Search Results (30)

Wearable antennas for wireless sensor network (WSN) applications require circularly polarized (CP) radiation to maintain stable communication link under human body movement and complex environments. However, many existing wearable CP antennas rely on either linearly polarized (LP) or CP radiator with a single axial ratio (AR) mode combined with external polarization conversion structures, which limit the achievable axial ratio bandwidth (ARBW). In this work, an all-textile wideband CP antenna with a square-ring notched slot radiator, a 50 Ω microstrip line, and a 3 × 3 nonuniform metasurface (MTS) is proposed for 5.85 GHz WSN applications. Unlike conventional CP generation approaches, the square-ring notched slot, analyzed using characteristic mode analysis (CMA), directly excites three distinct AR modes, enabling potential wideband CP radiation. The nonuniform MTS further improves IBW performance by exciting additional surface wave resonances. Moreover, the nonuniform MTS further enhances ARBW by redirecting the incident wave into an orthogonal direction with equivalent amplitude and a 90° phase difference at higher frequency region. The proposed antenna is composed of conductive textile and felt substrates, offering flexibility for wearable applications. The proposed antenna is measured in free space, on human bodies, and fresh pork in an anechoic chamber. The measured results show a broad IBW and ARBW of 84.52% and 43.56%, respectively. The measured gain and radiation efficiency are 4.47 dBic and 68%, respectively. The simulated specific absorption rates (SARs) satisfy both US and EU standards. Full article

This paper presents a design method of integrating scattering cancellation with array-level modification techniques for broadband RCS reduction (RCSR) of an array antenna. Taking a circular patch element as an example to explain how the RCSR method is used, an L-shaped feeding structure is adopted, with a dielectric substrate of Arlon Diclad 880 (tm). First, two elements with equal scattering amplitude but opposite-phase characteristics are proposed by adjusting the radiation patch dimensions and loading slots on the small patch based on characteristic mode analysis (CMA). Through arrangement of these two elements in a 2 × 2 array configuration, effective RCSR is demonstrated across 3.5–9.5 GHz. To further broaden the RCSR bandwidth, the 2 × 2 array is modified again on the ground plane using CMA. Through the integration of scattering cancellation and array-level modification techniques, a broadband RCSR design of the array antenna is realized across 2.5–11 GHz. To demonstrate the universality of the design method, 2 × 2 and 4 × 4 array antennas are designed, fabricated, and tested. The 2 × 2 array antenna can realize an average RCSR of 10.3 dB and a peak RCSR of 22 dB across 2.5–11 GHz. The 4 × 4 array antenna can realize an average RCSR of 8 dB and a peak RCSR of 23 dB across 2.5–10.5 GHz. Meanwhile, the transmission and radiation performance remains basically unchanged. The 2 × 2 array antenna works from 3.76 GHz to 5.45 GHz (36.7%) and the 4 × 4 array antenna works from 3.80 GHz to 5.30 GHz (31.1%). Their gains are 9.9 dBi for the 2 × 2 array antenna and 15.9 dBi for the 4 × 4 array antenna at 4.5 GHz. Measured results show a good agreement with calculated ones, which verifies the effectiveness and correctness of the design method. Full article

In this study, a dual-band dual-mode antenna without any complex feeding network is proposed. The proposed antenna is a type of cascaded cavity antenna, which introduces periodically arranged shorting vias. Using characteristic mode analysis (CMA), the modal behaviors of the proposed antenna without external sources, including modal significance, modal radiation patterns, and modal currents, are analyzed in detail. By setting two properly placed coaxial ports based on CMA, a dual-band antenna with different radiation patterns is realized by exciting different modes at low- and high-frequency bands, allowing the proposed antenna to have a pattern diversity characteristic. Meanwhile, when port 1 is excited, the radiation patterns at 3 and 5 GHz are symmetrical to the radiation patterns when port 2 is excited and vice versa. The prototype is fabricated and investigated experimentally. A good agreement between the simulated and measured results proves the effectiveness and practicality of the proposed antenna. Full article

