The unsteady interactions in rotating detonation turbine engines (RDTE) remain poorly understood. To address this, a 2D numerical model integrating a rotating detonation combustor (RDC) with a first-stage turbine is established to analyze flow structures and aerodynamics under various detonation modes. Proper orthogonal decomposition (POD) reveals intrinsic links between flow features and performance metrics. Results show that while the RDC generates total pressure gain, it induces significant unsteady flow. Guide vanes partially suppress pressure fluctuations but cannot eliminate total pressure losses or circumferential non-uniformity, reducing rotor efficiency. Increasing detonation wave numbers decreases total pressure gain at rotor inlet but improves flow uniformity: the counterclockwise double-wave mode exhibits optimal performance (27.9% work gain, 5.0% instability, 86.4% efficiency), whereas the clockwise single-wave mode shows the poorest (20.9% work gain, 11.8% instability, 84.0% efficiency). POD analysis indicates first-order modes represent time-averaged flow characteristics, while low-order modes capture non-uniform pressure distributions and pairing phenomena, reconstructing wave propagation. The study highlights discrepancies between turbine inlet’s actual unsteady flow and conventional quasi-steady design assumptions, proposing enhancing mean flow characteristics and increasing first-mode energy proportion to improve work extraction. These findings clarify the detonation wave mode–turbine performance correlation, offering insights for RDTE engineering applications. Full article

High-temperature pipelines, as core facilities in the fields of petrochemical and power, are constantly exposed to extreme working conditions ranging from 450 to 600 °C, facing risks of stress corrosion, creep damage, and other defects. Traditional shutdown inspections are time-consuming and costly. Meanwhile, existing electromagnetic acoustic transducers (EMATs) are restricted by their high-temperature tolerance (≤500 °C) and short-term stability (effective working duration < 5 min). This paper proposes a high-frequency circumferential guided wave (CLamb wave) EMAT based on a Halbach permanent magnet array. Through magnetic circuit optimization (Halbach array) and multi-layer insulation design, it enables continuous and stable detection on the surface of 600 °C pipelines for 10 min. The simulations revealed that the Halbach array increased the magnetic flux density by 1.4 times and the total displacement amplitude by 2 times at a magnet’s large lift-off (9 mm). The experimental results show that the internal temperature of the sensor remained stable below 167 °C at 600 °C. It was capable of detecting the smallest defect of a φ3 mm half-hole (depth half of the wall thickness), with a signal attenuation rate of only 0.32%/min. The signal amplitude of Q235 pipelines under high-temperature short-term detection (<5 min) was 1.5 times higher than that at room temperature. However, material degradation under high temperature led to insufficient long-term stability. This study breaks through the bottleneck of long-term detection of high-temperature EMATs, providing a new scheme for efficient online detection of high-temperature pipelines. Full article

The anti-corrosion layer of the pipe provides corrosion resistance and extends the lifespan of the whole pipeline. Heat-shrinkable tape is primarily used as the pipeline joint coating material bonded to the pipeline weld connection position after heating. Delineating the bonding strength and assessing the quality of the bonded structure is crucial for pipeline safety. A detection technology based on nonlinear ultrasound is presented to quantitatively evaluate the bonding strength of a steel-EVA-polyethylene three-layer annulus bonding structure. Using the Floquet boundary condition, the dispersion curves of phase velocity and group velocity for a three-layer annulus bonding structure are obtained. Additionally, wave structure analysis is employed in theoretical study to choose guided wave modes that are appropriate for detection. In this paper, guided wave amplitude, frequency attenuation, and nonlinear harmonics are used to evaluate the structural bonding strength. The results reveal that the detection method based on amplitude and frequency attenuation can be used to preliminarily screen the poor bonding, while the acoustic nonlinear coefficient is sensitive to bonding strength changes. This study introduces a comprehensive and precise pipeline joint bonding strength detection system leveraging ultrasonic-guided wave technology for pipeline coating applications. The detection system determines the bonding strength of bonded structures with greater precision than conventional ultrasonic inspection methods. Full article

