Search Results (25)

This study compares the heat transfer and pressure drop of three cell structures, namely Kelvin cells (KCs), ellipsoidal Kelvin cells (EKCs), and body-centered cubic (BCC) structures, at the cell scale in order to identify the superior configuration. Then, we conducted numerical simulations on the heat exchangers based on porous media, and evaluate their comprehensive performance. It is shown that KCs have a superior heat transfer. Their volumetric heat transfer coefficient (h_V) is more than 50% higher than that of EKCs and more than 100% higher than that of BCC structures. EKCs exhibit a lower pressure drop. In the heat exchanger performance optimization study, the Kelvin structure demonstrated significant heat transfer characteristics. Simulation data show that the heat transfer performance at the hot end of the Kelvin heat exchanger (KCHE) is enhanced by more than 40% compared to the conventional plate-fin structure (FHE), but its flow channel pressure drop characteristics show a significant nonlinear increase. It is noteworthy that the improved Kelvin heat exchanger (EKCHE), optimized by introducing elliptic cell topology, maintains heat transfer while keeping the pressure loss increase within 1.22 times that of the conventional structure. The evaluation of the heat transfer and pressure drop characteristics is consistent for both scales. In addition, the EKC configuration exhibits a superior overall heat transfer capacity. To summarize, this work proposes a systematic numerical framework encompassing cell unit screening through heat exchanger design, offering valuable guidance for the structured development and analysis of porous media heat exchangers in relevant engineering domains. Full article

This study employed a hydrothermal method to prepare V-doped MoS₂. The influence of varying filler ratios (30 wt%, 40 wt%, 50 wt%) on its absorption properties was analyzed. For annealing studies, a precursor powder with a 40 wt% filler ratio was heat-treated at 600 °C for 2 h. The results obtained through characterization and testing indicate that the unannealed 40 wt% filler sample demonstrates superior absorption performance, with minimum reflection loss (RL_min) of −32.24 dB, an effective absorption bandwidth (EAB) of 4.40 GHz, and 99.9% electromagnetic (EM) wave attenuation. However, upon subjecting the sample with a 40 wt% filling ratio to annealing treatment, a notable decrease in impedance matching degree was observed, and regions with impedance matching values close to 1 were no longer present. Consequently, it can be concluded that at a filling ratio of 40 wt%, the sample’s excellent attenuation coefficient in conjunction with its good impedance matching collectively contribute to its superior comprehensive absorption performance. Full article

Thermal protection systems play a pivotal role in astronautical engineering fields. However, traditional rectangular fin (RF) structures exhibit low thermo-fluid properties. Inspired by the minimal surfaces in nature, this study develops three types of triply periodic minimal surface (TPMS) lattices, namely, sheet primitive (SP), network I-WP (NW), and sheet I-WP (SW) by using mathematical formulae. The TPMS lattices are fabricated by laser powder bed fusion using AlSi10Mg powder. A convective heat transfer simulation model of TPMS lattices is established and validated through experiments. The fluid flow characteristics, heat transfer characteristics, and overall heat transfer performance of the TPMS lattices are comprehensively investigated based on the simulation model. Results show that the relationship between pressure loss and flow velocity of the TPMS lattices satisfies the Darcy–Forchheimer law. Compared to traditional RF structures, the TPMS lattices exhibit a more uniform temperature distribution at the same flow rate, and the highest convective heat transfer coefficient is increased by approximately 96.62%. This is due to the complex internal structures of the TPMS lattices, which enhance the disturbance of the fluid flow and further improve the heat transfer coefficient. The overall thermal transfer index ($\alpha$) of the TPMS lattices is higher than that of traditional RF structures with an order of ${\alpha }_{SP}>{\alpha }_{SW}>{\alpha }_{NW}>{\alpha }_{RF}$, which confirms the potential applications of TPMS lattices in thermal protection systems. Full article

The hypervapotron structure was considered to be a feasible configuration to meet the high heat-dissipating requirement of divertors in nuclear fusion devices. In this work, symmetric CuCrZr-based transverse microchannels (TMHC) and longitudinal microchannels (LMHC) with an integrated hypervapotron channel were proposed and manufactured, and subcooled flow boiling experiments were conducted using deionized water at an inlet temperature of 20 °C with a traditional flat-type hypervapotron channel (FHC) for comparison. The LMHC and TMHC obtained lower wall temperatures than the FHC for all conditions, and the TMHC yielded the lowest temperatures. The heat transfer coefficients of the LMHC and TMHC outperformed the FHC due to the enlarged heat transfer area, and the TMHC had the greatest heat transfer coefficient (maximumly increased by 132% compared to the FHC) because the transverse-arranged microchannels were conductive, promoting the convection and liquid replenishment ability by introducing branch flow between fins; however, the microchannels of the LMHC were insensible to flow velocities due to the block effect of longitudinal microchannels. The LMHC obtained the largest pressure drop, and the pressure drop for the FHC and TMHC were comparable since the transverse-placed microchannels had little effect on frictional pressure loss. The TMHC attained the greatest comprehensive thermohydraulic performance which might bring significant insight to the structural design of hypervapotron devices. Full article