This paper proposes a novel high-gain, wideband, circularly polarized (CP) metasurface (MTS) antenna. The antenna is composed of a centrally symmetric MTS and a slot-coupled feeding network. Through characteristic mode analysis (CMA), parasitic patches and mode-suppressing patches are added around the MTS to enhance the desired modes and suppress the unwanted modes. Subsequently, a feeding network that merges a ring slot with an L-shaped microstrip line is utilized to excite two orthogonal modes with a 90° phase difference, thereby achieving CP and high-gain radiation. Finally, a prototype with dimensions of 0.9λ₀ × 0.9λ₀ × 0.05λ₀ is fabricated and tested. The measured results demonstrate an impedance bandwidth (IBW) of 39.5% (4.92–7.37 GHz), a 3 dB axial ratio bandwidth (ARBW) of 33.1% (5.25–7.33 GHz), and a peak gain of 9.4 dBic at 6.9 GHz. Full article

In this paper, a printed hybrid-mode antenna for dual-band circular polarization (CP) is proposed. In the proposed antenna, one T-shaped element is fed by a coplanar waveguide and one L-shaped element is loaded to the ground plane. The relationship between the antenna’s geometric parameters and the circular polarization characteristic (axial ratio) is examined through electric current distribution and radiation field components. In addition, the antenna’s resonant modes are investigated through characteristic mode analysis (CMA). Through parametric studies, the range of two frequency ratios is explored, revealing that the antenna operates as a dual-band single-sense CP antenna, even in ranges where the two frequency ratios (the ratio of high frequency to low frequency) are smaller compared to antennas in other studies. The proposed antenna has a frequency ratio of less than 1.5 between the two frequencies and can be flexibly designed. The proposed antenna is designed for the 2.5 GHz band and 3.5 GHz band. The measured bandwidths of 10 dB impedance with a 3 dB axial ratio are 2.35–2.52 GHz and 3.36–3.71 GHz, respectively. Full article

This study investigates the design of omnidirectional antennas, using a characteristic mode analysis (CMA), and explores two distinct feeding methods. The first method employs equal-amplitude and in-phase excitation across all ports, whereas the second method utilizes equal-amplitude excitation with a 180° phase difference between adjacent ports. Both designs achieve operating bandwidths of 2.45–2.58 GHz and 2.42–2.45 GHz, respectively, with peak gains of 4.1 dBi and 4.4 dBi at 2.45 GHz. The proposed antennas exhibited high gain and low-profile characteristics, making them well-suited for applications in wireless energy harvesting. Full article

In this paper, a broad-angle low-scattering microstrip antenna for dual-polarization is designed based on characteristic mode analysis (CMA). The modal analysis of the reference antenna under dual-polarization incident plane waves is first carried out to guide radar cross section (RCS) reduction (RCSR) design in broad-angle range. Then, through the modifications on the radiation patch and ground, the modal currents of the important scattering modes in broad-angle range are cut off. Hence, a broad-angle low-RCS aperture-coupled microstrip antenna for dual-polarization is obtained. However, the radiation performance decreases due to the ground modification. A frequency selective surface (FSS) structure is designed and fills in the ground modification areas. With the FSS structure, the proposed antenna shows a good radiation and scattering performance. A low-RCS antenna prototype is fabricated and tested. The antenna works from 2.79 GHz to 2.87 GHz (2.82%), and the gain is 6 dBi at 2.84 GHz. For the co-polarization, it can realize RCSR from 0° to 90°, and the average and peak RCSRs are 9.0 dB and 17 dB, respectively. For the cross-polarization, it can realize RCSR from 0° to 18° and 22° to 90°, and the average and peak RCSRs are 5.0 dB and 20 dB, respectively. In the meantime, its transmission and radiation performance keeps well. The measured and simulated results are in good agreement, which validates the design. Full article

