The primary challenge associated with stainless steel in fuel cell operation is its susceptibility to corrosion, which leads to increased contact resistance and subsequent degradation of electrochemical performance. In general, the protective layers have been loaded onto the metal surface by widely used traditional techniques such as physical vapor deposition (PVD), or cathode arc ion plating. However, the above sputtering and evaporation ways require a high-vacuum condition, complicated experimental setups, higher costs, and an elevated temperature. Therefore, herein the achievement for uniform coatings over a large surface area has been realized by using a cost-effective strategy through a complete wet chemical process. The synergistic regulation of two conductive components and a plastic additive has been employed together with the entrapment of a surfactant to optimize the microstructure of the coating surface. The assembly of layered graphite and a polystyrene sphere could maintain both the high corrosion resistance feature and excellent electrical conductivity. In particular, the intrinsic vacant space in the above physical barriers has been filled with fine powders of indium tin oxide (ITO) due to its small size, and the interconnected conductive network with vertical/horizontal directions would be formed. All the key technical targets based on the U.S. Department of Energy (DOE) have been achieved under the simulated operating environments of a proton exchange membrane fuel cell. The corrosion current density has been measured as low as 0.52 μA/cm² (for the sample of graphite/mixed layer) over the applied potentials from −0.6 V to 1.2 V and its protective efficiency is evaluated to be 99.8%. The interfacial contact resistance between the sample and the carbon paper is much less than 10 mΩ·cm² (3.4 mΩ·cm²) under a contact pressure of 165 N/cm². The wettability has been investigated and its contact angle has been evolved from 48° (uncoated sample) to even 110°, providing superior hydrophobicity to prevent water penetration. Such an innovative approach opens up new possibilities for improving the durability and reducing the costs of carbon-based coatings. Full article

Traditional binary coatings like TiN and CrN display limited thermal stability and wear resistance under extreme conditions. High-entropy alloy nitride (HEAN) coatings offer a promising solution due to their customizable composition and unique properties, including high hardness, corrosion resistance, and thermal stability. This study focused on (AlCrNbTaTi)N HEAN coatings to address a critical need for materials capable of enduring extreme mechanical and tribological demands by examining the impact of aluminum content on their structural and mechanical properties, providing insights for optimizing coatings in harsh conditions through a self-assembled nanolayer structure with enhanced resilience and performance. The coatings were deposited via a cathodic arc by employing an AlCrNbTaTi alloy target composed of aluminum (20, 50, 60, 70%) and equal molar ratios of Cr, Nb, Ta, and Ti. The coatings were characterized through grazing incidence X-ray diffraction, SEM, HR-TEM, a nano-indentation test, and a friction and wear test. The results indicated that with increasing Al content, the structure of (AlCrNbTaTi)N coatings shifted from FCC to an amorphous state, leading to a reduction in the hardness and elastic modulus, accompanied by an increase in the wear rate and friction coefficient. The (AlCrNbTaTi)N coating, with an equal atomic ratio of metallic elements, showed potential as a hard tool coating. It demonstrated outstanding mechanical and tribological properties, with a 34.5 GPa hardness, 369 GPa modulus, 0.35 friction coefficient, and 8.2 × 10⁻¹⁹ m²·N⁻¹ wear rate. The findings highlight the potential of (AlCrNbTaTi)N coatings to extend tool life and improve operational efficiency, helping advance materials engineering for industrial applications. Full article

CrWN/MoN nano-multilayer coatings were deposited in pure N₂ by multi-arc ion plating using CrW and Mo targets, with the cathode co-controlled by a permanent magnet combined with an electromagnet. The effects of the thickness modulation period on the microstructure and mechanical and tribological performance were systematically analyzed by grazing-incident X-ray diffraction (GIXRD), transmission electron microscopy (TEM), Nanoindentation, scanning electron microscope (SEM) and profilometry using a Talysurf profilometer. The local coherent interfaces and nanoscale modulation period were confirmed by TEM, while the coatings were confirmed to be composed of fcc-CrWN and hexagonal δ-MoN by GIXRD. With the increase in the modulation period, the hardness of the CrWN/MoN nano-multilayer coatings decreased, and the values of the H/E ratio and friction coefficient showed the same variation trend. At an 8.0 nm modulation period, the CrWN/MoN nano-multilayer coating showed the maximum hardness (30.2 GPa), the lowest H/E value (0.082) and an H³/E*² value of 0.16. With the decrease in the modulation period, the average friction coefficient of the CrWN/MoN nano-multilayer coatings gradually decreased from 0.45 to 0.29, while the wear rate decreased from 4.2 × 10⁻⁷ mm³/Nm to 3.3 × 10⁻⁷ mm³/Nm. Full article