An isogeometric topology optimization (ITO) model for multi-material structures under thermal-mechanical loadings using neural networks is proposed. In the proposed model, a non-uniform rational B-spline (NURBS) function is employed for geometric description and analytical calculation, which realizes the unification of the geometry and computational models. Neural networks replace the optimization algorithms of traditional topology optimization to update the relative densities of multi-material structures. The weights and biases of neural networks are taken as design variables and updated by automatic differentiation without derivation of the sensitivity formula. In addition, the grid elements can be refined directly by increasing the number of refinement nodes, resulting in high-resolution optimal topology without extra computational costs. To obtain comprehensive performance from ITO for multi-material structures, a weighting coefficient is introduced to regulate the proportion between thermal compliance and compliance in the loss function. Some numerical examples are given and the validity is verified by performance analysis. The optimal topological structures obtained based on the proposed model exhibit both excellent heat dissipation and stiffness performance under thermal-mechanical loadings. Full article

Gas turbines are widely applied in many fields, and blade cooling is a key way to improve gas turbines’ power and efficiency. In order to explore a high-efficiency cooling method, a new variant configuration with unique coolant supply passage arrangements is proposed and explored in this paper. The numerical simulation method of solving the Navier–Stokes equations is used after mesh independence calculation and turbulence model validation. The results show that the variant structure has better streamlines distribution with double vortex flows in both the inner and outer chambers. Compared to the original configuration, the heat transfer intensity in the outer chamber is improved, and the globally averaged Nusselt number is 17.1% larger. The case with uniformly distributed nozzles has the best flow and heat transfer performance. As the nozzle number increases, the total pressure loss and friction coefficient decrease, but the heat transfer increases first and then decreases. The case of three nozzles has the best comprehensive cooling behavior. The aspect ratio has important influences on the double-vortex cooling configuration. Cases with small aspect ratios have higher local heat transfer intensity, but the flow loss is larger. The case with aspect ratio 4 has the best cooling performance. Full article

In the dynamic environment of fresh food supermarkets, managing the short shelf life and varying quality of vegetable products presents significant challenges. This study focuses on optimizing restocking and pricing strategies to maximize profits while accommodating the diverse and time-sensitive nature of vegetable sales. We analyze historical sales, pricing data, and loss rates of six vegetable categories in Supermarket A from 1 July 2020 to 30 June 2023. Using advanced data analysis techniques like K-means++ clustering, non-normal distribution assessments, Spearman correlation coefficients, and heat maps, we uncover significant correlations between vegetable categories and their sales patterns. The research further explores the implications of cost-plus pricing, revealing a notable relationship between pricing strategies and sales volumes. By employing Autoregressive Integrated Moving Average (ARIMA) and Long Short-Term Memory (LSTM) models, we forecast sales and determine optimal restocking volumes. Additionally, we use price elasticity theories and a comprehensive model to predict net profit changes, aiming to enhance profit margins by 47%. The study also addresses space constraints in supermarkets by proposing an effective assortment of salable items and individual product restocking plans, based on FP-Growth algorithm analysis and market demand. Our findings offer insightful strategies for sustainable and economic growth in the supermarket industry, demonstrating the impact of data-driven decision-making on operational efficiency and profitability. Full article

Thermoelectric generators are devices that transform thermal energy into electric energy. These devices play an influential role in our constantly developing civilization due to their energy conversion capabilities and advantages over other conventional methods. The material properties and thermoelectric phenomena are paramount to the design process of such devices. The design process must have a complex tool to model all the thermoelectric phenomena, such as, for example, the commercial numerical code of Ansys Mechanical. However, these numerical tools can be methodologically and computationally demanding. Thus, this study aims to develop a methodology through which to characterize thermoelectric generators by using a simplified one-dimensional numerical model that considers temperature-dependent N- and P-type material properties and convective heat losses. The proposed model’s results are compared and validated to a single thermoelectric leg and a complete thermoelectric commercial module, both modeled in Ansys Thermal-Electric. These results consider the different values for electric and thermal loads as current densities, electric resistivities, and heat transfer coefficients. The main result of this study is the correct prediction of the output voltage and output power given by the one-dimensional proposed model, which was validated against a comprehensive model and the commercial thermoelectric module’s information. Therefore, the proposed methodology of this study provides a deeper understanding of the thermoelectric energy conversion process, and it can guide the design and optimization of thermoelectric generators for practical applications. Full article

