In this paper, a rail-to-rail transconductance stable and enhanced ultra-low-voltage operational transconductance amplifier (OTA) is proposed for electrocardiogram (ECG) signal processing. The variation regularity of the bulk transconductance of pMOS and nMOS transistors and the cancellation mechanism of two types of transconductance variations are revealed. On this basis, a transconductance stabilization and enhancement technique is proposed. By using the “current-reused and transconductance-boosted complementary bulk-driven pseudo-differential pairs” structure, the bulk-driven pseudo-differential pair during the input common-mode range (ICMR) is stabilized and enhanced. The proposed OTA based on this technology is simulated using the TSMC 0.18 μm process in a Cadence environment. The proposed OTA consumes a power below 30 nW at a 0.4 V voltage supply with a DC gain of 54.9 dB and a gain-bandwidth product (GBW) of 14.4 kHz under a 15 pF capacitance load. The OTA has a high small signal figure-of-merit (FoM) of 7410 and excellent common-mode voltage (VCM) stability, with a transconductance variation of about 1.35%. Based on a current-scaling version of the proposed OTA, an OTA-C low-pass filter (LPF) for ECG signal processing with VCM stability is built and simulated. With a −3 dB bandwidth of 250 Hz and a power consumption of 20.23 nW, the filter achieves a FoM of 3.41 × 10⁻¹³, demonstrating good performance. Full article

The phonocardiogram (PCG) is a crucial tool for the early detection, continuous monitoring, accurate diagnosis, and efficient management of cardiovascular diseases. It has the potential to revolutionize cardiovascular care and improve patient outcomes. The PhysioNet/CinC Challenge 2016 database, a large and influential resource, encourages contributions to accurate heart sound state classification (normal versus abnormal), achieving promising benchmark performance (accuracy: 99.80%; sensitivity: 99.70%; specificity: 99.10%; and score: 99.40%). This study reviews recent advances in analytical techniques applied to this database, and 104 publications on PCG signal analysis are retrieved. These techniques encompass heart sound preprocessing, signal segmentation, feature extraction, and heart sound state classification. Specifically, this study summarizes methods such as signal filtering and denoising; heart sound segmentation using hidden Markov models and machine learning; feature extraction in the time, frequency, and time-frequency domains; and state-of-the-art heart sound state recognition techniques. Additionally, it discusses electrocardiogram (ECG) feature extraction and joint PCG and ECG heart sound state recognition. Despite significant technical progress, challenges remain in large-scale high-quality data collection, model interpretability, and generalizability. Future directions include multi-modal signal fusion, standardization and validation, automated interpretation for decision support, real-time monitoring, and longitudinal data analysis. Continued exploration and innovation in heart sound signal analysis are essential for advancing cardiac care, improving patient outcomes, and enhancing user trust and acceptance. Full article

The automotive industry and scientific community are making efforts to develop innovative solutions that would increase successful driver performance in preventing crashes caused by drivers’ health and concentration. High stress is one of the causes of impaired driver performance. This study investigates the ability to classify different stress levels based on capacitive electrocardiogram (cECG) recorded during driving by unobtrusive acquisition systems with different hardware implementations. The proposed machine-learning model extracted only four features, based on the detection of the R peak, which is the most reliably detected characteristic point even in inferior quality cECG. Another criterion for selecting the features is their low computational complexity, which enables real-time application. The proposed method was validated on three open data sets recorded during driving: electrocardiogram (ECG) recorded by electrodes with direct skin contact (high quality); cECG recorded without direct skin contact through clothes by electrodes built into a portable multi-modal cushion (middle quality); and cECG recorded through the clothes without direct skin contact by electrodes built into a car seat (lowest quality). The proposed model achieved a high accuracy of 100% for high-quality ECG, 96.67% for middle-quality cECG, and 98.08% for the lower-quality cECG. Full article

