This study presents a novel approach to manufacture a rigid printed circuit board (PCB) using sustainable polymers. Current PCBs use a fossil-fuel-based substrate, like FR4. This presents recycling challenges due to its composite nature. Replacing the substrate with an environmentally friendly alternative leads to a reduction in negative impacts. Polylactic acid (PLA) and Polyhydroxybutyrate (PHB) biopolymers are used in this study. These two biopolymers have low melting points (130–180 °C, and 170–180 °C, respectively) and cannot withstand the high temperature soldering process (up to 260 °C for standard SAC (SnAgCu, tin/silver/copper) lead free solder processes). Our approach for replacing the PCB substrate is applying the PLA/PHB carrier substrate at the end of the PCB manufacturing process using injection molding technology. This approach involves all the standard PCB processes, including wet etching of the Cu conductors, and component assembly with SAC solder on a thin flexible polyimide (PI) foil with patterned Cu conductors and then overmolding the biopolymer onto the foil to create a rigid base. This study demonstrates the functionality of two test circuits fabricated using this method. In addition, we evaluated the adhesion between the biopolymer and PI to achieve a durable PCB. Moreover, we performed two different end-of-life approaches (debonding and composting) as a part of the end-of-life consideration. By incorporating biodegradable materials into PCB standard manufacturing, the CO₂ emissions and energy consumption are significantly reduced, and installation costs are lowered. Full article

With the enhancement of environmental protection awareness and the implementation of related regulations, lead-free soldering materials are gradually replacing the traditional leaded soldering materials in the field of electronics manufacturing. Sn–Ag soldering materials have become a research hotspot because of their good mechanical properties, solderability, and thermal fatigue reliability, but their high cost limits their large-scale application. The low silver content of the Sn–Ag solder reduces the cost while maintaining an excellent performance. However, as the size of electronic components shrinks and the package density increases, the solder joint spacing decreases, the potential gradient increases, and electrochemical migration (ECM) becomes a key factor affecting the reliability of solder joints. In this study, the ECM failure process was simulated by the water droplet method, and the SEM and XPS analyses were utilized to investigate the ECM mechanism of Sn1.0Ag solder alloys, and the effects of different concentrations of NaCl solutions on their ECM were investigated. The results showed that the ECM of the Sn1.0Ag solder occurred in a 0.01 M NaCl solution, the dendritic composition was pure Sn, and the white precipitate was a mixture of Sn(OH)₂ and Sn(OH)₄. With the increase in the NaCl concentration, the corrosion resistance of the Sn1.0Ag solder alloy decreases and the ECM reaction intensifies, but with a high concentration of the NaCl solution, a large amount of precipitation hinders the migration of Sn ions, resulting in the generation of no dendrites. The present study provides new insights into the ECM behavior of a low-silver-content Sn–Ag solder system. Full article

Soldering with Sn alloys has always been the essential assembly step of microelectronics. The conductive Sn whiskers, which can spontaneously grow from soldering surfaces, mean a considerable reliability risk for microelectronics due to possible short circuit formation between the leads of the components. Since their discovery in 1951, thousands of research studies have been conducted to unravel their growth mechanisms and find effective prevention methods against them. Till 2006, the Sn whisker problem was solved and partially forgotten due to the very effective whisker suppression effect of Pb alloying into the solder materials. The lead-free change gave new impetus to the problem, which was further enhanced by the application of new material systems, growing reliability requirements, and accelerating miniaturization in the 21st century. Our review would like to give an overview of the Sn whisker’s history from the beginning till the latest results, focusing on the suppression solutions by the modification of the solder alloy compositions. Recently, promising results have been reached by alloying Bi and In, which are metals that are the focus of low-temperature soldering, and by composite solders. Full article

This study investigates the potential application of Zn5Al1.5Mg1.5Ti active solder in ultrasonic soldering of Al₂O₃ ceramics and Cu substrates. The research explores the microstructural characteristics, phase composition, and mechanical properties of the solder and the resulting joints. Particular attention is given to the formation mechanisms of the solder–substrate bond and the role of ultrasound activation in enhancing wettability and bond strength. The study aimed to provide a deeper understanding of active soldering processes and their suitability for high-temperature applications. The findings contribute to advancing lead-free soldering technologies for electronic and structural applications. Full article