Deposition of (Ti-Al)N/MoN multilayered coatings was carried out through a cathodic ion-plating system in an argon and then nitrogen atmosphere. Bilayer thickness (Λ) of all the samples were achieved, from 22 to 104 nm, by organizing substrate holder rotational speed (SRS). To obtain the optimum properties of the (Ti-Al)N/MoN coatings, the Ti and Al ratio was maintained at a level of 1:1. X-ray diffraction (XRD), high-resolution transmission electron microscopy (HRTEM), X-ray photoelectron spectroscopy (XPS), and Raman spectroscopy were utilized to analyze the crystal structure and morphology of the coatings. Mechanical and tribological properties were examined by nanohardness and atomic force microscopy (AFM). The preferred orientation of the (Ti-Al)N/MoN nanoscale multilayer films was TiAlN (200) and MoN (200), which had face centered cubic (fcc) and hexagonal structures, respectively. The hardness increased with the decrease in Λ (104 nm to 26 nm), and then it increased. The highest hardness of 37 GPa was revealed at Λ = 26 nm, whereas the least wear rate of 8.09 × 10⁻⁷ mm³/N.m was attained at Λ = 22 nm. Wear rate, roughness, and coefficient of friction were decreased with decreasing bilayer period. EDS results showed that Al and Ti contents were almost the same in all samples, as per design of the experiment. Full article

Hard coatings, such as transition metal nitrides, have been widely applied to improve the mechanical properties and tribological performance of cutting tools. The coatings in various multilayered or gradient structures have been designed to meet the demands of more severe service environments and more precise processing requirements. In this work, TiN/TiSiN coatings in several gradient and multilayered structures were deposited on cemented carbides by cathodic arc ion plating using Ti and TiSi alloy targets. The modulation period (Λ) of the multilayer gradually varies with thickness, ranging from 6 to 46 nm. The gradient multilayer coatings consist of a nanocrystalline-amorphous composite with compact growth. The coating with a modulation period first increasing and then decreasing has the highest hardness of 38 GPa, and the maximum residual compressive stress of −2.71 GPa, as well as the minimum coefficient of friction (COF) and wear rate. Gradient and multilayer structures moderate the brittleness caused by the presence of amorphous SiNx phase and optimize the mechanical properties and tribological performances of the coatings. Full article

TiCrAlN hard films based on TiN or CrN show superior properties in terms of hardness, wear resistance, and thermal stability due to the addition of alloying elements. AlCrTiN films based on AlN may have higher thermal shock properties, but the knowledge of AlCrTiN films with high Al content has been insufficient until now. In this study, two sets of AlCrTiN hard films with different Al contents of 48 at.% and 58 at.% among metal components were prepared via multi-arc ion plating so as to investigate the effect of Al content on the phase composition, hardness, and thermal shock resistance of the films. The same microstructures, morphologies, and thicknesses of the fabricated film samples were achieved by changing the combination of cathode alloy targets and adjusting the arc source current during deposition. The surface chemical composition, cross-sectional elemental distribution, microstructure, morphology, phase composition, surface hardness, film/substrate adhesion strength, and thermal shock performance of the AlCrTiN films were examined. The obtained results reveal that the two sets of AlTiCrN hard films are face-centered cubic solid solutions with a columnar fine grain structure and a preferred growth orientation of (200) crystal plane. The hardness of the AlCrTiN films can be improved up to HV2850 by properly reducing the Al content from 58 at.% to 48 at.%. Meanwhile, the film/substrate adhesion performance is strong enough in terms of critical loads greater than 200 N. Furthermore, the AlCrTiN films maintain high thermal shock resistance at 600 °C when the Al content decreases from 58 at.% to 48 at.%. The optimal composition of the AlCrTiN hard films is 25:13:15:47 (at.%), based on the consideration of hardness, adhesion, and thermal shock cycling resistance. This optimal AlCrTiN hard film can be suggested as an option for protective coatings of hot process die tools. Full article

In this research, titanium nitride (TiN) was applied to grade 1 titanium as a bipolar plate for a proton exchange membrane fuel cell (PEMFC). The TiN was deposited by the arc ion plating method (AIP) to investigate the electrochemical characteristics of the anode and cathode environments in the PEMFC. The corrosion experiments were conducted in an aqueous solution of pH 3 (H₂SO₄ + 0.1 ppm HF, 80 °C) determined by the Department of Energy (DoE). The hydrogen gas and air were bubbled to simulate the anode and cathode environments. The potentiodynamic polarization experiment showed that there was no active peak. The potentiostatic experiment showed that the current densities of the TiN-coated specimens were less than 1 μA/cm² in both the anode and cathode. As a result of observing the surface with an SEM before and after the potentiostatic experiment, only pinholes generated during the coating process were observed, and no corrosion damage was observed. Furthermore, electrochemical impedance spectroscopy (EIS) analysis showed that the coated specimens had a higher charge transfer resistance than the titanium substrate. In the case of interfacial contact resistance (ICR), the TiN-coated specimen displayed lower resistance than the titanium substrate and satisfied the DoE technical target of less than 10 mΩ·cm² at 140 N/cm². Full article