Reducing mutual coupling between radiation elements of compact MIMO vehicle antennas is of fundamental importance to achieve simultaneous high capacity and miniaturization. In this work, we propose a commercial vehicle MIMO antenna composed of two inverted-F elements that achieves high isolation of mutual coupling through the incorporation of the electric split ring resonator (SRR). The working mode and frequency band of the SRR are rationally selected based on characteristic mode analysis (CMA). Experimental results validate high isolation below −20 dB across a broadband frequency range from 1.7 GHz to 2.7 GHz, achieving a relative bandwidth of 45.4%, with a maximum reduction of 15 dB of the S21 parameter. Additionally, the MIMO antenna maintains stable performance in both return loss and radiation characteristics, with minimal degradation in gain and radiation pattern. This work provides a compact and bandwidth-enhanced solution for vehicular communication systems. Full article

A dual-band, dual-mode button antenna is proposed for emerging fifth-generation (5G) networks and Industrial, Scientific, and Medical (ISM) communication systems, as it operates at 3.5 GHz and 5.8 GHz, respectively. At the lower band, a monopole-like omnidirectional radiation pattern is achieved by loading shorting pins on curved strips for on-body communication. At the higher band, broadside circularly polarized radiation is achieved by loading an asymmetric U-shaped slot in the central chamferd patch for off-body communication. By using Characteristic Modal Analysis (CMA), a clear physical insight into the formation of dual polarization is provided. The −10 dB impedance bandwidth ranges from 3.48 to 3.60 GHz and 5.65 to 6.03 GHz, respectively. The 3 dB axial ratio (AR) bandwidth ranges from 5.71 to 5.85 GHz in the high band. Additionally, the antenna achieves a peak gain of 1.2 dBi in on-body mode and 6.9 dBi in off-body mode. The maximum specific absorption rate (SAR) calculated on the body tissues is below the US/EU standard thresholds of 1.6 W/kg and 2 W/kg. The measured results indicate that the antenna experiences only slight impact from human body loading and structural deformations. Given its notable features, the proposed design is well suited for Wireless Body Area Network (WBAN) applications. Full article

A compact Ka-band antenna array has been proposed to realize broadband and high gain for millimeter-wave applications. The antenna array is divided into a multilayer composed of a driven slot patch layer and a parasitic patch array layer, which is excited by a mixed CPW-Slot-Couple feeding network layer. According to characteristic mode analysis, a pair of narrow coupling slots are introduced in the driven patch to move the resonant frequency of characteristic mode 3 to the resonant frequency of characteristic mode 2 for enhanced bandwidth. In this article, a 1to4 CPW-Slot-Couple feeding network for a 2 × 2 driven slot patch array is implemented, and then each driven slot patch excites a 2 × 2 parasitic patch array. Finally, a proposed 4 × 4 × 3 (row × column × layer) Ka-band antenna array is fabricated to verify the design concepts. The measured results show that the frequency bandwidth of the antenna array is 25 GHz to 32 GHz, and the relative bandwidth is 24.5%. The peak gain is 20.1 dBi. Due to its attractive properties of miniaturization, broadband, and high gain, the proposed antenna array could be applied to millimeter-wave wireless communication systems. Full article

With the emergence of 5G and satellite communication applications, where millimeter-wave (mm-wave) active phased arrays play an important role, the demand for a highly integrated and cost-effective method to achieve mm-wave antennas is an inevitable trend. Antenna-in-package (AiP) design is therefore becoming a hotspot. This paper presents the design procedure for a broadband silicon-based stacked patch antenna in Ka-band, which realizes a practical AiP structure for phased-array module integration requirements. A stacked-patch antenna on a high-resistivity silicon (HRSi) substrate is demonstrated to effectively extend the bandwidth with the guidance of characteristic mode analysis (CMA).The proposed antenna element and its 2 × 2 array were designed and fabricated using silicon bulk micromachining and wafer-level bonding technology. The measured results from the fabricated antenna prototypes showed that (1) the antenna element had an impedance bandwidth of 13.8% from 26.2 to 30.1 GHz, and the peak gain was 6.1 dBi at 28.9 GHz; (2) the 2 × 2 array realized an impedance bandwidth of 11.4% from 27.2 to 30.5 GHz, and the peak gain was 9.3 dBi at 28.5 GHz. Full article