This study proposes a Sn58Bi/SAC305 layered composite solder designed for low-temperature applications. By alternating high-melting SAC305 and low-melting Sn58Bi layers, the composite achieves a liquidus temperature of ~180 °C, comparable to traditional Sn-Pb solder. Synchrotron X-ray imaging reveals dynamic interfacial interactions, including partial dissolution of SAC305 into molten Sn58Bi and Bi diffusion, mitigating segregation and forming defect-free interfaces with cellular structures. The 7-layer composite exhibits a peak shear strength of 44.3 ± 0.8 MPa at 200 °C, surpassing single Sn58Bi (41.8 ± 1.1 MPa) and SAC305 (31.6 ± 1.4 MPa), attributed to the refined microstructure and uniform dispersion of Ag₃Sn phases. Fracture analysis indicates mixed ductile–brittle failure modes influenced by intermetallic compounds (IMCs). This work provides insights into the role of layered structures in controlling element diffusion and interfacial reactions, advancing the design of low-temperature lead-free solders. Full article

A Sn58Bi composite solder reinforced by Ni nanoparticles was prepared using a mechanical mixing technique, and the thermomigration microstructure and properties of the solder joints were studied. The findings indicate that incorporating an appropriate quantity of Ni nanoparticles can enhance the microstructure of the composite solder and mitigate the coarsening of Bi-phase segregation. At 0.75 weight percent Ni nanoparticle content, the composite solder’s tensile strength is 59.7 MPa and its elongation is 54.6%, both of which are noticeably greater than those of the base solder. When the thermal loading time is 576 h, the shear strength of the composite solder joint is 25.5 MPa, which is 30.1% higher than that of the base solder joint. This study reveals that the shear fracture path shifts from the boundary region between the solder seam and the IMC layer to the IMC layer itself. Concurrently, the fracture mode evolves from a mix of brittle–ductile fracture, characterized by quasi-cleavage, to a predominantly brittle fracture, marked by numerous “rock candy-like” cross-sectional features and secondary cracking. Adding Ni nanoparticles to the Sn58Bi composite solder/Cu solder junction can significantly extend its service life. Full article

Sn-Cu-Ni lead-free solder alloy electrodeposited on copper substrate from a deep eutectic solvent (DES)-based electrolyte under direct current (DC) and pulsed current (PC) was subjected to a reflowing process at the industrial company MIBATRON S.R.L. (Otopeni, Romania). The alteration of the alloy’s composition and anti-corrosive properties upon exposure to the reflow process were investigated via Scanning Electron Microscopy (SEM-EDX), X-ray diffraction (XRD), linear sweep voltammetry (LSV) and electrochemical impedance spectroscopy (EIS). Corrosion studies conducted in sodium chloride solution revealed that the system obtained under the DC plating mode (Sn-Cu-Ni-DC) exhibited enhanced anti-corrosive properties compared to the system obtained under PC (Sn-Cu-Ni-PC) after reflowing. However, prior to reflowing, the opposite effect was observed, with Sn-Cu-Ni-PC showing improved anti-corrosive properties. These changes in anti-corrosive behavior were attributed to the modification of the alloy’s composition during the reflowing process. Full article

In the electronics industry, graphene is applied with modified lead-free solder. This review presents advances in the preparation, strengthening mechanisms, and property characterization of graphene composite solders. Graphene composite solders are divided into two main categories: unmodified graphene and metal-particle-modified graphene. The unmodified graphene composite solders are classified according to the different solder systems. Metal-particle-modified graphene composite solders are classified according to different metal particles. However, there are still challenges with graphene composite solders. The main challenge is the poor bonding of graphene to the substrate and the nonuniform dispersion. Future directions for the development of graphene composite solders are proposed. They can provide some reference for the development of new graphene composite solders in the future. Full article

