Search Results (57)

This study investigates the shear bearing capacity of aluminum alloy–concrete composite beams to address the limitations caused by the low elastic modulus of aluminum alloys. A finite element model was developed using the Concrete Damaged Plasticity (CDP) model for concrete and validated through parametric analysis. Key factors such as concrete strength, stirrup spacing, and cross-sectional dimensions were examined. An improved shear capacity formula was derived based on the tension–compression bar model and the superposition method. The proposed formula achieved an average ratio of 1.018 to finite element results, with a standard deviation of 0.151, and the proposed formula was validated against 22 FEA models, demonstrating excellent agreement with numerical results and confirming its reliability for practical engineering applications. This work provides a practical analytical approach for the shear design of aluminum–concrete composite structures. Full article

The predictive modeling of concrete degradation under freeze–thaw cycling remains a challenge due to complex damage mechanisms and limited simulation accuracy. A plastic damage constitutive model for fly ash concrete under freeze–thaw conditions was established based on experimental data and implemented via the concrete damage plasticity (CDP) model in ABAQUS. A modified stress–strain relationship and damage factor were introduced to describe mechanical deterioration across various freeze–thaw stages. Macro- and mesoscale finite element simulations were applied to simulate the stress–strain evolution, plastic deformation, and damage development. A validation against experimental data indicated a relatively high accuracy, with prediction errors of 1.61% at the macroscale and 5.81% at the mesoscale. The macroscale model effectively captures global stiffness degradation and strength loss, while the mesoscale model reveals the internal freeze–thaw damage mechanisms, including crack initiation and propagation. The results demonstrate the applicability of the proposed model for assessing freeze–thaw-induced damage in concrete structures exposed to cold environments. Full article

Tunnel lining structures, which are subjected to the combined effects of water and soil pressure as well as a water-rich erosion environment, undergo a corrosion-induced damage and degradation process in the reinforced concrete, gradually leading to structural failure and a significant decline in service performance. By introducing the Cohesive Zone Model (CZM) and the concrete damage plastic model (CDP), a three-dimensional numerical model of the tunnel lining structure in mining method tunnels was established. This model takes into account the multiple effects caused by steel reinforcement corrosion, including the degradation of the reinforcement’s performance, the loss of an effective concrete cross section, and the deterioration of the bond between the steel reinforcement and the concrete. Through this model, the deformation, internal forces, damage evolution, and degradation characteristics of the structure under the effects of the surrounding rock water–soil pressure and steel reinforcement corrosion are identified. The simulation results reveal the following: (1) Corrosion leads to a reduction in the stiffness of the lining structure, exacerbating its deformation. For example, under high water pressure conditions, the displacement at the vault of the lining before and after corrosion is 4.31 mm and 7.14 mm, respectively, with an additional displacement increase of 65.7% due to corrosion. (2) The reinforced concrete lining structure, which is affected by the surrounding rock loads and expansion due to steel reinforcement corrosion, experiences progressive degradation, resulting in a redistribution of internal forces within the structure. The overall axial force in the lining slightly increases, while the bending moment at the vault, spandrel, and invert decreases and the bending moment at the hance and arch foot increases. (3) The damage range of the tunnel lining structure continuously increases as corrosion progresses, with significant differences between the surrounding rock side and the free face side. Among the various parts of the lining, the vault exhibits the greatest damage depth and the widest cracks. (4) Water pressure significantly impacts the internal forces and crack width of the lining structure. As the water level drops, both the bending moment and the axial force diminish, while the damage range and crack width increase, with crack width increasing by 15.1% under low water pressure conditions. Full article

Ultra-high-performance concrete with steel fibers (UHPC) stands out for its exceptional mechanical properties and high ductility. The addition of steel fibers improves the tensile strength, allowing for its use in the design of structural elements subject to bending. The use of rice husk ash (RHA) as a natural mineral addition in the UHPC mixture offers significant advantages in terms of environmental impact and mechanical properties. Therefore, this work experimentally investigates the effect of RHA as a partial replacement for active silica fume on the flexural tensile strength and compressive behavior of UHPC. Additionally, a parametric study was conducted to examine the impact of varying prism geometries on the flexural tensile strength of UHPC with and without CCR in ABAQUS version 6.14. The experimental results made it possible to calibrate the UHPC parameters using RHA for numerical simulations of UHPC behavior based on the concrete damaged plasticity (CDP) model. The results indicated an increase of 4% in the compressive strength and 20% in the flexural tensile strength of UHPC with the addition of RHA. Furthermore, the numerical extrapolations of the flexural tensile strength test show that increasing the dimensions of the prisms reduces the strength by up to 30% of UHPC with RHA, evidencing the influence of geometry on the results. Full article