Home appliances generally comprise a mechanical envelope, or enclosure, of electrically conductive material (steel, aluminum, etc.) that houses electrical and electronic circuits. That envelope typically includes all kind of apertures, openings, holes, slots, windows, etc., to connect—physically and electromagnetically—the external space with its internal space. The performance of that envelope is a key element to comply with surface current EMI/EMC (Electro-Magnetic Interference/Electro-Magnetic Compatibility) regulations for electromagnetic interference, both emissions and immunity. Here, we present a novel theoretical proposal that consists of establishing the mathematical relationship of the coupling between the resonant modes of an internal cavity (RMs) contained in a conductive body and the characteristic modes (CMs) on the external surface of its envelope through the openings that connect those external and internal spaces, and doing so by means of equivalent virtual surface currents located in those openings. The comparative results of simulations and actual measurements of immunity in an anechoic chamber (measurements originally oriented to other purposes) are presented as above-mentioned evidence of resonating modes coupling on the frequency range 40–1000 MHz. However, this theoretical proposal is novel and remains to be developed in greater depth and detail in future works. Full article

In this work, an electronically reconfigurable dual-band dual-mode microstrip ring antenna with high isolation is proposed. Using characteristic mode analysis (CMA), the physical characteristics of the ring antenna are revealed, and two modes are appropriately chosen for operation in two sub-6 GHz “legacy” bands. Due to the inherent orthogonality of the characteristic modes, measured isolation larger than 37 dB was achieved in both bands without requiring complicated decoupling approaches. An integrated electronically reconfigurable matching network (comprising PIN diodes and varactors) was designed to switch between the two modes of operation. The simulated and measured results were in excellent agreement, showing a peak gain of $4.7$ dB for both modes and radiation efficiency values of $44.3\%$ and $64\%$, respectively. Using CMA to gain physical insights into the radiative orthogonal modes of under-researched and non-conventional antennas (e.g., antennas of arbitrary shapes) opens the door to developing highly compact radiators, which enable next-generation communication systems. Full article

A millimeter-wave broadband metasurface-based antenna with a low profile is proposed. In order to guide the mode excitation, the characteristic mode analysis (CMA) is used for the design and optimization of the proposed antenna. Four sets of coplanar patches with different dimensions on a thin printed circuit board are used to generate four adjacent broadside modes, which are directly fed by a coaxial probe. Then, to expand low-frequency bandwidth, a new resonant mode is introduced by etching slots on the parasite patch. Meanwhile, the extra mode introduced does not significantly change the radiation performance of the original modes. Moreover, dual slots are etched on the mid patch fed by the coaxial probe, which moves the orthogonal modes of the chosen modes out of the operating band to reduce cross-polarization levels. The proposed antenna realized 25.02 % (30–38.58 GHz) impedance bandwidth with dimensions of $1.423\times 1.423\times 0.029{\lambda }_{0 }^3$ (${\lambda }_0$ is the wavelength at 34 GHz in free space), and the realized gain in the band is 8.35–11.3 dB. Full article

With the continuous development of the IoT, compact wireless communication modules have become indispensable components, and their antennas are gradually being developed from external devices into onboard integrated devices. The serpentine antenna, a variant of the monopole antenna known for its small size and easy integration, is often applied to engineering practices. However, its performance has always been closely affected by the size of the surrounding grounding plane. By conducting a characteristic mode analysis (CMA), this study explored the variation patterns in the ground plane size and the resonant frequency. Based on the simulation results, it was clear that when the ground plane size is less than a quarter of the working wavelength, the ground plane will have a significant effect on the antenna’s resonant frequency. Thus, this study further analyzed a serpentine antenna with a grounding branch, and through analysis of the basic law of the influence of grounding structure on the antenna’s performance, we found that by adjusting the branch length, the matching performance of the antenna can be effectively improved. Furthermore, by changing the size of the ground plate, the antenna’s resonant frequency can be adjusted. Such a conclusion will hopefully provide a reference for future designs of integrated antennas in engineering applications. Full article