Carbon nanotubes (CNTs) are being applied with increasing frequency for advanced soldering. They have excellent mechanical, electrical, and thermal properties and are primarily used to reinforce lead-free solders. This paper discusses the strengthening mechanism of CNTs, introduces the preparation methods of CNT composite solders, and focuses on the review of tin-based lead-free solders reinforced with unmodified CNTs and metal-modified CNTs. The addition of CNTs can effectively improve the ultimate tensile strength, microhardness, shear strength, and creep resistance of the solder. However, the practical application of CNT composite solders has been a challenge for researchers for decades. The most significant issue is uniform dispersion due to the large density and surface differences between CNTs and solders. Other concerns are the structural integrity of CNTs and their limited addition amount, solder wettability, and interfacial bonding. CNT composite solders can only be widely used in a real sense when these challenges are properly addressed and overcome. At present, there is a lack of comprehensive reviews covering the structure, the strengthening mechanism, the preparation method of CNT composite solders, and the influence of CNT types on their strengthening effects. Therefore, this paper aims to fill this gap and contribute to solving the problems faced by the application of CNTs in solder. Future work is expected to focus on improving the dispersion and bonding of CNTs and optimizing the preparation method. Full article

Cu-based alloys are one of the most promising substrates to enhance the performance of lead-frame materials. In the present study, the interfacial reactions in the Sn-0.7 wt.% Cu (SC) lead-free solder reacting with Cu-3.3 wt.% Fe (C194), Cu-2.0 wt.% Be (Alloy 25), and Cu-3.3 wt.% Ti (C1990 HP) were investigated. The material underwent a liquid–solid interface reaction, and the reaction time was 0.5 to a few hours at the reaction temperatures of 240 °C, 255 °C, and 270 °C. The morphology, composition, growth rate, and growth mechanism of the intermetallic compounds (IMCs) formed at the interface were investigated in this study. The results showed that the reaction couples of SC/C194, SC/Alloy 25, and SC/C1990 HP formed IMCs, which were the [(Cu, Fe)₆Sn₅ and (Cu, Fe)₃Sn], [(Cu, Be)₃Sn and (Cu, Be)₆Sn₅], and [Cu₆Sn₅] phases, respectively. Finally, the IMC growth mechanism for the SC/C194, SC/Alloy 25, and SC/C1990 HP couples displayed reaction control, grain boundary diffusion control, and diffusion control, respectively. Full article

The application of Sn-0.7Cu-based composite solder in electronic packaging is limited due to its high melting point, poor wettability and low mechanical properties. Herein, we propose a strategy of adding Bi and Cr to improve the solderability of Sn-0.7Cu lead-free solder. The results show that the addition of Bi reduces the melting point of the composite solder. Moreover, the Cr particles adsorb at the interface between solder and substrate, thereby reducing the wetting angle of the composite solder. The wetting angle reaches a minimum value of 25.84° when the content of Cr is 0.2 wt.%. The addition of Bi and Cr changes the microstructure of the composite solder. The nucleation rate of β-Sn rises with the increase of Cr content, thus decreasing the size of β-Sn. Furthermore, the addition of Bi and Cr reduces the thickness of the intermetallic compounds (IMCs). This is due to the adsorption of Bi and Cr at the interface of IMCs hinders the atomic diffusion channels and inhibits the growth of IMCs. Full article

Sn-0.7Cu-based (all in wt.% unless specified otherwise) composite solders functionalized with Ni-coated carbon nanotubes (CNTs) with various weight proportions ranging from 0.01 to 0.2 wt.% were successfully produced. The Ni-coated CNTs were synthesized with discontinuous nickel coating by an improved electroless nickel plating technique. The microstructural, melting and wetting properties of Sn-0.7Cu-based composite solders were evaluated as a function of different amounts of Ni-coated CNTs addition. Compared to Sn-0.7Cu, it was observed that the microstructure of the composite solder added to the Ni-coated CNTs was still composed of the intermetallic compound Cu₆Sn₅ in a β-Sn matrix, but the micromorphology changed greatly. When 0.05 wt.% Ni-coated CNTs were added, the rod-shaped Cu₆Sn₅ particles disappeared, and all appeared in a form of dot-shaped Cu₆Sn₅ particles. DSC results showed only a slight decrease in the melting behavior of the composite solder. Experimental results unveiled that the addition of Ni-coated CNTs to Sn-0.7Cu solder could improve the wettability. With the addition of 0.05 wt.% Ni-coated CNTs, the wetting angle decreased by 13.35%, and an optimum wetting angle of 25.44° was achieved. Full article