Cardiovascular diseases are currently the leading cause of death worldwide. Thus, there is a need for non-invasive ambulatory (Holter) ECG monitors with automatic measurements of ECG intervals to evaluate electrocardiographic abnormalities of patients with cardiac diseases. This work presents the implementation of algorithms in an FPGA for beat-to-beat heart rate and RT interval measurements based on the continuous wavelet transform (CWT) with splines for a prototype of an ambulatory ECG monitor of three leads. The prototype’s main elements are an analog–digital converter ADS1294, an FPGA of Xilinx XC7A35T-ICPG236C of the Artix-7 family of low consumption, immersed in a low-scale Cmod-A7 development card integration, an LCD display and a micro-SD memory of 16 Gb. A main state machine initializes and manages the simultaneous acquisition of three leads from the ADS1294 and filters the signals using a FIR filter. The algorithm based on the CWT with splines detects the QRS complex (R or S wave) and then the T-wave end using a search window. Finally, the heart rate (60/RR interval) and the RT interval (from R peak to T-wave end) are calculated for analysis of its dynamics. The micro-SD memory stores the three leads and the RR and RT intervals, and an LCD screen displays the beat-to-beat values of heart rate, RT interval and the electrode connection. The algorithm implemented on the FPGA achieved satisfactory results in detecting different morphologies of QRS complexes and T wave in real time for the analysis of heart rate and RT interval dynamics. Full article

An accurate and compact electrocardiogram (ECG) device will greatly assist doctors in diagnosing heart diseases. It will also help to address the increasing number of deaths caused by heart disease. Accordingly, the goal of the project is to design and construct an easy-to-use compact 12-lead electrocardiogram device that communicates with a computer to create a system that can continuously monitor heart rate and which can be connected to allied medical systems. The design is based on an ECG receiver circuit utilizing an IC ADS1293 and an Arduino Nano. The ADS1293 has built-in input Electromagnetic Interference (EMI) filters, quantizers, and digital filters, which help in reducing the size of the device. The software has been created using the C# programming language, with Windows Presentation Foundation (WPF), aiding the collection of the ECG signals from the receiving circuit via the computer port. An ECG Multiparameter Simulator has been used to calibrate the ECG device. Finally, a plan has been developed to connect the arrangement to health systems according to HL7 FHIR (Health Level Seven Fast Healthcare Interoperability Resources) through Representational State Transfer Application Programming Interface (Rest API). The ECG device, completed at the cost of U$169 excluding labor, allows for the signal of 12 leads of ECG signal to be obtained from 10 electrodes mounted on the body. The processed ECG data was written to a JSON file with a maximum recording time of up to three days, managed by a Structured Query Language Server (SQL) Server database. The software retrieves patient data from electrical medical records in accordance with HL7 FHIR standards. A compact and easy-to-use ECG device was successfully designed to record ECG signals. An in-house developed software was also completed to display and store the ECG signals. Full article

In this study, we propose a model-based tool for the detection of obstructive apnea episodes by using ECG features from a single lead channel. Several sequences of recurrent apnea were provoked in separate 15-min periods in anesthetized rats during an experimental model of obstructive sleep apnea (OSA). Morphology-based ECG markers and the beat-to-beat interval ($RR$) were assessed in each sequence. These markers were used to train dynamic Bayesian networks (DBN) with different orders and feature combinations to find a good tradeoff between network complexity and apnea-detection performance. By using a filtering approach, the resulting DBNs were used to infer the apnea probability signal for subsequent episodes in the same rat. These signals were then processed using by 15-s epochs to determine whether epochs were classified as apneic or nonapneic. Our results showed that fifth-order models provided suitable RMSE values, since higher order models become significantly more complex and present worse generalization. A global threshold of 0.2 gave the best overall performance for all combinations tested, with $Acc$ = 81.3%, $Se$ = 69.8% and $Sp$ = 81.5%, using only two parameters including the RR and $Ds$ (R-wave downslope) markers. We concluded that multivariate models using DBNs represent a powerful tool for detecting obstructive apnea episodes in short segments, which may also serve to estimate the number of total events in a given time period. Full article