Fiber-reinforced polymers (FRPs) are effective for strengthening masonry walls. Debonding at the polymer–masonry interface is a major concern, requiring further investigation into interface behavior. This study utilizes detailed micro-modeling finite element (FE) analysis to predict failure mechanisms and analyze the behavior of brick masonry walls strengthened with externally bonded carbon fiber-reinforced polymer (CFRP) under in-plane loading. The research investigates three CFRP strengthening configurations (X, I, and H). The FE model incorporates the nonlinear behavior of brick masonry components using the Concrete Damage Plasticity (CDP) model and uses a cohesive interface approach to model unit–mortar interfaces and the bond joints between masonry and CFRPs. The results demonstrate that diagonal CFRP reinforcement enhances the ductility and capacity of masonry wall systems. The FE model accurately captures the crack propagation, fracture mechanisms, and shear strength of both unreinforced and reinforced walls. The study confirms that the model can reliably predict the structural behavior of these composite systems. Furthermore, the study compares predicted shear strengths with established design equations, highlighting the ACI 440.7R-10 and CNR-DT 200/2013 models as providing the most accurate predictions when compared to experimental results. Full article

The behavior of steel–concrete composite structures is significantly influenced by the efficiency of the shear connections that link the two materials. This research examines the performance of stud shear connectors, with an emphasis on analyzing the effect of different geometric design parameters. A computational model was created utilizing Python 3.13 to enable thorough digital monitoring of the influence of these parameters on the structural performance of composite connections. Developed within the ABAQUS framework, the model integrates geometric nonlinearity and the Concrete Damage Plasticity (CDP) approach to achieve detailed simulation of structural behavior. Essential design aspects, including stud diameter, stud height, head dimensions, and spacing in both longitudinal and transverse directions, were analyzed. The Python-based parametric model allows for easy modification of design parameters, ensuring efficiency and minimizing modeling errors. The significance of stud diameter changes was analyzed in accordance with Eurocode standards and previous studies. It was found that stud length has a reduced effect on structural performance, particularly when considering the concrete properties used in bridge construction, where compressive failure of the concrete zone is more critical at lower concrete strengths. Additional factors, such as stud head dimensions, were investigated but were found to have minimal effect on the behavior of steel–concrete composite connections. Longitudinal stud spacing emerged as a critical factor influencing structural performance, with optimal results achieved at a spacing of 13d. Spacings of 2d, 3d, and 4d demonstrated overlapping effects, leading to significant performance reductions, as indicated by comparisons of ultimate load and force–displacement responses. For transverse spacing, closer stud arrangements proved effective in reducing the likelihood of slip at the steel–concrete interface, enhancing composite action, and lowering stress concentrations. Additionally, reducing the transverse distance between studs allowed for the use of more shear connectors, increasing redundancy and enhancing performance, especially with grouped-stud connectors (GSCs). Full article

Currently, fiber-reinforced concrete, as a building material, is widely used in highway bridges and tunnel linings, and it has become a global research hotspot, with indoor tests, numerical simulations, performance studies, and application scenarios surrounding it. Many researchers have conducted experiments and analyses on the damage patterns of fiber-reinforced concrete under different conditions. However, there is relatively little research on the mechanical properties of fiber-reinforced concrete that already contains initial damage. This article establishes a micro-model composed of aggregates, mortar, and interface layers using MATLAB. It introduces the CDP (Concrete Damage Plasticity) constitutive equation for fiber-reinforced concrete and uses the least squares method to fit and validate the equation. After model validation, uniaxial compression tests are conducted on models with different initial porosities using the ABAQUS (2023) software, resulting in changes in crack damage, peak stress, and elastic modulus mechanical properties. The conclusions are as follows: The improved characteristic structure curve using the least squares method fits the experimental results well, and the rationality of the algorithm was verified by comparing it with physical tests. As the porosity increased from 2% to 8%, the peak stress decreased from 98.6% to 70.5% compared to non-porous fiber concrete with a significant rate of decrease of about 30%. After considering the strain rate, the peak stress increased slowly with increasing strain rate, but the elastic modulus increased at a significant rate, with a 1.26 times higher elastic modulus at a strain rate of 10⁰ than at a strain rate of 10⁻². This result provides a certain theoretical basis for the mechanical properties and damage modes of fiber-containing concrete in practical engineering. Full article

The structural assessment of masonry construction often requires the use of nonlinear 2D and 3D finite element analysis. This work describes a strategy for using energy outputs from such analyses to accurately assess failure conditions precipitated by increasing lateral load. The methodology relies on the analogy between plastic strains and fracture that is inherent to the concrete damaged plasticity (CDP) macro-model used to represent the quasi-brittle behavior of masonry material. At critical conditions, energy imparted to a structure by loading can no longer be completely stored as elastic strain energy and must be dissipated. This occurs with fractures in masonry, which are represented with plastic strains when using CDP material. The development of plastic dissipation energy can therefore be used as a measure for understanding the progressive collapse of a structure, as we illustrate with the following three case studies analyzed using Abaqus/CAE Explicit: the massive earthen pyramid at Huaca de la Luna (Trujillo, Peru), the Roman pozzolanic concrete vault of Diocletian’s Frigidarium (Rome, Italy), and the mixed-material triumphal arch of the San Pedro Apóstol Church of Andahuaylillas (Peru). The method is verified by other measures of failure and has particular applicability for seismic analysis of complex masonry and earthen structures. Full article