The effects of the Cu content on the microstructural, mechanical and tribological properties of the TiAlSiN–Cu coatings were investigated in an effort to improve the wear resistance with a good fracture toughness for cutting tool applications. A functionally graded TiAlSiN–Cu coating with various copper (Cu) contents was fabricated by a filtered cathodic arc ion plating technique using four different (Ti, TiAl₂, Ti₄Si, and Ti₄Cu) targets in an argon-nitrogen atmosphere. The results showed that the TiAlSiN–Cu coatings are a nanocomposite consisting of (Ti,Al)N nano-crystallites (~5 to 7 nm) embedded in an amorphous matrix, which is a mixture of TiO_x, AlO_x, SiO_x, SiN_x, and CuO_x phase. The addition of Cu atoms into the TiAlSiN coatings led to the formation of an amorphous copper oxide (CuO_x) phase in the coatings. The maximum nanohardness (H) of ~46 GPa, H/E ratio of ~0.102, and adhesion bonding strength between coating and substrate of ~60 N (L_C2) were obtained at a Cu content ranging from 1.02 to 2.92 at.% in the TiAlSiN–Cu coatings. The coating with the lowest friction coefficient and best wear resistance was also obtained at a Cu content of 2.92 at.%. The formation of the amorphous CuO_x phase during coating growth or sliding test played a key role as a smooth solid-lubricant layer, and reduced the average friction coefficient (~0.46) and wear rate (~10 × 10⁻⁶ mm³/N·m). Full article

A novel multilayer, solar selective absorbing coating that contains lamellar-distributed nanoparticles in its cermet-absorbing sublayers has been fabricated using ion-source-assisted cathodic arc plating. The multilayer coating shows an outstanding selectivity, i.e., a high solar absorptance (0.909), yet it has a low thermal emittance (0.163). More importantly, the long-term thermal stability tests demonstrate that the lamellar-structured absorbers can remain stable, even when annealed at 500 °C for 1000 h in ambient air. The coating’s enhanced selectivity and thermal stability were attributed to the formation of lamellar-distributed nanoparticles in the absorbing sublayer, which form many asymmetric Fabry–Pérot cavities. In this case, the light would be held in the Fabry–Pérot cavities and thus boost the absorptivity due to the increase in interaction time. Meanwhile, the unique distribution of the nanoparticles is also beneficial for enhancing the surface plasmon resonance absorption, and thus promoting the increase in solar selectivity. Furthermore, the excellent thermal stability is ascribed to the existence of amorphous matrices, which separate and seal the nanoparticles into honeycomb shells. In this case, the atomic diffusion in the nanoparticles would be significantly retarded as the amorphous matrices can remain stable below the crystallization temperatures, which can effectively slow down the growth and agglomeration of the nanoparticles. Full article

Aqueous zinc-ion batteries (ZIBS) are becoming more popular as the use of energy storage devices grows, owing to advantages such as safety and an abundant zinc supply. In this study, molybdenum powder was loaded directly on carbon fiber cloth (CFC) via multi-arc ion plating to obtain Mo@CFC, which was then oxidatively heated in a muffle furnace for 20 min at 600 °C to produce high mass loading α-MoO₃@CFC (α-MoO₃ of 12–15 mg cm⁻²). The cells were assembled with α-MoO₃@CFC as the cathode and showed an outstanding Zn²⁺ storage capacity of 200.8 mAh g⁻¹ at 200 mA g⁻¹ current density. The capacity retention rate was 92.4 % after 100 cycles, along with an excellent cycling performance of 109.8 mAh g⁻¹ following 500 cycles at 1000 mA g⁻¹ current density. Subsequently, it was shown that CFC-loaded α-MoO₃ cathode material possessed significantly improved electrochemical performance when compared to a cell constructed from commercial MoO₃ using conventional slurry-based electrode methods. This work presents a novel yet simple method for preparing highly loaded and binder-free cathodic materials for aqueous ZIBs. The results suggest that the highly loaded cathode material with a high charge density may be potentially employed for future flexible device assembly and applications. Full article