In this study, a noncontact fabric loop sensor based on magnetic-field-induced conductivity, which can simultaneously detect cardiac activity and respiration signals, was developed and the effects of the sensor’s shape and measurement position on the sensing performance were analyzed. Fifteen male subjects in their twenties wore sleeveless shirts equipped with various types of fabric loop sensors (spiky, extrusion, and spiral), and the cardiac activity and respiratory signals were measured twice at positions P2, P4, and P6. The measurements were verified by comparing them against the reference electrocardiogram (ECG) and respiratory signals measured using BIOPAC^® (MP150, ECG100B, RSP100C). The waveforms of the raw signal measured by the fabric loop sensor were filtered with a bandpass filter (1–20 Hz) and qualitatively compared with the ECG signal obtained from the Ag/AgCI electrode. Notwithstanding a slight difference in performance, the three fabric sensors could simultaneously detect cardiac activity and respiration signals at all measurement positions. In addition, it was verified through statistical analysis that the highest-quality signal was obtained at the measurement position of P4 or P6 using the spiral loop sensor. Full article

The development of smart cars with e-health services allows monitoring of the health condition of the driver. Driver comfort is preserved by the use of capacitive electrodes, but the recorded signal is characterized by large artifacts. This paper proposes a method for reducing artifacts from the ECG signal recorded by capacitive electrodes (cECG) in moving subjects. Two dominant artifact types are coarse and slow-changing artifacts. Slow-changing artifacts removal by classical filtering is not feasible as the spectral bands of artifacts and cECG overlap, mostly in the band from 0.5 to 15 Hz. We developed a method for artifact removal, based on estimating the fluctuation around linear trend, for both artifact types, including a condition for determining the presence of coarse artifacts. The method was validated on cECG recorded while driving, with the artifacts predominantly due to the movements, as well as on cECG recorded while lying, where the movements were performed according to a predefined protocol. The proposed method eliminates 96% to 100% of the coarse artifacts, while the slow-changing artifacts are completely reduced for the recorded cECG signals larger than 0.3 V. The obtained results are in accordance with the opinion of medical experts. The method is intended for reliable extraction of cardiovascular parameters to monitor driver fatigue status. Full article

Catechin is a major reactive substance involved in black tea fermentation. It has a determinant effect on the final quality and taste of made teas. In this study, we applied hyperspectral technology with the chemometrics method and used different pretreatment and variable filtering algorithms to reduce noise interference. After reduction of the spectral data dimensions by principal component analysis (PCA), an optimal prediction model for catechin content was constructed, followed by visual analysis of catechin content when fermenting leaves for different periods of time. The results showed that zero mean normalization (Z-score), multiplicative scatter correction (MSC), and standard normal variate (SNV) can effectively improve model accuracy; while the shuffled frog leaping algorithm (SFLA), the variable combination population analysis genetic algorithm (VCPA-GA), and variable combination population analysis iteratively retaining informative variables (VCPA-IRIV) can significantly reduce spectral data and enhance the calculation speed of the model. We found that nonlinear models performed better than linear ones. The prediction accuracy for the total amount of catechins and for epicatechin gallate (ECG) of the extreme learning machine (ELM), based on optimal variables, reached 0.989 and 0.994, respectively, and the prediction accuracy for EGC, C, EC, and EGCG of the content support vector regression (SVR) models reached 0.972, 0.993, 0.990, and 0.994, respectively. The optimal model offers accurate prediction, and visual analysis can determine the distribution of the catechin content when fermenting leaves for different fermentation periods. The findings provide significant reference material for intelligent digital assessment of black tea during processing. Full article

Ultra low power signal processing is an essential part of all sensor nodes, and particularly so in emerging wearable sensors for biomedical applications. Analog signal processing has an important role in these low power, low voltage, low frequency applications, and there is a key drive to decrease the power consumption of existing analog domain signal processing and to map more signal processing approaches into the analog domain. This paper presents an analog domain signal processing circuit which approximates the output of the Discrete Wavelet Transform (DWT) for use in ultra low power wearable sensors. Analog filters are used for the DWT filters and it is demonstrated how these generate analog domain DWT-like information that embeds information from Butterworth and Daubechies maximally flat mother wavelet responses. The Analog DWT is realised in hardware via g m C circuits, designed to operate from a 1.3 V coin cell battery, and provide DWT-like signal processing using under 115 nW of power when implemented in a 0.18 μm CMOS process. Practical examples demonstrate the effective use of the new Analog DWT on ECG (electrocardiogram) and EEG (electroencephalogram) signals recorded from humans. Full article