Technical literature provides experimental campaign results for four-pile caps with significant value in structural engineering. However, failure modes and measurement of these specimens are particularly challenging due to their volumetric nature. These experimental records are frequently utilized to evaluate analytical models focusing on less conservative than normative models to predict rupture force. Moreover, recent studies emphasize the necessity of developing simplified predictive models. In this context, the objective of this study was to evaluate the feasibility of regression models for estimating the rupture force associated with strut failure. The evaluation was based on a commonly used database and employed analysis of variance (ANOVA) at a 5% significance level to identify critical variables. The regression models were developed with variable interactions incorporated into the equations in three forms: (i) without interaction, (ii) with linear interaction, and (iii) with quadratic interaction. An analysis of the developed regression models identified a model with satisfactory accuracy. This model achieved an average predicted force ratio of 1.00 (COV = 14%) for the database and 1.03 (COV = 16.68%) for extrapolated numeric models in finite elements with the concrete damaged and plasticity (CDP) constitutive model, initially calibrated with experimental tests. A methodology was proposed to assist in the initial design of four-pile caps. Full article

Carbon-fiber-reinforced polymer (CFRP) laminates have gained attention for their potential to reduce carbon emissions in construction. The impact of carbon-fiber-reinforced polymer (CFRP Laminate) on carbon emissions and the influence of elasto-plastic analysis on this technique were studied in this research. This study focuses on how CFRP can affect the environmental footprint of reinforced concrete structures and how elasto-plastic analysis contributes to optimizing this strengthening method. Four flat RC slabs were created to evaluate this technique in strengthening. One slab was used as a reference without strengthening, while the other three were externally strengthened with CFRP. The slabs, which were identical in terms of their overall (length, width, and thickness) as well as their flexural steel reinforcement, were subjected to concentrated patch load until they failed. The strength of two-way RC slabs was analyzed using a concrete plastic damage constitutive model (CDP). Additionally, CFRP strips were applied to the tension surface of existing RC slabs to improve their strength. The load–deflection curves obtained from the simulations closely match the experimental data, demonstrating the validity and accuracy of the model. Strengthening concrete slabs with CFRP sheets reduced central deflection by 17.68% and crack width by 40%, while increasing the cracking load by 97.73% and the ultimate load capacity by 134.02%. However, it also led to a 15.47% increase in CO₂ emissions. Also, the numerical results show that increasing the strengthening ratio significantly impacts shear strength and damage percentage. Full article

This study investigated both the static and dynamic behavior of silicate materials through a series of experimental and numerical tests. Compression tests were conducted on cubic samples, three-point bending tests on beams, and perforation tests on silicate plates. In the compression tests, stress–strain curves were generated, enabling the calibration of the Concrete Damaged Plasticity (CDP) model for silicate materials. The tensile strength of the silicate was assessed using three-point bending tests, while dynamic perforation tests determined the impact resistance of silicate when subjected to a rigid projectile. The perforation tests provided insight into the failure mechanisms of silicate plates under projectile impact at velocities approaching the ballistic limit. Additionally, the numerical simulations for all the experimental tests were performed using the Abaqus software in order to validate the accuracy of the material behavior model and confirm the appropriateness of the calibrated parameters for the chosen model. The results showed a strong qualitative and quantitative correlation with the experimental data, demonstrating the robustness of the adopted approach. Full article

This paper presents a comprehensive finite element analysis (FEA) of pre-stressed Ultra High-Performance Concrete (UHPC) girders, showcasing intricate structural behaviors under various loading conditions. Utilizing advanced finite element modeling techniques, the study accurately simulates the flexural response of UHPC girders, integrating experimental results from large-scale laboratory tests conducted by researchers at the Turner-Fairbank Highway Research Center. This paper shows the effectiveness of simulating pre-stressing forces via initial equivalent temperature load with relatively accurate stress and strain predictions. The paper also delves into the moment–deflection relationships at critical stages, such as first concrete crack appearance, yielding, and strain localization, to capture the non-linear behavior of UHPC girders under pre-stressed conditions. Additionally, crack propagations were characterized by investigating the damage in tension (DAMAGET) plots. In summary, the results of the finite element model agree well with the experimental observations. Moreover, this study not only demonstrates the effectiveness of FEA in accurately simulating the complex structural behaviors of UHPC girders but also highlights its broader applicability to the design and analysis of other girder types, offering valuable insights compared to ordinary concrete beams. Full article

