gain, and simplified area-estimation errors. Wrapping was the most effective measure for improving global roundness and squeezing improved compaction without circularization. Coating reduced ruggedness in all groups, including the highly rugged low-compaction samples, where part of the contour regularization resulted from bridging indentations, causing higher surface than mass gain. Coating improved the mass-specific second moment in every sample group, with an anisotropy reduction in the immersion-coated sample group. Full article

Bamboo has evolved a highly optimized structural system in its culms, which this study transfers into lightweight fiber composite trusses fabricated by coreless filament winding. Focusing on the structural segmentation involving diaphragms of the biological role model, this design principle was integrated into the additive manufacturing process using a multi-stage winding, a tiling approach, and a water-soluble winding fixture. Through a FE-assisted analytical abstraction procedure, the transition to a carbon fiber material system was considered by determining a geometrical configuration optimized for structural mass, bending deflection, and radial buckling. Samples were fabricated from CFRP and experimentally tested in four-point bending. In mass-specific terms, integrating diaphragms into wound fiber composite samples improved failure load by 36%, ultimate load by 62%, and energy absorption by a factor of 7, at a reduction of only 14% in stiffness. Benchmarking against steel and PVC demonstrated superior mass-specific performance, although mōsō bamboo still outperformed all technical solutions, except in energy absorption. Full article

Robotic coreless filament winding using alternative material systems based on natural fibers and bio-based resin systems offers possible solutions to the productivity and sustainability challenges of the building and construction sector. Their application in modular, prefabricated structures allows for material-efficient and fast production under tightly controlled conditions leading to high-quality building parts with minimal production waste. Plant fibers made of flax or hemp have high stiffness and strength values and their production consumes less non-renewable energy than glass or carbon fibers. However, the introduction of natural material systems increases uncertainties in structural performance and fabrication parameters. The development process of coreless wound composite parts must thus be approached from the bottom up, treating the material system as an integral part of design and evaluation. Existing design and fabrication methods, as well as equipment, are adjusted to emphasize material aspects throughout the development, increasing the importance of material characterization and scalability evaluation. The reciprocity of material characterization and the fabrication process is highlighted and contributes to a non-linear, cyclical workflow. The implementation of extensions and adaptations are showcased in the development of the livMatS pavilion, a first attempt at coreless filament winding using natural material systems in architecture. Full article

The building industry needs to innovate towards a more sustainable future and can do so through a combination of more renewable material choices and less wasteful fabrication processes. To address these issues, a hybrid material and fabrication system was developed using laminated timber veneer and natural fibre-reinforced composites (NFRPs), two materials that are leveraged for their potential of strategic material placement in additive processes towards programmed material behaviour and performance. The main contribution is in the hybrid fabrication approach, using thin, bent laminated veneer as an embedded frame for coreless filament winding of NFRP, which removes the need for temporary, wasteful formwork that is typically required to achieve structurally performative bent timber or FRP elements. Integrative methods are developed for the design, simulation, and fabrication of a rocking chair prototype that illustrates the architectural potential of the developed fabrication approach. Full article

Coreless filament winding is an emerging fabrication technology in the field of building construction with the potential to significantly decrease construction material consumption, while being fully automatable. Therefore, this technology could offer a solution to the increasing worldwide demand for building floor space in the next decades by optimizing and reducing the material usage. Current research focuses mainly on the design and engineering aspects while using carbon and glass fibers with epoxy resin; however, in order to move towards more sustainable structures, other fiber and resin material systems should also be assessed. This study integrates a selection of potential alternative fibers into the coreless filament winding process by adapting the fabrication equipment and process. A bio-based epoxy resin was introduced and compared to a conventional petroleum-based one. Generic coreless wound components were created for evaluating the fabrication suitability of selected alternative fibers. Four-point bending tests were performed for assessing the structural performance in relation to the sustainability of twelve alternative fibers and two resins. In this study, embodied energy and global warming potential from the literature were used as life-cycle assessment indexes to compare the material systems. Among the investigated fibers, flax showed the highest potential while bio-based resins are advisable at low fiber volume ratios. Full article

Additive manufacturing processes, such as coreless filament winding with fiber composites or laser powder bed fusion with metals, can produce lightweight structures while exhibiting process-specific characteristics. Those features must be accounted for to successfully combine multiple processes and materials. This hybrid approach can merge the different benefits to realize mass savings in load-bearing structures with high mass-specific stiffnesses, strict geometrical tolerances, and machinability. In this study, a digital tool for coreless filament winding was developed to support all project phases by natively capturing the process-specific characteristics. As a demonstration, an aluminum base plate was stiffened by a coreless wound fiber-composite structure, which was attached by additively manufactured metallic winding pins. The geometrical deviations and surface roughness of the pins were investigated to describe the interface. The concept of multi-stage winding was introduced to reduce fiber–fiber interaction. The demonstration example exhibited an increase in mass-specific component stiffness by a factor of 2.5 with only 1/5 of the mass of a state-of-the-art reference. The hybrid design approach holds great potential to increase performance if process-specific features, interfaces, material interaction, and processes interdependencies are aligned during the digitized design phase. Full article

A hemispherical research demonstration pavilion was presented to the public from April to October 2019. It was the first large-scale lightweight dome with a supporting roof structure primarily made of carbon- and glass-fiber-reinforced composites, fabricated by robotic coreless filament winding. We conducted monitoring to ascertain the sturdiness of the fiber composite material of the supporting structure over the course of 130 days. This paper presents the methods and results of on-site monitoring as well as laboratory inspections. The thermal behavior of the pavilion was characterized, the color change of the matrix was quantified, and the inner composition of the coreless wound structures was investigated. This validated the structural design and revealed that the surface temperatures of the carbon fibers do not exceed the guideline values of flat, black façades and that UV absorbers need to be improved for such applications. Full article

The manufacturing process of robotic coreless filament winding has great potential for efficient material usage and automation for long-span lightweight construction applications. Design methods and quality control rely on an adequate digital representation of the fabrication parameters. The most influencing parameters are related to the resin impregnation of the fibers and the applied fiber tension during winding. The end-effector developed in this study allows efficient resin impregnation, which is controlled online by monitoring the induced fiber tension. The textile equipment was fully integrated into an upscaled nine-axis robotic winding setup. The cyber-physical fabrication method was verified with an application-oriented large-scale proof-of-concept demonstrator. From the subsequent analysis of the obtained datasets, a characteristic pattern in the winding process parameters was identified. Full article

It has become clear over the last decade that the building industry must rapidly change to meet globally pressing requirements. The strong links between climate change and the environmental impact of architecture mean an urgent necessity for alternative design solutions. In order to propose them in this project, two emergent fabrication techniques were deployed with natural fiber-reinforced polymers (NFRPs), namely tailored fiber placement (TFP) and coreless filament winding (CFW). The approach is explored through the design and prototyping of a stool, as an analogue of the functional and structural performance requirements of an architectural system. TFP and CFW technologies are leveraged for their abilities of strategic material placement to create high-performance differentiated structure and geometry. Flax fibers, in this case, provide a renewable alternative for high-performance yarns, such as carbon, glass, or basalt. The novel contribution of this project is exploring the use of a TFP preform as an embedded fabrication frame for CFW. This eliminates the complex, expensive, and rigid molds that are traditionally associated with composites. Through a bottom-up iterative method, material and structure are explored in an integrative design process. This culminates in a lightweight FlexFlax Stool design (ca. 1 kg), which can carry approximately 80 times its weight, articulated in a new material-based design tectonic. Full article