Recent efforts to understand low-temperature combustion (LTC) in internal combustion engines highlight the need to improve chemical kinetic mechanisms involved in the negative temperature coefficient (aka cool flame) regime. Interestingly, microgravity droplet combustion experiments demonstrate this cool flame behavior, allowing a greater focus on chemistry after buoyancy, and the corresponding influence of the conservation of momentum is removed. In Experimental terms, the LTC regime is often characterized by a reduction in heat transfer losses. Novel findings in this area demonstrate that lower entropy generation, in conjunction with diminished heat transfer losses, could more definitively define the LTC regime. As a result, the simulation of the entropy equation for spherical droplet combustion under microgravity could help us to investigate fundamental LTC chemical kinetic pathways. To provide a starting point for researchers who are new to this field, this effort first provides a comprehensive and detailed derivation of the conservation of entropy equation using spherical coordinates and gathers all relevant information under one cohesive framework, which is a resource not readily available in the literature. Subsequently, the well-known d² law analytical model is determined and compared to experimental data that highlight shortcomings of the law. The potential improvements in the d² law are then discussed, and a numerical model is presented that includes entropy. The resulting codes are available in an online repository to ensure that other researchers interested in expanding this field of work have a fundamental starting point. Full article

This article presents a comprehensive study on thermal and computational fluid dynamics (CFD) analysis of an innovative greenhouse dryer designed for passive operation under a no-load condition. The dryer incorporates hybrid thermal storage at the floor and a reflective mirror with thermocoal as the north wall, transforming a classical even-span greenhouse dryer into an efficient and effective system. The experimentation was conducted under clear sky conditions, with variations in global solar radiation (GSR) ranging from 166.6 to 1209 W/m², resulting in an average value of 875.9 W/m². The variations in GSR influenced other ambient parameters, including ambient temperature (28.7 °C to 35.6 °C), ambient relative humidity (33.2% to 45.7%), and ambient wind speed (0.1 to 1.02 m/s). Indoor parameters of the proposed dryer, such as inside temperature (31 °C to 47.35 °C), inside relative humidity (31.1% to 39.1%), ground temperature (44.2 °C to 70.6 °C), and outlet temperature (29 °C to 45.35 °C), were measured hourly. The average values of these parameters were 41.25 °C, 35.31%, 61.65 °C, and 39.25 °C, respectively. Quantitative parameters, including heat loss, overall heat transfer coefficient, coefficient of diffusion, and instantaneous efficiency, were calculated to evaluate the dryer’s performance. The proposed dryer exhibited an improved range of overall heat transfer coefficients (3.87 to 5.03 W/m² K) compared to the modified greenhouse dryer under passive mode and the conventional greenhouse under passive mode. CFD analysis provided temperature distribution plots showing a progressively increasing range of temperatures near the trays, ranging from 310 K to 335 K, suitable for natural convection drying. The findings highlight the superior performance of the innovative dryer compared to contemporary systems. This research contributes to the advancement of drying technology and holds potential for applications in the agriculture and food processing industries. Full article

With the development of the integrated circuit and chip industry, electronic products and their components are becoming increasingly miniaturized, high-frequency, and low-loss. These demand higher requirements for the dielectric properties and other aspects of epoxy resins to develop a novel epoxy resin system that meets the needs of current development. This paper employs ethyl phenylacetate cured dicyclopentadiene phenol (DCPD) epoxy resin as the matrix and incorporates KH550 coupling-agent-treated SiO₂ hollow glass microspheres to produce composite materials with low dielectric, high heat resistance, and high modulus. These materials are applied as insulation films for high density interconnect (HDI) and substrate-like printed circuit board (SLP) boards. The Fourier transform infrared spectroscopy (FTIR) technique was used to characterize the reaction between the coupling agent and HGM, as well as the curing reaction between the epoxy resin and ethyl phenylacetate. The curing process of the DCPD epoxy resin system was determined using differential scanning calorimetry (DSC). The various properties of the composite material with different HGM contents were tested, and the mechanism of the impact of HGM on the properties of the composite material was discussed. The results indicate that the prepared epoxy resin composite material exhibits good comprehensive performance when the HGM content is 10 wt.%. The dielectric constant at 10 MHz is 2.39, with a dielectric loss of 0.018. The thermal conductivity is 0.1872 Wm⁻¹ k⁻¹, the coefficient of thermal expansion is 64.31 ppm/K, the glass transition temperature is 172 °C, and the elastic modulus is 1221.13 MPa. Full article