A CrN/AlCrN coating was prepared on a carbide substrate and PCB milling cutter by the cathodic arc ion plating technique. The organization, mechanical and tribological properties of the coating were studied. The milling performance of the coated milling cutters was investigated by milling tests. The results show that the surface of the CrN/AlCrN coating is smooth and dense without obvious defects. The coating has high hardness, low roughness and good bonding strength, presenting excellent mechanical properties. The coating showed better tribological performance and a lower friction coefficient under low load than that under high load, and the wear forms were adhesive wear and a small amount of oxidation wear. The coated milling cutters showed excellent milling performance when working at lower feed rates. The service life of coated milling cutters is significantly higher compared to uncoated cutters. Full article

TiAlN coatings with different Al ratios were deposited by the cathodic arc ion plating (AIP) method, and the relationship between solid particle erosion resistance and structural, mechanical properties was investigated by a micro slurry-jet erosion (MSE) test. The crystal structure of TiAlN coating changes depending on the Al ratio. The coating shows a B1 single cubic phase between the Al ratio of 0 and 0.58; above this ratio, formation of a B4 hexagonal phase is observed. The mechanical properties such as hardness and Young’s modulus of the TiAlN coating also depend on the Al ratio and the crystal structure. The erosion rate decreases by increasing the Al ratio up to 0.58, as the coating is a cubic single phase. The TiAlN coating shows the lowest erosion rate at an Al ratio of 0.58. The erosion rate increases drastically as the crystalline phase changes from the B1 cubic to B4 hexagonal phase at the Al ratio of more than 0.58. The change in erosion rate is also discussed in connection with mechanical properties such as erodent particle hardness to coating hardness ratio and coating hardness to Young’s modulus ratio. Full article

To develop the hard and self-lubricating coatings applied for the industrial dry-cutting and die-casting machining tool fields, a series of MoTiAlN/MoN/Mo multilayered coatings were deposited on Si substrates under low substrate rotation by cathodic multi-arc ion plating. XRD, SEM, TEM, RBS, nanoindentation, and tribology tester were used to monitor the phase structure, morphology, component, nanohardness, and friction coefficient of the coatings. It was found that the coatings deposited at various substrate rotations comprised paramount cubic B1 structure TiAlN and Mo₂N phases. The micrographs confirmed that the mean modulation period and total physical thickness of multilayered TiAlN/Mo₂N coatings with a sharp interface fabricated at 2 revolutions per minute (rpm) were 26 nm and 1.15 μm. The mean nanohardness and friction coefficient were ca. 30 GPa and 0.4, respectively. RBS results along with the SIMNRA code allowed to estimate the total atomic concentrations and the physical thickness of individual sublayer as well as the modulation period of multilayered coatings, which demonstrated an efficiency of this approach for characterization of nano-multilayered structures. Full article

Cathode spot motion influences the physical characteristics of arc plasma and the related macroparticles (MPs) in resultant films; these MPs limit the application of arc ion plating (AIP). In this paper, a scanning radial magnetic field (SRMF) was applied to the cathode surface to control the cathode spot motion and reduce the MP contamination in the deposited films. It was shown that film surface morphologies prepared using SRMF were better than those using a static radial magnetic field (RMF). The improvement was greater with increased scanning range and frequency. Using SRMF, cathode spot motion was confined to a spiral trajectory on the cathode surface and the spots moved over a large area and at a fast-moving velocity. Both the large moving area and the fast velocity decreased the temperature on the cathode surface and thus reduced the emission of the MPs. Full article

CrN and Cr-Al-Si-N coatings were deposited on SUS304 and Si-wafers by a hybrid coating system. The Cr and Al-Si target were connected to the cathode arc ion plating (AIP) and high power impulse magnetron sputtering (HiPIMS), respectively. Various Al and Si contents in the coatings were obtained by changing the power of Al-Si target from 0 to 1 kW. The results demonstrated a face-centered cubic structure in all of the coatings. With increasing Al-Si target power, both the density and mean diameter of the macroparticles on the coating surface declined. As Al and Si contents increased, the microstructure of the Cr-Al-Si-N coatings evolved from a dense column structure, to a finer grain column structure, and then to a compact granular-like structure. The hardness of the coatings increased from 21.5 GPa for the pure CrN coating, to a maximum value of ~27 GPa for the Cr-Al-Si-N coating deposited at 0.4 kW, which was mainly attributed to the solid solution strengthening and increased residual stress. The addition of Al and Si contents led to enhanced wear resistance against alumina balls at both room and elevated temperatures. Meanwhile, the Cr-Al-Si-N coatings also exhibited an excellent resistance to high-temperature oxidation at 800 and 1000 °C, and improved corrosion resistance, as compared with CrN coatings. Full article