At present, researchers in the field of pipeline inspection focus on pipe wall defects while neglecting pipeline defects in special situations such as welds. This poses a threat to the safe operation of projects. In this paper, a multi-node fusion and modal projection algorithm of steel pipes based on guided wave technology is proposed. Through an ANSYS numerical simulation, research is conducted to achieve the identification, localization, and quantification of axial cracks on the surface of straight pipelines and internal cracks in circumferential welds. The propagation characteristics and vibration law of ultrasonic guided waves are theoretically solved by the semi-analytical finite element method in the pipeline. The model section is discretized in one-dimensional polar coordinates to obtain the dispersion curve of the steel pipe. The T(0,1) mode, which is modulated by the Hanning window, is selected to simulate the axial crack of the pipeline and the L(0,2) mode to simulate the crack in the weld, and the correctness of the dispersion curve is verified. The results show that the T(0,1) and L(0,2) modes are successfully excited, and they are sensitive to axial and circumferential cracks. The time–frequency diagram of wavelet transform and the time domain diagram of the crack signal of Hilbert transform are used to identify the echo signal. The first wave packet peak point and group velocity are used to locate the crack. The pure signal of the crack is extracted from the simulation data, and the variation law between the reflection coefficient and the circumferential and radial dimensions of the defect is calculated to evaluate the size of the defect. This provides a new and feasible method for steel pipe defect detection. Full article

In order to solve the problem that small defects hidden behind pipeline support parts are difficult to detect effectively in small spaces, such as offshore oil platforms, a meander-coil-type dual magnetic group circumferential magnetostrictive guided wave transducer is developed in this paper. The transducer, which consists of a coil, two sets of permanent magnets, and a magnetostrictive patch, can excite a high-frequency circumferential shear horizontal (CSH) guided wave. The energy conversion efficiency of the MPT is optimized through magnetic field simulation and experiment, and the amplitude of the defect signal is enhanced 1.9 times. The experimental results show that the MPT developed in this paper can effectively excite and receive CSH₂ mode guided waves with a center frequency of 1.6 MHz. Compared with the traditional PPM EMAT transducer, the excitation energy of the transducer is significantly enhanced, and the defects of the 2 mm round hole at the back of the support can be effectively detected. Full article

Ultrasonic-guided waves (UGWs) in defective pipes are subject to severe coherent noise caused by imperfect detection conditions, mode conversion, and intrinsic characteristics (dispersion and multiple modes), inducing the limited performance of anomaly imaging. To achieve the high resolution and accuracy of anomaly imaging, a multi-strategy hybrid sparse reconstruction (MHSR) method based on spatial–temporal sparse wavenumber analysis (ST-SWA) is proposed. MHSR leverages the capability of ST-SWA to extract the wavenumber dispersion curves, thereby providing a more refined and precise search space for MHSR. Furthermore, it mitigates the impact of coherent noise by conducting dispersion compensation on the reconstructed signal. The sparse compensated signals through MHSR are employed for sparse reconstruction imaging. To validate the efficacy of the proposed method, UGW testing is performed on the defective steel pipe, and the results demonstrate the significant enhancement of anomaly imaging in defect resolution and positioning accuracy. The lowest estimated errors for axial and circumferential defect positions are 10 mm and 4 mm, respectively. Full article

When pipe defects are generated above the T-type support structure location, it is difficult to distinguish the reflection signals caused by the weld bead at the support structure from the reflection echoes of pipe defects. Therefore, in order to effectively detect pipe defects, a waveform subtraction method with a circumferential shear horizontal (CSH) guided wave is proposed, which is generated by an electromagnetic acoustic transducer (EMAT). First, a CSH₀ guided wave mode with a center frequency of 500 kHz is selected to establish a three-dimensional model with and without pipe defects above the support structure. Following this, the influence of different widths of support structures on the echo signal is compared. Moreover, simulation and experimental results are used to compare the influence of different welding qualities on the detection results. Finally, the waveform subtraction method is used to process the simulation and experimental signals, and the influence of pipe defects with different lengths and depths is discussed. The results show that the non-through crack defect of 5 mm × 1 mm (length × depth) can be detected. The results show that this method can effectively detect the cracks by eliminating the influence of the weld echo, which provides a new concept for the detection of the defect above the support structure. Full article