Aiming at the impact of heat generation and temperature rise on the driving performance of a permanent magnet (PM) motor, taking the PM in-wheel motor (IWM) for electric vehicles as an object, research is conducted into the temperature distribution of the electromagnetic–thermal effect and cooling structure optimization. Firstly, the electromagnetic–thermal coupling model considering electromagnetic harmonics is established using the subdomain model and Bertotti’s iron loss separation theory. Combined with the finite element (FE) simulation model established by Ansoft Maxwell software platform, the winding copper loss, stator core loss and PM eddy current loss under the action of complex magnetic flux are analyzed, and the transient temperature distribution of each component is obtained through coupling. Secondarily, the influence of the waterway structure parameters on the heat dissipation effect of the PM-IWM is analyzed by the thermal-fluid coupled relationship. On the basis, the optimization design of waterway structure parameters is carried out to improve the heat dissipation effect of the cooling system based on the proposed chaotic mapping ant colony algorithm with metropolis criterion. The comparison before and after optimization shows that the temperature of key components is significantly improved, the average convection heat transfer coefficient (CHTC) is increased by 23.57%, the peak temperature of stator is reduced from 95.47 °C to 82.73 °C, and the peak temperature of PM is decreased by 14.26%, thus the demagnetization risk in the PM is improved comprehensively. The research results can provide some theoretical and technical support for the structural optimization of water-cooled dissipation in the PM motor. Full article

A downhole electric tubular resistive heater is proposed for the oil-shale in situ resorting. After flowing through a set of heating tubes, the outlet temperature and the flow rate of the injected gas can be conveniently adjusted to match the requirement of the pyrolysis temperature of the oil shale. The calculation demonstrates the effects of the inner diameter, the length of the heating tube, and the inlet flow rate on the heat transfer performance of the electric heater. It was found that, compared with the armored electric heaters, even with a small inject flow rate of 5 Nm³/min, the convective heat transfer coefficient of the inner flow exceeds 300 W/m² K, resulting in a much smaller thermal resistance. The outlet temperature of the heating gas can conveniently reach up to 900 °C with the absence of the complex structure of enhanced fins. Though the pressure loss is relatively larger under a high flow rate, the comprehensive index is still 40% higher, indicating that the present tubular electric heater is a promising candidate to deal with complex downhole conditions. Full article

Printed Circuit Heat Exchangers (PCHEs) are considered an excellent alternative for the main cryogenic heat exchanger of Floating Liquefied Natural Gas (FLNG) facilities due to their compact structure and strong heat transfer performance. However, it is unclear how to configure the geometry of the PCHE channels to achieve its optimal performance in the trans-critical liquefaction process of natural gas (NG), which is critical for the main heat exchanger. In this paper, we numerically studied the thermal-hydraulic characteristics of PCHEs with different channel types under the specified condition. The results elucidate that all channels have an enhancement of heat transfer near the pseudo-critical point of NG. All the wavy channels could improve the heat transfer performance of PCHEs, where the trapezoidal channel achieves the largest promotion. Compared with the straight channel, the local heat transfer coefficient could be increased by up to 53% in the trapezoidal channel. Additionally, vortex appeared at the bends of the wavy channels, which greatly increase the local friction loss. Among several channels, the total pressure drop of zigzag, fillet and the sinusoidal channel was almost the same, while that of the trapezoidal channel was the largest. Furthermore, we compared the comprehensive performance of different types of channels and found that the benefit of heat transfer enhancement could not offset the penalty of flow deterioration. Our work provides important guidance for the design of PCHEs employed in FLNG. Full article

Solar air heater is considered to be the most popular and widely used solar thermal system. Solar air heater (SAH) can be used in many applications, ranging from domestic to industrial purposes. However, it seems that the viability of SAH is not feasible due to the following two reasons: (i) the low convective heat transfer coefficient at the absorber plate is the reason that causes a low heat transfer rate to the flowing air, and (ii) the high temperature of the absorber plate insists on high heat losses, thus, reducing the thermal efficiency. The convective coefficient can be augmented by placing turbulators/roughness on the absorber plate, which induces turbulence in the flow passage near the absorber plate by disrupting and destabilizing the laminar sublayer. This comprehensive review has been presented to summarize the studies on artificial roughness/turbulators geometries to enhance the heat transfer rate. Various rib configurations (such as grits, grooves, blockages, baffles, winglets, protrusions, twisted taps, dimples, and mesh wires) and distinct arrangements of rib roughness (such as inclined, transverse, V shape, with gap) have been reviewed to present heat transfer and friction characteristics. Additionally, thermal efficiency and thermohydraulic efficiency (in terms of net effective efficiency) of various artificial roughnesses and rib configurations are presented under distinct operating conditions for comparing purposes. This comparative study has been presented to assess the most desirable ribs and their configurations. On the basis of net effective efficiency, a multiarc rib with gaps is found to be the best configuration among all and have the highest thermal and net effective efficiency of around 79%. Full article
