This article presents a comprehensive analysis of the technical characteristics of advanced versatile materials used in chipless radio-frequency identification (RFID) tags and antennas. The focus is on materials that are used as radiators and substrates. Crucial aspects include flexibility, weight, size, gain, environmental sustainability, efficiency, fabrication time and type, and cost. A comprehensive set of tables are presented that summarize and compare material properties. The materials include flexible high-tech ink substances, graphene, and liquid crystals, as well as metamaterials which possess properties that allow for an increased bandwidth. Printing techniques are discussed for high-performance high-resolution fabricated tags. This paper contributes by systematically comparing emerging materials for chipless RFID tags, highlighting their impact on performance and sustainability. It also provides practical guidance for material selection and fabrication techniques to enable next-generation wireless applications. It presents a broad understanding of various materials and their use. The paper provides direction for the deployment and utilization of inexpensive passive chipless RFID tags in future intelligent wireless networks. The advancement of chipless RFID is largely driven by the development of innovative materials, especially in the realm of advanced materials and smart materials, which enable the creation of more cost-effective, flexible, and scalable RFID systems. Full article

The accurate detection and reliable performance of chipless radio frequency identification (RFID) tags and sensors present significant challenges due to their inherently low radar cross section (RCS) and pronounced mutual coupling effects. These limitations adversely influence the quality (Q) factor and overall detectability, complicating the optimisation of chipless RFID systems for practical applications. This study investigates the performance characteristics and trade-offs among RCS, Q-factor, and detectability in Pi-shaped array configurations of chipless RFID tags. A comprehensive analysis of various array configurations is conducted, supplemented by a link budget evaluation to elucidate how different array structures impact system performance. The simulation results reveal that planar arrays outperform linear arrays in both RCS and Q-factor, highlighting essential trade-offs between tag identification range and angular coverage, which are influenced by array size and electromagnetic coupling. The findings emphasise optimising resonance quality and scattering efficiency to tailor chipless RFID systems for specific application requirements. This research provides valuable insights into the design and operation of chipless RFID arrays, contributing to their advancement in practical applications. Full article

RFID technology has been widely researched and used for structural health applications because of its compact, wireless, and scalable nature. This technology is divided into chipped and chipless sensors. Chipped sensors are costly due to their chipped tags, have narrowband operations, and contribute to shortcomings in detection capability. Chipless tags provide real-time monitoring of cracks in harsh environments like high-temperature areas and high electromagnetic interference areas. This paper presents a design of a novel chipless hybrid circular-hexagon sensor that uses the frequency signature-based method for metal crack detection and characterization using wideband frequency. This sensor is small in size (16 mm × 16 mm × 1.4 mm) and easily mountable in hard-to-reach areas. It is a low-cost, passive chipless sensor that can wirelessly monitor the cracks in metallic structures. The radar cross-section of the chipless tag shows a shift in the resonant frequency of the tag under crack and no crack conditions. Key contributions of this work are that through simulations and experimental investigation, the tag is shown to be able to detect mm-scale cracks, validating the concept and correlating the presence and size of the cracks based on the shift in resonant frequencies in which a pair of Vivaldi antennas are used as a transmitter and receiver to connect to the VNA. The designed small sensor tag is tested in a benchtop setup with no prior calibration, imitating the real-time environment conditions for crack detection. Full article

Frequency encoding chipless Radio Frequency Identification (RFID) tags have been frequently using the radar cross section (RCS) parameter to determine the resonant frequencies corresponding to the encoded information. Recent advancements in chipless RFID design have focused on the generation of multiple frequencies without considering the frequency position and signal amplitude. This article proposes a novel method for chipless RFID tag design, in which the RCS response can be located at an exact position, corresponding to the desired encoding signal spectrum. To achieve this, the empirical Taguchi method (TM), in combination with particle swarm optimization (PSO), is used to automatically search for optimal design parameters for chipless RFID tags with a fast response time, to comply with the frequency encoding requirements in the presence of the mutual coupling effect. The proposed design method is validated using I-slotted chipless tag structures that are fabricated and measured with different sets of resonant frequencies. Full article

Chipless RFID tags have attractive low-cost advantages. However, traditional RFID anti-collision algorithms cannot be applied due to a lack of computing and processing capabilities. Problems with multitag detection must be solved to commercialize chipless RFID tags. In this paper, an innovative method for frequency-domain chipless RFID tag detection is proposed. The tags’ scattered signals are processed via wavelet analysis, and a time–frequency plot that can read the code is obtained. When the distance between tags is too close to distinguish in the time–frequency plot, independent component analysis is used to separate individual scattered signals from mixed echo signals; then, the code is read by means of wavelet analysis. To validate the proposed method, C-shaped frequency-domain chipless RFID tag models and a multitag detection simulation scenario were constructed in selected software. The short-time matrix pencil method (STMPM), short-time Fourier transform (STFT), and the proposed method were compared. When the tag spacing is 0.05 m, the code can be read successfully. Compared with the STMPM, the proposed method greatly reduces the computational quantity and shortens the reading time. Furthermore, adjustment of the window width and search step parameters is avoided. Full article