Ultrasonic guided waves represent a new development in the field of non-destructive testing. Longitudinal guided waves are mostly used to monitor the damage of steel bars, but the received signal is usually degraded and noisy owing to its dispersive propagation and multimodal behavior, making its implementation and location challenging. The torsional mode of T (0, 1) is not dispersive in the propagation of a steel bar and only produces circumferential displacement. It was chosen, in this study, to conduct guided wave-based damage monitoring on steel bars to reduce the signal processing complexity. The defects of steel bars, including circular surface defects, internal defects, and uniform damage defects, were thoroughly investigated, respectively, using numerical simulation. The waves were excited and received using the pitch-and-catch technique and the collected monitoring signals were processed using Hilbert transformation to highlight the amplitude and time-of-flight values of the wave signals, which were used for defect identification. In this paper, the reflectivity of guided waves is compared between torsional waves and longitudinal waves, in each case. The impact of defect size changes on damage monitoring is studied and the sensitivity of both the wave frequency and the wave mode (L and T) is also discussed. The results show that the monitoring method based on the torsional wave T (0, 1) is more sensitive to surface defects than the conventional method based on longitudinal waves. The reflectivity of the torsional wave T (0, 1) can be twice that of the longitudinal wave L (0, 1) when the depth of the defect in the circumferential grooves is less than 50% of the diameter of the steel bar. It is more sensitive to shallow surface defects within half of the bar’s radius, and it can also effectively identify defects under the conditions of the uniform damage defects of steel bars, even when the measurements are heavily noise-polluted. This proves the superiority of the torsional guided wave T (0, 1) in defect monitoring and provides a theoretical basis for the application of the torsional guided wave T (0, 1) in actual monitoring. Full article

Periodic permanent magnet(PPM) electromagnetic acoustic transducers (EMATs) are commonly employed for axial defect inspection in pipelines. However, the lowest-order shear horizontal waves (SH0) guided waves have difficulties in distinctly differentiating internal and external defects. To enhance the signal-to-noise ratio and resolution, a unidirectional electromagnetic acoustic transducer (EMAT) based on Circumferential Lamb waves (CLamb waves) is developed. Through structural parameter optimization and excitation frequency adjustment, high-amplitude and low-dispersion CLamb waves are successfully generated in the high-frequency-thickness product region of the dispersion curve. Finite element simulations and experimental validation confirm the capability of this EMAT in exciting CLamb waves for the detection of crack-like defects. Experimental results demonstrate that the excitation efficiency of the CLamb EMAT exceeds that of the periodic permanent magnet electromagnetic acoustic transducer by more than tenfold. The defect reflection signal of the CLamb EMAT exhibits higher resolution and more significant amplitude compared to the PPM EMAT. The integration of this method with SH0 mode detection allows for the inspection of both internal and external defects in pipelines, offering a new avenue for EMAT applications in pipeline inspection. Full article

Ultrasonic guided wave technology has been successfully applied to detect multiple types of defects in pipes. However, the circumferential location and coverage of a defect are less studied because it is difficult to determine. In this study, the fundamental torsional mode T (0, 1) is selected to conduct monitoring of the circumferential defect in pipelines because of its almost non-dispersive property. A radar map of the peak wave signals at 30 circumferential positions is proposed to detect the damage. The circumferential defect of a steel pipe is thoroughly investigated using numerical simulation. First, the circumferential positioning of defects in various areas of the pipe is studied. Second, the results are compared to those based on longitudinal guide waves. Finally, the circumferential coverage of a defect in the pipeline is determined. The waves are excited and received using the pitch–catch approach, and the collected monitoring signals are processed using the Hilbert transformation. According to the findings, the circumferential defect in the pipe can be effectively identified from a ‘T’ shape in the radar image, and the monitoring method by the torsional guided wave is superior to the longitudinal wave method. The results clearly demonstrate the advantages of torsional guided waves in defect monitoring. The proposed method is expected to provide a promising solution to circumferential damage identification in pipelines. Full article

Pipeline structures are susceptible to corrosion, leading to significant safety, environmental, and economic implications. Existing long range guided wave inspection systems often fail to detect footprints of the concentrated defects, which can lead to leakage. One way to tackle this issue is the utilization of circumferential guided waves that inspect the pipe’s cross section. However, achieving the necessary detection resolution typically necessitates the use of high-order modes hindering the inspection data interpretation. This study presents the implementation of an ultrasonic technique capable of detecting and classifying wall thinning and concentrated defects using high-order guided wave modes. The technique is based on a proposed phase velocity mapping approach, which generates a set of isolated wave modes within a specified phase velocity range. By referencing phase velocity maps obtained from defect-free stages of the pipe, it becomes possible to observe changes resulting from the presence of defects and assign those changes to the specific type of damage using artificial neural networks (ANN). The paper outlines the fundamental principles of the proposed phase velocity mapping technique and the ANN models employed for classification tasks that use synthetic data as an input. The presented results are meticulously verified using samples with artificial defects and appropriate numerical models. Through numerical modeling, experimental verification, and analysis using ANN, the proposed method demonstrates promising outcomes in defect detection and classification, providing a more comprehensive assessment of wall thinning and concentrated defects. The model achieved an average prediction accuracy of 92% for localized defects, 99% for defect-free cases, and 98% for uniform defects. Full article