Driven by the need to deliver new, lead-free, eco-friendly solder pastes for soldering electronic components to Printed Circuit Boards (PCB), electrically conductive adhesives (ECAs) based on epoxy, carbon nanotubes (CNT), and exfoliated graphite (EG) were designed. The rheology of the adhesives prepared is paramount for the success of the deposition process, which is based on stencil printing. Thus, a rheological analysis of the process was first performed. Then, an experimental protocol was defined to assess the relevant viscoelastic characteristics of the adhesives for stencil printing application. Different composite formulations of epoxy/CNT/EG were produced. Their rheological characteristics were established following the designed protocol and benchmarked with a commercial solder paste. The thermal and electrical properties of the composite formulations were also characterized. As a result, a new, electrically conductive adhesive was delivered with potential to be an eco-friendly alternative to the solder paste currently used in stencil printing of PCB. Full article

SAC305 lead-free solder alloy is widely used in the electronic industry. However, the problems associated with the growth formation of intermetallic compounds need further research, especially at high temperatures. This study investigates the doping of Bismuth into SAC305 in the various compositions of 1, 2, and 3 wt.%. The microstructure in terms of intermetallic compound particles and mechanical properties was examined after thermal aging at temperatures of 100 °C and 200 °C for 60 h. The microstructure examination was observed using scanning electron microscopy, and the chemical composition of each alloy was confirmed with an energy dispersive X-ray. Tensile tests were performed to find the mechanical properties such as yield strength and ultimate tensile strength. The intermetallic compound’s phase analysis was identified using X-ray diffraction, and differential scanning calorimetry was done to study the temperature curves for melting points. Results showed that the addition of Bismuth refined the microstructure by suppressing the growth of intermetallic compounds, which subsequently improved the mechanical properties. The thermal aging made the microstructure coarsen and degraded the mechanical properties. However, the most improved performance was observed with a Bismuth addition of 3 wt.% into SAC305. Furthermore, a decrease in the melting temperature was observed, especially at Bismuth compositions of 3 wt.%. Full article

This paper elucidates the effect of isothermal ageing at temperature of 85 °C, 125 °C and 150 °C for 100, 500 and 1000 h on Sn-3.0Ag-0.5Cu (SAC305) lead-free solder with the addition of 1 wt% kaolin geopolymer ceramic (KGC) reinforcement particles. SAC305-KGC composite solders were fabricated through powder metallurgy using a hybrid microwave sintering method and reflowed on copper substrate printed circuit board with an organic solderability preservative surface finish. The results revealed that, the addition of KGC was beneficial in improving the total thickness of interfacial intermetallic compound (IMC) layer. At higher isothermal ageing of 150 °C and 1000 h, the IMC layer in SAC305-KGC composite solder was towards a planar-type morphology. Moreover, the growth of total interfacial IMC layer and Cu₃Sn layer during isothermal ageing was found to be controlled by bulk diffusion and grain-boundary process, respectively. The activation energy possessed by SAC305-KGC composite solder for total interfacial IMC layer and Cu₃Sn IMC was 74 kJ/mol and 104 kJ/mol, respectively. Based on a lap shear test, the shear strength of SAC305-KGC composite solder exhibited higher shear strength than non-reinforced SAC305 solder. Meanwhile, the solder joints failure mode after shear testing was a combination of brittle and ductile modes at higher ageing temperature and time for SAC305-KGC composite solder. Full article