Chipless radio frequency identification (RFID) technology is expected to replace barcode technology due to its ability to read in non-line-of-sight (NLOS) situations, long reading range, and low cost. Currently, there is extensive research being conducted on frequency-coded (FC) co-polarized radar cross-section (RCS)-based tags, which are widely used. However, detecting co-polarized chipless RFID tags in cluttered environments is still a challenge, as confirmed by measuring two co-polarized tags in front of a perfect metal reflector ($30.5\mathrm{cm}\times 22.5\mathrm{cm}$). To address this challenge, a realistic mathematical model for a chipless RFID system has been developed that takes into account the characteristics of the reader and the tag, as well as reflections from cluttered objects. This extensive mathematical model developed for linear chipless RFID systems in clutter scenarios holds the potential to greatly assist researchers in their exploration of RCS-based tags. By relying solely on simulations, this model provides a tool to effectively analyze and understand RCS-based tags, ultimately simplifying the process of generating more authentic tag designs. This model has been simulated and verified with measurement results by placing a single flat metal reflector behind two co-polarized one-bit designs: a dipole array tag and a square patch tag. The results showed that the interfering signal completely overlaps the ID of the co-polarized tag, severely limiting its detectability. To solve this issue, the proposed solution involves reading the tag in cross-polarization mode by etching a diagonal slot in the square patch tag. This proposed tag provides high immunity to the environment and can be detected in front of both dielectric and metallic objects. Full article

This paper presents a novel methodology for designing high-capacity frequency domain chipless RFID tags based on the backscattering principle. The tag consists of multiple square open-loop resonators loaded with a varying number of square metallic patches to form a mesh structure. Thus, in contrast to conventional designs, the overall physical size of each resonator remains fixed and does not change with respect to its operating resonant frequency. The RCS response of the proposed tag can be easily manipulated by varying the loading factor of each resonator. The tag size is further miniaturized by placing resonators on both sides of the substrate used. The tag configuration with resonators arranged in the form of a single row (4 × 1) printed on both sides of the substrate is finally chosen for maximum robustness and efficiency. The frequency shift coding (FSC) technique is used to encode more than one bit per resonator by using segments within sub-bands. The proposed tag encodes 16-bit data in a frequency band from 5.9 to 10.5 GHz and has a very high code density of 23.51 bits/cm² and a spectral efficiency of 3.47 bits/GHz. The design methodology is novel and leads to a very efficient chipless RFID tag that can be used in a variety of high-data-capacity applications. Full article

This paper presents a unique geometry of a chipless radio frequency identification (RFID) tag for encoding a large number of bits in a very small form factor. The tag geometry consists of semi-octagonal copper strips, sequentially laid on a single side of an ultra-thin substrate. A unique and robust encoding mechanism for the tag identification (ID) is proposed. The operating frequency spectrum of the tag ranges from 3.1 to 10.5 GHz. The tag is compact, having an overall size of 14.5 × 28 mm². The proposed tag exhibits very high code density of 9.85 bits/cm² and spectral efficiency of 5.4 bits/GHz. The unique geometric configuration of the proposed tag allows it to encode up to 40 bits of data as an RCS signature. This chipless RFID tag seems to be a potential candidate for a wide range of modern RFID applications. Full article

In the world of digitization, different objects cooperate with the Internet of Things (IoT); these objects also amplify using sensing and data processing structures. Radio frequency identification (RFID) has been identified as a key enabler technology for IoT. RFID technology has been used in different conventional applications for security, goods storage, transportation and asset management. In this paper, a fully inkjet-printed chipless radio frequency identification (RFID) sensor tag is presented for the wireless identification of tagged objects. The dual polarized tag consists of two resonating structures functioning wirelessly. One resonator works for encoding purpose and other resonator is used as a CO₂/temperature sensor. The sensing behavior of the tag relies on the integration of a meandered structure comprising of multi-wall carbon nanotubes (MWCNT). The MWCNT is highly sensitive to CO₂ gas. The backscattered response of the square-shaped cascaded split ring resonators (SRR) is analyzed through a radar cross-section (RCS) curve. The overall tag dimension is 42.1 mm × 19.5 mm. The sensing performance of the tag is examined and optimized for two different flexible substrates, i.e., PET and Kapton^®HN. The flexible tag structure has the capability to transmit 5-bit data in the frequency bands of 2.36–3.9 GHz and 2.37–3.89 GHz, for PET and Kapton^®HN, respectively. The proposed chipless RFID sensor tag does not require any microchip or a power source, so it has a great potential for low-cost and automated temperature/CO₂ sensing applications. Full article