A circumferential shear horizontal (CSH) guide wave-detection method using a periodic permanent magnet electromagnetic acoustic transducer (PPM EMAT) was proposed to solve the defect detection located at the inside of the pipe welded by supporting structures. Firstly, a low-frequency CSH₀ mode was selected to establish a three-dimensional equivalent model for the defect detection to cross the pipe support, and the ability of the CSH₀ guided wave to propagate through the support and weld structure was analyzed. Then, an experiment was used for the further exploration of the influence of different sizes and types of defects on detection after using the support, as well as the ability of detection mechanism to cross different pipe structures. The results show that both the experiment and the simulation received a good detection signal at 3 mm crack defects, which proves that the method can detect the defects by crossing the welded supporting structure. At the same time, the support structure shows a greater impact on the detection of small defects than the welded structure. The research in this paper can provide ideas for guide wave detection across the support structure in the future. Full article

Detection and criticality assessment of defects appearing in inaccessible locations in pipelines pose a great challenge for many industries. Inspection methods which allow for remote defect detection and accurate characterisation are needed. Guided wave testing (GWT) is capable of screening large lengths of pipes from a single device position, however it provides very limited individual feature characterisation. This paper adapts Plane Wave Imaging (PWI) to pipe GWT to improve defect characterization for inspection in nearby locations such as a few metres from the transducers. PWI performance is evaluated using finite element (FE) and experimental studies, and it is compared to other popular synthetic focusing imaging techniques. The study is concerned with part-circumferential part-depth planar cracks. It is shown that PWI achieves superior resolution compared to the common source method (CSM) and comparable resolution to the total focusing method (TFM). The techniques involving plane wave acquisition (PWI and CSM) are found to substantially outperform methods based on full matrix capture (FMC) in terms of signal-to-noise ratio (SNR). Therefore, it is concluded that PWI which achieves good resolution and high SNR is a more attractive choice for pipe GWT, compared to other considered techniques. Subsequently, a novel PWI transduction setup is proposed, and it is shown to suppresses the transmission of unwanted S0 mode, which further improves SNR of PWI. Full article

The electromagnetic guided wave transducer has been widely used in pipeline detection in recent years due to its non-contact energy conversion characteristics. Based on the Weidemann effect, an electromagnetic guided wave transducer that can realize the locating defect of the steel pipe was provided. Firstly, the principle of the transducer was analyzed based on the Weidemann effect. The basic structure of the transducer and the basic functions of each part were given. Secondly, the key structural parameters of the transducer were studied. Based on the size of the magnets and the coils, a protype electromagnetic guided wave transducer based on Wiedemann effect was developed. Finally, the experiments were carried out on the steel pipe with a defect using the developed transducer. The results show that the transducer can actuate and receive the T(0,1) and T(1,1) modes in the steel pipe. The axial positioning of the defect is located by moving the transducer axially. The circumferential positioning of the defect is located by rotating the transducer. Additionally, missed detection can be effectively avoided by rotating the transducer. Full article

The methodology based on reflected guided-wave by a reflector associated with an increase or a decrease in the cross-sectional area has the challenge of determining their location and identity. This paper presents a numerical investigation of a method for locating and identifying the reflector based on guided-wave circumferential scanning and phase characteristics. To determine the axial and circumferential positions of the reflector within the pipeline, the procedures of the guided wave-based circumferential scanning were presented, including data preprocessing, median filter, image smoothing and binary processing. Through theoretical analysis, we obtained the phase relationship between the guided-wave excitation signal and reflection signals generated by a reflector, such as corrosion, crack, weld and support, which caused the change in the cross-sectional area. Consequently, an algorithm based on the phase characteristics was proposed to determine the change and type of reflector. The spatial distances were calculated between the guided wave excitation signals with different phases and the concerned reflection signals, subsequently identifying the change and type of the reflector by comparing the distance values. An identification index named the reliable index for the character of the reflector (RICR) was defined to evaluate the reliability of the predicted results. Numerical and finite element simulation validations of the proposed method were performed. It has been found that if RICR was larger than 1.05, the results predicting the reflector type were reliable. The proposed method was found to be superior relative to the conventional correlation coefficient method according to the numerical results. Finally, the simulation results demonstrated that the proposed method could be potentially applied for locating and identifying reflectors in pipelines. Full article