Modeling the steel-concrete interface is a constant research topic in structural engineering. Several studies have explored advanced modeling methods, including cohesive models. This article fits into this context by investigating the bond strength at the steel-concrete interface based on a cohesive model. The numerical parameters considered in the software ABAQUS 2019 are investigated. The experimental and numerical results of pullout and beam tests were used as references for the parameters fitting process. With the Concrete Damaged Plasticity model (CDP), the physical non-linearity of the concrete was considered. The contact was described as a surface-to-surface interaction. The pullout tests’ cohesive parameters were fitted with experimental tests. Regarding the beam models, an analysis was carried out verifying the use of pullout fitting parameters in the beam models, aiming to compensate for the eventual absence of these data. For the pullout models, the cohesive parameters fitting process yielded better results than those obtained with the recommended values. Improvements were especially significant regarding slippage at the maximum pullout force. The use of pullout test-fitted parameters in the beam models had a smaller influence on the ultimate load predictions. However, the slippage predictions and beam deflection were more affected by the change in cohesive parameters. The bond modeling using a surface-based technique performed well at a low computational cost, considering the materials’ physical nonlinearities and 3D geometries. The results, also in general, did not significantly change the load predictions, which indicates a possibility of use in numerical simulations when the pullout data is available. Full article

An innovative form of steel–concrete composite beam, the steel–coarse aggregate reactive powder concrete (CA-RPC) composite beam with uplift-restricted and slip-permitted (URSP) connectors, is introduced in this paper. The aim is to enhance the cracking resistance under negative bending moments, which is a difficult problem for traditional composite beams, and to make the cost lower than using ordinary reactive powder concrete (RPC). An experimental investigation of the behavior of six specimens of simply supported steel–CA-RPC composite beams with URSP connectors under negative bending moments is presented in this paper. The test results validated that the cracking load of steel–CA-RPC composite beams could be approximately three times that of the ordinary steel–concrete composite beams while the bearing capacity and stiffness are almost the same. A numerical model, using the concrete damaged plasticity (CDP) model to simulate the behavior of the CA-RPC material, was proposed and successfully calculated the overall load–displacement relationship of the composite beams with sufficient accuracy compared with the experimental results, and the distribution of cracks and the failure mode of the beams could also be captured by this model. Furthermore, a parametric analysis was carried out to find out how the application of prestress, CA-RPC, and URSP connectors could affect the cracking resistance of the composite beams, and the results indicated that using CA-RPC and prestress made the main contributions and that the usage of URSP could boost the effect of the other two factors. The plastic resistance moment of the beams was also compared with the calculation results using the methods introduced in Eurocode 4, and it was proved that the calculation results were lower than the experimental results by approximately 10%, which meant that the method was reliable for this kind of composite beam. Full article

Four-pile caps made from concrete are essential elements for the force transfer from the superstructure to piles or pipes. Due to the difficulties in carrying out full-scale tests and all the instrumentation involved, the use of numerical models as a way to study the mechanical behavior of these elements presents itself as a good alternative. Such numerical studies usually provide useful information for the update and improvement of normative standards and codes. The concrete damaged plasticity (CDP) constitutive model, which combines damage and plasticity with smeared-crack propagation, stands out in the simulation of reinforced concrete. This model is composed of five parameters: dilatation angle (ψ), eccentricity (ϵ), ratio between biaxial and uniaxial compressive strength (σ_bo/σ_co), failure surface in the deviator plane normal to the hydrostatic axis (K_c), and viscosity (μ). For unidimensional elements, the values of the CDP parameters are well defined, but for volumetric elements, such as concrete pile caps, there is a gap in the literature regarding the definition of these values. This fact ends up limiting the use of the CDP on these structural elements due to the uncertainties involved. Therefore, the aim of this research was to calibrate two numerical models of concrete four-pile caps with different failure modes for the evaluation of the sensitivity of the CDP parameters, except for ϵ, which remained constant. As a result, the parameters σ_bo/σ_co and K_c did not significantly influence the calibration of the force × displacement curves of the simulated structures. Values of ψ and μ equal to 36° and 1 × 10⁻⁴, respectively, are recommended for “static” analysis, while for “quasi-static” analysis, ψ values ranging between 45° and 50° are suggested according to the failure mode. The results also showed to be sensitive to the constitutive relation of concrete tensile behavior in both modes of analysis. For geometric parameterization, the “static” analysis is recommended due to the lower coefficient of variation (3.29%) compared to the “quasi-static” analysis (19.18%). This conclusion is supported by the evaluation of the ultimate load of the numerical models from the geometrically parametric study compared to the results estimated by an analytical model. Full article