The analysis and experimental verification of the properties of four types of chipless RFID tags with an increased RCS response level designed and fabricated by conductive screen-printing using silver paste on foil and paper substrates was performed. The analytical formula for the quality factor of microstrip structures with a reduced conductivity of the metal layers was used to predict the changes and detectability of the backscattered RCS response. The analysis provides insight into the limitations and outlines the possibilities of chipless structures screen-printed on foil and paper substrates, which can be of significant benefit to further reducing the cost, and to speed up the production of these tags for identification and sensing purposes. Full article

The paper presents a proof-of-concept of a millimeter-wave identification system based on Van Atta array tags in the 60 GHz band. For interrogation of the tags, a vector network analyzer and a measurement transceiver were employed in alternative test configurations. The design, fabrication and measurements of co- and cross-polarized Van Atta arrays are presented in the paper. They can be treated as simple chipless RFID tags with frequency-response-based identification. Tags with various resonance frequencies are designed by scaling an optimized base model. The designed 57–67 GHz co-polarized and cross-polarized tags have small dimensions of approximately 23 mm × 21 mm and 40 mm × 25 mm, and they exhibit radar cross-section (RCS) levels of −16 dBsm and −21 dBsm, respectively. Owing to the retrodirective properties of Van Atta arrays, the RCS can be maintained at a high level within a broad range of angles of incidence. The system was validated in an anechoic chamber where the spectral responses of all the manufactured tags can be clearly distinguished from the environment, enabling their identification. Tests in a reflective environment were also performed, and they have shown that only the cross-polarized tags could be detected and identified in the presence of reflections from the tags’ surroundings. Full article

In this paper, a concept of a reconfigurable chipless radio frequency identification (RFID) sensor tag for detecting solvent vapors/gas in IoT applications was presented. The concept was based on the authors’ previously published rectangular loop structure equipped with a U-folded dipole loaded with a glide-symmetrical interdigital capacitor coated with a thin layer of tetrasulfonated copper phthalocyanine deposited as a sensing layer to improve the sensing capability in the presence of acetone vapor. In order to further maximize the sensitivity of the designed structure to the desired solvent, a circuit for a central frequency adjustment using a radio frequency varactor diode biased with a wireless power transfer (WPT) was designed. By varying the DC bias of the diode, a continuous tunable range of approximately 200 MHz was achieved. The proposed reconfigurable wireless sensor tag was manufactured and the frequency shift was verified by measurement. The proposed external frequency control can be applied to a wide class of electrical resonators. Full article

Coating degradation is a critical issue when steel surfaces are subject to weathering. This paper presents a chipless, passive antenna tag, which can be applied onto organically coated steel. Simulations indicated that changes associated with organic coating degradation, such as the formation of defects and electrolyte uptake, produced changes in the backscattered radar cross section tag response. This may be used to determine the condition of the organic coating. Simulating multiple aging effects simultaneously produced a linear reduction in tag resonant frequency, suggesting coating monitoring and lifetime estimation may be possible via this method. For coatings thinner than calculations would suggest to be optimum, it was found that the simulated response could be improved by the use of a thin substrate between the coated sample and the antenna without vastly affecting results. Experimental results showed that changes to the dielectric properties of the coating through both the uptake of water and chemical degradation were detected through changes in the resonant frequency. Full article

A 32-bit chipless RFID tag operating in the 4.5–10.9 GHz band is presented in this paper. The tag has a unique multiple-arc-type shape consisting of closely packed 0.2 mm wide arcs of different radii and lengths. The specific tag geometry provides multiple resonances in frequency domain of an RCS plot. A frequency domain coding technique has also been proposed to encode the tag’s RCS signature into a 32-bit digital identification code. The tag has an overall dimension of 17.9 × 17.9 mm², resulting in a high code density of 9.98 bits/cm² and spectral efficiency of 5 bits/GHz. The proposed tag is built on a low loss substrate bearing a very small footprint, thereby making it extremely suitable for large-scale product identification purposes in future chipless RFID tag systems. Full article

This work presents the design and analysis of newly developed reconfigurable, flexible, inexpensive, optically-controlled, and fully printable chipless Arabic alphabet-based radio frequency identification (RFID) tags. The etching of the metallic copper tag strip is performed on a flexible simple thin paper substrate (ϵ_r = 2.31) backed by a metallic ground plane. The analysis of investigated tags is performed in CST MWS in the frequency range of 1–12 GHz for the determination of the unique signature resonance characteristics of each tag in terms of its back-scattered horizontal and vertical mono-static radar cross section (RCS). The analysis reflects that each tag has its own unique electromagnetic signature (EMS) due to the changing current distribution of metallic resonator. This EMS of each tag could be used for the robust detection and recognition of all realized 28 Arabic alphabet tags. The study also discusses, for the first time, the effect of the change in font type and size of realized tags on their EMS. The robustness and reliability of the obtained EMS of letter tags is confirmed by comparing the RCS results for selective letter tags using FDTD and MoM numerical methods, which shows very good agreement. The proposed tags could be used for smart internet of things (IoT) and product marketing applications. Full article
